Ubiquiti INS-3AF-I-G User manual

Instant 802.3af Gigabit
Indoor PoE Converter
Model: INS-3AF-I-G
Quick Start Guide
®
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

Introduction
Thank you for purchasing the Ubiquiti
Networks® Instant 802.3af Gigabit
Indoor PoE Converter. This Quick Start
Guide is designed to guide you through
installation and also includes the
warranty terms.
Package Contents
Instant 802.3af Gigabit
Indoor PoE Converter
Model: INS-3AF-I-G
QUICK START GUIDE
®
INS-3AF-I-G Quick Start
Guide
TERMS OF USE: All Ethernet cabling runs must use CAT5 (or
above). It is the customer’s responsibility to follow local country
regulations, including operation within legal frequency channels,
output power, indoor cabling requirements, and Dynamic
Frequency Selection (DFS) requirements.
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

Hardware Overview
PoE In PoE Out
PoE In Gigabit 802.3af PoE port.
Connect this port to an auto-sensing
802.3af PoE Switch. The switch will
automatically activate PoE.
PoE Out Gigabit 24V passive PoE port.
Connect this port to a 24V passive PoE
device.
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

Installation
1. Connect the Ethernet cable from an
802.3af PoE switch to the PoE In port.
*640-00246-02*
640-00246-02
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

2. Connect an Ethernet cable to the
PoEOut port.
3. Connect the other end of the
Ethernet cable to the PoE device.
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

Specifications
INS-3AF-I-G
Dimensions Ø 30.26 x 95.5 mm
(Ø 1.91 x 3.76")
Weight 50 g (1.76 oz)
Network Interface
PoE In (802.3af)
PoE Out (24V Passive)
(1) Gigabit RJ45 Port
(1) Gigabit RJ45 Port
Max. Power Output 24V, 0.5A
Power Method 24V Passive PoE
(Pairs 4, 5+; 7, 8 Return)
Power Input 48V, 802.3af
ESD/EMP Protection ± 15kV
Operating Temperature 0 to 70° C (32 to 158° F)
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

Safety Notices
1. Read, follow, and keep instructions.
2. Heed all warnings.
3. Only use attachments/accessories specified by
the manufacturer.
WARNING: Do not use this
product in a location that can be
submerged by water.
WARNING: Avoid using this
product during an electrical
storm. There may be a remote risk
of electric shock from lightning.
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

Electrical Safety Information
1. Compliance is required with respect to voltage,
frequency, and current requirements indicated
on the manufacturer’s label. Connection to a
different power source than those specified
may result in improper operation, damage
to the equipment or pose a fire hazard if the
limitations are not followed.
2. There are no operator serviceable parts inside
this equipment. Service should be provided only
by a qualified service technician.
3. Contact a qualified electrician or the
manufacturer if there are questions about the
installation prior to connecting the equipment.
4. Protective bonding must be installed in
accordance with local national wiring rules and
regulations.
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

Limited Warranty
UBIQUITI NETWORKS, Inc (“UBIQUITI NETWORKS”)
warrants that the product(s) furnished hereunder
(the “Product(s)”) shall be free from defects in
material and workmanship for a period of one
(1) year from the date of shipment by UBIQUITI
NETWORKS under normal use and operation.
UBIQUITI NETWORKS’ sole and exclusive obligation
and liability under the foregoing warranty shall
be for UBIQUITI NETWORKS, at its discretion, to
repair or replace any Product that fails to conform
to the above warranty during the above warranty
period. The expense of removal and reinstallation
of any Product is not included in this warranty. The
warranty period of any repaired or replaced Product
shall not extend beyond its original term.
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

Warranty Conditions
The above warranty does not apply if the Product:
(I) has been modified and/or altered, or an
addition made thereto, except by Ubiquiti
Networks, or Ubiquiti Networks’ authorized
representatives, or as approved by Ubiquiti
Networks in writing;
(II) has been painted, rebranded or physically
modified in any way;
(III) has been damaged due to errors or defects
in cabling;
(IV) has been subjected to misuse, abuse,
negligence, abnormal physical,
electromagnetic or electrical stress, including
lightning strikes, or accident;
(V) has been damaged or impaired as a result of
using third party firmware;
(VI) has no original Ubiquiti MAC label, or is missing
any other original Ubiquiti label(s); or
(VII) has not been received by Ubiquiti within
30days of issuance of the RMA.
In addition, the above warranty shall apply only if:
the product has been properly installed and used at
all times in accordance, and in all material respects,
with the applicable Product documentation.
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

