Tview D51TSB User manual

D51TSB
OPERATION INSTRUCTIONS
Please read the manual in detail before using this product.
This product is made of precision components, keep it away from moisture.
D51TSB
LOU D
SEL
D51TSB
TVIEW

TABLE OF CONTENTS
Safety Precautions.......................................................................1
Main Features.............................................................................2
Accessories ...............................................................................3
Appearance and function introduction ..........................................4
Unit Installation...........................................................................5
Instruction for install and uninstall face panel................................9
User introduction .......................................................................11
Wire connection .........................................................................11
Unit Rear Side Connection...........................................................12
Remote Control Operation...........................................................13
Basic operation..........................................................................14
Connect To Storage Accessories..................................................16
Touch Screen Menu And Operation ..............................................17
RADIO Function Interface ..........................................................18
Bluetooth function system...........................................................19
DVD Mode Menu Interface...........................................................20
CD Mode Basic Operation............................................................20
USB/SD Operation......................................................................21
System Menu Setup....................................................................22
Common Menu Setup..................................................................23
AUDIO/VIDEO Menu Setup..........................................................23
DVD System Setup......................................................................25
Function Index Sign.....................................................................29
Warning.....................................................................................29
Disc Notes.................................................................................30
Simple Trouble-Shooting Guide...................................................31

01 02
MAIN FEATURES
Thank you for your support of the company's products and options. This unit is
crystallization of the modern high-tech.It is a cross-functional player mode and
adjustable true color LCD Automatic retractable screen LCD touch screen.
Allows you to be arbitrary choice To appreciate the program. Here, we wish you to
personally experience this high-tech products can be Perfect fun and enjoyment.
To ensure proper use of this product, please read this owner's manual carefully
before operating this unit and keep it for future reference.
Note: The graphics of this manual are for your reference only, please in-kind
products prevail,
!!
!!
!!
!!
This product without waterproof function. To avoid the risk of fire breakout
or electric shock, please do not expose this unit in the rain or moist environ-
ment. Do not open the cabinet. Such operation will absolve relative mainte-
nance guarantee. Only the legally authorized professionals are allowed to
conduct such operation.
LASER: This unit installs a laser system. To ensure proper use of this prod-
uct, please read this owner's manual carefully before operating this unit and
keep it for future reference. If the unit requires maintenance, please contact
an authorized professional. Please operate according to correct
process in order not to hurt by laser beam.
Please use this unit at normal temperature. Do not put the unit under -10
degree or higher than +60 degree environment. Otherwise it will distort the
plastic shell, debase the display quality and products quality.
Installation should be very tight and secured to prevent the fallen unit hurt
people and damage the unit when moving on or a sudden brake.
Please install carefully to avoid damaging working platform. Please clean
the internal working platform, and ensure sufficient space for installation.
Inner shell will be installed on the working platform. Then install the mainfr-
ame, connecting the power and video signals jack, then put mainframe into
the shell. Then assemble the shell with the mainframe device.
Please do not try to repair display device by yourself. It is made up of many
precision electronic elements, and any dismantlement or refit will make it
damaged or broken. If any problem on the unit, please switch off the power
immediately, and consult your nearest seller or distributor.
Please keep the monitor away from the pollution of moisture, dust, water
soot etc. Please switch off the power immediately if any moisture or other
objects pollute , please contact the seller or distributor.
If you drive with the sound at a level preventing you from hearing sounds
outside the car please keep the unit at an appropriate sound level, otherwise
this may affect your driving and cause an accident.
For your safety, please do not watch or operate the monitor when you are
driving.
SAFETY PRECAUTIONS Preface
1. 5”Wide screen TFT LCD monitor.
2.This unit is with touch icon interface.
3. DVD/RADIO/AUX/USB/SD/BLUE/CAR REVERSING function build in.
4. DVD/VCD/MP3/CD/MPEG compatible.
5. FM/AM digital synthesizer tuner with 30 memory presets.
6. Intelligentize bluetooth function, for you to make and answer the phone
comfortably.
7.Hi power 45Wx4, 4 RCA stereo audio output, can connect to power amplifier.
8. Signal : 1 video output, 1 video input.
9. Under car reverse mode, can auto switch to the reversing mode, if connect
to the camera, can observe the back side of car to ensure the safety.
10. Menu language: CHINESE/ ENGLISH display.
11. Menu function: all function is operated by OSD menu.
12. Display system: auto PAL/NTSC.
13. Video mode: Brightness/ Standard/Soft three preset video mode.
14. Display panel adjust: Panel angle can be adjustable.
15..Support SD card to play MP3/MP4/WMA/AVI/JPEG media format.
16. USB connector can support removable disc, and with MP3/WMA audio
display and picture browse function.
17. Clock display: 12/24 hours clock display
18. Remote control: full function remote control operation
19. Picture pixel: 800*3(R.G.B)*480
20. Power: DV+12V/±10%

