Uniden R3 User manual

LONG RANGE Radar/Laser Detector
User’s Manual
R3
© 2019 Uniden America Corporation
Irving, Texas
Issue 5, January 2019
Printed in Korea

CUSTOMER CARE
At Uniden®, we care about you!
If you need assistance, please do NOT return this product to your place of purchase
Save your receipt/proof of purchase for warranty.
Quickly find answers to your questions by:
• Reading this User’s Manual.
• Visiting our customer support website at www.uniden.com.
Images in this manual may differ slightly from your actual product.
DISCLAIMER: Radar detectors are illegal in some states. Some states prohibit
mounting any object on your windshield. Check applicable law in your state and
any state in which you use the product to verify that using and mounting a radar
detector is legal. Uniden radar detectors are not manufactured and/or sold with the
intent to be used for illegal purposes. Drive safely and exercise caution while using
this product. Do not change settings of the product while driving. Uniden expects
consumer’s use of these products to be in compliance with all local, state, and
federal law. Uniden expressly disclaims any liability arising out of or related to your
use of this product.

CONTENTS
CUSTOMER CARE.......................................................................................................... 2
R3 OVERVIEW .............................................................................................5
FEATURES ........................................................................................................................ 5
WHAT’S IN THE BOX...................................................................................6
PARTS OF THE R3........................................................................................6
NON-KEY ELEMENTS .................................................................................................. 8
POWER CORD................................................................................................................. 8
OLED DISPLAY .............................................................................................................10
INSTALL AND TURN ON R3..................................................................... 11
INSTALL/POWER ON..................................................................................................11
Windshield ............................................................................................................11
Dashboard.............................................................................................................12
MENU SYSTEM......................................................................................... 12
BASIC OPERATIONS ................................................................................ 19
FEATURE DETAILS ................................................................................... 20
AUTO DIM......................................................................................................................20
Set DIM to Auto from the R3/Power Cord..................................................20
Congure Auto from MENU............................................................................21
USER MARKS (LASER AND RADAR SITES).........................................................22
RED LIGHT CAMERA POINT DELETE ...................................................................22
HIGHWAY VS CITY MODE ........................................................................................22
POP MODE ....................................................................................................................23
SCAN DISPLAY .............................................................................................................23
MODE DISPLAY............................................................................................................24
TIME DISPLAY...............................................................................................................24
ALARM PRIORITIES.....................................................................................................24
THREATS.........................................................................................................................25
MUTE MEMORY...........................................................................................................25
AUTO MUTE/AUTO MUTE VOLUME.....................................................................25
USER SPEED LIMIT......................................................................................................26
QUIET RIDE....................................................................................................................26

RED LIGHT CAMERA QUIET RIDE .........................................................................26
MAINTENANCE........................................................................................ 27
MAINTAINING THE EQUIPMENT ...........................................................................27
UPDATING THE FIRMWARE/DATABASE .............................................................27
TROUBLESHOOTING............................................................................... 27
SPECIFICATIONS ..................................................................................... 28
FCC/IC COMPLIANCE .............................................................................. 28
FCC COMPLIANCE......................................................................................................28
IC COMPLIANCE..........................................................................................................29
ONE-YEAR LIMITED WARRANTY ........................................................... 29

- 5 -
UNIDEN
LONG RANGE RADAR/LASER DETECTOR
USER’S MANUAL
R3
R3 OVERVIEW
Uniden’s R3 is a top of the line Radar Detector with a built-in GPS feature. With
the R3, you can mark geographical points where you commonly encounter radar
transmissions. These can be school zones, red-light cameras, and places where police
frequently monitor traffic. You can mark these points so the detector will announce
“User mark ahead” when you approach them. Among other announcements, the
Voice Notification feature lets you know when you are approaching a radar and what
type of radar it is (red light, speed, etc).
FEATURES
• Super Long Range Laser Radar Detection
• MRCD/MRCT (Alert priority: Laser, MRCD, Ka, K, X) with customizable tones
• Voice Notifications
• Radar band frequency displays
• GPS for Red Light and Speed camera locations
• Up to 500 GPS lockouts
• Easy to read OLED display
• User Mark set and voice notification
• Advanced K and Ka band filters
• Spectre I and IV undetectable
• Displays Signal Strength and Vehicle Battery Voltage
• Max. Speed Warning System
• Red light camera point delete
• X, K, MRCD, Ka, and Laser band selectable alert tones
• Bogey tone (Alert tones 1 - 5)
• X, K, and Ka band user-defined sensitivity levels
• Auto mute volume levels (Off, On: 0 - 5)
• Ka Frequency Voice Alert
• Auto Dim
• Overspeed Alert Mute

- 6 -
WHAT’S IN THE BOX
R3 Radar
Detector
12V DC Power
Cord with RJ11
Connector
Windshield
Mounting Bracket
(1 Suction Cup)
Windshield
Mounting
Bracket
(2 Suction Cups)
Not Shown:
Hook and Loop Fastener Tape
Owner’s Manual
PARTS OF THE R3
Audio
Jack
Power
Jack
POWER
VOL +
MENU
VOL −
USB
Eagle
Eye
Latch
Slot
MUTE/DIM
MARK
Latch
Release
K
R
A
M
KEY PRESS TO... PRESS AND HOLD TO ...
POWER Turn R3 on and off. NA
VOL + Turn volume up (7 levels: 0 - 6; Default = 4).
In Menus, go to next item.
Quickly turn volume up or
down.
VOL – Turn volume down (7 levels: 0 - 6; Default
= 4).
In Menus, go to previous item.
MENU Access the Menu system.
In Menus, press to cycle through options
for the current menu item.
When in Menu mode, exit
the Menu system.
When NOT in Menu mode,
changes modes between
Highway, City, and
Advanced.

