Turfmech Buffalo Series Programming manual

A member of the Turfmech group
Buffalo 20, 24 & 27”
OPERATOR & PARTS MANUAL
For Serial number:
BU20/4-XX-XXX onwards
BU24/4-XX-XXX onwards
BU27/4-XX-XXX onwards
(AM81589 Issue B March 2013)
English version
Turfmech Machinery Limited
Hangar 5, New Road, Hixon, Stafford, ST18 0PJ, United Kingdom
Tel: [phone]
Fax: [phone]
[e-mail]
www.turfmech.co.uk
For Allett spare parts
Tel: [phone]
Fax: [phone]
[e-mail]
www.allett.co.uk

2
READ THIS MANUAL BEFORE USING AN ALLETT BUFFALO CYLINDER
MOWER.
YOUR SAFETY IS INVOLVED
IT IS ESSENTIAL THAT OPERATORS STUDY THIS DOCUMENT FOR THEIR
OWN SAFETY.

3
Contents
1.0 Introduction
1.1 Model type and serial number
2.0 Pictograms and Decals
3.0 Safety notes
4.0 Assembly
5.0 Operating controls
6.0 Using your mower
6.1 Starting
6.2 Stopping
6.3 Adjusting the bottom blade - setting “on cut”
6.4 Height of cut adjustment
6.5 Engaging drive to the cylinder
6.6 Engaging drive to the land roll
6.7 Park brake
6.8 Mowing
7.0 Maintenance
7.1 Adjusting land drive and cylinder cables
7.2 Checking the engine oil
7.3 General engine maintenance
7.4 Fuel
7.5 Grease points
7.6 Bottom blade grinding angles
7.7 Inspection of safety critical components
7.8 Maintenance schedule
8.0 Making adjustments to your mower
8.1 Floating handle bars
8.2 Delivery plate and fins
9.0 Vibration reduction
10.0 Noise reduction
11.0 EC Declaration of conformity
12.0 Fault finding when mowing
13.0 Specification
14.0 Guarantee
15.0 Parts Section

4
1.0 Introduction
The Buffalo lawn mower range is designed as a professional lawn and sports turf
mower.
The lawn mower is powered by a petrol engine, it is self propelled via a belt and
chain drive to the land roll. The land roll has an internal geared differential. Power is
transferred to the cutting cylinder via toothed belt drive.
The Buffalo mowers are designed for the management of high quality turf. Use in any
way other than that stated is considered contrary to the intended use. Compliance
and strict adherence to the conditions of operation, service and repair as specified in
this manual also constitute essential elements of the intended use.
The way in which the Buffalo mower is operated and maintained will have a profound
effect on its performance and reliability.
A Buffalo mower should be operated, serviced and repaired only by persons who are
familiar with its particular characteristics and who are familiar with the relevant safety
procedures.
The safety precautions outlined in this manual and all other generally recognised
regulations on safety must be observed at all times.
Any modifications carried out to a Buffalo mower will relieve Turfmech Machinery
Limited of liability for any resulting damage or injury.
This manual is based on information available at the time of publication.
Turfmech Machinery Limited reserves the right to amend product specifications
without prior notification.
1.1 Model type and serial number
The model can be found in two places:
1. On the top cover of the mower.
2. On the serial number plate located on the right side of the mower chassis.
The serial number can be found on the serial plate.
Please enter your information below
Model:
Serial Number:

5
2.0 Pictograms and Decals
3.0 Safety notes
Read these instructions carefully, be familiar with the controls and the proper use of
the lawnmower.
Learn how to stop the lawnmower quickly in an emergency.
Never allow children or people unfamiliar with these instructions to use the
lawnmower. Local regulations may restrict the age of the operator.
Never mow while people, especially children or pets are nearby
Never pick up or carry the lawnmower while the motor is running.
Keep in mind that the operator or user is responsible for accidents or hazards
occurring to other people or their property.
Whilst mowing, always wear substantial footwear and long trousers. Do not operate
the equipment when barefoot or wearing open sandals.
Wear appropriate protective clothing and equipment when you are operating the
lawnmower, such as safety glasses, long trousers, substantial footwear and ear
protection. Long hair, loose clothing or jewellery can get tangled in moving parts.
Thoroughly inspect the area where the lawn mower is to be used and remove all
objects that may be thrown by the machine.
WARNING - petrol is highly flammable.
- Store fuel in containers especially designed for this purpose
- Refuel outdoors only and do not smoke while refuelling
- Add fuel before starting the engine. Never remove the cap of the fuel tank or add
petrol whilst the engine is running or the engine is hot.
- If petrol is spilt, do not attempt to start the engine, move the machine away from the
area of spillage and avoid creating any source of ignition until petrol vapours have
dissipated.
- Replace the fuel tank and container caps securely
Refer to manual before carrying out
maintenance,
Engine On/Off switch, Read manual
before starting
Guaranteed Sound power level
emitted by the mower
Bottom blade to cylinder adjustment
Flying debris, keep bystanders away. Warning, sharp blades, do not touch rotating blades.
The blades continue to rotate after the mower is switched off