5
03 04
12
13
10
11
9
8
5
2
3
4
1
7
LOU D
SEL
D51TSB
Appearance and function introduction
1. /SRC: Power on / off, Under power on mode, press this button to
switch RADIO/DVD/TV/AUX mode; Press for long time to turn off.
2. MUTE/LOUD: For mute function, press for long second to turn on/off
the LOUD.
3. VOL+: Control for the volume increase, and can use for MENU
adjustment.
4. VOL–: Control for the volume reduce, and can use for MENU
adjustment.
5. Remote Control window.
6. SEL: Sound function select, choose “VOL”“BAS”“TRE”“BAL”“FAD”
to adjust that you need.
7. SD card jack.
8. / ANGLE: Panel angle adjustment, press for long second to eject
the disc.
9. /AST: PLAY/PAUSE.
10. : Detachable panel button.
11.BAND: PAL/NTSC/AUTO system switch. Radio band selection.
On RADIO mode to select brand of radio: FM1/FM2/FM3. AM1/AM2
On DVD-USB/SD-BT-AUX mode to select the system: NTSC/PAL/AUTO
12.DISP: Display Time on/off, press this button to display the time on the
left top of panel. Long press by screen black, long press again or touch
the screen, screen bright
13.USB JACK
6
TVIEW

05 06

07 08

09 10
3.Raise up the face panel
4.Carry out the face panel
Note: please process the step as the instruct, if force to take
out the face panel will be easy to broken the material and can
not catch the head unit.
Instruction for install and uninstall face panel:
2.The left side of face panel will move out
1: Press the button
The face panel is for security design, the face panel available detachable, press
the button, the face panel will be move out, raise up the moved our side, the take
out the face panel. Please reference the fig. 1,2,3,4, as below:

11
Unit Rear Side Connection
12
RA DIO A N T
RAD IO
N EN NA AATERA TD P
ACC
(RED)
(YELLOW)BATT(Memory backup)
BATTERYBATTERY GND
(BLACK)
(BLUE/WHITE)ANT-CON
An t enn a c ont rol c a ble
REAR RIGHT
REAR LEFT
FRONT RIGHT
FRONT LEFT
(GRAY)
(GRAY/BLACK)
(GREEN)
(GREEN/BLACK)
(PURPLE)
(PURPLE/BLACK)
(WHITE/BLACK)
(WHITE)
BRAKE-CON
(PINK)
REVERSE-CON
(ORANGE)
Ma n ual b r ake s wit c h
MUTE-CON
(BROWN)
AMP-CON
(BLUE)
Ex t ern a l pow er am p lif i er co ntro l cab l e
Re v ers e m irr or co n tro l c abl e,co nne
ct e d to th e c ar ba cki n g lam p .
YELLOW/VIDEO O U T 1
Display
YELLOW/VIDEO O U T 2
Dis p l ay
YE L L O W/B ACK -V I D EO - IN
Cam e r a
WHITE/RL O U T
LI N E -OUT-R
LI N E -OUT-L
SU B W O OF ER
SUBWOOFER
WHITE/FL O U T
RED/RR O U T
RED/FR OUT
YE L L O W/VIDEO IN
WHITE/AU T I O L IN
RED/AUTIO R I N
BL EOT I NU T O H M CI
87 6 5432
910 1 1 12 1 3 14 15 1 6
PU RP LE /RR +
GREEN/RL+
GREEN(BLACK)/ RL-
BROWN/MUTE-CO N
GREY/FR +
GREY(BLACK)/ FR-
WHITE/FL+
WHITE(BLACK)/FL-
OR AN GE /REVERSE-CO N
RED/ACC
BL A CK /G ND
PU RP LE (BLACK)/ RR -
BL UE (WHITE)/ANT-CO N
PINK/BRAKE-CON
BLUE/AMP-CON
1
FUS E
YELLOW/BATT(Memory backup)
BLUE/AM P-CON
Wire connection
User instroduction
1.Please connect the signal cable with power cable according to “Unit rear side
connection” to connect to power and signal.
2.After connect to power, press the power button, then the picture will show the
RADIO mode.
3.When display DVD or VCD disc, the unit is automatically identify the video
system PAL and NTSC.
4.Can through the button on panel to adjust the function. And can use the remote
control or touch screen to adjust the function.
5.FM mode will be factory default when without any signal input. If put the disc or
USB/SD, the picture will auto read the file and enter to play picture.
1. (BLACK)GND: connect to ground.
2. (BLUE/WHITE) ANT-CON: Antenna amplifier output control
3. (BROWN) MUTE-CON: Mute control cable
4. (ORANGE)REVERSE-CON: Car reversing cable
5. (PURPLE) RR+: Rear right audio output (positive pole)
6.(GREY) FR+: Front right audio output (positive pole)
7. (GREEN ) RL+: Rear left audio output (positive pole)
8.(WHITE ) FL+: Front left audio output (positive pole)
9.(WHITE/BLACK) FL-: Front left audio output (cathode)
10.(GREEN/BLACK) RL-: Rear left audio output (cathode)
11.(GREY/BLACK) FR-: Front right audio output (cathode)
12.(PURPLE/BLACK) RR-: Rear right audio output (cathode)
13. (PINK) BRAKE-CON: Hand brake connection cable
14. (BLUE) AMP-CON: Amplifier output control
15. (RED) ACC: Connect to battery positive pole
16. (YELLOW) BATT(Memory backup): Power cable
(positive pole)
(Cathode)

