unispectral Monarch UNS53000 User manual

Monarch™- Multi-spectral Camera
Add-On Assembly Guide
UNS53000

Unispectral Proprietary, 2021 Page 2 of 11
TABLE OF CONTENTS
1PARTS LIST...............................................................................................................3
2TRIPOD ADD ON .......................................................................................................4
3MOBILE PHONE ADD ON .........................................................................................5
4CABLE ADD ON.........................................................................................................6
4.1 TRIPOD &CABLE ADD ONS................................................................................................................8
4.2 MOBILE PHONE &CABLE ADD ONS..................................................................................................10

Unispectral Proprietary, 2021 Page 3 of 11
1 Parts List
The MONARCH assembly kit contains the following parts:
2. Monarch Camera
3. Tripod Add On
1. M2 Screw Set
x4 short
x4 long
+
4. Cable Add On 5. Mobile Phone Add On 6. USB Cable

Unispectral Proprietary, 2021 Page 4 of 11
2 Tripod Add On
•Insert the 4 short screws into the designated slots in the back of the Tripod Add On
•Place the screws into the according threads in the back of the MONARCH camera and
screw in tightly.
x4 short
+
+

Unispectral Proprietary, 2021 Page 5 of 11
3 Mobile Phone Add On
•Insert the 4 short screws into the designated slots in the back of the Mobile Phone Add
On.
•Place the screws into the according threads in the back of the MONARCH camera and
screw in tightly.
+
+
x4 short

Unispectral Proprietary, 2021 Page 6 of 11
4 Cable Add On
•Place the USB cable in the designated slot in the Cable Add On, flat surface of the USB
plug facing up.
•Connect the USB Cable while in the add on to the MONARCH Camera.
+
+
x4 short
+

Unispectral Proprietary, 2021 Page 7 of 11
•Insert the 4 short screws into the designated slots in the back of the Cable Add On,
threading into the MONARCH Camera threads, and screw in tightly.

Unispectral Proprietary, 2021 Page 8 of 11
4.1 Tripod & Cable Add Ons
•Place the USB cable in the designated slot in the Cable Add On, flat surface of the USB
plug facing up.
•Connect the USB Cable while in the add on to the MONARCH Camera.
+
+
+
+

Unispectral Proprietary, 2021 Page 9 of 11
•Place the Tripod Add On on top of the Cable Add On so the slots are aligned
•Insert the 4 long screws into the designated slots in the back of the Cable Add On,
threading into the MONARCH Camera threads, and screw in tightly.

Unispectral Proprietary, 2021 Page 10 of 11
4.2 Mobile Phone & Cable Add Ons
•Place the USB cable in the designated slot in the Cable Add On, flat surface of the USB
plug facing up.
•Connect the USB Cable while in the add on to the MONARCH Camera.
+
+
+
x4
long
+

Unispectral Proprietary, 2021 Page 11 of 11
•Place the Tripod Add On on top of the Cable Add On so the slots are aligned.
•Insert the 4 long screws into the designated slots in the back of the Cable Add On,
threading into the MONARCH Camera threads, and screw in tightly.
