Ugo Wi-Fi Speaker User manual

1 UGO®Wi-Fi®Speaker User Manual Version 1.0
UGO®Wi-Fi®Speaker
User Manual
Version 1.0
Learn How To Use The UGO®Wi-Fi®Speaker

2 UGO®Wi-Fi®Speaker User Manual Version 1.0
Contents
1. User Manual Overview.......................................................................................................................................................................3
2. UGO® Wi-Fi®Speaker Buttons and Ports...........................................................................................................................................3
3. Download the Muzo Player App.........................................................................................................................................................4
4. Connect the speaker to Wi-Fi®...........................................................................................................................................................5
5. The Muzo Player App Overview.........................................................................................................................................................7
6. TuneIn App Overview.........................................................................................................................................................................9
7. iHeartRadio App Overview...............................................................................................................................................................10
8. Spotify App Overview.......................................................................................................................................................................11
9. Connect the Speaker to a Bluetooth®Device...................................................................................................................................12
10. Connect the Speaker Using the LINE IN Port ................................................................................................................................13
11. Connect the Speaker to a Micro SD Card......................................................................................................................................13
12. Connect the Speaker to Stored Music ..........................................................................................................................................15
13. Setup a Music Player App Not Supported by the Muzo Player App...............................................................................................16
14. Connect and Manage Multiple UGO® Wi-Fi®Speakers..................................................................................................................16
15. Troubleshoot..................................................................................................................................................................................18
16. Technical Specifications.................................................................................................................................................................19
17. Warranty and Replacement Policy.................................................................................................................................................19

3 UGO®Wi-Fi®Speaker User Manual Version 1.0
Figure 1 –UGO®Wi-Fi®Speaker Front
Decrease Volume
and Skip Audio
Backwards Button:
Press to skip audio
backwards through a
playlist. Press and
hold to lower the
volume level of the
speaker.
1. User Manual Overview
The UGO®Wi-Fi®Speaker User Manual teaches a user how to successfully operate UGO®’s only Wi-Fi® certified speaker. A
user will learn the following:
Understand the speaker’s buttons and ports.
Download and operate the Muzo Player app with the speaker.
Connect the speaker to Wi-Fi®, Bluetooth®, a 3.5mm cable and a micro SD card.
Play a favorite music player app with the speaker.
Connect to multiple UGO®Wi-Fi® Speakers.
Troubleshoot the speaker.
Understand the speaker’s technical specifications, warranty and replacement policy.
2. UGO® Wi-Fi®Speaker Buttons and Ports
Mode Lights: There are 3 lights to indicate the mode setting. WIFI is a solid white light that
indicates Wi-Fi®mode. BT is a blue light that indicates Bluetooth®mode which blinks when
ready to pair and solid when paired and connected to a Bluetooth®device. AUX is a solid green
light that indicates LINE IN mode.
Power Button:
Press and hold to
turn the speaker
ON or OFF.
speaker.
Increase Volume and
Skip Audio Forwards
Button: Press to skip
audio forwards through
a playlist. Hold to raise
the volume level of the
speaker.
Play/Pause Button: Press to pause or
play the audio being played on the
speaker.
Mode Button: Press to
change the mode setting.
White light indicates Wi-Fi®
mode, Blue light indicates
Bluetooth®mode and
green light indicates LINE
IN mode.

4 UGO®Wi-Fi®Speaker User Manual Version 1.0
Figure 2 –UGO® Wi-Fi® Speaker Back
3. Download the Muzo Player App
The Muzo Player app is required to connect and control the speaker with Wi-Fi®. Download the app onto
a smartphone or tablet from either an app store or QR codes.
Download the Muzo Player App from an App Store Steps
1. Select a smartphone or tablet that can be connected to a Wi-Fi®connection.
2. Find and open an app store on the smartphone or tablet. Common app stores are Play
Store, Android Market, Google App and App Store.
3. Search for “Muzo Player” and locate the app.
4. Download the Muzo Player app onto the smartphone or tablet. The Muzo Player app icon is now displayed on the
smartphone or tablet (see Figure 3 –Muzo Player App Icon). The app can be located in an app folder or on one of
the displayed screens with other apps.
Download the Muzo Player from a QR Code Steps
1. Select a smartphone or tablet that can be connected to a
Wi-Fi® connection.
2. Find and open a QR reader app on the smartphone or
tablet.
3. Scan one of the QR codes on this page (see Figure 4 –QR
Codes for the Muzo Player App).
4. Open the Muzo Player app store page.
5. Download the Muzo Player app onto the smartphone or tablet. The Muzo Player app icon is now displayed on the
smartphone or tablet (see Figure 3 –Muzo Player App Icon). The app can be located in an app folder or on one of
the displayed screens with other apps.
DC IN Port:
Plug in the
power cord to
recharge the
speaker’s
battery.
Micro SD Card
Port: Insert a
micro SD card with
music or other
audio files to play
on the speaker.
WPS Button: Press to
setup a Wi-Fi®connection
with the speaker.
Reset Button:
Press to reset
the speaker.
LINE IN: Plug in
any 3.5mm cable to
connect directly to
an audio device
with a headphone
jack.
Figure 3 –Muzo
Player App Icon
Figure 4 –QR Codes for the Muzo Player App