13 14
Remote Control Operation
1. Power
Press this button to turn on/off the unit.
2. PLAY/PAUSE
3. MUTE
Press this button to turn off speaker, press
again to resume.
4.Cursor direction key
Press this button to move cursor to
left/right/up/down.
5.SYSTEM SELECT：AUTO/NTSC/PAL
6.ENTER
7.VOLUME :VOL+/VOL-
8.PREV: SEEK- / SEEK+
Under DVD mode, short-press it for next
or previous item. Long-press it for fast
forward/fast back. Under FM mode,
adjust radio frequency, each plus / minus
the frequency increase or decrease.
9.ST/PROG
the display rank of music
10.OSD
Press it will display the disc
information.
11.SEL
Sound function select.
12.AMS/RPT
Under FM mode, press for
searching function.
Under DVD mode, press for
single song play or single song repeat.
13.LOC/AF/RDM
On DVD mode , press it for play song by
production system.
14.NUMBER
Song choose
15.AUDIO choose mode.
16.MENU display
17.Language select
18.GOTO title, chapter
19.MODE: Switch mode
RADIO-AUX-DVD-BLUE-SD/USB
20. / : STOP/PLAY
21.ANGLE
DVD display disc there are more
angle select (need the disc support)
22.SLOW:slow forward/slow playing
23.SETUP
DVD system setup.
24.TITLE
DVD disc character showing
25.ZOOM
Press it can ZOOM or shrink display
picture.
26. Eject button
Press this button to eject or slot-in
the disc.
27. Display panel slip out
28. Display panel retract
29.CLOSE:Display screen slip out/
retract
Precautions before using remote control unit
1.Please pull out the PVC when the remote control unit is first using.
2.Don't drop or step on remote control unit or subject it to shocks.
3.Note that it maybe impossible to operate the main unit if there are obstacles
between it and the remote sensor.
4. Using the remote control unit within the specified operating range.
Remote control unit operating range
Horizontal: ±30 degree
Vertical: ±30 degree
Distance: 6M
3.
2.
1.
Replacing the battery
Basic operation
1 3219
26
27 28 29
1.Power on /off
Press the “ ” button on panel or remote control, enter to power on mode,
re-pressing the button to turn off.
2.Press OSD to show the play and disc information in the LCD when the main
unit is in play mode. Press “GOTO”,the screen show the same effect as“OSD”
button, press it, the disc information title or chapter choice could be displayed
vid up, down, left and right cursor of remote control and confirmation button.
3.Press AUDIO to select the audio language when the main unit is in play mode
for DVD disc. Press AUDIO to select the audio channel when the main unit is in
play mode for VCD, CD disc.
4.Press SUBTITLE to select the sub-title when the main unit is in play mode.
5. Press ANGLE to select the play angle when the main unit is in play mode for
DVD disc, there is no function for other disc. It will be no working if the disc not
have this function.

