Tuta B12 User manual

TUTA B12
GSM REMOTE CAMERA
User Manual
Manual version 3.0

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
2
TUTA Series GSM Remote Camera
Thank you for purchasing the TUTA camera. This camera is a remotely controlled
image-capturing device consisting of a microphone, infrared lighting and a high quality
300,000-pixel camera. The TUTA camera can capture images according to
pre-programmed remote commands and send them to your multimedia messaging (MMS)
enabled mobile phone. You can control and change the camera settings via SMS
command.
The MMS sent by the TUTA camera can be viewed by using your mobile phone. You also
can opt to view a slide of consecutive photos taken by the GSM Remote camera.
The built-in high-light infrared LED’s allows the camera to capture clear images, even in
dark environment.
The TUTA camera is compatible with standard 433MHz wireless sensors such as panic
buttons, PIR-, door magnet- and smoking sensors.
All services and functions need to be supported by the selected GSM network and a SIM
card.
This brochure suits for TUTA-B12 model.
Details of the functioning and advanced operation of this camera are described in this
instruction manual.

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
3
CONTENTS
For your safety ...........................................................................................................5
Exception clause........................................................................................................6
Chapter 1 Structure Instruction ........................................................................................7
1.1 Package contents...............................................................................................7
1.2 Products features...............................................................................................8
1.3 Remote control instruction..................................................................................9
Chapter 2 Installation and power on/off..........................................................................10
2.1 Installing the SIM card....................................................................................100
2.2 Extending the camera’s base board ..Σφάλμα! Δεν έχει οριστεί σελιδοδείκτης.0
2.3 Connecting to power adapter..........................................................................111
2.4 Mounting the camera ......................................................................................111
2.5 Power on/ off..................................................................................................122
Chapter 3 Define the user and basic operation ............................................................133
3.1 User authorization level..................................................................................133
3.2 Setup master number.....................................................................................144
3.2.1 Add a master number to the camera..........................................................144
3.2.2 Change the master number.......................................................................144
3.2.3 Change password.....................................................................................144
3.3 Define family user ..........................................................................................155
3.3.1 Add a family number .................................................................................155
3.3.2 Delete family number................................................................................155
3.4 Define guest user...........................................................................................155
3.5 MMS parameter settings ................................................................................155
3.6 Capturing images...........................................................................................166
3.7 Arming or disarming the camera.....................................................................177
3.7.1 Arming TUTA camera................................................................................177
3.7.2 Camera alarm...........................................................................................177
3.7.3 Disarming TUTA camera ...........................................................................177
3.8 Emergency alarms .........................................................................................188

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
4
3.9 Wireless sensor(s) ...........................................................................................18
3.9.1 Loading sensor to camera...........................................................................18
3.9.2 Removing a sensor from camera.................................................................19
3.10 Resetting the camera .....................................................................................19
Chapter 4 Advanced settings.......................................................................................200
4.1 Remote control...............................................................................................200
4.1.1 Pairing a remote control............................................................................200
4.1.2 Remote control instruction.........................................................................200
4.1.3 Removing remote controls from the camera ..............................................211
4.2 Infrared body detector....................................................................................211
4.3 Camera language...........................................................................................211
4.4 Image size .....................................................................................................211
4.5 Image quantity ...............................................................................................211
4.6 Beep tone ......................................................................................................222
4.7 SMS alarm setting..........................................................................................222
4.8 MMS alarm setting .........................................................................................222
4.9 Dialing phone call when the alarm is triggered................................................222
4.10 LED indicator setting....................................................................................222
4.11 SMS notification upon the power supply changes .........................................222
Chapter 5 General troubleshooting..............................................................................233
Chapter 6 Main technical parameters...........................................................................244
Appendix: SMS commands list ....................................................................................255

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
5
1. Purchase a GSM SIM card (mobile phone card) from a
GSM network service provider and install it in the camera.
This SIM card number is referred as TUTA camera number
on this brochure.
2. The user needs to activate the MMS function and Caller ID
Presentation function of SIM card, and deactivate PIN
code of the SIM. Contact with GSM network service for
support.
3. Change the original password at the beginning use. Be
sure to keep the password and SIM card number secret.
Do not disclose this information to anyone other than the
authorized users in order to ensure your safety.
For your safety
This product is a wireless signal
transmission device. Keep it away from
electronic equipment likely to interfere
with the wireless signals to avoid signal
interference.
Switch off your TUTA and mobile phone
when entering areas marked
"Explosive", "Might explode", "Turn Off
wireless transceiver devices", etc.

