USER MANUAL
20V CORDLESS BLOWER
UGB01

Technical data
Voltage: DC 20 V
No load speed: 6500-13000/min
Weight: 1.7kg
Max Blow speed: 120mph
Charging time:
Battery:
4h
2.0Ah Li-ion
Explanation of Symbols on your
product
!
Warning
!
Read the manual
!
Do not dispose of batteries. Return exhausted
batteries to your local collection or recycling point.
!
Contains Li-ion battery. Battery must be recycled or
disposed of properly.
!
Always charge the battery between temperatures
32°F-104°F (0°C-40°C).
!
Do not burn
!
Wear eye protection
!
Wear ear protection
!
Do not use in the rain
SAFETY INSTRUCTIONS
!
WARNING: IMPORTANT SAFETY
INSTRUCTIONS
When using an electrical appliance, basic precautions
should always be followed, including the following:
READ ALL INSTRUCTIONS BEFORE USING
THIS APPLIANCE
INTENDED PURPOSE
!
WARNING:
A garden blower is not a wet suction device!
The device is designed only for blowing of dry leaves
in private households and as a hobby device in the
garden. Any other utilization, which is not explicitly
approved in these directions, can lead to damage to
the device and represent a serious danger to the user.
The device must not be employed in areas where
there is health endangering debris or as a wet suction
device.
The device is designed for use by adults.
Young people over 16 years may use the device under
supervision only.
The use of the device in the rain or in a humid
environment is forbidden.
The manufacturer is not liable for damage which is
caused through inappropriate use or incorrect
operation
!
WARNING: To reduce the risk of fire, electric
shock, or injury:
1. Do not leave appliance when plugged in. Unplug
from outlet when not in use and before servicing.
2. WARNING: To Reduce the Risk of Electric Shock
– Do not use on wet surfaces. Do not expose to rain.
Store indoors.

3. Do not allow to be a toy. Close attention is
necessary when used by or near children.
4. Use only as described in this manual. Use only
manufacture’s recommended attachments.
5. Do not use with damaged cord or plug. If appliance
is not working as it should, has been dropped,
damaged, left outdoors, or dropped into water, return
it to a service center.
6. Do not pull or carry by cord, use cord as a handle,
close a door on cord, or pull cord around sharp edges
or comers. Do not run appliance over cord. Keep cord
away form heated surfaces.
7. Do not unplug by pulling on cord. To unplug, grasp
the plug, not the cord.
8. Do not handle plug or appliance with wet hands.
9. Do not put any object into openings. Do not use
with any opening blocked; keep free of dust, lint,
hair, and anything that may reduce air flow.
10. Keep hair, loose clothing, fingers, and all parts of
body away form openings and moving parts.
11. Turn off all controls before unplugging.
12. Use extra care when cleaning on stairs.
13. Do not use to pick up flammable or combustible
liquids, such as gasoline, or use in areas where they
may be present.
14. Always turn off this appliance before connecting
or disconnecting either hose or motorized nozzle.
15. Use only the charger supplied by the
manufacturer to recharge.
16. Do not pick up anything that is burning or
smoking, such as cigarettes, matches, or hot ashes.
17. Do not use without dust bag and/or filters in
place.
18. Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type
of battery pack may create a risk of fire when used
with another battery pack.
19. Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
20. When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
burns or a fire.
21. Under abusive conditions, liquid may be ejected
from the battery; avoid contact.
If contact accidentally occurs, flush with water. If
liquid contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause irritation
or burns.
Safe Operation Practices for Cordless Blowers
and Vacuums
1. Safety Instructions
1.1.Training
1) Read the operating and service instruction manual
carefully. Be thoroughly familiar with the controls
and the proper use of the equipment.
2) Never allow children to operate the tool.
3) Keep the area of operation clear of all persons,
particularly small children, and pets.
4) Do not use the tool for any job except that for
which it is intended.
1.2 Preparation
1) Thoroughly inspect the area where the equipment
is to be used and remove all stones, sticks, wires,
bones, and other foreign objects.
2) Operate the tool only in daylight or in good
artificial light.
3) Never operate the equipment on wet materials.
Always be sure of your footing. Keep a firm hold on
the handle and walk, never run.
1.3 Operation
1) Do not put hands or feet near or under rotating
parts.