15 16
USB mini jack
Moveable memory
USB
LOU D
SEL
D51TSB
TVIEW
6. Press ZOOM every times, The picture will change to 2X 3X 4X 1/2X 1/3X, 1/4X
and normal. (Note: When playing MP3/USB/SD, this button is non-function.)
7. Press SLOW in the remote control unit to slow playing. Change the playing
speed to 1/2, 1/3, 1/4, 1/5, 1/6 and 1/7 through pressing SLOW button. Press
SLOW button to skip frame when the unit is in pause mode.(The sound is mute
when the main unit is in fast or slow playing except CD and MP3 disc. Press
PLAY to resume normal playing.)
8. The main unit may play the list according to the following program list:
Press ST/PROG, the menu will shown in the LCD.
Hint: T is for Title, C is for Chapter for DVD disc.
DVD disc will be divided into several parts is call
Title. Then title will be divide into chapter;
Normally one movie only corresponding to one
title. CD disc will divide into several item. For
KARAOKE disc one music corresponding to one
title.
Use the / / / and number button, to input the
corresponding title, chapter, same as the picture
showing:
NOTE:
(1).The program list will be cancel when the main unit is power off or eject
the disc.
(2).There is no program function for some disc.
(3).The unit can not play the list if you select the item that does not exit in
the disc.
9. Adjust the display angle
Press “ANGLE” button on panel. Screen angle will according to ADJ 1/ ADJ 2/ADJ 3/
ADJ4/ADJ0 to retract or slip out.
10. Working mode.
When the unit under power on mode, short-press “SRC” button on panel or press
“MODE” on remote control to switch the main unit display mode as below:
RADIO-DVD-AUX
11. Detachable panel
This product is designed for guard against theft safety, the panel can be
detached, press the " " button can take down the panel.
PR O G
PR O G
Play
Cl e ar
Exit
Play
Clear
Exit
Connect To Storage Accessories.
SD
SD ca rd
CONNECTTING WITH USB
1.Under power on mode，connector the USB, it will be play the USB.
2.It will display “USB READ ”, then play the file.
3.Pull out the USB when you want to stop playing.
If there are some file in the memory card that can't to play, please format the
external memory first ,then connect to the unit to read the file.
CONNECTTING WITH SD CARD
1.Under power on mode，connector the SD card, it will be play the SD card
2.It will display “USB READ ”, then play the file.
3.Pull out the SD card when you want to stop playing.
Note: Please take attention for the SD card using direction, the SD card
arrowhead will forward to the unit display side, then insert the card.

17 18
11
2
10 7
3 4
15
6
12 9
8 13 1 411
1. TFT/OFF: Close Screen
2. MUTE: Touch MUT icon to turn off the sound, press again to
resume to previous volume level.
3. BND: Select FM/AM wave band
5. APS: APS signal scan Touch APS icon, will auto search FM signal.
4/6. / : Channel increase/ reduce:
Adjust radio frequency, each plus / minus the frequency increase
or decrease.
7. LUD: LOUD information
Touch it to turn on/off the loud.
8. EQ sound effect
There are “POPULAR, CLASSICALITY, ROCK” three kind of sound
mode for circulate select, if going on will turn off EQ.
9. ST: STEREO
Press it to turn on or off.
10. : BACK TO MAIN MENU
11. Mode display
Mode display for reserve the RADIO frequency, press it to display
the channel, Hold on touching the icon, can reserve the current
frequency to relative position.
12/14. VOL+ /VOL-: volume button
13. SEL audio function
Audio adjust button. Press it to choose “VOL”“TRE”“BAS”“L/R”“F/R”,
then press”VOL-” “VOL+” to adjust that you need.
TOUCH SCREEN MENU AND OPERATION
Press “SRC” button on panel or “ MODE” on remote control to
choose function display pictures, the touch screen to enter the
main menu screen: see below picture
RADIO FUNCTION INTERFACE
After turn on the unit, will enter to RADIO mode automatically; Or press
RADIO icon on main menu or “SRC” on panel or “MODE” button on
remote control to switch RADIO function:
6
87.50
1
87.50
3
87.50
5
87.50
4
87.50
2
87.50
RADIO
Fm2
87.50MHZ
12:45AM
6
87.50
SEL
VOL
-
VOL
+
APSAPS
BNDBND LUDLUD EQEQ STST
TFTTFT
OFFOFF
MUTEMUTE
1 2 3 4 5678 9
14
13
12
10
11
1.RADIO:FM/AM radio mode
2.TV function mode
(optional function)
3.DVD mode
(have disk can be entering)
4.USB/SD:USB signal input mode,
on any mode inserted the USB/SD,
the system will automatically read
play. (Connect the USB/SD can be
to enter)
5.GPS: navigation mode
(optional function)
Touch screen "1,2,3,4,5,6,9,12" the center of the corresponding function,
the screen immediately enter to interface of your chosen functions mode. If
have connected signal source, there are clear picture for you to enjoy. Touch
the screen "7" point turn off the power; touch "8,10" point can enter the setup
menu to set product function and display; specific instructions, please refer
to the corresponding menu interface. Touch screen "11,13" point to adjust
the panel angle up or down to meet your visual requirements. Touch the "14"
point to eject the disc within disc storage.
Note: This product “ GPS” and “TV” functions are optional, and this unit does
not come with these functions. In this manual do not explain.
6.BLUE:BLUE TOOTH function
7. :POWER
8. :Enter to common menu
setting
9.AUX1:Video signal input mode
10. :Enter to MENU setting
11. :Panel angle upward
12. AUX2:Rear View Parking
Video Input
13. :Panel angle down
14. :Disc eject

