Tysso Fixed Mount CCD Barcode Scanner User manual

Fixed Mount CCD Barcode
Scanner - User Manual

Fixed Mount CCD Barcode Scanner - User Manual
2 | P a g e
Introduction
This CCD Bar Code scanner module is well designed with high quality components.
The improved digitizer provides very accurate barcode scanning signal to decoders.
With different scanning ranges, It’s ideal to meet the application requirement.
Because it has the compact and small dimensions, integrating this module to most of
housings is a easy job. It simplifies the development process and can save developing
time. The TTL output allows the scanner module to be universally accepted by most
decoders.
The built-in decoder is an advanced and versatile decoding facility for bar coding
systems. It works with variety of bar code types and computer interfaces.
• Compact Size
Convenient fit in most of housing
• Single 5 Volts Power Supply
Simplified connection to one input power source
•RS232 Signal Output with decoded signal
Optical Characteristic
Light Source 660nm
Sensor
CCD Sensor with 2048 pixels
PCS Up to 0.45
Scan Rate 100 scans / sec.
Ambient Light 2000 Lux max. (Fluorescent)
Depth of Field 4” (100mm) for 20 mil (0.50mm)
barcode
Resolution 4 mil (0.1mm)

Fixed Mount CCD Barcode Scanner - User Manual
3 | P a g e
Electrical Characteristics
Supply Voltage
DC +5V
+
5%
Output Voltage (Typ.) +5V
Output Voltage (Min.) 4.5V
Logic High Space/Bar (Optional)
Logic Low Bar/Space (Optional)
Power Consumption
Stand by (Max.) 40mA
Operation (Max.) 140mA
Power Enable Control Active High
Timing Diagram

Fixed Mount CCD Barcode Scanner - User Manual
4 | P a g e
Physical Characteristics
Weight: 33g Material: PC + Fiber
Dimension: Unit:mm

Fixed Mount CCD Barcode Scanner - User Manual
5 | P a g e
Environment
Operating Temperature 0°C to 45°C
Storage Temperature -20°C to 60°C
Relative Humidity 20% to 85% (Mon-condensing)
Shock 1 meter drop on Concrete Surface
Performance
Scan Rate 100 scans / sec (signal directional)
Width of Field 47.5 mm + 0.59
╳ (Distance to CD-
610 ) mm
Depth of Field 4 inch (100mm)
Resolution 4mil (0.1mm)
PCS PCS 0.45
Reading Angle Test Conditions: Code 39, 10mil,
PCS0.9
Forward
+ 30 Degree
Up & Down
+ 45 Degree
Left & Right
+
40 Degree
Dead Zone Up & Down 8 Degree
Pin Assignment
PCB Connector Type: JST Pitch 1.25mm 10 Pins connector
Pin No.
Function
1 RTS
2
CTS
3 TXD
4 GND
5
PCDATA
6 PCCLK1
7 VCE
8 KBCLK
9
KBDATA
10 RXD

Fixed Mount CCD Barcode Scanner - User Manual
6 | P a g e
Decode Zone
Test Conditions: Code 39 PCS 0.9

Fixed Mount CCD Barcode Scanner - User Manual
| P a g e
More Information
- Decoded symbologies;
Code 39, Code 32, Interleaved 2 of 5, Industrial 2 of 5, IATA , Matrix 2 of 5, China postage, Code 128,
Code 11, Code 93, MSI-PLESSY, Codebar/NW7, Code 4, EAN-13/JAN-13, UPC-A, EAN-8/JAN-8,
ISBN/ISSN
- Scan mode: Trigger modes, Continous modes
- Programming: By user’s manual or by software via RS-232 or keyboard
- Host control: By providing trigger commands
- Support Remote programming by Computer Host via Serial Cable
Manufacturer
2F, No. 165, Sec. 2, Ta-Tung Rd.,
Hsi-Chih 221, Taipei Hsien, Taiwan
Tel : [phone]
Fax: [phone]
E-Mail: [e-mail]
FAMETECH INC.
URL: http://www.fametech.com.tw
