U-Line Echelon 2075DWRRSS User manual

INTRODUCTION
Congratulations on your purchase of your U-Line drawer unit. A pioneer in
the field for more than 40 years, U-Line is the world’s number one man-
ufacturer of built-in, under-counter ice making and specialty refrigeration
products. U-Line dedicates 100% of its research and development to
these products. The result: U-Line technology leads the market with inno-
vation, design, depth of product line and performance.
U-Line also backs customers with a strong dealer network.
U-Line’s commitment to quality even extends to environmentally safe
packaging. U-Line products are making life more convenient in homes,
businesses, and hotels around the world.
PLEASE READ all instructions completely before attempting
to install or operate the unit.
The icons 2075DWRR refrigerator unit, CO2075DWR
refrigerator/ice maker combination and 2075DWRWC Wine
Captain
®
drawer units are used throughout this manual to help you identify the
specifics to your U-Line product. Once you have your unit installed, we suggest
you keep this manual in a safe place for future reference. Should any prob-
lems occur, refer to the TROUBLESHOOTING section of this manual. This
information will help you quickly identify a problem and get it remedied. In the
event you require assistance, please contact the dealer where you purchased
your unit.
1

PLEASE RECORD YOUR MODEL’S INFORMATION
Whenever you call to request information or service, you will need to
know your model number and serial number. You can find this informa-
tion on the serial plate located on the inside wall of your unit and on the
product registration card.
PRODUCT REGISTRATION CARD
The package containing this manual also includes your product registra-
tion information. Warranty coverage begins at the time your unit was
purchased.
NOTE
Complete and mail the Product Registration Card as soon as
possible to validate the registration date. You may also reg-
ister the product online at www.U-LineService.com.
If you do not return your Product Registration Card, U-Line will use the
date of sale to the U-Line distributor as the first date of
warranty for your unit. Please also record the purchase date of your U-
Line unit and your dealer’s name, address and telephone number.
Model Number: ______________________________________
Serial Number: ______________________________________
Purchase Date: ______________________________________
Dealer Name: ______________________________________
Dealer Address: ______________________________________
Dealer Telephone: ______________________________________
Keep this manual and the sales receipt together in a safe place for further
reference.
User’s Manual
2

TABLE OF CONTENTS
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
LEVELING THE UNIT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
CONNECTING THE WATER SUPPLY . . . . . . . . . . . . . . . . . . . . . .11
BUILT-IN INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
CUSTOM DRAWER PANELS . . . . . . . . . . . . . . . . . . . . . . . . . .14
INITIAL START-UP AND ADJUSTING THE
TEMPERATURE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
TEMPERATURE CONTROLLER . . . . . . . . . . . . . . . . . . . . .23
TEMPERATURE CONTROLLER . . . . . . . . . . . . . . . . . . . . .24
TEMPERATURE CONTROLLER . . . . . . . . . . . . . . . . . . . . .26
OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
ICE MAKER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
CLEANING & MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . .38
STAINLESS STEEL MODELS . . . . . . . . . . . . . . . . . . . . . . . . .38
STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . .43
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . .44
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . .45
IF SERVICE IS REQUIRED . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
3

User’s Manual
SAFETY PRECAUTIONS
Do not attempt to install or operate your unit until you have read the safe-
ty precautions in this manual. Safety items throughout this manual are
labeled with a Danger, Warning or Caution based on the risk type.
DEFINITIONS
This is the safety alert symbol. It is used to alert you to poten-
tial personal injury hazards. Obey all safety messages that fol-
low this symbol to avoid possible injury or death.
DANGER indicates an imminently hazardous situation which,
if not avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation which,
if not avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation which, if
not avoided, may result in minor or moderate injury.
CAUTION
CAUTION used without the safety alert symbol indicates a
potentially hazardous situation which, if not avoided, may
result in property damage.
Indicates installation, operation or mainenance information
which is important but not hazard related.
CAUTION
!
!WARNING
DANGER
! !
!
4

