UBC BEST Operating instructions

Operating and Maintenance Manual
Chest Freezers

1
Table of Content
General information……………………………2
Destination of the operating manual ................... 2
Part 1. Specifications
and completeness of sets ................................... 3
Specifications of chest freezers ………………..4
Part 2. Technical details
and maintenance ............................................... 5
2.1. Operating temperature range ....................... 5
2.2. Unpacking .................................................... 5
2.3. Placement and installation ........................... 6
2.4. Commissioning ........................................... 7
2.5. Temperature parameters ............................. 8
2.6. Tips and remarks ......................................... 8
2.7. Safety rules ...................................................... 9
2.8. Safety requirements .................................. 10
Part 3. Cleaning and servicing ............................. 13
3.1. General points ............................................ 13
3.2. Defrosting .................................................. 13
3.3. Refrigerator cleaning ................................. 15
3.4. Storage and transportation ......................... 16
3.5. Storage without packaging ........................ 16
3.6. Disposal Information……………………..16
Part 4. Typical malfunctions
and troubleshooting ........................................ 18
Part 5. Warranty Liability ................................... 21
Service center addresses ................................... 33

2
General information
Destination of the operating manual
This manual is intended to familiarize you with the device, the
principle of operation, the peculiarities of operation, including the
rules of installation, switching on, loading with the device,
maintenance and repair of chest freezer during the whole period of
its operation. The equipment service life is 5 years.
The operation manual uses symbols, the meaning and
explanation of which are given in the table:
Symbol Meaning Explanatio
n
Recommendations The user should pay attention and act
as recommended to ensure proper
operation of the equipment.
Warnings The user should pay attention and act
according to the instructions to avoid
damage to the equipment and to
comply with safety regulations.
When purchasing a chest freezer, check its performance, completeness, no mechanical
damage, the presence in the documentation of the sale date, the seller's signature, and
stamped.Keep the user's manual for the entire period of use of the chest freezer.
Compliance requirements
Products comply with standards
EN 60335-2-24:2010/А1:2019/А2:2019/А11:2020,
EN60335-1:2012/A11:2014/A13:2017/A14:2019/A2:2019,
EN60335-2-89:2010/A1:2016/А2:2017
EN61000-3-2:2014, EN 61000-3-3:2013,
EN 61000-6-1:2007, EN 61000-6-3:2007/А1:2011/АС:2012
and Council Directive ЕС 2014/35/ЕС and 2014/30/ЕС.

3
Part 1: Specifications and completeness
of sets
The chest freezer is a device that is designed for
storing frozen food. The general view of the chest
freezer is shown in the picture. Please refer to the
instruction manual for brief specifications of the chest
freezer.
The following items are included in the scope of delivery:
Supply set
Unit of measurement
BEST
FREEZE
PRIMA
NIX MAGNIT
VICTORY
BEST FLAT
FREEZE FLAT
PRIMA FLAT
NIX FLAT
MAGNIT FLAT
VICTORY FLAT
BEST SOLID
FREEZE SOLID
PRIMA SOLID
NIX SOLID
VICTORY SOLID
ROCK
MAGNA
Chest freezer
User's manual
Baskets* 4 5 4 5
Casters
Package
Mechanical lock kit
Supply set
Unit of measurement
STAR
AURORA
STORM
LEGEND
KING
CYLINDER -50
EXPERT 150 FLAT EXPERT 250 FLAT EXPERT 350 FLAT EXPERT 500 FLAT EXPERT 550 FLAT EXPERT 600 FLAT
EXPER T 1 50 B LIND EXPER T 2 50 B LIND EXPER T 3 50 B LIND EXPER T 5 00 B LIND EXPER T 5 50 B LIND EXPER T 6 00 B LIND
Chest freezer
User's manual
Baskets* 4561 45
Casters
Package
Mechanical lock kit _
Pc.
1
1
363616
4
Pc.
1
1
3361
4
1
11
1
1
* The number of baskets can be changed at the customer's request
The chest freezer model, refrigerant brand and charging dosage, power,
mains parameters are indicated on the nameplate, which is glued to the
back of the outside of the freezer chest.

