Uni-Line Smart Sense SMART 3000 User manual

SMART 3000 Touchscreen Thermostat
Quick Start Guide
www.robertshaw.com
©2015 Robertshaw 7/15 – 352-00198-001 RevB
by Uni-Line®

2
IMPORTANT SAFETY INFORMATION
WARNING: ELECTRICAL SHOCK HAZARD – Turn off power at the main
power source by unscrewing fuse or switching circuit breaker
to the OFF position before installing, removing, or cleaning
this thermostat.
WARNING: FIRE AND ELECTRIC SHOCK HAZARD – This device should be
installed by a qualified service technician with due regard
for safety as improper installation could result in a fire and
electric shock hazard.
WARNING: FIRE AND ELECTRICAL SHOCK HAZARD – This is a 24V AC
low-voltage thermostat. Do not install on voltages higher
than 30V AC.
• Do not switch system to cool if the temperature is below 50°F (10°C). This
can damage your cooling system and may cause personal injury.
• Do not short (jumper) across terminals on the gas valve or at the system control
to test installation. This will damage the thermostat and void the warranty.
• Do not connect ground to any terminal in this unit.
• All wiring must conform to local and national building and electrical codes
and ordinances.
• Use this thermostat only as described in the manual.

3
Thank you for purchasing a SmartSense
TM
thermostat by Uni-Line
®
. The SMART 3000
isamul-funconthermostat.Severalconguraonsmaybeprogrammed
throughthebuoninterfaceorremotely,usingModbuscommunicaons.
Thisisaquickstartguideonhowtoperformthebasicinstallaon,programming
andtesngoftheSMART3000soitfunconsasasingle-stage,manual
thermostat.
Onlythestepsneededtoprovideafunconingthermostatwithminimalfeatures
andprogrammingwillbediscussed.Whennished,thethermostatwillbe
operaonalforthefollowing:
• Manual thermostat
• 1 Speed Fan
• 1 Heat/1 Cool
• 2 pipe mode
• Thermostat controlled fan
• Short cycle timer at five minutes
• Single setpoint

4
Mounting the SMART 3000 Thermostat
IMPORTANT: The SMART 3000 can only be as accurate as the onboard
temperaturesensor,oritsoponalremotetemperaturesensor(s)
permit. The SMART 3000 should be mounted in a location that is
typical of the ambient room temperature. Do not install near the
floor,inadraft,behindadoor,oronanon-insulated,exteriorwall.
InstalltheSMART3000awayfromexposuretosunlightandfourto
five feet (1.2 to 1.5 m) above the floor.
Figure 1
• Locate the slot on the housing at the bottom. Take note of the hinge points
and the connection between the two halves.
• Insert a screwdriver or coin into the slot and twist. This will separate the two
halves.

5
• Continue to swing the top half upward. This will release the tabs holding the
top half in place.
• Pull the control wires through the large opening in the base plate.
• Position the base plate on the wall and attach it with appropriate fasteners
(two screws with drywall anchors are supplied). The base plate should be
visibly level.
• Block any holes where wires are pulled through a wall opening. This will
prevent drafts from entering the back of the thermostat.
Do not use
these holes for
mounting.
Figure 2
IfthisinstallaonwillbeusingModBuscontrolsorremotesensors,becertainto
includetheproperwirestomakethoseconnecons.

6
Switch Set-Up
LocatetherowofeightfunconDIPswitches.
Figure 3
Switch 1 2 3 4 5 6 7 8
Position OFF OFF ON ON ON OFF OFF OFF
NOTE: ThiswillconfiguretheSMART3000asamanualheat/cool,singlestage,
single setpoint thermostat.

7
Wiring
Terminal Funcon
C 24V Common or Neutral
R 24V AC - This voltage is switched back through the relays
Hi Indoor Fan High Speed (NOT Used in Single fan speed mode -
Sw 1 = OFF)
Med Indoor Fan Medium Speed (NOT Used in Single fan speed mode -
Sw 1 = OFF)
Low Indoor Fan Low Speed (Used in single and three fan speed mode)
Y Compressor or Cool - (Based on Sw 2 setting)
W - O/B Reversing Valve or Heat - (Based on Sw 2 setting)
A1 – Cool 0 to 10V Output for Cooling (Typically used to control modulating valves)
A2 – Heat 0 to 10V Output for Heating (Typically used to control modulating valves)
A3 – Fan 0 to 10V Modulating Output for Indoor DC Fan
Com – 0V 0Vterminal-Usedfor0to10V,sensorordigitalinputsgroundreference
A ModBus Data A
B ModBus Data B
SI Remote temperature sensor input (Remote/average/ModBus data use)
DI Digital (Switched input) for forced unoccupied or initiate doorbell
function

8
Terminal Funcon
WC Window Contact - Forces SMART 3000 OFF if window open > five min
(Adjustable)
DS Door Switch – Monitors room door status for occupancy detection
PIR PIR (Movement sensor) input for occupancy detection
TheSMART3000ispoweredby24VACandrequiresthe24VACacveand
neutraltobeconnectedtotheR(acve)andC(Neutral)terminalstofuncon.
The 24V AC applied to the SMART 3000 R terminal is switched back through the
2A relays to the equipment.
Figure 4

9
Fan
Cool
Heat
24 V AC
24 C Neutral
Figure 5
Close the Cover
• Hold the cover up and connect the top hinge points between the two halves.
• Position the top cover with the pins in the base plate openings.
• Swing the top half downward until it snaps in place. The electrical pins at the
bottom will slide into the terminal strips.

10
Apply Power
• Apply the 24V AC power to the SMART 3000. The screen should display the
current temperature.
Test
Eachpressofabuonshouldproduceanaudiblebeep.
Figure 6
• Press the Fan button to test the fan operation.
• Use the Up and Down arrow buttons to adjust the setpoint.
• Adjust the setpoint five degrees above the room temperature. After a few
moments the heating system should come ON.
• Adjust the setpoint five degrees below the room temperature. After a few

11
moments the heat system will stop. The cooling system should come ON.
NOTE: There may be a delay of up to four minutes performing this test due to
anticycle delay timer.
The SMART 3000 system is now operational. It will function as a single
setpoint, manual thermostat with a single speed fan.