GENERAL PRECAUTIONS
RISK OF CHILD ENTRAPMENT. Before you throw away your
old refrigerator or freezer, take off the doors and leave
shelves in place so that children may not easily climb inside.
•Never attempt to repair or perform maintenance on the
unit until the electricity has been disconnected.
•Altering, cutting of power cord, removal of power cord,
removal of power plug, or direct wiring can cause serious
injury, fire and/or loss of property and/or life and will void
the warranty.
•The anti-tip kit must be installed on this unit before it is
used. Never use the drawers as steps or a shelf to sup-
port more than the drawers’ content.
CAUTION
•Do not lift unit by drawer’s handle.
•Use care when moving the unit. Some edges are sharp and
may cause personal injury. Wear gloves when moving or
repositioning the unit.
•Allow unit temperature to stabilize for 24 hours before use.
•Failure to clean the condenser every three months can
cause the unit to malfunction. This could void the warranty.
•Never install the unit behind closed doors. Be sure front
grille is free of obstruction. Obstructing free air flow can
cause the unit to malfunction, and may void the warranty.
CAUTION
•Use only genuine U-Line replacement parts. Imitation parts
can damage the unit, and may void the warranty.
!WARNING
DANGER
! !
5

User’s Manual
INSTALLATION
SITE PREPARATION
Your U-Line drawer unit must be installed under a counter or in a wall.
These units are designed so they can be installed next to a wall. The
crisper in the and the caddy in the can be accessed from
either side.
1. Position the unit on a flat, level surface, capable of supporting the
entire weight of the unit. Remember the unit will be significantly
heavier once it is fully loaded.
2. This unit requires grounded and polarized 115 VAC, 60Hz, 15A cir-
cuit (normal household current).
ELECTROCUTION HAZARD!
Electrical Grounding Required. This appliance
is equipped with a three prong (grounding)
polarized plug for your protection against pos-
sible shock hazards.
•NEVER remove the round grounding prong from the plug.
•NEVER use a two-prong grounding adapter.
•NEVER use an extension cord to connect power to the
unit.
Where a two-prong wall receptacle is encountered or a
longer power cord is required, contact a qualified electrician
to have it replaced in accordance with applicable electrical
codes.
DANGER
! !
66

Your U-Line Drawer unit is designed so it can be installed next to the wall
on either side (Figures 1, 2).
Figure 1 – Right wall installation
The anti-tip kit must be installed on this unit before it is used.
Never use the drawers as steps or a shelf to support more
than the drawers’ content.
3. These units must be installed in a wall or under a counter top to
allow for the installation of the anti-tip kit. The drawer unit can be
installed with an appliance or fixture located in front of it, as long as
there is adequate clearance for the drawer to be opened and
removed when servicing (Figure 3).
U-Line recommends you consider additional clearance in front of the
open drawer for convenience.
!WARNING
DWR001A
7

8
User’s Manual
Figure 2 – Left wall installation
Figure 3 – Front Clearance
DWR003A
CAB I N ET
O
R W A LL
DWR002A

4. – Connect the water supply line. See CONNECTING THE
WATER SUPPLY for installation requirements.
5. Position the unit to allow free air flow through the front grille
(Figure 4).
Figure 4
6. Wipe inside of unit and all inside drawer components with a clean,
water dampened cloth only.
LEVELING THE UNIT
It is important that the unit is level. All Échelon™ Series units are
equipped with adjustable feet for leveling and height adjustment
(Figure 5).
To level the unit:
1. Adjust all four leveling feet evenly so that the top of the cabinet is at
the desired installation height.
2. Using a level of at least two feet in length, measure the level of the
floor where the unit is to be installed. Measure back-to-front and
side-to-side and note the measurements.
3. With the unit on a level surface, adjust the feet, as appropriate, to
compensate for the floor level measurements noted in Step 2.
OFF
ON
DWR004
INTAKE EXHAUST
9

10
User’s Manual
4. Place the unit in position where it is to be installed. Re-check cabi-
net height and levelness (Figure 6) and adjust if necessary.
Figure 5
Figure 6
5. - Gently push unit into position to prepare for built-in
installation.
DWR021
LEVEL
TWO PLACES
DWR005
RAISE LOWER
10

11
CONNECTING THE WATER SUPPLY
Install a 1/4 inch outside diameter copper water line (not
supplied with unit) from the nearest COLD water pipe. When
connecting the water supply, follow these guidelines:
•Review the local plumbing codes before you install the unit.
•In most instances, the cold water supply will come from the base-
ment through a hole in the floor.
•The water pressure should be between 15 and 150 psi.
•Install a shut-off valve in the 1/4 inch outside diameter supply line
(not supplied with unit).
•Connect sufficient tubing to the unit to allow the unit to be moved
for cleaning and servicing. However, make certain that the tubing
is not pinched or damaged during installation.
•U-Line recommends the use of copper tubing for installation.
1. Locate the compression fitting
and ferrule packed in the unit.
Slide the compression fitting
and ferrule over the 1/4 inch
outside diameter water supply
line. Do not use thread seal-
ing compound or tape. Using
two wrenches, tighten the
compression fitting on the
supply line (see Figure 7). Do
not overtighten.
Figure 7
UL134_CO
2. Carefully bend the water supply
line into position and connect
the line to the solenoid valve
(see Figure 8). Avoid kinking
the water supply line.
Figure 8
UL103_CO
WATER
CONNECTION