4
Specifications of chest freezers
BEST
FREEZE
PRIMA
NIX
MAGNIT
VICTORY
BEST FLAT
FREEZE FLAT
PRIMA FLAT
NIX FLAT
MAGNIT FLAT
VICTORY FLAT
BEST SOLID
FREEZE SOLID
PRIMA SOLID
NIX SOLID
VICTORY SOLID
ROCK
MAGNA
W
(mm) 620 800 1060 1350 1470 1640 620 800 1060 1350 1470 1640 620 800 1060 1350 1640
D
(mm)
H
(mm) 916 1042
The total volume of
th e co mp artment L. 153 224 325 438 440 551 156 227 330 445 492 560 966 1156
Useful volume L. 104 156 232 316 351 401 119 177 261 355 421 448 695 786
Number of
baskets*** ps. 4 5 4 5
The temperature in
the inner volume* °С
Climate class* 3
Gross weight* Kg5558617182845760647688894548557077114142
Net weight* Kg4952556572755154586878793840486268104130
The p ower n etwo rk
p ara meters )*
V/H
z
Power consumption
(av erag e) Wt. 160 160 230 240 250 340 160 160 230 240 250 320 170 182 200 360 460
Cooling agent**
80
R 404a / R 290 R 290 R 404a
6
-18…-25
4/7/5 4
~220/50
36361
159 231 335 451 567
Chest freezers
Model name
FROST STRE AM
Overall dimensions
(Wx Dx H)*
2000
640 730 925
956 940 980
STAR
AURORA
STORM
LEGEND
KING
CYLINDER -50
EXP ERT 1 50 FLAT EXP ERT 2 50 FLAT EXP ERT 3 50 FLAT EXP ERT 5 00 FLAT
EXPERT550FLAT
EXP ERT 6 00 FLAT
EXPERT 15 0 B LIND EXPERT 25 0 B LIND EXPERT 35 0 B LIND EXPERT 50 0 B LIND EXPERT 55 0 B LIND EXPERT 60 0 B LIND
W
(mm) 620 800 1060 1350 1640 ‐ 620 800 1060 1350 1470 1640 620 800 1060 1350 1470 1640
D
(mm)
‐
H
(mm) 875
Diameter (Ø)* Ø
(мм) 460
The total vo lume of
the compartment L. 140 205 300 405 510 54 146 213 311 419 464 528
Useful volume L. 96 145 217 297 377 43 124 184 271 367 407 464
Number of
baskets*** ps. 4 5 6 1 4 5
The temperature in
the in ner volume* С
Climate class* 4/7
Gross weight* Kg54559726829653425263737982405061697377
Net weight* Kg48553646748630374758687477354559646872
The power network
parameters )*
V/H
z
Power consumption
(av era ge) Wt. 150 150 210 215 300 130 125 125 180 190 190 210 90 90 135 140 140 160
Cooling agent**
4/7/5 3
~220/50
R 290
3 361
-1 8 …-2 5 -1 8 …-2 5
‐‐
135 199 291 394 436 496
Chest freezers
Model name
FROST STREAM FRESH STREAM
Overall dimensions
(WxDxH)* 640 640 730
910 880 870
*___ The company-manufacturer reserves the right to make changes in a device's design which do not worsen its performance, which result in insignificant changes
of technical parameters, without additional notification of the consumer. Technical parameters may also be changed depending on changes in customer requirements.
**__ According to TU requirements, cooling agents permitted for use on the territory of the Russian Federation should be used in the chest freezer.
When delivering chest freezers for export, the cool agents permitted for use on the territory of this country should be used in them.
***__ The number of baskets can be changed at the customer's request.

5
Part 2:
Technical details and maintenance
2.1. Operating temperature range
The chest freezer can be used both indoors and outdoors, in street
conditions.
The manufacturer guarantees normal operation of the chest freezer
under conditions of temperature exposure according to climatic class.
To ensure the temperature range inside the freezing chamber, the chest
freezer is equipped with a thermostat. The thermostat has the following
factory settings: minimum temperature in the chest freezer compartment
at which the compressor is switched off -25°C, maximum temperature
in the chest freezer compartment at which the compressor is switched
on -18°C.
2.2. Unpacking
Unpack the chest freezer carefully - do not turn it over, do not
put it on its side, and then visually check for damage. Remove the
device from a shipping pallet.

