U.S. Solid USS-LD00001 User manual

For questions or concerns, e-mail [e-mail], visit www.ussolid.com, or
call [phone]
Automatic Label Dispenser
This manual should be made available to all users of this
equipment. For best results and for maximum durability of
the equipment, carefully read and follow all instructions.

I. Gar I. Product Specifications
Brand
U.S. Solid
Model
USS-LD00001
Display
6 digit LED
Applicable Label Width
6 - 140 mm (0.24 to 5.51 inches)
Applicable Label Length
4 - 200 mm (0.16 to 7.87 inches)
Core Diameter
25 - 75 mm (1 to 3 inches)
Max. Roll Diameter
250 mm (9.84 inches)
Power Supply
AC110V, 60Hz
I. Gar II. Machine Introduction
Counter
Length Knob
Speed Knob
Power On/Off
Core Insert
Hanger Shaft
Label Guide
U pin
Rewinder Shaft
Sensor
Sensor Bracket
Press Plate
Dispensing Plate
Rubber Washer

For questions or concerns, e-mail [e-mail], visit www.ussolid.com, or
call [phone]
I. Gar III. Operating Instructions
1. Mount the Hanger Shaft onto the machine.
2. Install one Core Insert onto the Hanger Shaft, and then install the
label roll onto the Core Insert with the labels facing out.
3. Install the white Rubber Washer so that it holds the Core Insert
against the roll.
4. Pull the leading edge of the label paper under the Label Guide,
through the Press Plate, around the Dispensing Plate and down
towards the Rewinder Shaft. Then, grip the label paper end into the
groove on the Rewinder Shaft and fix the end with the U Pin. Make
sure the paper is fairly straight. (See the attached picture.)
5. Gently adjust the position of the black rubber on the Label Guide rod.
Note that it is important to exercise care on this step; too much
force may cause the label to tear.
6. Point the sensor towards the desired label stop position. You can
either pivot the sensor on the shaft, or rotate the metal bracket, or
both.

7. Turn the Power Switch to “On”.
8. Adjust the Speed and Length Knobs until the desired settings of the
label feed are achieved.
. Gar IV. Applications .
This machine is suitable for self-adhesive labels, barcode labels, security
labels, packaging labels, anti-counterfeit labels, hot stamping stickers,
stickers, printing patterns, chrome paper, and many more!
. Gar V. Pack List .
1 – Automatic Label Dispenser
1 – Power Cable
1 – User Manual
Gar VI. Warranty
The machine’s motor and circuit board have a 1 year warranty. This
warranty covers any defects in material or workmanship under normal
use.
Within 30 days of delivery, U.S. Solid will either work with you to repair
your product with replacement parts, replace the product after receiving
the returned defective machine, or accept a returned defective machine for
a full refund.
After the first 30 days but still within the first 1 year of delivery, U.S. Solid
will send new or refurbished replacement parts at no charge so you can
repair the product on your own.
