UMAX Technologies visionbook 12WRx User manual

12WRx
EN·CZ·SK·PL·HU
GRAY
RED
YELLOW
TU
RQ
U
O
IS
E

12WRx
USER MANUAL
ENGLISH

| EN | 4 |
× OVERVIEW
12
13 13
14
8
9
10
12
11
345 66 7
15
16
17
1. webcamera
2. LCD screen
3.
4. caps lock indicator
5. num lock indicator
6. microphone
7.
8. touchpad
9. USB 3.0
10. charging port and charging indicator
11. mini-HDMI video output
12. USB Type-C (data transfer)
13. speakers
14. M.2 SATA SSD 2280
15. USB 2.0
16. 3.5mm audio jack (headphones+microphone)
17. microSD card slot
| EN | 4 |

| EN | 5 |
× TURNING ON
Press and hold the for a couple of seconds to
turn on your computer. Charge your computer before first use.
× CHARGING
To charge your computer, connect the provided charger to the
charging port. Do not use other than the provided charger for
charging your computer.
You can see the charging status by looking at the charging
indicator.
Red light - charging in progress
Green light - charging finished
× OTHER INDICATORS
Solid light - computer is turned on
Blinking light - computer is in sleep mode
Caps Lock indicator
Solid light - Caps Lock is turned on
Num Lock indicator
Solid light - Num Lock is turned on

| EN | 6 |
× GET STARTED WITH TIPS IN WINDOWS
Find surprising things you can do in Windows with the Tips app
– it’s included in Windows 11. To find the app, choose Start >
Tips on your device.
× KEYBOARD SHORTCUTS IN WINDOWS
Launches Start menu
Launches Action Center
+
Shows Desktop
+
+Launches File Explorer
+Launches Settings
+Launches Cast panel
Locks your computer
+
| EN | 6 |

| EN | 7 |
Minimazes all applications
+
Launches Search
+
Launches Project panel
+
Launches Run
+
Launches Accessibility settings
+
Launches context menu of the Start button
+
Launches Magnifier and zooms in screen
+
Zooms out screen in Magnifier
+
× KEYBOARD SHORTCUTS WITH FN KEY
+Enables or disables the touchpad
+Puts the laptop into Sleep mode
Launches emoticons and symbols
+

| EN | 8 |
Turns the screen
+
Turns the speaker
+
Turns the speaker volume down
+
Turns the speaker volume up
+
Decreases display brightness
+
Increases display brightness
+
Turns Airplane mode
+
Skip to previous track or rewind
+
Play or pause
+
Skip to next track or fast forward
+
Toggles the display mode
+
Insert
+
Enables or disables Num Lk
+
| EN | 8 |

| EN | 9 |
× TOUCHPAD GESTURES IN WINDOWS
Slide Horizontally Slide Vertically
Slide Diagonally
Prt Scr
+
Pg Up Home
+ +
Pg Dn End
1 2 3 4
5 6 7 8
9 0 . +
- * /
+ +
× NUMERIC KEYBOARD
Tap & Double Tap
Tap an app to select it.
Double tap an app to launch it.

| EN | 10 |
Drag and Drop
Double tap an item then slide the same finger
To drop the item to its new location lift your
finger.
Left Click
Click an app to select it.
Double click an app to launch it.
Right Click
Click to open the right-click menu.
Two Finger Tap
Tap two fingers to simulate the right-click
function.
Two Finger Scroll (Up/Down)
Slide two fingers up or down to scroll.
Two Finger Scroll (Left/Right)
Slide two fingers left or right to scroll.
Zoom Out
Bring together two fingers to zoom out.
Zoom In
Spread apart your two fingers to zoom in.
Two Finger Drag and Drop
Select an item and then press and hold
the left button. Using your other finger
slide on the touchpad to drag the item.
| EN | 10 |

| EN | 11 |
Three Finger Tap
Tap three fingers to invoke Search.
Three Finger Swipe Left/Right
Swipe three fingers left or right to switch
between open apps.
Three Finger Swipe Up
Swipe three fingers up to open Task View.
Three Finger Swipe Down
Swipe three fingers down to show desktop.
Four Finger Tap
Tap four fingers to invoke Action Center.
× ADDING MICRO-SD CARD
Insert the microSD card (microSD,microSDHC or microSDXC)
in the correct direction and orientation as shown on the image
below. Improper way may damage the card or the slot in the
laptop. The maximum supported capacity is 128 GB.

| EN | 12 |
× ADDING M.2 SATA SSD STORAGE
You can add a storage space for saving files and installing
programs by adding an M.2 SATA SSD drive. Important: The
M.2 SSD must be a SATAtype, NVMe is not supported! The
supported length of M.2 SATA SSD is 2280.
2. Unscrew the hatch on the back side of your laptop.
3. Insert the M.2 SATA SSD in the orientation shown on the
picture.
4. Screw the security screw to hold the SSD in place.
5. Screw back the protection hatch.
New SSD drive might need to be initialized and formatted
before it can be used.
1. Press Windows + X to open Windows context menu.
2. Select Disk Management.
3. Pop up window will appear. Follow the steps to initialize the
drive and format it as NTFS.
| EN | 12 |