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
6
Do not throw this product in a fire, as
this may cause the battery to explode.
Exception clause
1. We operate on a policy of continuous
development. We reserve the right to make
changes and improvements to any of the
products described in this document without
prior notice.
2. For the latest product information, please
visit: http://www.i-tuta.com. We don’t
guarantee for the document veracity,
reliability or any content except regulate in
proper laws, including no guarantee for
product suitability for intended application.
3. Use only this product according to the law.
We take no responsibility for the illegal use
of this product.
4. We take no responsibility for any loss of data
or income; or any special, incidental,
consequential or indirect damages
howsoever caused.
5. The contents of this document are provided
(as is). Except as required by applicable
law, we provide no warranties of any kind,
expressed or implied, including, but not
limited to the accuracy, reliability or contents
of this document. We reserve the right to
revise this document or withdraw it at any
time without prior notice.
This product should only be operated
from power approved by the product
manufacturer. The use of any other
types of power may damage the
product.
Keep the product and its accessories
out of the reach of children.

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
7
Chapter 1
Structure Instruction
1.1 Package contents
Camera host 1 pc Remote control 2 pcs
Power adapter 1 pc User manual 1 pc

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
8
1.2 Products features
Figure 1: TUTA camera instructions
Tip: Keep the camera lens clean to insure best image quality.

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
9
1.3 Remote control instruction
Battery: One 3.0V CR2032 battery.
Battery: One 27A/12V battery.
Figure 2: Remote control instruction
Note: There is battery holder on the rear of the remote control. When this battery is running
out of power, the TUTA camera will emit BEEP warning tone and then send a SMS
notification message to Master user.

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
10
Chapter 2
Installation and power on/off
2.1 Installing the SIM card
Remove the rubber cover from the left side of the camera.
Open the SIM/USIM card slot by pressing the small dot beside the card slot with
the tip of a pencil, and pop open the slot.
Insert the card into the slot.
Push the slot back into place.
Put the rubber cover back in its place.
2.2 Extending the camera’s base board
Hold the base of the camera and
pull the top part and the bottom part
(base) in opposite directions (i.e.
away from each other).
Then the slot buckle will be pulling
open.
The head of the camera can now be
moved freely and located at any
direction.

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
11
2.3 Connecting to power adapter
Connect the adapter to an AC power, and
connect the mini-USB plug to the power
interface of the TUTA camera .(See Figure 1
TUTA camera instruction)
This camera has a built-in rechargeable
Lithium battery.
The camera will notify the user when the
power changes. For example, if the power
adapter is disconnected or failure of AC
power occurs, the TUTA camera will notify
the user: External power cut. The device is
operating on battery.
If the TUTA camera is again connected to the external power or the AC power is
restored, a notification will be sent to the user stating: The device is now resuming
the use of external power source.
Low battery: The configuration settings cannot be saved when the TUTA camera
is operating on low battery.
2.4 Mounting the camera
The TUTA camera can be mounted on a wall (vertically with the screws) or placed on
any suitable horizontal surface.
How to choose the installation location:
To capture better image quality, avoid any areas where bright light will be shining
directly into the lens of the camera.
In order to avoid backlit photography, the camera should be located where it can
look down the monitoring place with the minimum angle of 30 degrees.
The GSM network’s signal strength may affect the image, live voice quality and
MMS transmission speed. On installation the user should verify that TUTA camera
is located in an area with a strong network signal.
After installation, the user should perform a test-run by taking several images and
sending them to the user’s mobile phone. This allows the user to check the image
quality of the camera. The position of TUTA camera can then be adjusted until a
satisfactory image quality level is reached.

