UniGuard UM666 User manual

UniGuard Technology Limited
- - www.uniguardgps.com
1
Magnetic GPS Tracker
User Manual
UM666
Attention:
Charge is forbidden.
24Hrs per locate: 3 Years (Default)

UniGuard Technology Limited
- - www.uniguardgps.com
2
1 GPS Tracking System Introduction
Portable GPS Tracker UM660 integrates GPS and GSM functions, which could
send vehicle location and status to mobile and Internet. It utilizes GPS and LBS double
locating. Its advantage is that the builtin battery can last 2 years at reporting interval
every 24hrs. No wires connection. Place and Work. The system structure is as below:

UniGuard Technology Limited
- - www.uniguardgps.com
3
2 Product Description
2.1 Specification
Content Specifications
Dimensions 66 x 52 x 36mm
Weight 105g
Network GSM/GPRS
Band 850/900/1800/1900Mhz
GPS chip UBLOX-7
GSM Module MTK6260D
GPS sensitivity -159dBm
GPS accuracy 5m
Time to First Fix Cold status 45-120s
Warm status 35s
Hot status 1s
Battery Non-rechargeable dry battery
6000 mAh
Standby 2 years
Storage Temperature -40 to 85 ℃
Operation Temperature -20 to 55 ℃
Humidity 5%-95% non-condensing

UniGuard Technology Limited
- - www.uniguardgps.com
4
2.2 Picture and main functions:
3 Commands
Function SMS command
Set IP and Port adminip123456 104.243.132.242 8000
Set Domain and Port adminip123456 www.gpspos.net 8000
Set APN apn123456 aaa bbb ccc
Set Working Mode:1 2 3 RTC123456 2
Check Device Status check123456
Restart Device reset123456
Working Mode explanation:
LBS cannot locate out of China. Mode 2 is advised to use out of China.
【Mode 1-LBS Mode】：every 24 hours wakeup 1 time to send LBS data

UniGuard Technology Limited
- - www.uniguardgps.com
5
Send command: RTC123456 1
【Mode 2-GPS Mode】：every 24 hours wakeup 1 time to send GPS data
Send command: RTC123456 2
【Mode 3-Real time Mode】：every 60seconds time interval to send GPS data
Send command: RTC123456 3
Attention:
Attention: Don’t switch to Mode 3 randomly otherwise device
will out of battery very soon.Only use Mode 3 for urgent real time
tracking.
4 Web Tracking
5.1Login www.gpspos.net to start web tracking service with your own
account
5.2 Download wechat, register a wechat account, search
GPSCARTRACK and follow, login the system with your own account.
6 Cautions
6.1 Keep the unit dry.
6.2 Don’t use & store the unit in dusty places.
6.3 Don’t put the unit in overheated or overcooled places.
6.4 Handle carefully. Don’t vibrate or shake it violently.
6.5 Clear the unit with a piece of dry cloth.
6.6 Don’t paint the unit.

UniGuard Technology Limited
- - www.uniguardgps.com
6
UM666 Testing Guide
Before installing in vehicle, make sure all settings are ready to configure.
1) Device defaults 24 hours time interval LBS mode【Mode 1】
2) If need to switch to 24 hours time interval GPS mode【Mode 2】， steps as
below:
3) Note: device only working last 3 minutes after power on, user need finish
below SMS setting within 3 minutes; if failed then re-start device power on again to try.
Send IP SMS: adminip123456 104.243.132.242 8000
Send APN SMS:
apn123456+space+apn+space+name+space+password
Send GPS Mode SMS: RTC123456 2
Remark: If power on device at 09:00 am, then device will
wakeup for 3 minutes at 09:00 am everyday.
Insert SIM
,
Move device outside Turn on device
Send: RTC123456 2 Set IP and Port Set APN
Install in vehicle