| EN | 13 |
× SAFETY INFORMATION
Operating temperature: 10° to 35° C, storage temperature: -25° to 45° C, relative
humidity: 0% to 90% (noncondensing).
Built-in battery. Do not attempt to replace or remove the battery yourself. You
may damage the battery, which could cause overheating and injury. The battery
should be replaced by an authorized service provider, and must be recycled or
disposed of separately from household waste.
Handle with care. It has sensitive electronic components inside. Place it on a
stable work surface that allows for air circulation under and around the computer.
Your computer can be damaged if dropped, burned, punctured, or crushed,
or if it comes in contact with liquids, oils, and lotions. Do not use a damaged
computer as it may cause injury.
Liquid exposure. Keep your computer away from sources of liquid, such as
drinks, oils, lotions, sinks, bathtubs, shower stalls, and so on. Protect your
computer from dampness, humidity, or wet weather, such as rain, snow, and fog.
Charging. Charge only with the included power adapter. Other power adapters
might not meet safety standards, and using such power adapters could pose a
risk of death or injury. Using damaged power adapters or cables, or charging
when moisture is present, can cause fire, electric shock, injury, or damage to your
computer or other property. Do not use a power adapter in wet locations, such as
near a sink, bathtub, or shower stall, or connect or disconnect the power adapter
with wet hands.
Medical device interference. It contains components and radios that emit
electromagnetic fields, including magnets, which may interfere with pacemakers,
defibrillators, and other medical devices. Maintain a safe distance between
your medical device and computer. Consult your physician and medical device
manufacturer for information specific to your medical device.
Repetitive motion. When you perform repetitive activities such as typing or
playing games, you may experience discomfort in your hands, arms, wrists,
shoulders, neck, or other parts of your body. If you experience discomfort, stop
using computer and consult a physician.
Choking hazard. Some accessories may present a choking hazard to small
children. Keep these accessories away from small children.
High-consequence activities. Your computer is not intended for use where
the failure of the computer could lead to death, personal injury, or severe
environmental damage.
Explosive and other atmospheric conditions. Using computer in any area with a
potentially explosive atmosphere may be hazardous—particularly in areas where
the air contains high levels of flammable chemicals, vapors, or particles such as
grain, dust, or metal powders. Exposing computer to environments having high
concentrations of industrial chemicals, including evaporating liquified gases such
as helium, may damage or impair its functionality.

| EN | 14 |
© 2021 Umax Czech a.s. All rights reserved. Umax, Umax logo, Visionbook and Visionbook logo are
trademarks of Umax Czech a.s. Windows is a registered trademark of Microsoft Corporation.
All other trademarks are the property of their respective owners.
× TECHNICAL SUPPORT AND SERVICE
CENTER
[phone]
[email protected]
Umax Czech a.s.
Kolbenova 962/27e
198 00 Prague 9
Czech Republic
× MANUFACTURER
Umax Czech a.s., Kolbenova 962/27e, 198 00 Prague 9,
Czech Republic
Importer hereby declares that this wireless device is in
compliance with the essential requirements and other relevant
provisions of the R&TTE Directive and Radio Equipment
Directive 2014/53/EU, as applicable. A copy of the EU
Declaration of Conformity is available at www.umax.cz.
Do not dispose of electrical appliances as unsorted municipal
waste, use separate collection facilities. Contact your local
authority for information regarding the collection systems
available. If electrical appliances are disposed of in landfills or
dumps, hazardous substances can leak into the groundwater
and get into the food chain, damaging your health and well-
being. Please contact your local or regional waste authority for
more information on collection, reuse and recycling programs.

UŽIVATELSKÝ MANUÁL
ČEŠTINA
12WRx

| CZ | 18 |
× SEZNÁMENÍ S NOTEBOOKEM
12
13 13
14
8
9
10
12
11
345 66 7
15
16
17
1. webkamera
2. LCD obrazovka
3. indikátor zapnutí
4. indikátor caps lock
5. indikátor num lock
6. mikrofon
7. tlačítko pro zapnutí
8. touchpad
9. USB 3.0
10. port pro nabíjení a indikátor nabíjení
11. mini-HDMI video výstup
12. USB Type-C (přenos dat)
13. reproduktory
14. slot pro M.2 SATA SSD 2280
15. USB 2.0
16. 3.5mm audio jack (sluchátka+mikrofon)
17. slot pro microSD kartu
| CZ | 18 |

| CZ | 19 |
× ZAPNUTÍ
Na několik sekund zmáčkněte a podržte tlačítko pro zapnutí
pro zapnutí počítače. Před prvním zapnutím jej nabijte.
× NABÍJENÍ
Pro nabití počítače zapojte dodanou nabíječku (12V 2A) do
portu pro nabíjení. Nepoužívejte jinou než dodanou nabíječku
pro nabíjení vašeho počítače.
Stav nabíjení se zobrazuje na indikátoru nabíjení.
Červené světlo - probíhá nabíjení
Zelené světlo - nabíjení dokončeno
× DALŠÍ INDIKÁTORY
Indikátor zapnutí
Nesvítí - počítač je vypnutý
Svítí - počítač je zapnutý
Bliká - počítač je v režimu spánku
Indikátor Caps Lock
Svítí - režim Caps Lock je zapnutý
Indikátor Num Lock
Svítí - numerická klávesnice je zapnutá

| CZ | 20 |
× ZAČÍNÁME S APLIKACÍ TIPY VE
WINDOWS
V aplikaci Tipy najdete překvapivé věci, které můžete ve
Windows dělat – je součástí Windows 11. Pokud chcete aplikaci
najít, zvolte Start > Tipy.
× KLÁVESOVÉ ZKRATKY VE WINDOWS
Otevře nabídku Start
Otevře Centrum akcí
+
Zobrazí desktop
+
Spustí Průzkumník souborů
+
Otevře Nastavení
+
Otevře panel Vysílat
+
Zamkne počítač
+
Minimalizuje všechny aplikace
+
+Spustí Hledání
| CZ | 20 |