6
- Replace faulty silencers
- Do not operate the engine in a confined space where dangerous carbon monoxide
fumes can collect.
- Before using, always visually inspect to see that the cutting cylinder is not worn or
damaged.
Mow only in daylight or in good artificial light.
Avoid operating the lawnmower in wet grass, where feasible.
Always be sure of your footing on slopes.
Walk, never run.
Mowing on banks can be dangerous:
- Mow across the face of sloes – never up and down.
- Be particularly careful of your footing on slopes or wet grass.
Exercise extreme caution when changing direction on slopes.
Do not mow excessively steep slopes.
- Use extreme caution when stepping back or pulling the lawnmower towards you.
Stop the blades if the lawnmower has to be tilted for transportation when crossing
surfaces other than grass and when transporting the lawnmower to and from the area
to be mowed.
Do not tilt the lawnmower when engaging the blades, except if the lawnmower has to
be tilted for starting in long grass. In this case, do not tilt it more than absolutely
necessary and lift only the part which is away from the operator. Always ensure that
both hands are in the operating position when returning the mower to the ground.
Never operate the lawnmower with defective guards or without the safety devices, for
example deflectors and grass catchers in place.
Do not change the engine governor settings or overspeed the engine. Operating an
engine at excessive speed may increase the hazard of personal injury.
Disengage all blade drive clutches before starting the engine
Start the engine carefully according to instructions and with feet well away from the
blades. Do not tilt the mower when starting. Keep clear of the discharge opening at
all times. Never pick up or carry a lawnmower while the engine is running.
Do not put hands or feet near or under rotating parts while the lawnmower is being
operated.
Stop the engine and disconnect the spark plug lead:
- Before checking, cleaning or working on the lawnmower
- After striking a foreign object, inspect the lawnmower for damage and make repairs
before restarting and operating the lawnmower.
- If the lawn mower starts to vibrate abnormally (check immediately).
- Before making height of cut adjustment
Stop the engine:
- Whenever you leave the machine
- Before refuelling
- Before checking blockages
- Before making a height of cut adjustment
Reduce the throttle setting during engine shut-down and turn the fuel off at the
conclusion of mowing.
Keep all nuts, bolts and screws tight to be sure that the lawnmower is in safe working
condition.
Never store the lawnmower with petrol in the tank inside a building where fumes may
reach an open flame or spark.
Allow the engine to cool before storing in any enclosure.
To reduce the fire hazard, keep the engine, silencer and fuel storage area free of
grass, leaves or excessive grease.
Check the grassbox frequently for wear or deterioration.
Replace worn or damaged parts for safety.
Go slow when using a trailing seat, especially when cornering.
If the fuel tank has to be drained, this should be done outdoors.
Be careful during the adjustment of the lawnmower to prevent entrapment of the feet
and hands between moving blades and fixed parts of the lawnmower.

7
Ensure replacement parts fitted are manufacturer’s original or approved by the
manufacturer.
4.0 Assembly
1) Fold handles back to a comfortable operator height and tighten 4 bolts
2) Fold down grass box cradle and fit grass box
3) Release the handbrake
1
x4
3
2

8
5.0 Operating controls
1) Handle bar ON/OFF switch
12) Starter grip
2) Throttle
13) Fuel valve lever
3) Cutting cylinder engagement
14) Choke lever
4) Land roll engagement
15) Oil dipstick
5) Park brake
16) Spark plug
6) Top handle bar
17) Air filter
7) Cable adjuster
18) Fuel filler cap
8) Bottom handle bar
19) Bottom blade adjuster
9) Grass box hoop
20) Front roller adjuster
10) Grass box
21) Front roller
11) Engine ON/OFF switch
22) Vibration mounts
2
1
3
4
5
6
7
8
9
10
16
18
17
14
13
12
11
15
20
19
22
21