2) If the equipment should start to vibrate
abnormally, stop the motor and check
immediately for the cause. Vibration is generally a
warning of trouble.
3) Stop the motor whenever you leave the equipment,
and before making any repairs or inspections.
4) Shut the motor off and wait until the fan comes to
a complete stop before removing the bags
5) Do not wash with a hose, avoid getting water in
motor and electrical connections.
1.4 Maintenance
1) Keep all nuts, bolts, and screws tight to be sure the
equipment is in safe working condition.
2) Check bag frequently for deterioration and wear,
and replace worn bags. Check that replacement bags
comply with the original manufacturer’s
recommendations or specifications.
ADDITIONAL SAFETY
INSTRUCTIONS FOR YOUR TOOL
1. Do not charge appliance in damp or wet locations.

2. Do not use battery-operated appliance in rain.
3. Remove or disconnect battery before servicing,
cleaning or removing material from the gardening
appliance.
4. Do not dispose of the battery in a fire. The cell
may explode. Check with local codes for possible
special disposal instructions.
5. Do not open or mutilate the battery. Released
electrolyte is corrosive and may cause damage to the
eyes or skin. It may be toxic if swallowed.
6. Exercise care in handling batteries in order not to
short the battery with conducting materials such as
rings, bracelets, and keys. The battery or conductor
may overheat and cause burns.
7. Charge only using the charger provided with the
tool.
8. Do not place outlet tubes near eyes or ears when
operating.
9. Do not cross gravel paths or place the tool on
gravel while the tool is switched on.
10. Do not place any objects into the openings and
moving parts.
11. Before removing the blow tube, always switch off
the tool, remove the battery and allow the tool to run
down.
12. Avoid dangerous environment. Do not use
appliances in damp or wet location.
13. Do not use in rain.
14. Keep children away. All visitors should be kept at
a distance from work area.
15. Dress properly. Do not wear loose clothing or
jewelry. They can be caught in moving parts. Use of
protective gloves and substantial footwear is
recommended when working outdoors. Wear
protective hair covering to contain long hair.
16. Use right appliance. Do not use appliance for any
job except that for which it is intended.
17. Do not force appliance. It will do the job better
and with less risk of injury at the rate for which it was
designed.
18. Do not overreach. Keep proper footing and
balance at all times.
19. Stay alert. Watch what you are doing. Use
common sense. Do not operate appliance when you
are tired.
20. Store idle appliances indoors. When not in use,
appliances should be stored indoors in dry, and high
or locked-up place, out of reach of children.
21. Check damaged parts. Before further use of the
appliance, a guard or other part that is damaged
should be carefully checked to determine that it will
operate properly and perform its intended function.
Check for alignment of moving parts, binding or
moving parts, breakage of parts, mounting, and any
other condition that may affect its operation. A guard
or other part that is damaged should be properly
repaired or replaced by an authorized service center
unless indicated elsewhere in this manual.
BATTERY
1. Never attempt to open or modify battery for any
reason. Released electrolyte is corrosive
and may cause damage to eyes and skin. It may be
toxic if swallowed.
2. Under extreme conditions, battery leakage may
occur. When you notice liquid on the battery, proceed
as follows:
• Carefully wipe the liquid off using a cloth.
Avoid skin contact.
• In case of skin or eye contact, follow the
instructions below.
• The battery fluid, a 25-30% solution of
potassium hydroxide, can be harmful. In case
of skin contact, immediately rinse with water.
Neutralize with a mild acid such as lemon juice
or vinegar. In case of eye contact, rinse
abundantly with clean water for at least 10
minutes.
3. Do not expose to water.
4. Do not store in locations where the temperature
may exceed 104°F (40°C).
5. Charge at room temperature: 64°F-75°F
(18°C-24°C), never at ambient temperatures below
40°F (4°C) and above 104°F (40°C).
6. Charge only using the charger provided with the
tool.
7. Before charging, make sure that the battery is dry
and clean.
8. Use only the correct type of battery for the tool.
9. Exercise care in handling and storing batteries in
order not to short them with conductive materials
such as rings, keys, coins. There is a real risk of the
battery or the conductor overheating, causing fire or
burns.
10. Do not dispose of battery in fire. It may explode.
Follow instructions and regulations given by local
authorities concerning environmental protection.