- 7 -
KEY PRESS TO... PRESS AND HOLD TO ...
MUTE/
DIM
MUTE
MUTE on - Press MUTE/DIM to mute
an alarm. Returns to normal operation
10 seconds after the alert ends or if a
different band is detected during Mute
mode. Mute On displays for a few
seconds.
MUTE off - Press MUTE/DIM to restore
audible alarms before the 10 second
automatic mute time-out.
MUTE MEMORY
Save a Mute Location (Mute Memory) -
press MUTE/DIM again while Mute On
displays to save that GPS location and
frequency to memory. Mute Memory
displays on the screen.
R3 stores up to 500 Mute Memory points.
Delete Mute Memory - Press MUTE/
DIM while Mute Memory displays; the R3
displays a delete confirmation message.
Press MUTE/DIM again to confirm.
MUTE RED LIGHT CAMERA VOICE ALERT
Mute the voice alert for a red light camera
alarm. Press MUTE/DIM while the voice
alarm for a red light camera sounds. The
voice alarm mutes.
MUTE ALERTS FOR POI OVERSPEED ALERT
AND USER LIMIT SPEED
When R3 alerts you to an overspeed or
speed limit situation (an alarm sounds and
the alert displays), you can press MUTE/
DIM to silence that alarm.
DIM - Changes the
display and key backlight
brightness:
Auto (Default). Set 2
automatic time periods
and brightness levels for
the OLED display (see page
17).
Bright
Dim
Dimmer
Dark (Dark is off unless
there is alert.)
Off (Off regardless of
whether or not there is
an alert.)
DURING RED LIGHT
CAMERA ALERT
Press and hold MUTE/
DIM to delete the red light
camera point.
RED LIGHT CAMERA POINT
DELETE
When R3 alerts you to a
red light camera (the alert
displays), you can press
and hold MUTE/DIM to
delete that camera point.
After confirming this
deletion, R3 will not give
an alert for that camera.
MARK User Mark. A User Mark is a manually
tagged geographic location where an
alarm is usually found. The R3 alerts when
close to these User Marks.
Add - Press MARK when you are at the
alarm location.
Delete - Press MARK when you are at an
alarm location that has been marked.
An error message displays/sounds if
memory is full or there is a GPS error.
Delete all User Marks.

- 8 -
NON-KEY ELEMENTS
ELEMENT WHAT IS DOES
Eagle Eye Provides a 360° monitoring radius.
Latch Slot Insert the bracket latch into this slot.
Mini USB Provides PC connection for data updates.
Audio Jack Plug in headset.
Eject Press to release the bracket latch.
Power Jack Plug the 12V Power Cord here.
Signal Strength Displays received signal strength (5 levels).
POWER CORD
USB port
MUTE
button
LED

- 9 -
ELEMENT WHAT IT DOES...
MUTE
button
(Although
not labeled,
press
and hold
MUTE to
access DIM
functions)
• Press the MUTE button to mute an alarm. Returns to normal
operation 10 seconds after the alert ends or if a different band is
detected during Mute mode. Mute On displays on the R3 for a few
seconds.
• Save a Mute location (Mute Memory) - press the MUTE button
again while Mute On displays on the R3 to save that GPS location
and frequency to memory. Mute Memory displays on the screen.
R3 stores up to 500 Mute Memory points.
• Delete Mute Memory - Press the MUTE button while Mute
Memory displays on the R3; the R3 displays a delete confirmation
message. Press the MUTE button again to confirm.
• Red Light Camera Point Alert Mute/Delete - When R3 alerts you
to a red light camera (the alert displays), you can press MUTE
to mute or delete (press and hold) that camera point. After
confirming this deletion, R3 will not give an alert for that camera.
• Mute Overspeed Alarms - When R3 alerts you to an overspeed or
speed limit situation (an alarm sounds and the alert displays), you can
press MUTE to silence that alarm
• Press and hold the MUTE button to change the display and key
backlight brightness.
DIM function. Press and hold for DIM options to display on the
OLED. Press the button again to scroll through and select one of the
following options:
• Auto (Default; see page 14 to set OLED brightness levels and
start times.)
• Bright
• Dim
• Dimmer
• Dark (Dark is off unless there is alert.)
• Off (Off regardless of whether or not there is an alert.)
Dim level cannot be changed during a Red Light Camera alert.
LED (Red) • Off: Power is off.
• Steady on: Power is on.
• Flashing: Receiving an alert. The faster it flashes, the stronger the
signal.
USB Port Use this USB port to charge mobile devices.

- 10 -
OLED DISPLAY
The OLED display on the front of the unit changes depending on what events are
happening.
If GPS = ON, the OLED’s left display area shows the display selected in the menus
(see page 16).
If GPS = Off, the OLED’s left display area shows Volt regardless of user settings.
The following table provides examples of the most common displays.
OLED EXAMPLES MEANING
Scanning for Frequencies
mph
42
Hwy
Displays to indicate
end of a scan cycle.

Information displayed in example:
• Speed (mph or km/h)
• Wave
• Heart icon (end of search cycle)
• Highway/City/Advanced
Frequency Found
Volt
12.8 K 24.120 GHz
Information displayed:
• Band type Type (X, K, KA)
• Frequency number
• Voltage
• Status Area (Mute Memory, Quiet Ride, etc)
Speed Camera Alarm
mph
5 8
270 ft
S p e e d
Information displayed:
• Current speed in mph/km/h
• Distance to speed camera
• Speed camera icon
Red Light Camera Alarm
mph
5 8
270 ft
Information displayed:
• Current speed in mph/km/h
• Distance to red light camera
• Red light camera icon
User Mark Detected
mph
5 8
1090 ft
Information displayed:
• Current speed in mph/km/h
• Distance to user mark
• User mark icon