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
12
2.5 Power on/off
Power on:
Operation
Indicator light
Status
Turn the power
switch to ON
position.
Red light is on for 3-5 seconds.
Red light flashing slowly for
about 35 seconds.
A BEEP tone will be heard.
Green light flash slowly or
green light be solid on.
TUTA camera is
disarmed(flash) or
armed(solid.)
Power off:
Turn the power switch to downside OFF position.

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
13
Chapter 3
Define the user and basic operation
3.1 User authorization level
There are three levels, each with a different authorization level, namely Master, Families
and Guest.
Table 3.1 the difference in authority for Master, Families and Guests users:
User Type
Functions
Master
Families
Guests
Change authority, password
YES
NO
NO
Automatic Alarm
Receive SMS
YES
NO
NO
Receive MMS
YES
NO
NO
Receivealarmcalling
YES
YES
NO
Emergency alarm
Receive SMS
YES
NO
NO
Receive MMS
YES
NO
NO
Receive emergency
calling
YES
YES
(Only emergency number)
Call the camera to listen in live voice
YES
YES
NO
Get status, images, help and instruction by
sending SMS command
YES
YES
YES(Password)
Set the camera by SMS command
YES
YES
NO
Add, modify or delete sensor
YES
YES
NO
Camera language setting
YES
NO
NO
Set infrared body detect function
YES
YES
NO
Note:
Any MMS enabled mobile phone can receive the images captured by the TUTA camera
by sending SMS command with password.
Any SMS enabled mobile phone can control the TUTA camera with the password
command.
About the SMS Command:
The password must be a four-digit number.
The original password is 1234.

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
14
The maximum digits that are allows for the phone number is sixteen.
The TUTAcamera will reply to the user after it receives the SMS command.
Note:
The # symbol must be included when typing an SMS command.
No spaces allowed within the commands.
3.2 Setup master number
The Master user has all the rights of changing the camera’s settings and receives alarm
messages from camera. In order to enable all the functions on the camera, the Master
user must store his/her mobile number in the camera’s memory. Only one Master’s mobile
number (Master number) is allowed for a camera.
3.2.1 Add a master number to the camera
The user must edit and send the following SMS (text message) to camera from a mobile
phone (the phone number will be the Master number) to:
Setup master number: #00#PhoneNumber#(1)
The PhoneNumber is the camera installed SIM card’s phone number. In the US, the area
code + number is sufficient. Ex: #00#9045551234#
If it is necessary to add a country code in front of the phone number, for example
#00#[phone]#(+49isthecountrycodeof Germany,123456789isSIM’s phone number).
If the camera reply master number already exists, please refer the Reset Factory Setting
section of the manual to delete old master number.
3.2.2 Change the master number
Master user sends following SMS message in order to:
Change the master user’s number: #14#NewMasterNumber#(2)
3.2.3 Change password
In order to ensure your privacy and safety during the use of this camera, change the
password once start to use the TUTA camera.
Master user sends following SMS message to:
Change the password: #04#oldpassword#newpassword#(3)
The password is a four digit number.
The original password is 1234.

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
15
3.3 Define family user
Family users have the authority to listen in on the camera, receive images, load the
sensors and remote controls to the camera, and receive notification when the motion
detector activated. The family user’s mobile numbers are set by the Master user. The
family users should remember and safeguard the camera’s phone number.
3.3.1 Add a family number
The Master user can send following SMS message in order to:
Add a family number: #06#FamilyNumber#(4)
Add several family numbers: #06#FamilyNumber#...#FamilyNumber#(5)
Up to 10 family users’ number can be stored on one camera.
3.3.2 Delete family number
The Master user can send following SMS message in order to:
Delete a family number: #113#FamilyNumber#(6)
Delete several family numbers simultaneously:
#113#FamilyNumber#…#FamilyNumber# (7)
Delete all family numbers: #113# (8)
3.4 Define guest user
Any selected person can operate in the Guest category if they know the password and the
unit’s phone number. The Guest user(s) can then use their mobile phones to send a SMS
command including password to the TUTA camera in order to obtain an MMS image.
3.5 MMS parameter settings
Normally the camera will preset local operator MMS settings in the firmware when it first
starts up, so that the user does not need to setup the MMS parameters. But if the GSM
operator changes the MMS parameters or a local setting does not preset in the firmware,
the user will receive SMS when they request MMS images: Sorry, the network is busy,
MMS sending failed. The Master number can setup the MMS parameters manually by
following method.
Six MMS parameters be set on the camera. The Master user should send two SMS