Returns
No Products will be accepted for replacement
or repair without obtaining a Return Materials
Authorization (RMA) number from UBIQUITI
NETWORKS during the warranty period, and the
Products being received at UBIQUITI NETWORKS’
facility freight prepaid in accordance with the RMA
process of UBIQUITI NETWORKS. Products returned
without an RMA number will not be processed and
will be returned freight collect or subject to disposal.
Information on the RMA process and obtaining an
RMA number can be found at:
www.ubnt.com/support/warranty
Disclaimer
EXCEPT FOR ANY EXPRESS WARRANTIES PROVIDED
HEREIN, UBIQUITI NETWORKS, ITS AFFILIATES,
AND ITS AND THEIR THIRD PARTY DATA, SERVICE,
SOFTWARE AND HARDWARE PROVIDERS HEREBY
DISCLAIM AND MAKE NO OTHER REPRESENTATION
OR WARRANTY OF ANY KIND, EXPRESS, IMPLIED
OR STATUTORY, INCLUDING, BUT NOT LIMITED TO,
REPRESENTATIONS, GUARANTEES, OR WARRANTIES
OF MERCHANTABILITY, ACCURACY, QUALITY OF
SERVICE OR RESULTS, AVAILABILITY, SATISFACTORY
QUALITY, LACK OF VIRUSES, QUIET ENJOYMENT,
FITNESS FOR A PARTICULAR PURPOSE AND
NON-INFRINGEMENT AND ANY WARRANTIES
ARISING FROM ANY COURSE OF DEALING, USAGE
OR TRADE PRACTICE IN CONNECTION WITH SUCH
PRODUCTS AND SERVICES. BUYER ACKNOWLEDGES
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

THAT NEITHER UBIQUITI NETWORKS NOR ITS
THIRD PARTY PROVIDERS CONTROL BUYER’S
EQUIPMENT OR THE TRANSFER OF DATA OVER
COMMUNICATIONS FACILITIES, INCLUDING THE
INTERNET, AND THAT THE PRODUCTS AND SERVICES
MAY BE SUBJECT TO LIMITATIONS, INTERRUPTIONS,
DELAYS, CANCELLATIONS AND OTHER PROBLEMS
INHERENT IN THE USE OF COMMUNICATIONS
FACILITIES. UBIQUITI NETWORKS, ITS AFFILIATES
AND ITS AND THEIR THIRD PARTY PROVIDERS
ARE NOT RESPONSIBLE FOR ANY INTERRUPTIONS,
DELAYS, CANCELLATIONS, DELIVERY FAILURES,
DATA LOSS, CONTENT CORRUPTION, PACKET LOSS,
OR OTHER DAMAGE RESULTING FROM ANY OF THE
FOREGOING. In addition, UBIQUITI NETWORKS does
not warrant that the operation of the Products will
be error-free or that operation will be uninterrupted.
In no event shall UBIQUITI NETWORKS be
responsible for damages or claims of any nature
or description relating to system performance,
including coverage, buyer’s selection of products
(including the Products) for buyer’s application and/
or failure of products (including the Products) to
meet government or regulatory requirements.
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

Limitation of Liability
EXCEPT TO THE EXTENT PROHIBITED BY LOCAL LAW,
IN NO EVENT WILL UBIQUITI OR ITS SUBSIDIARIES,
AFFILIATES OR SUPPLIERS BE LIABLE FOR DIRECT,
SPECIAL, INCIDENTAL, CONSEQUENTIAL OR OTHER
DAMAGES (INCLUDING LOST PROFIT, LOST DATA,
OR DOWNTIME COSTS), ARISING OUT OF THE USE,
INABILITY TO USE, OR THE RESULTS OF USE OF
THE PRODUCT, WHETHER BASED IN WARRANTY,
CONTRACT, TORT OR OTHER LEGAL THEORY, AND
WHETHER OR NOT ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES.
Note
Some countries, states and provinces do not allow
exclusions of implied warranties or conditions, so
the above exclusion may not apply to you. You
may have other rights that vary from country to
country, state to state, or province to province.
Some countries, states and provinces do not allow
the exclusion or limitation of liability for incidental
or consequential damages, so the above limitation
may not apply to you. EXCEPT TO THE EXTENT
ALLOWED BY LOCAL LAW, THESE WARRANTY TERMS
DO NOT EXCLUDE, RESTRICT OR MODIFY, AND ARE
IN ADDITION TO, THE MANDATORY STATUTORY
RIGHTS APPLICABLE TO THE LICENSE OF ANY
SOFTWARE (EMBEDDED IN THE PRODUCT) TO YOU.
The United Nations Convention on Contracts for the
International Sale of Goods shall not apply to any
transactions regarding the sale of the Products.
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

Compliance
FCC
Changes or modifications not expressly approved by
the party responsible for compliance could void the
user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference,
and
2. This device must accept any interference
received, including interference that may cause
undesired operation.
NOTE: This equipment has been tested and found
to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference when the equipment
is operated in a commercial environment. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instruction manual, may cause
harmful interference to radio communications.
Operations of this equipment in a residential area
is likely to cause harmful interference in which case
the user will be required to correct the interference
at his own expense.
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

Industry Canada
CAN ICES-3(A)/NMB-3(A)
This Class A digital apparatus complies with
Canadian CAN ICES-3(A).
CAN ICES-3(A)/NMB-3(A)
Cet appareil numérique de la classe A est conforme
à la norme NMB-3(A) Canada.
CE Marking
CE marking on this product represents theproduct is
in compliance with all directives that are applicable
to it.
Online Resources
Support support.ubnt.com
Community community.ubnt.com
Downloads downloads.ubnt.com
www.4Gon.co.uk [email protected] Tel: [phone] Fax: [phone]

©2016 Ubiquiti Networks, Inc. All rights reserved. Ubiquiti,
Ubiquiti Networks, the Ubiquiti U logo, and the Ubiquiti
beam logo trademarks or registered trademarks of
Ubiquiti Networks, Inc. in the United States and in other
countries. All other trademarks are the property of their
respective owners.
NBPH120716
www.ubnt.com
