UT06 OBDII Plug & Play GPS Tracker
User Manual

UniGuard Technology Limited
www.uniguardgps.com
1. Installation Figure
Please insert a SIM Card (with GPRS, SMS and Caller ID display
service) into UT06, and connect it to OBD II interface of the Vehicle
directly. Please check the device status through LED light after power on:
LED indicates Power, it should be on when the vehicle is started.
LED indicates status of Signals.
Flashing per one second which indicates GSM registers
successfully.
Flashing per three seconds once which indicates GPS is
obtaining orientation
It is still on which indicates GSM has registered and GPS has
obtained the orientation. It’s working well.
If it is on for 0.1 second then off for 0.1 second more than 3
minutes, please make sure SIM card inserted well. Without SIM card, the
device cannot work.
2. SMS Operation Instruction
SMS Format: A******,cmd,param1,param2…
1. ******is the password, Initial Password is 000000
2. cmd is the command ID.
3. Param is the command parameter. Different cmd use
different parameters. All the parameters must use half-angle
symbol. Wrong SMS format or wrong password, it will not
respond.

UniGuard Technology Limited
www.uniguardgps.com
2.1 Location Enquiry (000)
Message format:A******,000
e.g. A000000,000
Reply:
http://maps.google.com/maps?q=22.54079,113.93923
09-10-20 17:38:30 Speed:20
You will open the website to Enquiry on google Map directly.
2.2 Change Password (001)
Message format：A******,001,New Password
e.g. A000000,001,123456
Note:000000 is the old password ,123456 is the new
password.
Reply：Set Password OK!
2.3 Real-time return setting (002)
Message format：A******,002, XXX
XXX=0 is for STOP, value of XXX is within [15~64800]
seconds.
e.g. A000000,002,30
Message replied after successful setting: Set time interval (30)
OK!
Message contains position information will be sent in every 30
seconds after successful setting.
2.4 Alarm and Listen Telephone Number setting (003)
Message format：A******,003,P, TelNumber

UniGuard Technology Limited
www.uniguardgps.com
P=1 is forAalrm and listen
P=2 or 3 is the second\ the third listen number.
e.g. A000000,003,1,136xxxxxxxx
Message replied after successful setting：Set Telephone OK!
After it’s set successfully, once there is an alarm happened, the
device will alert to Alarm Number and Tracking System by
message.
If you dial with one of these three numbers you set, it can be
connected automatically after the 3th rings. Then you can
listen the voice in the vehicle.
2.5 Over-Speed Alarm Setting (005)
Message format：A******,005,XXX
XXX=[000,200] (unit: km/h)XXX=00 is close the function.
e.g. A000000,005,020
Message replied after successful setting: Set Over speed (20)
KM OK!
If the vehicle is over speed you set, it will send alarm message
to Alarm Number: 20 KM/H Over speed!
2.6 Geo-Fence Setting(006)
Message format：A******,006,XX
XX =[00-50] (Unit:100m) .
When XX=0, e-Fence is OFF. And the maximum limited value
of XX is 50*100=5000m. e.g. A000000,006,10
Reply: Set Distance (1000)M OK!
When user is out of the bound region (e.g. 1020m), a prompt

UniGuard Technology Limited
www.uniguardgps.com
message will be sent to the user: 1020m is further than
1000m!
2.7 Restart Tracker (099)
Message format:A******,099,RESETSYSTEM.
It will restart the device after 30 seconds after receive the SMS,
it will response:Reset System OK!
3. GPRS Communication Settings
3.1 Set APN (Access Point NAME) (012)
Message format: A******,012,APN
Length ofAPN is limited within 100 characters
E.g:A000000,012,CMNET
“CMNET” is the APN of China Mobile
3.2 Set the IP and Port of GPRS Server (010)
Message format: A******,010,IP,PORT
e.g. A000000,010,104.243.132.242,5500
104.243.132.242 is the IP of GPRS_server, 5500 is the port of
GPRS Server application.
3.3 Open GPRS function (011)
Message format: A******,011,X
(note: x=1 open GPRS, X=0 close GPRS)
e.g. A000000,011,1
GPRS function will be open, and the device will send data to

UniGuard Technology Limited
www.uniguardgps.com
Internet. Users can turn off this function though send SMS:
A000000,011,0
3.4 Query the GPRS Setting (004)
Message format: A******,004
The device will send back GPRS setting parameters. You can
check whether the parameter set correctly by it.
(1) Device ID
(2) APN (Contact SIM provider to get correct APN)
(3) Server IP address
(4) Server port
(5) GPRS open status (0- off , 1- on)
(6) GPRS connecting status (0- Internet is not connected, 1- connected)
(7) GSM signal value (1~31), if it’s less than 13, the signal is too weak,
and the device can’t upload data to server automatically.