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
16
commands to the camera as follow.
Set MMS center: #124#MMScenter#(9)
Set APN parameters:
#125#Proxy IP#WAPProxyPort#HTTPProxyPort#APN#Username#Pssaword# (10)
Check the current operative network parameter settings: #55# (11)
The MMScenter should be the MMS center address of GSM provider.
For example: #124#http://mmsc.monternet.com#
#125#10.0.0.172#9201#80#cmwap#wap#wap#
3.6 Capturing images
Authority:
Master/ family / guest can send an SMS to the camera to get the MMS image or to send
the image(s) to an appointed mobile.
Master/ family member can just call the camera to get the images.
Method 1:
A Master or family user calls the camera and hangs up upon hearing the ringing
tone (within 10 seconds).
The TUTA camera will reply SMS notification: Request received, TUTA camera is
sending an MMS image.
The user will then receive the MMS message in a few moments.
The guest users are unable to capture an image by using method 1.
Method 2:
The user sends following SMS message in order to:
Capture one image and send to the user mobile:
For master and family users: #03# (12)
For guest users: #03#password#(13)
Capture several images and send to the user mobile:
For master and family users: #03#ImageQuantity#(14)
For guest users: #03#Password#ImageQuantity#(15)
The Image quantity should be in the range of 1-8 when the image size is set at
160×128 or 320×240 (Refer image size setting elsewhere in the manual.) The
default image size is 320×240(QVGA).
TheImage quantity shouldbeinthe rangeof1-2 when the image size is set at 640×480.

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
17
3.7 Arming or disarming the camera
3.7.1 Arming TUTA camera
When the user arms the TUTA camera, the built-in infrared body detector (PIR) will
start working and detecting body heat. The TUTA camera will automatically send
alarm message or making a phone call once the infrared body detector (PIR)
triggered.
There will be 30 seconds alarm suspension period; the user can leave the camera
location during this time to avoid a mis-alarm.
Method 1:
The Master or family user sends following SMS message in order to:
Arming TUTA camera: #01# (18)
Method 2:
Press on the remote control, while pointing it in the direction of the TUTA
camera. The TUTA camera will emit a BEEP tone, to indicate that arming the TUTA
camera is successful. (Refer remote control instruction instructions in the manual
elsewhere.)
3.7.2 Camera alarm
Once the camera is triggered in its armed state, the LED will flash fast in green, then turn
red and flash fast. It will send an alarm notification via SMS, MMS or make voice calling
according to the established setting. After it finishes the alarm process, the camera will
enter a one minute alarm-suspension period and the camera will be able to alarm again
after that one minute.
3.7.3 Disarming TUTA camera
Method 1:
The Master or family user sends following SMS message in order to:
Disarming TUTA camera: #02# (19)
Method 2:
Press the button on the remote control and the camera will emit a BEEP tone to
show the TUTA disarm successfully. (Refer remote control instruction setup in the
manual elsewhere.)