12
User’s Manual
12
3. For recessed installations,
allow extra water supply line
length to provide slack for easy
removal from the recessed
area (see Figure 9). This will
also safeguard against kinking
the line.
Figure 9
CAUTION
If you are not intending to use
the ice maker and do not con-
nect the water supply (or turn
the supply valve off), it is
imperative to raise the bucket
arm of the ice maker (see
Figure 10). Failure to raise the
bucket arm may result in
damage to the water valve.
Figure 10
NOTE
After completing the installation, turn on the water and
recheck water connection for leaks. Apply additional tighten-
ing if needed. Do not use thread sealing compound or tape.
4. Plug in the power cord.
5. Gently push the unit into position to prepare for built-in installation.
UL002A_CO
DWR033

13
BUILT-IN INSTALLATION
Your U-Line product is designed for built-in installation only. When built-in,
it does not require additional air space for the top, sides, or rear.
However, the front grille must NOT be obstructed.
NOTE
Required for ease of installation and door opening, you must
allow an additional 1/4"to width of unit.
Unit Dimensions
* For full overlay drawer panels, add 3/4".
NOTE
The additional depth required for full overlay drawer panels only
applies to the and . The is not designed
to accept full overlay drawer panels.
Once the unit is leveled and placed into the wall or under a
cabinet, it is ready to be secured to the wall or cabinet with the anti-tip
system (Figure 11).
Follow the instructions included with the anti-tip kit.
The anti-tip kit must be installed on this unit before it is used.
Never use the drawers as steps or a shelf to support more
than the drawers’ content.
!WARNING
Width Height Depth*
23-15/16" 34-1/8" 24"

14
User’s Manual
Figure 11
CUSTOM DRAWER PANELS
NOTE
The is not designed to accept custom drawer panels.
Two types of custom drawer panels can be installed on
your U-Line unit to harmonize with or accent the
surrounding decor.
FULL OVERLAY DRAWER PANEL
Full overlay drawer panels completely cover the drawer frames and han-
dle to give a built-in appearance. See Table 1 for full overlay drawer panel
dimensions (Figure 15, see page 15).
Table 1. Full Overlay Panel Dimensions
A1B2C1
Top panel with 1/2"gap 11-13/16" 14-3/4" 1"
between drawers
All bottom panels 11-13/16" 14-3/4" 1"
1Screw hole location
2Overall panel height
COUNTER TOP
OR WALL HEADER
ATK001a
C
C
B
A

15
OVERLAY PANEL KIT PARTS
•The total weight of both drawer panels must not weigh
more than 20 lbs.
•The thickness of the drawer panel must be 3/4".
Remove existing drawer front from cabinet:
1. Open drawer. Pull door gasket
(Figure 12) out of the groove (top
edge of door only). Start in the mid-
dle and pull outward, moving
toward the edge. This may take
some force.
2. Remove the two screws located on
both sides of the lower handle.
Remove the handle (Figure 13).
3. Slide the existing drawer panel and
cardboard spacer out of the
drawer frame. Discard the spacer.
Attaching the full overlay panel:
4. If required, attach optional cabinet
handle hardware to the overlay panel
at this time. If an optional cabinet
handle is installed, make sure the
mounting screw heads are counter-
sunk.
Part Number Description Quantity
42120 Spacer Nylon 3/8 OD x .19 ID 10
42121 Screw #10 x 5/8 Round Head 10
GASKET
SCREW
HANDLE
DWR_OL_00
1
Figure 13
DWR_OL_002
Figure 12

16
User’s Manual
16
5. On a clean surface, place the wood panel face down and tape the
existing drawer panel (removed in step 3) on the back of the wood
panel (Figure 14) and drill the five (5) holes (5/32" drill 3/8" deep)
through the coated steel panel and 3/8" into the wood panel
according to the diagram (Figure 15). Remove tape from the draw-
er panel, and enlarge the five holes in the front panel using a .0201"
drill (#7) drill.
Figure 14
Figure 15
DOOR PANEL
BOTTOM OF
WOOD PANEL
BACK OF
WOOD PANEL
SIDE OF
WOOD PANEL
TAPE
11/32" BOTTOM 3/8" BOTH SIDES
DWR_OL_003
B
1"
1"
C
A
TOP OF WOOD PANEL
5/32" X 3/8" DEEP
5 PLACES
VINYL COATED
STEEL PANEL
23-3/4"
11-7/8"
DWR_OL_004b

