PS4000 and PS5000
Touchscreen Programmable Thermostat
Installation and Owners Manual

IMPORTANT SAFETY INFORMATION
WARNING: ELECTRICAL SHOCK HAZARD – Turn off power at the main
power source by unscrewing fuse or switching circuit breaker
to the OFF position before installing, removing, or cleaning
this thermostat.
WARNING: FIRE AND ELECTRIC SHOCK HAZARD – This device should be
installed by a qualified service technician with due regard
for safety as improper installation could result in a fire and
electric shock hazard.
WARNING: FIRE AND ELECTRICAL SHOCK HAZARD – This is a 24V AC
low-voltage thermostat. Do not install on voltages higher than
30V AC.
• Donotswitchsystemtocoolifthetemperatureisbelow50°F(10°C).Thiscan
damageyourcoolingsystemandmaycausepersonalinjury.
• Donotshort(jumper)acrossterminalsonthegasvalveoratthesystemcontrol
totestinstallation.Thiswilldamagethethermostatandvoidthewarranty.
• Donotconnectgroundtoanyterminalinthisunit.
• Allwiringmustconformtolocalandnationalbuildingandelectricalcodesand
ordinances.
• Usethisthermostatonlyasdescribedinthemanual.

PS4000/PS5000 Touchscreen Programmable Thermostat
Contents
Application/Features................................................................................................................2
Specifications.........................................................................................................................4
Installation..............................................................................................................................13
Wiring............................................................................................................... ......................17
PowertheThermostat............................................................................................................34
Installer Set-up.......................................................................................................................47
Installer System Test..............................................................................................................58
Owners Manual......................................................................................................................61
Programming.........................................................................................................................67
Troubleshooting.....................................................................................................................94
1

PS4000/PS5000 Touchscreen Programmable Thermostat
PRODUCTDATA
APPLICATION
The PS5000 Touchscreen Programmable Thermostat is an effortless,7-Day programmable
thermostat that provides universal system compatibility, precise comfort control and is
easy to program.
The PS5000 Thermostat provides temperature controlfor gas, oil, electric, millivolt, and heat
pumps for up to 3 heat /2 cool systems including dual fuel operation plus dehumidification
control.
2
The PS4000 Touchscreen Programmable Thermostat is an effortless, 7-Day programmable
thermostat that providesuniversal system compatibility, precise comfort control and is
easy to program.
The PS4000 Thermostat provides temperature control for gas, oil, electric, millivolt and
heat pump for 1 heat /1 cool systems including dual fuel operation.

PS4000/PS5000 Touchscreen Programmable Thermostat
FEATURES
·Large, clear display with backlight shows current temperature, set temperature and
thermostat in the dark.
·Menu-driven programming make set-up effortless.
·Beautiful ergonomic design is smart and sophisticated.
·Touchscreen interaction.
·Real-time clock keeps time during power failures and automatically updates to
daylight savings.
·Saving Changes notification lets you know when the schedule changes have been
saved.
·Change/check reminders let you know when to service or replace filters or batteries.
·Various Holdoptions allow you to override the program schedule as desired.
·Armchair programming allows you to remove the thermostat from the wall for
programming.
3

PS4000/PS5000 Touchscreen Programmable Thermostat
SPECIFICATIONS
Thermostat Description:
noitpircseDerutaeF
Powering methods 24V AC common wire or AA batteries
System types
PS4000 (1 Heat/1 Cool)
PS5000 (3 Heat/2 Cool)
·Gas, oil or electric heat with air conditioning
·Warm air, hot water, high-efficiency furnaces, heat
pumps, steam and gravity
·Heat on
ly inclu des po
w
er to open and powe
r
to
close zonevalves and normally-open
zone valves
·Heat only with fan
·Cool only
·750 mV heating systems
elbatcelesrevoegnahcotuArolaunaMAuto changeover
Heat-Off-Cool-Auto (EMER for heat pumps)gnittesmetsyS
Auto-On-CircgnittesnaF
4

PS4000/PS5000 Touchscreen Programmable Thermostat
Electrical Ratings:
Temperature Setting Range:
Heating: 40°F to 90°F (4°C to 32°C)
Cooling: 50°F to 99°F (10°C to 37°C)
Operating Ambient Temperature:
32°F to 120°F (0°C to 49°C)
Shipping Temperature:
-30°F to 150°F (-34.4°C to 65.6°C)
5
Terminal Voltage (50/60 Hz) Running Current
W Heating 20 - 30V AC 1 Amp max.
W Heating (Power pile) 750 mV DC 100 mAmp
Y Cooling 20 - 30V AC 1 Amp max.
G Fan 20 - 30V AC 1 Amp max.