19 20
TITLETITLE
NO L INKNO L INK
1
2
3
4
5
6
7
8
1. Dialing button: make and answer the phone.
2. pressing this button is the conversion of mobile patterns and bluetooth mode
under calling state
3. Delete button: touch the button can delete the already input number.
4. Match button: touch the button can send out bluetooth match information.
5. Hang up button: end the call or refuse the call.
6. Quit the bluetooth system.
7.0-#: number button
8. Status Information shows column.
1. Starting up and enter into the bluetooth system picture.
2. Open up the bluetooth equipment of the mobile phone can search this unit's
bluetooth equipment“CAR KIT”.Then match the bluetooth by presentation.
3. Input 4 figures pass code“0000”,this unit's bluetooth will be set up to the
authorized equipment of the mobile phone. If the match is successful the
of the bluetooth picture will show “LINK OK”
Tips: If it unable to match please starting up again. After setting up the unit to
authorized equipment, the bluetooth will connect or enter into mobile phone
bluetooth system automatically. Select “CAT KIT”to connect it.
4. After you match successfully you can make and answer the phone comfortably.
Under any system the calls will switch to bluetooth system automatically. It's
convenient for you to operate. Within the effective limits, this unit can also
transmit the music which is playing in the mobile phone. And can adjust the
voice through mobile phone. (Within the effective limits of 10 meters).
Cautions:
This unit can only match with one mobile phone equipment which has bluetooth
function.
The bluetooth function of this unit can only receive audio frequency information.
status
Operating instructions
Bluetooth function system DVD MODE MENU INTERFACE
Press “SRC” on panel or “MODE” on remote control to switch to DVD
menu; Or on main menu to touch DVD enter to DV mode:
1 : Back to main menu
2/3 / :Fast forward/Fast back
4 :Stop
5 :Play/Pause
6 OSD: Press it will display the disc
information
7 AUDIO: Press it to select the audio
language when the main unit is in
play mode for DVD disc
8/9/18/15: / / / Upward
/Downward/Left/Right
10 MENU
11/12 / :previous/Next
13 : Tools, Touch this item
enter to AUDIO/VIDEO menu
14/17/19 / / : Next
16 OK : sure
20 :Angle
21 :Repeat
22 TITLE
23 :Subtitles
24 NUM: Selections songs
25 :Zoom
CD MODE BASIC OPERATION
When you play the CD disc, will display CD disc and track display mode on
top of the DVD interface.
Note: When display the CD, the operation interface is the same as DVD operation.
You can through the “AUDIO”button on remote control to choose the audio effect;
And press “GOTO” button on remote control to choose the title and chapter display.
Note: On DVD display menu, some of simple function can use the touch panel to
operate, but some functions have to through remote control to operate. If there
are without disc inside, can't enter to DVD mode.
++
…………
AUDIOAUDIO
MENUMENU
NUMNUM
OSDOSD
OKOK
DVD
5
8
4
7
13
12
10
2
6
3
1
15
19
242221
18
20 23
17
16
14
11
9
25
……
+
Above / / / and "OK" functions only available on Some disc or Mp3/SD
playing. under CD/DVD display condition, touching screen left the default is the
former song or unit, right is the next

