FEATURES/BENEFITS
Parts Department • 1-800-424-TRUE True Website: www.truemfg.com
Toll Free Number • 1-800-325-6152
•Environmentally friendly (R404A), refrig-
erant.
•Freezer holds -10°F (air off evaporator coil,
-20°F) for the best in food preservation.
•Shelving - (3) heavy duty, PVC coated wire
shelves per section (4) different interior kits
available. (field installation required).
•Exterior - 300 series stainless steel front,
sides, bottom and back (the finest stainless
available).
•Interior - attractive, NSF approved, white
aluminum sides and back. 300 series
stainless floor and solid door liner.
•Automatic defrost system time-initiated, tem-
perature-terminated.
•Automatic evaporator fan motor delay dur-
ing defrost cycle.
•Minimum wattage heater in cabinet frame
and door.
•Foamed-in-place polyurethane high density
cell insulation (CFC free).
•Lifetime guaranteed recessed door han-
dles on solid doors.
•Door locks standard.
•Exterior mounted digital electronic ther-
mometer features manual defogger.
•Positive seal self-closing doors with 90
degree stay open feature. Lifetime guaran-
teed door hinges.
•Standard backguard improves airflow
(excludes pass-thru model).
•4” diameter swivel castors standard equip-
ment. 6” legs available.
•Incandescent interior lighting on solid door
models; Fluorescent interior lighting, inte-
grated door light (IDL) on glass door models.
•Energy efficient, triple pane, thermal insulated
glass on glass door models.
•Pass-thru freezer designed to be rear-loaded
from prep area and front accessed.
•Top mounted unit positioned out of food
zone to maximize storage capacity.
•Self-contained system.
TA3F-3S
TA1F-1G
TA2FPT-2S-2S
TA Series
†Depth does not include 13/8" for door handles (glass door models only).
* Height does not include 5” for castor height or 6” for optional legs.
* Height does not include 1” for system mechanical components.
‡Requires 115/208-230/60 Hz, single phase, 3 pole, 4 wire circuit.
* Height does not include 5” for castor height or 6” for optional legs.
* Height does not include 1” for system mechanical components.
‡Requires 115/208-230/60 Hz, single phase, 3 pole, 4 wire circuit.
Reach-In Freezers
Model Swing Doors Cu. Ft. HP Amps Crated Weight
Cabinet Dimensions
L D† H*
SOLID DOORS
TA1F-1S 1 s/s 31 1/210.8 410 29 x 343 / 4x 781 / 4
TA2F-2S 2 s/s 56 3/413.0 704 513/8x 343 / 4x 781 / 4
TA3F-3S ‡ 3 s/s 85 11/211.8 790 761/2x 343 / 4x 781 / 4
SOLID HALF DOORS
TA1F-2HS 2 s/s 31 1/210.8 410 29 x 343 / 4x 781 / 4
TA2F-4HS 4 s/s 56 3/413.0 704 513/8x 343 / 4x 781 / 4
TA3F-6HS ‡ 6 s/s 85 11/211.8 790 761/2x 343 / 4x 781 / 4
GLASS DOORS
TA1F-1G 1 gls 31 3/410.2 435 29 x 347 / 8x 781 / 4
TA2F-2G ‡ 2 gls 56 1 9.1 N/A 513/8x 347 / 8x 781 / 4
All dimensions rounded up to the nearest 1/8”.
NEW
NEW
Pass-Thru Freezer
Model Swing Doors Cu. Ft. HP Amps Crated Weight
Cabinet Dimensions
L D H*
SOLID DOORS
TA2FPT-2S-2S ‡ 4 s/s 56 1 9.1 754 513/8x 371/4x 781/4
All dimensions rounded up to the nearest 1/8”.
Curb mountable units for TR, TA & TG series only. (5% list upcharge)
Remote cabinets available 14% off list (condensing units
supplied by others; system comes standard with
404A expansion valve and requires R404A refrigerant).
Consult factory technical service dept. for BTU information.