9
6.0 Using your mower
6.1 Starting
1) Move the fuel valve lever to the
ON position
2) For a cold Tstart move the
choke lever to the CLOSED
position |\|
To restart a warm Rengine
leave the choke lever in the
OPEN position
MAX
MIN
1/3 position
3) Set the throttle to 1/3 position
between MIN and MAX
4) Turn the engine switch to the ON
position
5) Move the handle bar mounted engine
switch to the ON position

10
6.2 Stopping
1) Move the throttle lever to MIN position
2) Move the handle bar mounted stop switch to OFF
3) Turn the petrol tap OFF
To stop in an emergency move the handle bar mounted stop switch to OFF
6.3 Adjusting the bottom blade - setting “on cut”
The bottom blade is correctly adjusted when the cutting cylinder lightly brushes the
bottom blade as the cylinder is turned. Contact should be made across the full width
of the bottom blade.
The blades act like a pair of scissors, as a test correctly adjusted blades will cleanly
cut a piece of good quality writing paper across the width of the blade. The bottom
blade should be adjusted if the grass is not cut cleanly and evenly.
WARNING – Blades are sharp always wear gloves
6) Pull the starter grip lightly until
you feel resistance, then pull
briskly. Return the starter grip
gently
7) If the choke lever was moved to
the CLOSED position |\| to start
the engine, gradually move it to
the OPEN position |||as the
engine warms up

11
1 & 3
2
To set the cutting cylinder on cut:
1) Tilt the mower back and wedge securely
2) Turn the adjuster screws anti clockwise to move the bottom blade closer to the
cylinder
Turn the adjuster screws clockwise to move the bottom blade further from the
cylinder
3) When making adjustments to the bottom blade frequently check progress by
cutting a piece of paper
Do not over tighten the bottom blade – the cylinder should be able to spin with
little resistance
If you are still unable to cleanly cut paper, inspect the bottom blade and cylinder. If
they appear, rounded, damaged or excessively worn they may need to be reground
or replaced. New bottom blades should always be reground attached to the bottom
blade carrier. For bottom blade grinding angles see the section 7.6
The bottom blade adjusters can sometimes become very tight and may be hard to
turn. If this is the case:
1) Slacken off the grub screw on the collar
2) Rotate the adjuster anti-clockwise 1/8th of a turn
3) Tighten the grub screw
Bottom blade
adjustment decal

12
6.4 Height of cut adjustment
The height of cut is set by altering the position of the front roller.
WARNING - blades are sharp, always wear gloves
1) Set “on cut” first, refer to section 6.3
2) Adjust and lock the bolt on the height setting bar to your desired height of cut
3) Slacken the four front roller fasteners
4) Tilt the mower back and wedge securely
5) With the height setting bar near one end of the bottom blade, locate the bolt head
on top of the bottom blade and under the rear roller
6) Adjust the front roller so it makes contact with the height setting bar
7) Tighten the front roller fasteners on the side you have adjusted
8) Move the height setting bar to the other end of the bottom blade and repeat steps
5-8
6.5 Engaging drive to the cylinder
1) Gradually squeeze the cylinder bail bar towards the top handle – see section 5.0)
2) Release the bail bar to stop the cylinder
6.6 Engaging drive to the land roll
1) Gradually squeeze the drive bail bar towards the top handle – see section 5.0
2) Release the bail bar to stop forward movement
6.7 Park brake
To engage the park brake:
1) Pull and hold the red lever on the top handle bar
2) Tighten the lock handle
6.8 Mowing
1) Before mowing check the engine oil level and fill the petrol tank (see maintenance
section)
2) Start the engine – see section 6.1
3) Engage drive to the cylinder
4) Release the park brake
5) Engage drive to the land roll
Front roller
Cutting cylinder
Rear roller
Bottom
blade
Height of
cut
Height bar