17
6. Attach the drawer panel to the wood panel using #10 x 5/8"
(U-Line P/N 42121) wood screws and nylon spacers (U-Line P/N
42120). The nylon spacers fit between the wood panel and the draw-
er panel as shown (Figure 16).
Figure 16
Drawer panel and wood panel must be aligned properly or
drawer will not operate correctly.
Assembling the drawer and wood panel:
7. Install the overlay panel by sliding the drawer panel back into the
drawer frame.
8. Replace the handle assembly and secure with the two screws
removed in Step 2.
9. Starting at the corners and working toward the center, push the
drawer gasket back into place.
TYPICAL
WOOD
PANEL
PLASTIC SPACER
FIVE REQUIRED
#10 X 5/8" ROUND
HEAD SCREW
FIVE REQUIRED
DRAWER PANEL
DWR_OL_005

18
User’s Manual
CUSTOM INSERT DRAWER PANEL
Custom drawer panels can be inserted into the drawer frames to match the
surrounding decor. Custom drawer panels
can be flat or raised, as long as the
maximum panel thickness where inserted
into the drawer reveal (channel) is 1/4"
thick. For raised panels, the depth of
the reveal is 1/4" on all four sides. See
Table 2 for custom drawer panel insert
dimensions (Figure 17).
Table 2. Custom Insert Drawer
Panel Dimensions
The total weight of both drawer panels or panel inserts
must not weigh more than 20 lbs.
DRAWER HANDLE OPTIONS
Black drawer models come from the factory, equipped to
be used with full overlay drawer panels. Please refer to
your user’s manual for instructions on preparing and
installing the full overlay drawer panels.
For all applications where full overlay drawer panels are
not used (examples are: custom 1/4 inch panel inserts,
or no panel at all - standard black finish), replacement
drawer handles MUST be installed on each drawer. The
part number is 11926-4-BLK and can be purchased from
your U-Line dealer.
AB
12-15/16" 23-1/32" Figure 17

19
Install the custom insert as follows:
Insert edges may be SHARP! Use care when installing.
1. Open drawer. Pull drawer gas-
ket out of groove (top edge of
drawer only). Start in the mid-
dle and pull outward, moving
toward the edge (Figure 18).
This may take some force, be
careful.
2. Remove the three screws
behind the gasket. Carefully pull
the top handle up and off. You
may discard the top handle as
it will be replaced with the full
handle.
3. Remove the two outside
screws and the lower handle
(Figure 19).
4. Remove existing panel and
cardboard spacer. The panel
and spacer are no longer
needed and may be discarded.
!WARNING
Figure 18
FULL HANDLE
STANDARD
HANDLE
Figure 19
DWR020
FULL HANDLE SHOWN

User’s Manual
20
5. Slide custom drawer panel insert into 1/4" channel in drawer front.
6. Attach the full handle to the lower handle using the 3 screws
removed in step 2.
7. Holding drawer gasket out of the way, replace handle on drawer mak-
ing sure it is seated properly on insert and that screw holes line up.
8. Install two screws removed in step 3.
9. Starting at the corners and working inward, push drawer gasket into
place on the drawer.
WOOD TRIM ON WINE RACKS (WINE CAPTAIN®)
Your is equipped with a natural wood trim on the wine racks
and the wine caddy for appearance and durability. The wood trim has
been coated at the factory with a clear vinyl sealer, which will ade-
quately protect the wood in normal usage.
To prevent permanent damage to the inner liner of your
Wine Captain
®
, the wine rack wood trim MUST be
removed from the unit for staining and/or finishing. Allow
stain/finish to dry thoroughly (at least 24 hours per coat)
in accordance with the stain/finish manufacturer’s
instructions prior to re-installing the wood trim inside the
cabinet of the Wine Captain
®
. Failure to do so may cause
the inner liner of the unit to have a permanent odor, which
is not covered by the warranty.
You have 3 options regarding the wood trim on the wine racks.
(1) You can leave as is, (2) add a final finish coat or (3) you may
stain the wood trim. The final finish coat was not applied at the facto-
ry so that the wood trim could be stained. YOU CANNOT STAIN
THE WOOD TRIM ONCE YOU APPLY THE FINAL FINISH. Review
the following guidelines when staining and or sealing the wood to
ensure proper adhesion and durability of the finish.
!WARNING