Dispose of old batteries at an appropriate waste

disposal facility.
CHARGERS
1. Use your charger only to charge the battery in the
tool which it was supplied. Other batteries could
burst, causing personal injury and damage.
2. Never attempt to charge non-rechargeable
batteries.
3. Do not expose the charger to water.
4. Do not open the charger.
5. Do not probe the charger.
SAVE THESE INSTRUCTIONS
1. Refer to then frequently and use then to instruct
others who may use this tool. If someone borrows
this tool, make sure they have these instructions.
2. Use only identical replacement parts.
!
CONTENTS:
1. Battery Pack 2. Handle 3. Trigger 4. Trigger
Lockout 5. Speed switches 6. Locking Press Button
7.Working head 8. Locking Press Button 9. Blower
Tube 10. Extension Tube
CHARGING BATTERY (Fig.1)
Before attempting to charge the battery pack,
thoroughly read all Safety Instructions.
The battery needs to be charged before first use
and whenever it fails to produce sufficient power on
jobs that were easily done before.
The battery may become warm while charging;
this is normal and does not indicate a problem.
NOTE: After several charge and discharge cycles, the
battery will attain full capacity.
!DO NOT CHARGE THE BATTERY
AT AMBIENT TEMPERATURES BELOW 4ºC
OR ABOVE 40ºC （BELOW 40ºF OR ABOVE
104ºF）.
Fig.1
◆Plug the mains plug of the adaptor into a
socket outlet, At this time, the green light of
charging seat lights up. Insert the battery pack
into the charger station, At this time, red right
on and green light off. The battery charge-
control indicator indicates the charging
progress. The indicator lights up red during the
charge procedure. The battery is completely
charged when the indicator lights up green
again.
Disconnect the battery charger from the mains
supply when not using it for longer periods.
IMPORTANT CHARGING NOTES
1. After normal usage, your battery pack should be
fully charged in about 4 hours. Allow the battery to
cool down before charging after using the saw.
(NOTE: A hot battery placed in the charger will not
charge)
2. DO NOT charge the battery pack in an air
temperature below 40°F (4 °C) or above 104°F (40
°C). This is important and will prevent serious
damage to the battery pack. Longest life and best
performance can be obtained if battery pack is
charged when air temperature is about 75°F (24°C).
3. While charging, the charger may hum and become
warm to touch. This is a normal condition and does
not indicate a problem.
4. If the battery pack does not charge properly
• Check current at receptacle by plugging in a lamp
or other appliance.
• Check to see if receptacle is connected to a light
switch which turns power off when you turn out the
lights.
• Move charger and battery pack to a surrounding air
temperature of 40°F (4°C) to 104°F (40°C)
• If the receptacle and temperature are OK, and you
do not get proper charging contact (DESA Power
Tools) service center.
5. The battery pack need to be charged before first
using and should be recharged when it fails to
produce sufficient power on jobs which were easily
done previously. DO NOT CONTINUE using this
product with its battery pack in a depleted condition.
(NOTE: After several charge and discharge cycles,
the battery will attain full capacity.)
6. To prolong battery life, avoid leaving the battery
pack on charger for extended periods of time (over 30
days without use). Although overcharging is not a
safety concern, it can significantly reduce overall
battery life.

7. The battery pack will reach optimum performance
after being cycled 5 times during normal usage.
There is no need to run the batteries down completely
before recharging. Normal usage is the best method
of discharging and recharging the batteries.
ASSEMBLY
!
Fig.2
!
Fig.3
ASSEMBLING THE BLOWER TUBE (Fig. 2 &
Fig. 3)
1. Fit the Blower Tube to the motor housing as
shown in Fig 2. Check the Blower Tube is firmly
secured.
2. Disassembling the Blower Tube, you can separate
the tube.(Fig. 3) Cocked up the next part of the
extension Down Blower Tube⑧, so that you can
separate the Down Blower Tube.(Fig. 3) Do not
try to separate the tubes by force or by using
tools.
!
Fig.4
ASSEMBLY FUNCTION OF SWIVEL
HEAD(Fig. 4)
Hold the handle ②tightly. Slide the locking press
button ⑤up and then turn the work head to the
desired position. Release the locking press button ⑤
again and check whether the work head is locked in
place.
Note:The work head can be locked in five
positions(0°、18°、36°).
