Griddle User Manual
Griddle
User Manual
Please read this manual before using.
1
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM

Griddle User Manual
TT Series Stainless Electric Griddle is designed by advantages of overseas products. They
have features of new style, reasonable structure, easy to operate, good warmer result and
saving energy. They form a complete producing system with YXD Series Electric Baking Oven,
BS Series Pillar Warmer Display Cabinet, EF Series Electric Fryer and HT Series Electric
Cooking Oven, with features of easy operation, reasonable distribution and occupy less space.
They are equipments for Chinese and Western food restaurant, Karaoke room and fast-food
restaurant.
I. Basic parameter
Model Name Voltage Power
Size of
vat
Dimension Note
TT-WE101 Griddle 220V~240V 3KW 550×350 550×430×230
Single temperature
controller
TT-WE102 Griddle 220V~240V
380V~415V 4.4KW 728×400 730×500×230 Double temperature controller
TT-WE106 Griddle/Grill 220V~240V
380V~415V 3KW 550×350 550×450×230
Single temperature
controller
TT-WE104 Griddle/Grill 220V~240V
380V~415V 4.4KW 728×400 730×500×230
Double temperature
controller
TT-WE1283 Griddle 220V~240V 6KW 700×400 760×600×350
Double temperature
controller
TT-WE1284 Griddle/Grill 220V~240V 6KW 700×400 760×600×350
Double temperature
controller
II. Instruction
Double temperature controllers are besides two sides of the machine and they can be used
alone. The left one can control the temperature of the left vat; the right one can control the
temperature of the right one.
Shut on the power switch K1, the green indicator is on, at that time electricity reaches to the
machine. Rotate the temperature controller clockwise to the red point, at that time the yellow
indicator is on and the green indicator is off. The green indicator is on and the electric heating
tube works again and the temperature goes up again. It repeats again and again to make sure
temperature is constant in the setting range.
According to different food and adjust the needed temperature to get the deal result of making
food.
III. Troubleshooting
Trouble
Cause
Resolution
1. Shut on power switch
K1, the indicator is not
on.
1. Fuse of power switch is burned.
2. The connection of power cord is not well.
1. Replace a suitable fuse.
2. Firm power cord.
2. Yellow indicator is not
off. The ascend of
temperature cannot be
controlled.
1. The connection of indicator is wrong.
2. Temperature controller is out of action.
1. Correct it with right
connection.
2.
Replace temperature
controller.
3. Indicator is not on, but
temperature control is
normal.
1. The contact of indicator is not well.
2. Indicator is burned.
1. Firm connection.
2. Replace indicator.
2
NO.18 - 105, HUAGANG GARDEN, ZHONGSHAN AVENUE, GUANGZHOU, CHINA
T: 86-20-38768241 | F: 86-20-38769376 | WWW.TWOTHOUSANDCO.COM

Griddle User Manual
IV. Attention for installation
The using voltage of the machine must be coordinated with the supplied voltage.
User should install a suitable power switch or air switch.
There is a grounding screw behind this oven. The grounding blot should be connected with
more than 2.5square mm copper wire according to safety rules for safety sake.
Before using this product, please check all parts and power supply and ground connection.
The shell of this machine must be grounded well for safety sake!
V. Circuit diagram
S－TEMPERATURE CONTROLLER; S1－TEMPERATURE LIMITER; EH－HEATING TUBE; HL1－POWER
INDICATOR (GN); HL2－HEATING INDICATOR (YE); KM－AC CONTACTOR;E－GROUND PROTECTION
TT-WE1283 TT-WE101 TT-WE102
TT-WE106 TT-WE104
TT-WE1284