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
18
3.8 Emergency alarms
User can press the remote control emergency button to make the camera alarm.
The TUTA camera will stop any current operation once it receives an emergency alarm
signal and start to process emergency alarm. The TUTA camera will dial the master
number 3 times until someone answers. If, after 3 attempts, there is no answer, the TUTA
camera will automatically stop dialing and revert to its preset mode. The Master can listen
in the live audio to answer the call.
3.9 Wireless sensor(s)
Standard 433MHz wireless sensors, such as infrared body sensors, wireless door magnet
sensors, wireless smoke detector etc. can be set as an alarm sensor of the camera. Up to
15 wireless sensors and wireless panic buttons can be loaded onto one TUTA camera.
There are two modes for wireless sensor:
Arming alarm mode: the sensor will only alarm when the camera in its armed mode.
Normally door sensors and infrared sensors work with this mode.
Always alarm mode: the sensor will always alarm once the sensor triggered even the
camera is in its disarmed mode. Normally smoke detectors, gas detectors and panic
buttons will work with this mode.
3.9.1 Loading sensor to camera
1. Power on the wireless sensor.
2. The Master or family user sends following SMS message to make TUTA camera
enter loading mode:
Arming-alarm mode: #05#SensorDescription#(20)
Always-alarm mode: #196#SensorDescription#(21)
SensorDescription is used for identify different sensors affiliated with each
camera. It can be numbers and letters.
SensorDescription could be empty. For #05#, TUTA camera will recognize the
sensors with name Sensor and number such as: Sensor1, Sensor2, Sensor3. For
#196#, the TUTA camera will recognize the sensors with name SOS and number
such as SOS1, SOS2, SOS3.
Up to 9 characters can be include in the SensorDescription
The default for a sensor alarm is to only send an SMS. If the user wants the
camera to send SMS & MMS of this sensor alarm, add an * in front of sensor
description, such as #05#*door#.
3. When the TUTA camera receives the SMS command, it will emit a BEEP tone and the
indicator will flash red and green alternately. The TUTA camera will then send a
notification SMS to the user: Camera pairing sensor, activate sensor then wait for

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
19
confirmation SMS.
4. The user then needs to make the sensor work and transmit signal to be captured by
the TUTA camera.
5. When the TUTA camera receives the sensor signal, it will emit a BEEP tone and send
a notification message SMS: Sensor *** successfully paired.
6. To exit the loading mode manually, press the SET button of the camera, TUTA camera
will emit a Beep… tone and exit the loading mode.
3.9.2 Removing a sensor from camera
The Master or family user sends following SMS message to the TUTA camera:
Remove a sensor: #112#SensorDescription#...#SensorDescription#(22)
Remove all sensors: #112# (23)
Sensordescriptionshouldbetheexistingsensor whichtheuserwantstoremove.
3.10 Resetting the camera
User can reset the camera to factory settings if the user forgets the master number or
camera does not work normally.
After resetting to the factory setting, the camera will delete all set numbers and other set
values and the user will need to setup the master number from the beginning.
Method 1: Reset via the camera
Switch the TUTA camera off. It must remain off for a minimum of 20 seconds.
Press and hold the SET button and then switch the TUTA camera back on.
The indicator light will be green for 2-4 seconds after which it will flash red.
If resetting of TUTA camera is successful, a BEEP tone will be emitted.
Method 2: Reset via SMS command
The Master user sends following SMS message to TUTA camera:
Reset the camera: #08#password#(24)

TUTA-B12 GSM REMOTE CAMERA USER MANUAL
20
Chapter 4
Advanced settings
4.1 Remote control
4.1.1 Pairing a remote control
Normally the remote control will be paired in factory. if the remote camera can not work
with TUTAcamera, user should pair the remote control separately. A camera can pair up to
5 remote controls.
Operations
Status
Camera indicator
1. Press and hold the Set key
for 2 seconds
Indicator light turns to
orange (Learning mode)
Green, flashing or
constantly light.
2. Press any button on the
remote control (with battery
inside) to send a signal to TUTA
camera.
TUTA camera will emit a
BEEP tone and indicator
will turn green for 2S.
(Added successfully.)
Orange, flashing
3. Repeat step2 to load another
new remote camera.
Orange, flashing
4. Press the Set key to exit the
learning mode or waiting for 15
seconds to auto-exit.
Indicator light turns green,
flashing or constantly
light. (Exit learning mode)
Orange, flashing
4.1.2 Remote control instruction
There are three buttons on the remote control:
A. Arm the TUTA camera
When is pressed, the indicator light on the TUTA camera will turn green. This
indicates that the TUTA camera is in armed mode.
B. Disarm the TUTA camera
When is pressed, the indicator light on the TUTA camera will slowly flash green.
This indicates that the TUTA camera is in disarmed mode.
C. Emergency button
When is pressed, the indicator light on the TUTA camera will rapidly flash
green. Then the TUTAcamera will dial the master user’s number. A live audio stream