21 22
USB/SD Operation
When the machine is connect USB / SD, touch the main menu "USB/SD"
icon, the screen displays "SD" or "USB",and will auto read and display
the file. If under the playing mode, and insert the card, no need to choose
the any function, will auto get into the display mode.
When display USB or SD card, touch panel menu is the same as
DVD menu, also the same operation, Touch the DVD menu / / /
button move to the file bag, file,MP3 icon or JPEG icon.
After more cursor to the display bag, then press "OK" to ensure the
icon; The chosen file will be display by order.
After you choose the JPEG display, touch again the OK button to confirm
this picture, then touch again the number / / / button can change
the picture direction to up/down/left/right.
Note: While the USB/SD is playing, and if you eject the disc or slot-in the
disc, the display will pause for few second, this is normal situation.
After finish the disc operation will resume the display. pull out the USB/
SD when you want to stop playing
Key
56
1. File bag
4. JPEG Icon
3. Mp3 Icon
2. File
5. Video Icon Key 6. Menu Icon
SYS T EM MENU SE TUP
Press “ “ picture on main menu, on AUX mode, Click the screen will
enter to system menu setup:
1/2、VOL-/VOL+:
Volume adjust
3/4、TRE-/TRE+:
High volume balance
adjust
5/6、BAS-/BAS+:
Low volume balance adjust
7/8、 -/+:
Display picture brightness
adjust
9/10、 -/+:
Display picture contrast
adjust
11/12、R/F:
Rear/ Front audio
adjust
13/14、 -/+:
Display picture colorful
adjust
15/16、 -/+:
Display picture acutance
adjustment
17/18、L/R:
left / right audio adjust
19、DBAS:
Sub-woofer on /off
20、MBP:
Listen respectfully left/right on /
off
21、STD:
Standard video select
22、LOUD:
LOUD ON/OFF
23、 EQ: sound select
There are “POPULAR,
CLASSICALITY, ROCK” three
kind of sound mode, can through
EQto select or turn off EQ.
24、BACK:
Back (back to last step)
You can operate above function follow the instruction. When you choose
above “VOL” “TRE” “BAS” “R/F” “L/R”, through “SEL” button can adjust
it directly .
1
23
17
22
16
21
15
20
14
24
18
19
13
712
6
5114103928
SYSTEM MENU SETUP

23 24
1
91110 8
7
6
5
4
3
2
COMMON MENU SETUP
On main menu page, touch “ position can enter to currency menu setup:”
1、 : Exit menu
2、CLOCK SET: Touch “H” on panel and “ M”, then touch “+” “-“ to adjust the time.
3、RDS MODE: Wireless Data Broadcasting System to open or closed
(only in the English mode, it can be set).
4、REARVIEW CAMERA： Touch “left “ or “right” to set the position of your
rearview camera.
5、RADIO FREQ: FM area setup
It's convenient for your to use this product, we already setup five
RADIO area for your select, only through the touch screen text to choose the
position which you listen to.
6、OSD LANG: Language Setting: Chinese and English Display is included for
your choice.
7、MODE display picture: After choose the sub-menu, touch the relatively
items to setup.
8.Touch Screen Calibration
When the touch-screen functionality offset, click it into touch-screen
calibration. Or on DVD stop playing mode, use the remote control continuous
input "ZOOM / / " three keys may also enter the touch-screen calibration.
When entering touch function, follow the prompts click the "+" center, Until
succeed calibration then automatically exit
AUDIO/VIDEO MENU SETUP
Under DVD mode, touch “ ” button enter to “AUDIO/VIDEO”menu
setting interface:
Same as below picture1.2:
(Picture 1) Audio setting interface
1
6
5
4
3
2
7
Touch 8
191817 20
16
15
13
12
14
(Picture 2) Video setting interface
1. AUDIO: Audio mode. Touch this
function, the icon is concave, then
will enter to audio setting mode.
2. VIDEO MODE: Touch this function,
the picture is concave, then will
enter to video setting mode.
3. VOLUME ADJUST
Touch the “-” “+” function on the
screen, the volume will change.
4 BAS: Bourdon volume adjust
Touch the“-”“+”function on
the screen, the bourdon volume
will change.
5. TRE: Alt volume adjustment
Touch the“-”“+”function
on the screen, the alt volume will
change.
6. BAL: Left and right track
adjustment Touch the“-”“+”
function on the screen, the left
right track volume will change.
7. FAD: Front and Rear volume
adjustment Touch the“-”“+”
function on the screen, the front
and Rear volume will change.
8. LOUD
Touch here can turn on or turn
off the loud.
9. DBAS: Bourdon mode. Touch
here to enter to bourdon
display mode.
10. MBP: Listen position
Touch here to choose left or
right listen position.
11. EQ: Sound effect mode
Touch here to choose the
preset sound mode: popular,
rock, classicality.
12. BRI: Brightness
Touch the“-”“+”function
on the screen, to adjust the
picture brightness.
13. CON: Contrast. Touch the “-”
“+”function on the screen, to
adjust the picture contrast.
14. COL: Color. Touch the “-” “+”
function on the screen, to adjust
the picture color.
15. HUE: Hue. Touch the “-” “+”
function on the screen, to adjust
the picture hue.
16. STDY: STANDARD MODE
17. USER: USER-DEFINED MODE
18. BRIG: BRIGHTNESS
19. SOFT: SOFT
20. SHAR: SHARP

