Udoo Bolt Installation instructions

Revision 1.3 - April 19, 2019
GET STARTED AND
SAFETY INSTRUCTION MANUAL

PACKAGE CONTENTS
Here are the items you’ll nd inside the UDOO BOLT Package:
- 1 x UDOO BOLT* - 1 x SHIELDING BAG
* Beware of the warm and moving parts (like the fan) when using
UDOO BOLT
SAFETY INFORMATION
- CE certication retained using only the UDOO BOLT qualied Power Supply.
When not using UDOO BOLT qualied Power Supply, use 19VDC (min 60W
power) PSUs certied for your country (make sure that the power cable is less
than 3 mt. long).
- This product should be operated in a well-ventilated environment and, if
used inside a case, the case should not be covered.
- This product should be elevated on a stable, at, electrically non-conducti-
ve surface whilst in operation, and clear from any object that can induce a
short-circuit.
- Do not expose it to water, moisture or heat from any source; UDOO BOLT is
designed for reliable operation at normal ambient room temperatures.
- Avoid handling the warm and moving parts (like the fan) and generally the
printed circuit board while it is powered.
- Only handle by the edges to minimise the risk of electrostatic discharge
damage.
- Take care whilst handling to avoid mechanical or electrical damage to the
printed circuit board and connectors. Also use a grounded wrist strap or tou-
ch a safely grounded object before you handle components.

UDOO BOLT V3UDOO BOLT V8
FEATURES
BOARDS
AMD RYZEN™
EMBEDDED V1202B
AMD RYZEN™
EMBEDDED V1605B
DUAL CORE/QUAD THREAD
@ 2.3GHZ (3.2 BOOST)
QUAD CORE/EIGHT THREAD
@ 2.0GHZ (3.6 BOOST)
AMD RADEON™ VEGA 3
GRAPHICS (3 GPU CU)
AMD RADEON™ VEGA 8
GRAPHICS (8 GPU CU)
DIRECTX® 12 TECHNOLOGY OPENCL, OPENGL, THE VULKAN® API
H.265 DECODE & (8-BIT) ENCODE, VP9 DECODE
2X SLOT SO-DIMM DUAL-CHANNEL 64-BIT DDR4
2400 MT/S WITH ECC SUPPORT UP TO 32GB
32GB EMMC 5.0 HIGH SPEED DRIVE
SSD SATA MODULE'S SLOT M.2 SOCKET 2 KEY B 2260
(FEATURED ALSO PCI-E X2)
NVME MODULES SLOT M.2 SOCKET 3 KEY M 2280
(PCI-E X4 GEN 3 INTERFACE)
SATA III 6 GBIT/S STANDARD CONNECTOR
GIGABIT ETHERNET REALTEK RTL8111G
SLOT M.2 SOCKET 1 KEY E 2230 FOR OPTIONAL WIFI/BT COMBO
2X USB 3 TYPE-A
2X USB TYPE-C :
- USB 3.1 GEN 2
- DISPLAYPORT ALTERNATE MODE
- DUAL ROLE PORT (DRP) USB POWER DELIVERY (USB-PD) 3.0
2 X HDMI 1.4 / 2.0A
2 X DP ALTERNATE MODE ON USB TYPE-C
HD AUDIO CODEC REALTEK ALC888S
MICROPHONE + HEADPHONE COMBO CONNECTOR (TRRS)
PRE-AMPLIFIED STEREO SPEAKER CONNECTORS (UP TO 3W)
DIGITAL OPTICAL AUDIO S/PDIF AND ANALOG STEREO OUTPUT COMBO JACK 3.5MM CONNECTOR
FRONT PANEL HEADERS, IR RECEIVER,
FAN CONTROLLER, RTC BATTERY INCLUDED
ARDUINO LEONARDO COMPATIBLE:
- 12X ANALOG INPUTS
- UP TO 23X DIGITAL INPUT/OUTPUT (7 PWM)
- 1X UART 1X I2C 1X SPI
- 3X GROVE CONNECTORS:
- 1X ANALOG INPUT, 1X UART OR DIGITAL I/O,
1X I2C OR DIGITAL I/O
EMBEDDED CONTROLLER I/O :
- 2X UART, 2X I2C, 1X SPI, 1X KEYBOARD SCAN, 1X FAN CONTROLLER, 10X GPIO
Processor
CPU Core
Graphics
Multimedia
Memory
Mass Storage
Networking
USB
Video Interfaces
Audio Interfaces
Other Interfaces
I/O
OS 64bit
Power In
Dimensions
DC IN JACK 19V
USB TYPE-C POWER IN
12CM X 12CM - 4.72” X 4.72”