PS4000/PS5000 Touchscreen Programmable Thermostat
Operating Relative Humidity (Non-condensing):
5% to 90%
Cycle Rates (at 50% Load):
Heating: Selectable 1 - 12 cycles per hour
Cooling: Selectable 1 - 6 cycles per hour
Clock Accuracy: +/- 1 minute per month
6
Batteries:
Two replaceable AA alkaline batteries will power the thermostat when 24V AC
common is not
used. A non-replaceable lithium batte
r
y with ten-year life is inside the thermostat. Unde
r
normal use the lithium battery will maintain the calenda
r
and time settings. The alkaline
batteries maintain the calenda
r
and time after lithium battery is no longer functional.

PS4000/PS5000 Touchscreen Programmable Thermostat
Cool Indication:
Touchscreen Thermostats show "Cool On" on the screen when Cool is activated.
Heat Indication:
Touchscreen Thermostats show "
Heat On " on the screen when Heat is activated.
7
Auxiliary Heat Indication:
PS5000 Touchscreen Thermostats show "
Au x Heat On" on the screen when Auxiliary
Heat is activated.
Emergency Heat Indication:
PS5000 Touchscreen Thermostats show "
He at On" on the screen when Emergency
Heat is activated and the System mode is in the EMER position.
Calibration:
Touchscreen Thermostats are factory-calibrated and require no field calibration.

PS4000/PS5000 Touchscreen Programmable Thermostat
Nomenclature:
Series System Stages
A
pplication
PS4000 1 Heat / 1 Cool PS4000 - Standard
3 Heat / 2 Cool PS5000 - Standard
PS5000
Mounting Means:
Touchscreen Thermostat: Mounts directly on the wall in the living space using mounting
screws and anchors provided.
Outdoor Sensor: Mounts outside of living space with mounting clips and screws provided.
Remote Indoor Sensor: Mounts directly on the wall using mountingscrews and anchors
provided.
8
Dimensions:
1. TouchscreenThermostat: see Figure 1
2. Touchscreen Thermostat Back Case: see Figure 2
3. Outdoor Sensor Mounting Clip: see Figure 3
4. CoverPlate: see Figure 4

PS4000/PS5000 Touchscreen Programmable Thermostat
9
Figure 1. Touchscreen The
r
mostat dimensions in inches. (mm).
5.98 in.(152mm)
4.48in. (114mm)
1.235in.(30.60mm)

PS4000/PS5000 Touchscreen Programmable Thermostat
10
Figure 2. Touchscreen The
r
mostat Back Case dimensions in inches. (mm).
1.51 in.(38.5mm) 0.84 in .(21.5mm)
1.77 in.(45mm)
1.67 in.(42.5mm)

PS4000/PS5000 Touchscreen Programmable Thermostat
Figure 3. Outdoor Senso
r
Mounting Clip dimensions in inches. (mm).
11
R1.6in.(4mm)
1.82 in.(46.3mm)
R0.04in.(1mm)
R0.098 in.(2.5mm)
1.10 in.(28.1mm)
0.62 in.(16mm)
1.56 in .(39.7mm)
0.24 in.(6.2mm)
0.44 in .(11.2mm)
R0.098in.(2.5mm)
0.08 in.(2mm)
1.49 in.(38mm)
0.17in.(4.2mm)

PS4000/PS5000 Touchscreen Programmable Thermostat
Figure 4. Cover Plate dimensions in inches. (mm).
12
3.29 in.(83.5mm)
0.85in .(21.5mm)
3.29 in.(83.5mm)
5.35 in.(136mm)
4.13 in.(105mm)