25 26
SYSTEM SETUP
TV SY ST EM
TV TY PE
PASSWORD
RATING
DEFAULT
NTS C
PAL
AUT O
SYSTEM SETUP
TV SY ST EM
TV TY PE
PASSWORD
RATING
DEFAULT
4:3PS
4:3LB
16:9
SYSTEM SETUP
TV SY ST EM
TV TY PE
PASSWORD
RATING
DEFAULT RESTORE
SYSTEM SETUP
TV SY ST EM
TV TY PE
PAS SW ORD
RATING
DEFAULT
3PG
6R
1KI D SA FE
4PG13
7NC-17
2G
5PG-R
8ADULT
SYSTEM SETUP
TV SY ST EM
TV TY PE
PASSWORD
RATING
DEFAULT
--------
DVD SYSTEM SETUP
1.SYSTEM SETUP
Under the DVD display mode, press the “SETUP” button on remote control,
can enter to DVD system menu setup. Press the “ / / / ” button on
remote control to move the cursor to setup the SYSTEM setup, LANGUAGE
SETUP, AUDIO SETUP, VIDEO SETUP, SPEAKER SETUP and DITIGAL
SETUP. Below is for the details menu for your reference:
LANGUAGE SETUP
OS D LA NG UA GE
AU DI O LA NG
SU BT IT LE L AN G
ME NU LANG
GERMAN
POR TU GUE SE
ENGLISH
SPANISH
CHINESE
FRENCH
LANGUAGE SETUP
OS D LA NG UA GE
AU DI O LA NG
SU BT IT LE L AN G
MENU LANG
GER MA N
PORTUGUESE
ENGLISH
SPANISH
CHINESE
FRE NC H
LANGUAGE SETUP
OS D LA NG UA GE
AU DI O LA NG
SU BT IT LE L AN G
ME NU L AN G
GERMAN
PORTUGUESE
ENGLISH
SPANISH
CHINESE
FRENCH
LANGUAGE SETUP
OS D LA NG UA GE
AU DI O LA NG
SU BT IT LE L AN G
ME NU L AN G
GERMAN
PORTUGUESE
ENGLISH
SPANISH
CHINESE
FRENCH
2.LANGUAGE SETUP
RENEW MANUAL
PASSWORD: this unit factory default have set password “0000”, if you need
,choose the password item to type it to breake lock. After open lock ,can choose
children lock to amend the grade, after amend then back to password to type 4
number password , press ensure button to lock again.
RATING: this function only fit to the DVD disc come with children lock grade.
Through it to control which kind of disc can read. Children lock limited grade
have seven level,
choose “no limited” to cancel the lock function. Factory default is no limited.
Note: If password have been locked, children lock setting will can't change.