GETTING STARTED
Here’s what you need to get started:
- 1 or 2 x DDR4 SO-DIMM Memory
- 1 x UDOO BOLT Power Supply* or other 19VDC (min 60W power) PSUs cer-
tied for your country ( Make sure that the power cable is less than 3 mt. long)
- 1 x Bootable USB Drive with OS installation on it**;
- 1 x Monitor with HDMI or USB-C cable;
- 1 x Keyboard and Mouse.
* The UDOO BOLT Power Supply is purchased seperately.
RAM INSTALLATION
The UDOO BOLT has two 260-pin SO-DIMM sockets for DDR4 memory.
- Supports 4GB, 8GB and 16GB DDR4 SO-DIMMs up to 32GB.
- Supports 1.2V DDR4-2400 DIMMs with dual channel architecture.
In order to exploit the Dual-Channel mode make sure that you install memory
modules of the same type and density in different channel DIMM slots.
Follow these steps to install the DIMM:
- 1: Pull both clips on either side of the slot outwards. Align the DIMM modu-
le with the slot.
- 2: Press the module straight down until the plastic clips tick and close. En-
sure that the module ts tightly into the DIMM slot. Push the clips inwards to
check.
** This product comes without OS installed. To install it fol-
low the get started you’ll nd in UDOO website: http://www.
udoo.org/get-started-bolt/

TOP VIEW
Gigabit Ethernet1
2x USB Type-C3
2x HDMI 2.05
AMD Ryzen Embedded V10007
IR receiver9
Audio Headset Jack11
Pre-amplied Speakers13
DC-IN 19V2
3x Grove Connectors4
Arduino - Compatible Pinout6
Front Panel8
Power Button10
2x USB 3.1 Type-A12
S/PDIF14
TM
TM
2x SO-DIMM RAM 15
1
23 3
4
55
6
7
89
10 11
12 12
15
15
13
14
4
4

BOTTOM VIEW
SSD/PCI-e M.2 Socket 2 Key B16
SATA Power18
Embedded Controller I/O20
AT Mega32U4 Arduino - Compati-
ble Microcontroller
22
Connectivity M.2 Socket 1 Key E17
SATA 3.019
eMMC 5.0 32GB21
NVMe M.2 Socket 3 Key M23
TM
16
17
18
19
20
21
22
23

NOTICES
Federal Communications Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Any changes or modications not expressly approved by the grantee of this
device could void the user’s authority to operate the equipment.

WARRANTY
This product is subject to the Italian Law Decree 24/2002, acting European Directive
1999/44/CE on matters of sale and warranties to consumers.
The warranty on this product lasts for 2 years.
Under the warranty period, the Supplier guarantees the buyer assistance and service
for repairing, replacing or credit of the item, at the Supplier’s own discretion.
Items cannot be returned unless previously authorized by the supplier.
The authorization is released after completing the specic form available on the
web-site http://www.udoo.org/customer-care/ (Open a New Ticket -> Return
Merchandise Application).
The RMA authorization number must be put both on the packaging and on the docu-
ments shipped with the items, which must include all the accessories in their original
packaging, with no signs of damage to, or tampering with, any returned item.
The error analysis form identifying the fault type must be completed by the customer
and has must accompany the returned item.
Following a technical analysis, the supplier will verify if all the requirements, for which
a warranty service applies, are met. If the warranty cannot be applied, the Supplier
will calculate the minimum cost of this initial analysis on the item and the repair costs.
Costs for replaced components will be calculated separately.
All changes or modications to the equipment not explicitly approved by
SECO S.r.l. could impair the equipment’s functionalities and could void
the warranty

INFORMATION AND ASSISTANCE
What do I have to do if I’m experiencing problems with my product?
The following services are available:
- UDOO website: visit http://www.udoo.org to receive the latest information on the
product. In most cases it is possible to nd useful information to solve the problem.
- UDOO Forum: join to the community of UDOO users. In the forum, available at
http://www.udoo.org/forum/, it is possible to search the multiple topics of the commu-
nity, and look for other users that had the same kind of problem - and how they solved
it. It is also possible to post new topics to ask for specic help.
- Repair centre: it is possible to send the faulty product to the SECO Repair Centre. In
this case, follow this procedure:
- Returned items must be accompanied by a RMA Number. Items sent wi
thout the RMA number will be not accepted.
- Returned items must be shipped in an appropriate package. SECO is not
responsible for damages caused by accidental drop, improper usage, or
customer neglect.
Note: Please have the following information before asking for technical
assistance:
- Name and serial number of the product;
- Description of Customer’s peripheral connections;
- Description of Customer’s software (operating system, version, application software,
etc.);
- A complete description of the problem;
- The exact words of every kind of error message encountered.
To request a RMA number, please visit http://www.udoo.org. On the bottom of the
page, please select “Customer Care”, click on the “Open a New ticket” button and.
A RMA Number will be sent within 1 working day (only for on-line RMA requests).
RMA number request