6
2.3. Placement and Installation
To ensure normal operation, the device must be installed
away from heaters and in a place protected from direct sunlight.
Do not allow precipitation in the form of rain and snow to
enter the device.
•
The device is equipped with rotary rollers. Make sure the floor
surface is not inclined and facilitates easy movement and
installation of your device.
•
Install the brake rollers in front of the chest.
Placement and installation of the chest freezer on site
should provide a free area of at least 20 cm from the chest
ventilation grilles to the fence or dimensional object to ensure free
air circulation.
Insufficient air circulation around the chest freezer leads to
reduced productivity and increases the likelihood of breakdowns
and equipment failure.
•
Check the power cord and plug for mechanical damage by
visual inspection.

7
If mechanical damage to the power cord or plug is
detected, DO NOT connect the device to the power supply. The
power cord and plug must be replaced
• Plug the mains plug of the chest freezer into a grounded power
socket.
DO NOT operate the chest freezer without a grounding
contact in the mains socket. It is not allowed to connect several
chest freezers to one mains socket of power supply via an
"extension" with branch sockets.
2.4. Commissioning
Turn on the power of the chest freezer, to do this connect the
chest power cord to the network. A sign of the switching on of the
freezer chest in the cooling mode is the switching on of the
compressor and the condenser fan.
Allow the device to run for 1.5 hours without putting food into it
and the glass doors must be closed tightly.
It is advisable to keep the products packaged in the device.
In the event of a sudden power failure, the chest freezer must be
switched off. Pause for 5 minutes to switch on again.

8
Do not load the device with products above the loading
limit (index red line inside the camera).
Remember, the chest freezer is designed for storing frozen
food.
Do not store explosive materials or aerosol containers with
combustible displacement gases such as propane, butane,
pentane, etc. in the device. Escaping gases may ignite from
electrical parts. Such aerosol packs can be easily recognized by
the content printed on them or by the flame symbol.
Before starting up the equipment, read carefully the rules
of preparation for operation and the rules of operation of a chest
freezer as specified in this manual.
2.5. Temperature parameters
The setting parameters of the thermostat can only be
changed if necessary by the employee of the service department
servicing this equipment. Unauthorized changes to the thermostat
settings will result in an expiry of the warranty period.
2.6. Tips and remarks
Sudden power outage
1. Covering the outer glass surfaces with a cover helps to keep the
temperature as low as possible for a longer period of time.

9
2. If there is a prolonged lack of power, place dry ice in the
freezer compartment.
3. If possible, reduce the number of door openings/closings.
4. If possible, avoid placing new portions of food in the chest
freezer as this leads to an increase in the temperature inside the
compartment.
If the device is not used for a long time.
1. Disconnect the device from the mains (unplug the power cord from
the socket) and remove everything from the freezer compartment.
2. Clean the interior and remove all water. Leave the door open
until the freezer compartment is completely dry to avoid mildew and
odor.
2.7. Safety rules
Personnel involved in the installation and commissioning of the
chest freezer must be familiar with this manual and work in
accordance with its recommendations and requirements.
Heating the chest crown is a constructive solution to
prevent the glasses from fogging it is not a malfunction!
Follow the precautions and safety precautions in section 2.8
during operation.