OPERATION
!WARNING! The charger and battery pack
are specially designed to work together so do not
attempt to use any other devices. Never insert or
allow metallic objects into your charger or battery
pack connections because of an electrical failure and
hazard will occur.
1. BEFORE USING YOUR CORDLESS
BLOWER
You must charge once before use.
The battery charger supplied is matched to the Li-ion
battery installed in the machine.
Do not use another battery charger.
2. CHARGING YOUR BATTERY PACK
The Li-ion battery is protected against deep

discharging. When the battery is empty, the machine
is switched off by means of a protective circuit: The
tool holder no longer rotates.
In a warm environment or after heavy use, the battery
pack may become too hot to permit charging. Allow
time for the battery to cool down before recharging.
3. TO REMOVE OR INSTALL BATTERY PACK
(Fig. 5)
!
Fig.5
●Always release the On/Off switch before
insertion or removal of the battery pack.
●To remove the battery pack, withdraw it from the
tool while pulling the Battery Release Button
(10) down.
●To insert the battery pack, groove along the
handle and insert in the full position, until the
Battery Release Button (10) bounce back to
normal position again.
Do not use force when inserting the battery
pack. If the cartridge does not slide in easily, it is
not being inserted correctly.
4. STARTING/STOPPING (Fig. 6)
!
Fig.6
press trigger③until the stop, This will turn blower
on. Then push trigger lockout④and release the
trigger, In this way, the trigger is locked. Continue to
press the trigger, And then release the trigger, this
turn blower off.
5. SPEED REGULATION(Fig. 7)
!
Fig.7
The blower is stepless speed regulation. (6) for the
high speed, The speed switch spin down to (1) as the
low speed.
6. USING THE BLOWER
The blower is intended for residential use only.
Use the blower outdoors to move debris from hard
surfaces. This blower is not designed to clear leaves
from large grassy areas, or move wet, heavy debris.
USER TIPS
- Hold the blow tube approx 7” above the ground
when operating the tool. Use a sweeping motion from
side to side. Advance slowly keeping the accumulated
debris/leaves in front of you.

!
Caution!
- After blowing the debris/leaves into a pile, it is easy
to dispose of the pile.
- Do not blow hard objects such as nails, bolts, or
rocks.
- Do not operate the blower near bystanders or pets.
- Use extra care when cleaning debris from stairs or
other tight areas.
- Wear safety goggles or other suitable eye protection,
long pants, and shoes.
STORAGE
!
WARNING! Store the blower indoors, in a cool dry
location, out of reach of children and animals.
If storing Blower for more than 30 days, follow steps
below.
1. Remove battery from Blower.
2. Charge battery completely. (Note: It could take up
to 4 hours to completely charge the battery.)
3. When battery is completely charged, remove from
charger
IMPORTANT: To prolong battery life, avoid leaving
battery on charger for extended periods of time (over
30 days without use).
4. Store Blower and battery
• in a high or locked place, out of children’s reach.
• in a dry place.
• in a carrying case.
DISPOSAL：
The packaging material is reusable. Rid yourself of
the packaging in an environmentally friendly way
and put it in the collection of recyclable materials.
Dispose of the product and the batteries in view of
the environment if you want to separate. The device
and the batteries should not be thrown into the
household garbage. Bring them to the recycling
center for the used electrical and electronic devices.
You can consult to the local government for more
information. Remove the batteries first.
!
PARTS AND SERVICE:
HOW TO OBTAIN REPLACEMENT PARTS: A
replacement parts list is available online at Ukoke.com/
Amazon.com/Walmart.com/newegg.con,. Replacement parts
can be purchased online or by calling Ukoke Customer
specialist (909)-606-4551 or by Email:[e-mail]
Replacement parts can also be obtained at one of our
Return centers.
HOW TO LOCATE A Return CENTER: Return centers
can be located at 19575 East Walnut Drive South, Units C16,
City of Industry, California 91748. Ukoke Customer
specialist (909)-606-4551 or by Email:[e-mail]
..........

LIMITED WARRANTY STATEMENT
UKOKE TECH INC., warrants to the original retail
purchaser that this UKOKE™ brand outdoor product is free
from defect in material and workmanship and agrees to repair
or replace, at UKOKE TECH INC.’s, discretion, any
defective product free of charge within these time periods
from the date of purchase.
n Three years if the product is used for personal, family or
household use;
n 90 days, if used for any other purpose, such as
commercial.