5 UGO®Wi-Fi®Speaker User Manual Version 1.0
4. Connect the Speaker to Wi-Fi®
The Muzo Player app is required to connect the speaker to Wi-Fi®. If the Muzo Player app has not been downloaded onto a
smartphone or tablet then first complete the Download the Muzo Player App section (see page 4). Once successfully
downloaded, use the following steps to connect the speaker to a local Wi-Fi® network.
Connect the Speaker to Wi-Fi® Steps
1. Find and connect a smartphone or tablet with the Muzo Player app to a local Wi-Fi®
network.
2. Open the Muzo Player app. A “Searching for MUZO Wireless Hi-Fi System…” text will be
displayed on the screen. Press [Wi-Fi Setup Wizard] (see Figure 5 –Muzo Player App
Searching for a Wi-Fi®Network).
3. Select [YOUR WIRELESS_2.4G]. Do NOT select [YOUR WIRELESS_5G] because this
will not connect with the UGO®Wi-Fi® speaker (see Figure 6 –Muzo Player App Wi-Fi®
Network Setting). Then press [Next]
4. Enter the local Wi-Fi® password (see Figure 7 –Wi-Fi®Network Password). Then press
[Next]
5. Press and hold the power button for 3 seconds on the front of the speaker (see Figure 8
–Power Button). The white LED light will begin to flash.
Figure 5 –Muzo Player App Searching for a Wi-Fi®Network
Figure 6 –Muzo Player App Wi-Fi®Network Setting
Figure 7 –Wi-Fi® Network Password
Figure 8 –Power Button

6 UGO®Wi-Fi®Speaker User Manual Version 1.0
6. Wait until a chime is heard then press the WPS button on the back of the speaker (see
Figure 9 –WPS Button). The speaker will state “Searching for Wi-Fi® connection”. Press
[Next] and then the speaker will state “Waiting for Wi-Fi® connection”(see Figure 10 –
Muzo Player App Wi-Fi®Setup Mode).
7. Wait for the connection to be made between the speaker and the smartphone or tablet
(see Figure 11 –Muzo Player App Searching for the Speaker). The wait could be take up
to 1 minute.
8. Observe the smartphone or tablet screen display “Device is connected to (insert local Wi-
Fi®network name) successfully” and then the speaker state “Wi-Fi®connected”. Then
press [Next] (see Figure 12 –Muzo Player App Connected to the Speaker).
Figure 9 –WPS Button
Figure 10 –Muzo Player App Wi-Fi® Setup Mode
Figure 11 –Muzo Player App Searching for the Speaker
Figure 12 –Muzo Player App Connected to the Speaker

7 UGO®Wi-Fi®Speaker User Manual Version 1.0
Figure 14 –Muzo Player App DEVICE LIST Screen
9. Observe the displayed Muzo Player app’s DEVICE LIST screen confirming a successful
Wi-Fi® setup and connection. The user may now operate the Muzo Player app to play
audio on the speaker (see Figure 13 –Muzo Player App DEVICE LIST Screen).
5. The Muzo Player App Overview
The Muzo Player app has many unique audio features to allow a user to easily find the perfect audio and play on the UGO®
Wi-Fi® Speaker. The Muzo Player app has three screens to operate audio.
DEVICE LIST Screen
Once the UGO®Wi-Fi® Speaker is connected to the local Wi-Fi® network and the Muzo Player app
is opened on the smartphone or tablet then the opening screen will be the DEVICE LIST (see
Figure 14 –Muzo Player App DEVICE LIST Screen). The Muzo Player app allows up to 8 UGO®
Wi-Fi® speakers to be connected simultaneously. Each connected speaker will display as a
“DEVICE” and play the same or different audio. The audio being
played will be displayed next to that device. To connect multiples
speakers, see the Connect and Manage Multiple UGO®Wi-Fi®
Speakers section (see page 16)
Music Player Screen
Swipe the screen to the right when on the DEVICE LIST screen and
the Music Player screen will be displayed (see Figure 15 –Muzo Player App
Music Player Screen). The Music Player will play selected audio from one of
the audio apps found on the Dashboard, off of a smartphone/tablet or the
micro SD card. Skip forwards or backwards through playlists, play/pause
audio and save favorite stations/audio on the Muzo Player app.
Figure 13 –Muzo Player App DEVICE LIST Screen
UGO® Wi-Fi®Speaker 1
Displayed as a “DEVICE”.
Adjust Which Speaker Channels on the UGO®Wi-Fi® Speaker to Play
Audio. Options are Stereo (LR), Left Channel (L) and Right Channel (R).
Adjust the UGO® Wi-Fi®Speaker Settings like the Name and Speaker
Information. Also Access Preset Content to the Speaker.
Figure 15 –Muzo Player App Music Player Screen
Displayed Audio Playing.
Play/Pause Audio.
Save Favorite Audio.
Skip Forwards or Backwards Through Playlists.
Display Playlist.