10
2.8. Safety requirements
The device complies with Class I of electrical safety.
Before connecting the chest freezer to the electric power network,
make sure that
– the network voltage corresponds to the value given on the
device nameplate (+10%, –15%);
– the power cord and plug are not damaged.
The chest freezer must be connected to a grounded power supply
socket. Do not connect the freezer to a power supply with a faulty
overcurrent protection. Check this before starting the installation process.
Do not use any adapters, additional sockets or extension cords that
do not match the current load of the device.
If there are signs of faulty wiring (smell, smoke), disconnect the power
supply to the device and call a service technician to remedy the fault.
It is forbidden to operate the
chest freezer:
•
if the nominal supply voltage indicated on the nameplate deviates
by more than + 10% - 15%.
•
in case of high level of humidity and dustiness of the environment
(relative humidity above 75%, when ceiling, walls, floor and other
objects in the room are covered with moisture);

11
• under conditions of chemically active environment, which leads to
destruction of electrical insulation and oxidation of conductive
contact connections
• with a conductive floor surface.
The chest freezer must be disconnected from the
power supply in the following cases:
• when cleaning the chest freezer inside and outside;
• when moving the device;
• when performing operations related to servicing the chest freezer
and troubleshooting;
Intended use
Do not store bottles or containers in the chest freezer. The contents
may freeze and containers may explode and cause injury. The device
is designed to store ice cream and frozen food. Storage of other
products may have a significant effect on products already stored in the
appliance.
The manufacturer is not responsible for possible injury to
the user or damage to the equipment if the requirements in this
section of the manual are not complied with.

12
R600a - isobutane or R290 - propane is used as the
refrigerant of the refrigerated cabinet (the brand and dose of
the refrigerant are indicated on the nameplate of the
refrigerator) - natural gas, which is combustible, then the
refrigerating cabinet is is labeled with a special warning label
located behind the product in the area of the refrigeration
unit, with the obligatory indication of the gas brand. As a
result of accidental damage to the refrigerant circuit, avoid
any kind of naked flame or potential sources of ignition and
thoroughly air the room where the refrigerator is located. The
volume of the room should be 1 m for every 8 g. of refrigerant
R600a or R290 in the product. Never turn on the refrigerator
with signs of damage. If you have doubts about the health of
the product, contact an authorized service center.
ATTENTION! Do not use electrical appliances inside the
device.
ATTENTION! Do not block the cooling vents in the
cabinet or in the built-in design!
ATTENTION! Do not damage the refrigerant circuit.
ATTENTION! Do not use mechanical devices or other
means to accelerate the defrosting process.

13
Part 3: Cleaning and servicing
3.1. General points
Disconnect the chest freezer from the power supply before
cleaning or servicing.
Repair of the chest freezer and maintenance of the closed
refrigerant systems, refrigerant charging can be carried out only by
persons authorized to work with refrigerants and soldering with the
open flame of the gas burner.
The type and dose of the refrigerant is indicated on the
nameplate of the chest freezer.
The freezer chest is designed in such a way as to minimize the
amount of maintenance work. By complying the requirements and
recommendations in this manual, you will ensure the quality and
efficiency of this equipment. Cleaning and maintenance within the
scope of this manual will reduce the risk of chest freezer breakage
and increase the efficiency of this equipment. The chest freezer
must be maintained as part of the routine inspection and periodic
maintenance described in this manual.
3.2. Defrosting
Frosting on the inside walls of the chest freezer may reduce its
productivity. It is recommended to defrost the device when the ice
is more than 10 mm thick.

14
The defrosting process:
•
Unplug the device before defrosting.
•
Take the products out of the camera, wrap them in paper and
store them in a cold place.
•
Leave the device doors open.
•
Remove the internal plug at the bottom of the chest freezer and
allow the ice to melt.
•
Place a water collecting container under the drain pipe, take out the
plastic plug on the back of the chest freezer.
•
Make sure that the ice inside the chest freezer has melted. Wipe
the inside and outside of the chest freezer and its components
with a soft dry cloth. If they are too dirty, wipe them with a cloth
moistened with a detergent, then wipe dry with a soft clean cloth.
•
Reinstall the outer and inner plugs.
•
Close the doors, plug the device into the mains, load the device
after 1.5 hours.
To avoid damage to the device DO NOT use hot water,
sharp objects or electric heaters when defrosting.
Do not use bleaching agents or solvents to clean the chest
freezer (especially cleaning agents containing chlorine and
abrasives).