This warranty extends to the original retail purchaser only
and commences on the date of the original retail purchase.
Any part of this product found in the reasonable judgment of
UKOKE TECH INC. to be defective in material or
workmanship will be repaired or replaced without charge for
parts and labor by an authorized service center for UKOKE
™ brand outdoor products.
The product, including any defective part, must be returned
to an authorized UKOKE service center within the warranty
period. The expense of delivering the product to the service
center for warranty work and the expense of returning it back
to the owner after repair or replacement will be paid by the
owner. UKOKE TECH INC.’s, responsibility in respect to
claims is limited to making the required repairs or
replacements and no claim of breach of warranty shall be
cause for cancellation or rescission of the contract of sale of
any UKOKE™ brand outdoor product. Proof of purchase
will be required by the dealer to substantiate any warranty
claim. All warranty work must be performed by an
authorized service dealer.
This warranty is limited to ninety (90) days from the date of
original retail purchase for any UKOKE™ brand outdoor
product that is used for rental or commercial purposes, or any
other income-producing purpose. This warranty does not
cover any product that has been subject to misuse, neglect,
negligence, or accident, or that has been operated in any way
contrary to the operating instructions as specified in this
operator’s manual. This warranty does not apply to any
damage to the product that is the result of improper
maintenance or to any product that has been altered or
modified. The warranty does not extend to repairs made
necessary by normal wear or by the use of parts or
accessories which are either incompatible with the
UKOKE™ brand outdoor product or adversely affect its
operation, performance, or durability. In addition, this
warranty does not cover:
A.Tune-ups – Spark Plugs, Carburetor, Carburetor
Adjustments, Ignition, Filters
B.Wear items – Bump Knobs, Outer Spools, Cutting Lines,
Inner Reels, Starter Pulleys, Starter Ropes, Drive Belts,
Tines, Felt Washers, Hitch Pins, Mulching Blades, Blower
Fans, Blower and Vacuum Tubes, Vacuum Bag and Straps,
Guide Bars, Saw Chains
ALL IMPLIED WARRANTIES ARE LIMITED IN
DURATION TO THE STATED WARRANTY PERIOD.
ACCORDINGLY, ANY SUCH IMPLIED WARRANTIES
INCLUDING MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE, OR OTHERWISE, ARE
DISCLAIMED IN THEIR ENTIRETY AFTER THE
EXPIRATION OF THE APPROPRIATE THREE-YEAR OR
NINETY-DAY WARRANTY PERIOD. UKOKE TECH
INC.’S, OBLIGATION UNDER THIS WARRANTY IS
STRICTLY AND EXCLUSIVELY LIMITED TO THE
REPAIR OR REPLACEMENT OF DEFECTIVE PARTS
AND UKOKE TECH INC., DOES NOT ASSUME OR
AUTHORIZE ANYONE TO ASSUME FOR THEM ANY
OTHER OBLIGATION. SOME STATES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED
WARRANTY LASTS, SO THE ABOVE LIMITATION
MAY NOT APPLY TO YOU. UKOKE TECH INC.,
ASSUMES NO RESPONSIBILITY FOR INCIDENTAL,
CONSEQUENTIAL, OR OTHER DAMAGES
INCLUDING, BUT NOT LIMITED TO, EXPENSE OF
RETURNING THE PRODUCT TO AN AUTHORIZED
UKOKE SERVICE CENTER AND EXPENSE OF
DELIVERING IT BACK TO THE OWNER, MECHANIC’S
TRAVEL TIME, TELEPHONE OR TELEGRAM
CHARGES, RENTAL OF A LIKE PRODUCT DURING
THE TIME WARRANTY SERVICE IS BEING
PERFORMED, TRAVEL, LOSS OR DAMAGE TO
PERSONAL PROPERTY, LOSS OF REVENUE, LOSS OF
USE OF THE PRODUCT, LOSS OF TIME, OR
INCONVENIENCE. SOME STATES DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATION OR EXCLUSION MAY NOT APPLY TO
YOU.
This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.
This warranty applies to all UKOKE™ brand outdoor
products manufactured by or for UKOKE TECH INC., and
sold in the United States and Canada.#
