Ultra max Uxdc16 User manual

UXDC16 Underwater Digital Camera

QUICK INSTALLATION GUIDE

Step 1 Remove tape and packing materials Step 2 Install battery in Camera Step 3 Open back of housing and gently install camera

(insert external memory card here if needed) make sure the camera is firmly seated

Step 4 Gently close back of housing. DO NOT FORCE. Step 5 Turn swivel locking knob clockwise until safety locking lever is seated

If housing does not close properly, check to ensure ( “Click “ sound will be heard ).

that camera is seated correctly

Step 6 Remove protective file from Caseback LCD Display Step 7 Remove protective films from Lensport before starting to take photos

underwater

HOUSING CARE AND MAINTENANCE

1. Rinse housing thoroughly with fresh, clean water after each use. Be sure to rinse buttons well as salt residue will cause buttons stick.

2. Check both O-Rings on housing front and case back every time housing is opened or closed to ensure they are clean and free of debris,

3. Keep O-Rings lightly lubricated with Silicone Oil.

4. Do not try and remove inner O-ring housing front unless replacing it.Inner O-ring is glued in.

5. Store housing in open, unlocked position so O-ring does not flatten.

6. Store in a cool and dry place.

7. Remove batteries from camera when storing

INSTALLATION OF OPTIC CABLE CONNECTOR FOR EXTERNAL FLASHES

Step 1 Peel-off backing film of the adhesive tape Step 2 Gently press and fit the Connector base onto the camera flash window

Step 3 Plug the Optic Cable Jacks into the connector holes Step 4 Connect the other end of the Optic Cable Jacks to your external

flash

NOTICE:-

IF ONLY SINGLE EXTERNAL FLASH IS USED, INSERT THE SOFT JACK INCLUDED TO COVER ONE HOLE OF THE OPTICAL CABLE CONNECTOR

TO AVOID ACCIDENTAL TRIGGERING OF OTHER DIVER’S EXTERNAL FLASHES USING SLAVE SENSORS

ULTRAMAX Product Warranty

Ultramax provides warranty on products purchased from authorized dealers OR official ULTRAMAX website online store only. Copy of the purchase receipt

must accompany all warranty returns. Warranty will not be supported for Purchases from unauthorized dealers.

STANDARD LIMITED WARRANTY

ULTRAMAX warrants its products against defects in material and workmanship for ONE year from Date of Purchase. Pursuant to this Limited Warranty,

ULTRAMAX will, at its option, repair or replace the defective products. Repair and/or replacement may include the use of refurbished parts or products.

"Refurbished" means products or parts that have been factory restored to their original specifications and qualities.

Warranty coverage only applies to the original purchaser purchased from ULTRAMAX’s authorized dealers or official ULTRAMAX website online store. Proof

of Purchase must be included with all warranty returns.

To obtain warranty service, contact ULTRAMAX to obtain a Return Authorization number (RA No) AND Return Address details (FOR USA ONLY). Product

and Proof of Purchase must be returned, freight prepaid, to ULTRAMAX with RA number clearly marked on the package. Product must be sent in original or

comparable packaging that safely protects the contents. It is the owner's responsibility to back up and save all data, video files and photos or software.