13
7.0 Maintenance
WARNING – Stop the engine and remove the spark plug cap
To ensure long and reliable service, carry out the following maintenance regularly:
Regularly check for obvious defects such as a loose, dislodged or damaged blades,
loose fixings and worn or damaged components.
Check that covers and guards are undamaged and correctly fitted. Carry out
necessary maintenance or repairs before use..
Clean the exterior of the machine thoroughly using a soft brush and cloth. Remove all
debris, especially from the air filter and engine fins.
If the mower should happen to fail despite the care taken in manufacture and testing,
repair should be carried out by an authorised Allett dealer.
7.1 Adjusting land drive and cylinder cables
If the mower or cylinder doesn’t drive adequately it may be necessary to adjust the
drive cable as follows:
1) Slacken lock nut
2) Turn the adjuster a few times clockwise
3) Retighten the adjuster with the lock nut
When correctly adjusted, drive to the land roll or cylinder is engaged when the bail
bar is squeezed against the top handle. When released drive MUST disengage.
7.2 Checking the engine oil
Change the engine oil after the first 8 hours of use. The oil should then be changed
every 50 hours or at the end of each season before storage, whichever is sooner.
1) With the mower standing on level ground, unscrew and remove the engine oil filler
dipstick (15)
2) Wipe the oil filler dipstick clean: insert the oil dipstick, then remove it again. Do not
screw it in.
3) Check the oil level
4) Add a good quality SAE 10W-30 oil in small quantities at a time, allowing it to
settle. Repeatedly add oil and check the level until it reaches the upper limit.
1 & 3
2

14
SAE 10W-30 oil is recommended for general use. It is important to use the
recommended oil to avoid damage to your engine. Engine oil capacity is 0.6L
7.3 General engine maintenance
Check and clean the air filter (17), replace if necessary. See engine manual for
details.
Check and clean the fuel sediment bowl and spark plug. See engine manual for
details.
For all other engine adjustments and maintenance refer to the engine manual.
7.4 Fuel
Petrol deteriorates over time. Engine starting may be difficult if you use petrol kept for
more than 30days. Always run the fuel tank dry when storing over 30 days.
1) Remove the petrol filler cap (18), slowly add unleaded petrol to the tank, fill to
approximately the top of the strainer gauze.
2) Replace petrol filler cap
3) Wipe up any spilt petrol from the engine before starting the mower

15
7.5 Grease points
8 Grease points in total
(Remove covers to access grease points)
A) 2 cylinder bearings (1 pump every 1-2 weeks)
B) 2 rear roller bearings (1 pump every month)
C) 3 drive shaft bearings (1 pump every 1-2 weeks)
D) 1 idler pulley bearing (1 pump every 1-2 weeks)
Recommended best practice is to grease little and often
7.6 Bottom blade grinding angles
The cutting performance of the Buffalo 34 is highly dependent on the condition of
both the cylinder and bottom blade. Poorly maintained parts will lead to a poor quality
of cut.
Newly fitted bottom blades will need to be ground when bolted to the blade carrier to
ensure a perfectly flat cutting edge.
It is advisable that grinding/reconditioning is carried out by an authorised Allett dealer
to the angles shown below.
7.7 Inspection of safety critical components
The below parts are critical to the safe operation of your lawnmower, before each use
check that:
When the park brake is engaged the mower can not move.
The guards, deflectors and the grass box are in good condition and secured in place
The On/off engine switch stops the mower in case of an emergency
When the bail bars are released the cylinder and land roll drive stop immediately
C
B
D
A

16
7.8 Maintenance schedule
Activity
Task
Daily
Weekly
Monthly
Yearly
Check
Engine oil level
●
Fuel level
●
Air cleaner condition
●
Guards in place
●
Cutting cylinder
●
Fasteners
●
Chain and belt tension
●
Spark plug
●
Clean
Debris/grass from mower
●
Engine cooling fins
●
Fuel sediment bowl
●
Air filter elements
●
Inside guards
●
Test
Parking brake
●
On/off switches
●
Drive engagement/disengagement
●
Replace
Engine oil
●
Spark plug
●
Air filter elements
●

17
8.0 Making adjustments to your mower
8.1 Floating handle bars
The upper and lower handle bars are isolated with rubber vibration mounts. The
lower handle bar is also suspended via springs. The sprung lower handle bar is
designed to “float” off the rubber stops when in use. The spring tension can be
adjusted by rotating the spring anchor.
1) Slacken the locking nut
2) Rotate the spring anchor to adjust spring tension
3) Tighten the locking nut
8.2 Delivery plate
The delivery plate covering the rear of the cylinder can be adjusted to alter the grass
trajectory into the grass box.
1) Loosen the 2 delivery plate screws
2) Adjust the delivery plate forwards or backwards then tighten the screws
1 & 3
2
1
2