27 28
3.AUDIO SETUP
4.VIDEO SETUP
+4
+6
+2
0
-2
-4
-6
VIDEO SETUP
BRIGHTESS
HUE
SATURATION
CONTRAST
SHARPNESS
12
10
8
6
4
2
0
VIDEO SETUP
BRIGHTESS
HUE
SATURATION
CONTRAST
SHARPNESS
12
10
8
6
4
2
0
VIDEO SETUP
BRIGHTESS
HUE
SAT UR ATI ON
CON TR AST
SHA RP NES S
12
10
8
6
4
2
0
VIDEO SETUP
BRIGHTESS
HUE
SATURATION
CONTRAST
SHARPNESS
AUDIO SETUP
AUD IO O UT
KEY
SPDIF/OFF
SPDIF/RAW
SPDIF/PCM
AUDIO SETUP
AUD IO O UT
KEY #
+4
+2
0
-2
-4
b
8
6
4
2
0
VIDEO SETUP
BRIGHTESS
HUE
SATURATION
CONTRAST
SHARPNESS
5.SPEAKER SETUP
6.DIGITAL SETUP
DIGITAL SETUP
OP MO DE
DUA L MO NO
DY NA MI C RA NG E
LIN E OU T
RF RE MO D
DIGITAL SETUP
OP MO DE
STE RE O
MON O L
MON O R
MIX M ON O
DUA L MO NO
DY NA MI C RA NG E
DIGITAL SETUP
OP MO DE
DUA L MO NO
DY NA MI C RA NG E FULL
6/8
4/8
2/8
OFF
In the speaker set menu “LT/RT” “STEPEO” “VSS” three submenu choices.

29 30
FUNCTION INDEX SIGN
WARNING:
1. In order to ensure the safe operation of the machine in the removing panel,
please wait for five seconds and then fasten panel.
2. To ensure the accurate of touch function, please touch the center point
of relative function.
3. There are build in anti-jamming system in touch screen, To prevent the
wrong position touch, please keep to touch this function for 0.5 second,
then the product will get respond for your instruction.
4. Please do not use the object, which is bigger than the function icon to
touch the screen. Otherwise the touch function will failure or give the
wrong operation to other function.
5. To ensure the panel safety, please don't press or use the sharp object
to touch the panel.
6. Don't play the severity scratch disc, otherwise will damage the DVD
play capability.
7. Be sure to distinguish the anode and the cathode when connecting the
power. If connect wrong, the fuse in filter box will melt immediately to
protect unit. Then please replace the same parameter fuse.
8. DC 12V should be best to connect with the power adapter to prevent
from the over-voltage drop the may influence the normal work of the
monitor.
FM Frequency range
MW Frequency range
S/N 30db
S/N Ratio
S/N Ratio
S/N Ratio
87.5～108.0MHZ
522～1620KHZ
15dBu
35dBu
50dBu
40dBu
80dBu
Video output scope
Max output power
75Ω
75Ω
4Ω60W*4CH
1+/-0.2V
≥600
FM
AM
AUDIO
VIDEO Video Hovizontal
Resolaton
Antenna resistance
Antenna resistance
Noise limit sensitivity
9. Keep this machine away from too hot, or under effect of moisture, dust
or oil smoke, avoid this machine from dropping or impacting, never
extrude or chafe this machine with sharp objects.
10. Dangerous high voltages are present inside the enclosure. Do not
open the cabinet, non-professionals can not disassemble unit.
11. Installation should be very tight and secure. Preventing the fallen unit
hurt people when moving on or a sudden brake.
Disc Notes.
5.3"
480xR.G.BX2 34
5°C~45°C
Wor king
temperatur e

31 32
ALARM
For your safety, driver are advised not to watch the display when driving.
It's prohibited in law of some countries when driving and operating to
watch displayer.
SIMPLE TROUBLE-SHOOTING GUIDE
Symptom Probable Cause Solution
Black Screen
1.No12 voltage
2.Brightness or contrast
ratio is too small
3.no high-voltage
1 .check the power is on or
connect rightly
2. check the A/V Cable
is loose or not
3. Increase the brightness
and contrast ratio
NO picture
1.No sources output
2.The video concentric plug
becomes loose
1.Check the output of VCD
or DVD
2.Replace with the A/Vcable
3.Ti ghten the Video input
cable
color picture
1 Video sources have
no output
2.Color ratio should be
re-adjust
1.check the video sources
2.Enter into the Menu to
re-adjust
With a little regular light
spots and color spots on
the screen or black
horizontal line in the
It is normal symptom in the
active matrix display
technology.
it is normal symptom in
view range with a little
regular light spots on
display screen.
Unclear picture
1.Poor quality of the
video sources
2.Bright &Contrast
1.Replace with the high
quality videodisc
2.Reset Bright &contrast.
The outer cover of the
monitor has been deformed
1.External temperature is
too high.
2.The power has not been
switched off for a long time.
1.The surround temperature
should not exceed to 0-60
degrees.
2.Tu rn off the power after
using the unit.
If your product fails, please follow the way of exclusion, if it is still
unresolved, please contact the professional or supplier.