8 UGO®Wi-Fi®Speaker User Manual Version 1.0
Dashboard Screen
Swipe the screen to the right twice or click < symbol in the upper left
corner on the DEVICE LIST screen and the Dashboard will be
displayed (see Figure 16 –Muzo Player App Dashboard Screen).
The Dashboard has audio apps that allow a user to search the
internet for music, sports, news, podcasts and more. A user can search by
genre, location, and language using audio providers like Spotify,
iHeartRadio and TuneIn. Access playlists and saved favorite audio. A
user can switch from the Wi-Fi® setting to either LINE IN, Bluetooth®
or the micro SD card to access other audio sources.
Add or Remove Audio Apps from the Dashboard Steps
1. Press [Add More Services] on the Dashboard. A screen will be displayed that shows all
the available audio apps (see Figure 17 –Muzo Player App Add More Services Screen).
2. Select which audio apps to be displayed on the Dashboard by pressing the dot next to
the app’s name and swipe the dot to the right. A green background next to the dot
signals the app will be displayed on the Dashboard. Swipe the dot to the left to remove
the app from the Dashboard.
3. Press the < symbol in to upper left corner of the screen to return to the Dashboard
screen.
Figure 16 –Muzo Player App Dashboard Screen
Saved Favorite Audio.
Audio Saved on a
Smartphone or Tablet.
Audio Apps.
Add or Remove Audio
Apps.
Adjust to LINE IN,
Bluetooth® or the
Micro SD Card.
Figure 17 –Muzo Player App Add More Services Screen

9 UGO®Wi-Fi®Speaker User Manual Version 1.0
6. TuneIn App Overview
TuneIn is one of the audio apps on the Muzo Player app Dashboard. TuneIn is the easiest audio app to find music from over
100,000 radio stations and more than 4,000,000 podcasts streaming from every continent, even Antarctica. There are radio
stations covering music, sports, news and talk in various languages.
TuneIn Navgation Steps
1. Setup the UGO®Wi-Fi®speaker to the Muzo Player app (see Connect the Speaker
to Wi-Fi®on page 5).
2. Open the Muzo Player app.
3. Swipe the screen to the right twice or click < symbol in the upper left corner on the
DEVICE LIST screen and the Dashboard will be displayed.
4. Press [TuneIn] (see Figure 18 –TuneIn Selection).
5. Observe the TuneIn app menu of audio selections. Choose the desired audio from
local radio, music, talk, sports and podcasts. Audio selection can be filtered by
location and language (see Figure 19 –TuneIn App Menu Screen).
For more TuneIn app information, visit the TuneIn website: https://beta.tunein.com/
Figure 18 –TuneIn Selection
Figure 19 –TuneIn App Menu Screen

10 UGO®Wi-Fi®Speaker User Manual Version 1.0
7. iHeartRadio App Overview
iHeartRadio is one of the audio apps on the Muzo Player app Dashboard. The app has over 1,500 radio stations or a user can
create commercial-free and all-music custom stations featuring selected songs from a favorite artist. iHeartRadio has one of
the best search functions that can look up specific songs, artists and albums compared to other audio apps on the Muzo
Player app Dashboard. The search function also produces results of similar music allowing a user to easily discover new
music.
iHeartRadio Navgation Steps
1. Setup the UGO®Wi-Fi®speaker to the Muzo Player app (see Connect the
Speaker to Wi-Fi®on page 5).
2. Open the Muzo Player app.
3. Swipe the screen to the right twice or click < symbol in the upper left corner on
the DEVICE LIST screen and the Dashboard will be displayed.
4. Press [iHeartRadio] (see Figure 20 –iHeartRadio Selection).
5. Login into iHeartRadio with an email address and password. If a user does not
have an iHeartRadio account, press [Sign Up] and follow the displayed
instructions to set up an account (See Figure 21 –iHeartRadio Login Screen).
6. Observe the iHeartRadio menu of audio selections. Choose the desired
audio from live radio stations, custom radio stations and podcasts (see
Figure 22 –iHeartRadio Menu Screen).
For more iHeartRadio app information, visit the iHeartRadio website:
https://www.iheart.com/
Figure 20 –iHeartRadio Selection
Figure 21 –iHeartRadio Login Screen
Figure 22 –iHeartRadio Menu Screen