PS4000/PS5000 Touchscreen Programmable Thermostat
INSTALLATION
When Installin
g
this Product
1. Read these instructionscarefully. Failure to follow the instructionscan damage the
product or cause a hazardouscondition.
2. Check the ratings given in the instructions to make sure the product is suitable for your
application.
3. Installer must be a trained, experienced service technician.
4. After completing installation, use these instructions to verify the product is operating
properly.
Selectin
g
Location
Install the thermostat about 5 ft. (1.5m) above the floor in an area with good air circulation at
average temperature. See Figure 5.
Do not install the thermostat where it can be affected by:
• Drafts or dead spots behind doors and in corners.
• Hot or cold air from ducts.
• Radiant heat from sun or appliances. Concealed pipes and chimneys.
• Unheated (uncooled) areas such as an outside wall behind the thermostat.
13

PS4000/PS5000 Touchscreen Programmable Thermostat
Figure 5. Selecting thermostat location.
14
5 FEET
(1.5 METERS)

PS4000/PS5000 Touchscreen Programmable Thermostat
Installin
g
Wall Plate
CAUTION
Electrical Hazard.
Can cause electrical shock or equipment damage.
Disconnect power before wiring.
The thermostat can be mounted horizontally on the wall
1. Position and level the wall plate (for location only).
2. Use a pencil to mark the mounting holes.
3. Removethe wall platefrom the wall and, if drywall, drill two holes in the wall, as marked.
For firmer material such as plaster, drill two holes. Gently tap anchors (provided) into the
drilled holes until flush with the wall.
4.
Positionthe wall plate over the holes, pulling wires through the wiring opening. See Figure 6
5. Insert the mountingscrews into the holes and tighten.
15

PS4000/PS5000 Touchscreen Programmable Thermostat
Figure 6. Mounting wall plate.
16
WALL
WIRES THROUGH
WALL AND WIRE
SLOT
WALL ANCHORS
MOUNTING
HOLES(2)
MOUNTING
SCREWS(2)

PS4000/PS5000 Touchscreen Programmable Thermostat
WIRING (FIGURE 9-21)
All wiring must comply with local electrical codes and ordinances.
1. Select the set of terminal identifications (Table 1) that corresponds with system type
(conventional or heat pump in Figure 7).
2. Loosenthescrews for the appropriate system type selected; see Table 1. See Table 2
for terminal designation descriptions. Insert wires in the terminal block under the loosened
screw. See Figure 8.
3. Securely tighten each screw.
PS4000 PS5000
4. Push excess wire back into the hole.
5. Plug thehole with nonflammable insulation to prevent drafts from affecting the thermostat.
6. See Figure 9 through 21 for typical wiring hookups.
Figure 7. Selecting terminal identifications for system type.
17
S1 S2 C R RC E L Y2 YG
S1 S2 CRRC W W2 Y2 Y G
O/B AUX
CONVENTIONAL
HEAT PUMP
SCREW
TERMINALS
S1 S2 C R RC L
S1 S2 C R RC W Y G
O/B
Y G

PS4000/PS5000 Touchscreen Programmable Thermostat
Table 1. Selecting Terminal Identifications for System Type.
System TypeModel Wall Plate Terminal
Identifications
Wiring Diagram
Figures
Standard Heat/Cool Conventional 9, 10
lanoitnevnoCylnOtaeH
PS4000
PS5000
PS4000
PS5000
PS4000
PS5000
PS4000
PS5000
PS4000
PS5000
PS5000
PS4000
PS5000
PS5000
PS4000
PS5000
11
Heat Only with Fan Conventional 12
Hea
t
Onl
y
Powe
r
to openandpowe
r
to close zone valves Conventional 13
Normall
y
Open Zone Valves Heat Onl
y
Conventional 14
lanoitnevnoCylnOlooC 15
Standard Multistage up to 3 Heat/2 Cool Conventional 16, 17
Heat Pump with No Auxiliary Heat Heat Pump 18, 19
Heat Pump with Auxiliary Heat Heat Pump 20, 21
18