15
3.3. Refrigerator cleaning
The chest freezer refrigerator must be cleaned at least
once a month.
•
Disconnect the device from the mains.
•
Remove the protective grilles of the unit.
•
Remove dust, fluff and foreign objects from all of the plates of the
condenser and the fan. Clean the condenser plates with a stiff brush
(not metal). If possible, clean the clogged spaces between
condenser plates with a vacuum cleaner or compressed air.
The condenser should be cleaned carefully, without
damaging the plates.
•
Inspect the condenser and the inside of the freezer compartment
for damage. If any damage to the surface or tubes is detected,
contact the service department to repair the damage.
•
Install the unit's protective grilles in reverse order.

16
After cleaning and inspection, make sure that all
removable parts are installed in their places and firmly fixed. Do
not use water when cleaning the condenser and electrical
equipment.
3.4. Transportation
The chest freezer may only be transported in an upright position
(door up). In this case, the equipment may be switched on
immediately after the transportation.
The device must not be used at ambient temperatures below 5°C.
By the switching off the device, it should be switched on again not
earlier than in 5 minutes.
When moving the device from the cold into a warm room, let it
warm up for at least 2 hours. After that, the product can be connected
to the power supply network.
3.5. Storage
The chest freezer may only be stored in an upright position (door
up) in a dry, ventilated room protected from direct sunlight and water
ingress.
3.6. Disposal Information.
When the product is completely worn out, it must be disposed of
in an environmentally friendly manner. To do this, contact the
service center serving your region.
ATTENTION! If you decide not to use your refrigerator
before you throw it away, take care of its disposal.

17
 ATTENTION! Your refrigerator contains carbon dioxide
in the insulating foam in this case, you should contact the local
organization responsible for recycling.
Correct disposal of this product. WEEE (Distributed by the
European Union and other European countries, where there is a
system for collecting and recycling used household appliances.)
This marking on the product or literature indicates that the product
should not be disposed of with other household waste to prevent
possible harm to the environment from the uncontrolled
proliferation of waste, and optimize the process of recycling and
reuse of materials.
Consumers can donate their used equipment to special collection
points or, if permitted by national law, return the company when
purchasing a new similar product.

18
Part 4: Typical malfunctions and
troubleshooting
Before carrying out repair work, please refer to the list of specific
faults, their causes and troubleshooting recommendations in the
table below.
Service and repair of the chest freezer should be carried out only
by specialists of the technical service who have the right to carry
out repairs and maintenance of equipment of this type.
Disconnect the chest freezer from the power supply before
carrying out any repairs, cleaning or maintenance work.
With the power supply connected, test and adjustment work
must only be carried out by a specialist service technician.
The system containing the refrigerant must not be de-
pressurized. If necessary, this operation may only be carried out
by a service technician.
Table of typical malfunctions
Type of
malfunction
(breakage)
Possible reason Actions taken
The device is
connected to
the power
supply, but
does not work.
•
There is no voltage in
the mains socket
•
The mains plug is not
fully inserted to the
socket.
•
The thermostat is
damaged.
•
Check for voltage in
the network.
•
Check that the power
cord is working properly
and plug it into the
socket all the way to the
end.
 Call the service
technician to replace
the thermostat.

19
Insufficient
cooling in the
inner chamber
(condenser
fan running ).
•
Refrigerant leak from
the refrigeration system.
•
The air condenser
plates are clogged.
•
Poor air circulation.
•
Incorrect
thermostat settings.
•
Large amounts of ice
and hoarfrost in the
freezer compartment.
•
Products are placed
above the loading line.
•
The chest freezer is placed
near the heater, stove
or under direct sunlight.
•
The door is not tightly
closed.
•
Unplug the chest
freezer. Call the service
technician to diagnose
leaks and repair.
•
Unplug the chest
freezer. Clean the air
condenser plates.
•
Make space around the
chest freezer for free air
circulation.
•
Call the service
technician to change the
thermostat settings.
•
Defrost the chest
freezer.
•
Remove excess product
from the chamber up to the
loading line.
•
Insulate chest
freezer from heat
source.
•
Close the door
The compressor
runs without
shutting down.
•
Malfunction
of the thermostat.
Call the service technician
to reset the thermostat
settings.