18
9.0 Vibration reduction
Best practices for reducing vibration emission:
The mower is designed to operate at low engine speeds. Adequate performance can
be achieved at little over idle speed.
Inspect the rubber vibration mounts for signs of wear and deterioration, replace if
necessary. Properly adjust the sprung floating handle bars to improve operator
comfort and further limit vibration transmission (See section 8.1).
A well maintained mower with an accurately ground and balanced cylinder is
recommended to limit vibration emission. Forcing the mower to cut longer grass than
intended or mowing on unsuitable surfaces will result in higher levels of vibration and
wear.
10.0 Noise reduction
Best practices for reducing noise emission:
This mower is designed to operate at low engine speeds. Adequate performance can
be achieved at little over idle speed. Setting minimal contact between the cylinder
and bottom blade will also help reduce noise emissions. Forcing the mower to cut
longer grass than intended or setting it to work at great depths may cause higher
levels of noise emission.
Damaged exhausts or loose guards can increase noise emissions. Therefore, before
use inspect the exhaust system for signs of wear and ensure the guards are securely
attached and in good condition.

19
11.0 EC Declaration of conformity
We: Turfmech Machinery Limited
of: Hangar 5, New Road, Hixon, Staffordshire, ST18 0PJ, UK
declare that:
Equipment: Lawn mower
Model name/number: Buffalo 20, 24 & 27 (Cutting width 0.51, 0.61 & 0.69m)
in accordance with the following directives:
2004/108/EC Conforms with the essential protection requirements of the
Electromagnetic Compatibility Directive and its amending Directives.
2006/42/EC Conforms with the essential requirements of the Machinery Directive
and its amending Directives.
2000/14/EC Conforms with the essential requirements of the Noise Directive and
its amending Directives. The conformity assessment procedure
followed was in accordance with Annex VI of the Directive
Has been designed and manufactured to the following standards:
EN ISO 12100-1:2003+A1:2009
Safety of machinery. Basic concepts, general principles for design. Basic terminology,
methodology.
EN ISO 12100-2:2003+A1:2009
Safety of machinery. Basic concepts, general principles for design. Technical principles.
BS EN 836:1997
Garden equipment – Powered lawnmowers – Safety
Measured Sound Power Level (2000/12/EC, BS EN 836 Annex H): 93dB LWA
Guaranteed Sound Power Level (2000/14/EC): 98dB LWA
Uncertainty K = 2.5dB
Sound Pressure Level (BS EN 836 Annex H): Buffalo 20 – 83dB LPA,
Buffalo 24/27 – 84dB LPA
Wear hearing protection!
Vibration test code BS EN 836 Annex G, xx m/s/s xx uncertainty
Notified body: AV Technology, Handforth, Cheshire
Technical construction file is kept by: Turfmech Machinery Ltd, Hangar 5, New Road, Hixon,
Staffordshire, ST18 0PJ, UK
I hereby declare that the equipment named above has been tested and found to comply with
the relevant sections of the above referenced specifications. The unit complies with all
essential requirements of the Directives
Signed by:
Name: Austin Jarrett
Position: Managing Director
Done at: Turfmech Machinery Ltd
On: 30th January 2013

20
12.0 Fault finding when mowing
Problem
Possible cause
Remedy
Occasional blades of uncut
grass.
Ground speed too fast.
Height of cut too high
Reduce forward travel speed.
Reduce height of cut.
Poorly adjusted bottom blade.
Re-adjust bottom blade.
Blunt cutting cylinder/bottom blade.
Grind/recondition as necessary.
Drive belt slipping.
Adjust belt tension.
Strips of uncut grass
between adjacent runs.
Overlap between runs too small.
Increase overlap between runs.
Uneven cut on uneven
ground.
Uneven ground conditions.
Reduce forward travel speed,
change direction of cut.
Scalping of grass.
Height of cut too low for conditions.
Increase height of cut.
Uneven ground conditions.
Increase height of cut, change
direction of cut.
Ribbing of grass
perpendicular to direction of
travel.
Forward travel speed too fast.
Reduce forward travel speed.
Tram lining of grass in the
direction of forward travel.
Bottom blade in ground contact.
Poor cylinder to bottom blade
adjustment.
Increase height of cut.
Re-adjust bottom blade.
Worn cylinder bearings.
Replace worn parts.
Excessive bottom blade
wear.
Bottom blade in heavy ground
contact.
Increase height of cut.
Blunt cutting edge.
Grind/recondition.
Cylinder in heavy contact with
bottom blade.
Re-adjust the bottom blade to
cylinder clearance.
Excessively abrasive ground
conditions.
Increase height of cut.
Cylinder knocks while
rotating.
High spots on the cutting edges.
Grind/recondition cylinder and
bottom blade.
Worn cylinder bearings.
Replace worn parts.
