U-Line Echelon Combo C2275DWR User manual

F
eatures Benefits
&
8900 North 55th Street • Milwaukee, Wisconsin 53223 • Phone: [phone] • Fax: [phone]
www.u-line.com
COMBO DRAWER
REFRIGERATOR/FREEZER/ICE
MAKER MODEL C2275DWR
Capacity: 3 cu. ft (refrigerator)/2 cu. ft (freezer)/
up to 6 lbs daily ice production and 10 lbs ice storage
Defrost Type: Frost-free
Colors: Stainless Steel, Overlay
Feature Benefit
Standard 24" width with two
drawers
Can be installed into a standard 24"-wide cabinet opening
Touch Control Digital
Technology
• Full-featured, easy-view command center - right at your
fingertips
• Easy to set and see the refrigerator temperature
• Manages key model functions and provides user alerts
Patented frost-free technology • Top drawer is dedicated to refrigeration, with exclusive
organizational features.
• Lower drawer is equipped with an ice maker and provides
frozen food storage.
Daily ice rate of up to 6 lbs Removable ice bucket stores up to 10 lbs of ice.
No drain required • Easy and inexpensive to install
• Only requires a 1/4" outside diameter water line for the
ice maker
Multiple organizing features:
- Adjustable “Slide and Divide”
- Clear organizing bin in top
drawer
- Located in refrigerator (top) drawer. Provides the ability to
“divide” the drawer for item storage.
- Holds wine, 2-liter bottles and other items. Slides back and
forth, allowing easy access to items located beneath the
“organizing bin.”
Stainless steel refrigerator
drawer interior
• Sleek designer appearance in the top refrigerator drawer
• Corrosion resistant
Built-in • Provides a custom look
• No additional clearance around sides, top or rear for
ventilation. Do not obstruct the front grille.
Black liner Elegant visual appearance
Stainless steel • Offers a full wrap stainless steel drawer front, a curved
sculpted stainless handle, a stainless-like grille and a black
cabinet
• Optional bold commercial-style stainless steel handle
available for purchase
Overlay model • 3/4" full overlay drawer panel capability is standard
• Provides a fully integrated appearance with surrounding
décor
• For a 1/4" drawer panel, one must order replacement
drawer handles for EACH drawer (part # 26070-01-S).
Heavy-duty, full extension
drawer slides
Allow easy accessibility to contents in the back of drawers
Vinyl-clad cabinet • Black vinyl cabinet on all models provides a rich, textured
look
• More resistant to scratching, peeling or flaking
Recessed interior lights Automatically illuminates when the door is opened
Leveling legs More precise undercounter fit, durable, factory-installed
Sabbath or “Black Out” mode Easily turn off all lights and control displays
Contemporary grille design Integrates seamlessly with surrounding cabinets

Dimensions Specifications
&
8900 North 55th Street • Milwaukee, Wisconsin 53223
Phone: [phone] • Fax: [phone] • www.u-line.com
July 2007 © 2007 U-Line Corporation Printed In U.S.A.
Combo Drawer Refrigerator/Freezer/Ice Maker Model C2275DWR
Specifications Capacities
(1) Amps pertain to a 110/115 volt, 60 Hz electrical environment.
Anchoring device included and is required for all installations.
Please visit www.U-Line.com for Installation Guide.
All specifications subject to change without notice.
C2275DWR
C2275DWR
(Stainless Steel)
23-15/16
(60.8)
3/4" WOOD PANEL
SUPPLIED BY
CUSTOMER
*WATER
VALVE
*POWER
CORD 14-3/4
(37.5)
5-7/8
(14.9)
2-7/8
(7.3)
34-1/8
(86.7)
FULL
RETRACT
HEIGHT
35-1/8
(89.2)
FULL
EXTEND
HEIGHT
3-3/8
(8.6)
24-7/16
(62.1) WITH 3/4"
OVERLAY FRAME
23-11/16
(60.2)
21-7/16
(54.5)
26-3/16
(66.5)
23-3/4
(60.3)
21-7/16
(54.5)
*WATER INLET VALVE
*ON BACK OF UNIT INCHES (CENTIMETERS)
Shipping Weight:
Overlay Models
Stainless Steel Models
156 lbs (71 kg)
164 lbs (74 kg)
(1) Running Amps 2.5
(1) Maximum Start-up Amps 26.5
Refrigerator volume 3 cubic feet
Freezer volume 2 cubic feet
Approximate daily ice production Up to 6 lbs
Ice storage Up to 10 lbs
