Connect the DIN Rail via the End Clamp (2A09)
to protective earth ground with low impedance.
The modules are grounded to PE when they are
snapped onto the DIN Rail.
When in operation, do not look directly into the
transmit optical port or use magnification or
focusing equipment to view optical output.
IEC 60825-1, Class 1 LED Product
FDA 21 CFR 1040.10 & 1040.11
CAUTION: Use of controls and/or adjustments or
the performance of procedures other than those
specified herein may result in hazardous infrared
radiation exposure.
When used in Hazardous Locations:
Class I, Division 2, Groups A, B, C & D, T3C.
Substitution of components may impair suitability
for Class I, Division 2. Power, input and output
(I/O) wiring must be in accordance with Class I,
Division 2 wiring methods and in accordance with
the authority having jurisdiction. User shall
provide power through a 3.33A maximum fuse or
power the unit with a Class 2 power source. Do
not connect/disconnect equipment unless area is
known to be non-hazardous and power is
switched off. Certified components for use in a
suitable enclosure. The maximum ambient
temperature is 75°C.
Further technical information can be obtained by
contacting Ultra Electronics, NSPI Fiber Optic
Products Group.
Phone: 800.880.9333
512.434.2800
Fax: 512.434.2901
Email: fiberop@weedinstrument.com
Visit:
www.ultra
-
nspi.com
Safety and Warning Information
Important Notice - Before utilizing the product, the user
should determine the suitability of the product for its intended
use. The user assumes all risk and liability in connection with
such use. ULTRA ELECTRONICS’ WRITTEN WARRANTY
FOR THE PRODUCT IS MADE IN LIEU OF ALL OTHER
WARRANTIES, EXPRESSED OR IMPLIED WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. The user's exclusive remedy for
breach of Ultra Electronics’ written warranty shall be the
repair or replacement of such quantity of product which is
proven to be defective. In no case shall Ultra Electronics be
liable for any special, incidental, or consequential damages
based upon breach of contract, negligence, strict liability or
other legal theory.
Ultra Electronics, NSPI
Round Rock, Texas, USA
Publication Number: RM0900200 Rev. 8/09
G408M
EOTec Managed Ethernet Switch
Ethernet Standards:
IEEE 802.3(U)(X)
Ethernet Protocols: All 802.3 supported
Ports
Fiber Ports: 100/1000Base-FX
SFP, LC Connections
RJ45 Ports: 10/100/1000Base-T(X)
Power Input
Requirement: 10 to 30Vdc @ 500mA
Connection: Pluggable Cage-Clamp
Screw Terminal block
Installation Instructions
Ultra Electronics, Nuclear
Sensors & Process
Instrumentation
Power:
The module may be powered from any supply
capable of delivering 10 to 30Vdc at 500mA.
Power connection is via a removable screw
terminal block located at the bottom of the unit.
Two power inputs are provided for redundant
power, if needed. Neither power input is internally
fuse protected.
Ethernet:
The front panel RJ45 connectors are shielded and
employ an auto-crossover circuit such that either a
straight through or a crossover cable may be
connected. Shielded, data-quality, category 5e
cable is recommended. The typical maximum
cable length is 328ft (100m).
Fiber:
Ports 5, 6, 7 & 8 can be used as either wire ports
or fiber ports, but not both simultaneously. The
fiber ports are compatible with SFP (Small Form
Factor Pluggable) fiber modules. These modules
accept LC fiber connectors. An SFP module locks
in place when inserted and lifting its wire bale
unlocks the SFP module for removal.
Specifications/Compliances
Operational Settings
Ethernet Standards: IEEE 802.3(U)(X)
Ethernet Protocols: All standard IEEE 802.3
Ethernet Isolation: 1200VRMS (1 minute)
Wire Ethernet Ports
Shielded RJ45: Auto 10/100/1000 Base-
T(X), Auto full/half-
duplex, Auto crossover
Wire Cable Length: 328ft/100m
Power Requirements: 10 to 30Vdc, 500mA max
Power Connector: Pluggable, Cage-clamp,
Screw terminal block,
Accepts 12 to 24AWG
Fiber Ethernet Ports:
Connection: LC Compatible
Data Rate: 1000Base-FX, Full-
duplex
Operating Range
Temperature: -40 to 75°C
Relative Humidity: 0 to 95%
(non-condensing)
Flammability: UL 94V-0
Hazardous Locations: Class I, Division 2,
Groups A, B, C & D, T3C
LED Indicators
P1, P2 (Power): Green - On with power applied
1 - 8 Off with no connection
On Green with 1Gbps link
On Amber with 10/100Mbps link
Flashes with activity
STATUS: Green - Off or flashing if internal
error exists.
On if switch is normal
OK: Green - Off ring of power fault
On when normal
Connections
DIN Rail Mounting
Installation on DIN rail:
Place the top lip of the module's DIN rail
mounting clip onto the DIN rail. While applying
pressure to the top rear portion of the unit, swing
the lower portion of the unit towards the mounting
surface until it "clicks" and locks into place.
Removal from DIN rail:
Pushing down on the top rear causes the DIN rail
mounting clip to move downward and disengages
it from the DIN rail. Tilt the module up and lift it
off of the DIN rail.
Little or no user configuration is needed if the unit
is used as a standard switch. Management
functions can be set up via the console ports or
Ethernet ports. The default IP address is 10.2.0.1
and the default subnet mask is 255.0.0.0
Direct to Panel Mounting
