UniStream®
Technical Specifications
UAG-XKxxx, UAG-XKPxxx,
UAG-CX-XKPxxx, UAG-CX-XKPLxxxx
and UAG-XKPLxxxx
This guide provides specifications for Unitronics’ Short Range and Long Range Local Expansion
Adapter Kit for Uni-I/O™.
All Kits comprise a Base unit, an End unit, and a connecting cable. The cable length varies
according to kit model.
Short-range adapter Kits
Up to 3 meters
Long-range adapter Kits
3 meters and up
Kits whose models contain the letter 'P' include a built-in power supply; a powered adapter module
supports a greater number of I/O modules.
There are two main classes of adapters:
UAG-XK
Both the Base and End units of these adapters have DIN-rail clips. You can:
Snap the base onto the DIN-rail type structure on the back of UniStream Modular HMI
Snap the base directly onto a UniStream PLC
UAG-CX
The base unit of these adapters has a plug; the end unit has DIN-rail clips. You can plug the
base unit only into the I/O Expansion Jack offered by the UniStream Built-in series.
Note that the maximum number of modules supported by a single controller is provided in the
controller’s technical specifications.
Technical specifications are available in the Unitronics Technical Library at www.unitronicsplc.com.
Adapter Models
The ‘x’s in the model numbers are placeholders for the cable lengths.
Model Installation Options Integrated
Power Supply Module Support
UAG-XKxxx DIN-rail structure
DIN-rail
No 8, includes any modules directly
connected to a controller
UAG-XKPxxx Yes 16, in addition to any modules
directly connected to a controller
UAG-XKPLxxxx Yes
UAG-CX-XKPxxx Plug into controller
Jack Yes 16
UAG-CX-XKPLxxxx
Power Supply
Adapters without an integrated power supply:
UniStream Modular and UniStream PLC controllers can supply power to a maximum of 8 modules.
Adapters that do not have a power supply draw power from UniStream and supply it to the
modules. This means, for example, that if there are 3 modules directly connected to the controller,
you can add an additional 5 via this type of adapter.
Adapters with integrated power supply:
must be connected to a 24VDC power source. The adapter can then supply up to 16 modules with
power, regardless of any directly connected to the controller.
Installation Guides are available in the Unitronics Technical Library at www.unitronicsplc.com.
Unitronics 1

UAG-XKxxx, UAG-XKPxxx and UAG-CX-XKPxxx
UniStream®
Power Supply UAG-XKxxx UAG-XKPxxx, UAG-CX-XKPxxxx, UAG-CX-XKPLxxxx,
UAG-XKPLxxxx
Input voltage Not applicable 12 or 24 VDC
Permissible range
Not applicable 10.2 to 28.8 VDC
Max. current
consumption Not applicable 0.9@12VDC, 0.5A@24VDC
Available Cable Length
Module
Length
UAG-XK125 125cm (49”)
UAG-XKP125 125cm (49”)
UAG-CX-XKP125 125cm (49”)
UAG-XK300 300cm (118”)
UAG-XKP300 300cm (118”)
UAG-CX-XKP300 300cm (118”)
UAG-CX-XKPL600 600cm (20’)
UAG-CX-XKPL1200 1200cm (40’)
UAG-CX-XKPL1500 1500cm (50’)
UAG-CX-XKPL2000 2000cm (66’)
UAG-CX-XKPL3000 3000cm (98’)
UAG-XKPL600 600cm (20’)
UAG-XKPL1200 1200cm (40’)
UAG-XKPL1500 1500cm (50’)
UAG-XKPL2000 2000cm (66’)
UAG-XKPL3000 3000cm (98’)
LED Indications
Base Unit There are no LEDs in the Base Unit.
End Unit Green Output
state
Comment
UAG-XKxxx Link Off Cable is not connected, or no power from the Base unit
On Link has been established with the base unit
UAG-XKPxxx
UAG-CX-XKPxxxx
UAG-XKPLxxxx
UAG-CX-XKPLxxxx
Power Off No external power
On External power is connected to the unit
Link Off Cable is not connected, or no power from the Base unit
On Link has been established with the base unit
Unitronics 2

UAG-XKxxx, UAG-XKPxxx, UAG-CX-XKPxxx, UAG-CX-XKPLxxxx, UAG-XKPLxxxx
Technical Specifications
Daisy-Chaining: Extending and Expanding I/Os
Up to five Local Expansion Adapters may be chained to each other. The maximum number of I/O
modules that can be connected to a single controller is:
85, for UniStream modular. This includes modules directly connected to the controller.
88, for UniStream PLC. This includes modules directly connected to the controller.
80, for UniStream bulit-in with I/O Expansion Jack.
UniStream can be expanded locally in a single cabinet, using Short range Adapters of up to 3 meters
each (UAG-XKxxxx , UAG-XKPxxxx and UAG-CX-XKPxxxx).
It can also be expanded further to another cabinet, using the Long Range Expansion Adapter
(UAG-XKLxxxx, UAG-CX-XKPLxxxx) as shown in the following drawings:
Single Cabinet
Two Cabinets
Daisy-chaining Rules
In order to connect a UniStream™ controller to more than one row of I/O modules via Local I/O
Expansion adapters, you must follow these rules:
UniStream Modular and UniStream PLC
Up to 2 Short-range adapters can be daisy-chained to the controller or to any of the modules that
are connected directly to the controller. These may be either two
UAG-XKPxxxx (that include an integrated power-supply), or one UAG-XKPxxxx and one UAC-
XKxxxx.
When daisy chaining, you can include only 1 Long-range adapter. You may connect it directly to the
controller or to any of the elements that are expanded from it.
UniStream Built-in
Up to 2 Short-range adapters can be daisy-chained to the controller. A UAG-CX-XKPxxx must be
plugged into the jack, and may be followed by a UAG-XKPxxxx or one UAC-XKxxxx.
UniStream™ controllers of all series
Since long range adaptors have integrated power supplies, you may follow any Long-range adapter
by daisy-chaining up to 2 Short range adapters. These may be either two UAG-XKPxxxx, or one
UAG-XKPxxxx and one UAG-XKxxxx.
Unitronics 3

UAG-XKxxx, UAG-XKPxxx and UAG-CX-XKPxxx
UniStream®
Configuration Examples
Notes:
1. All examples use the USP-104-B10 10.4” HMI panel.
2. The amount of modules at all examples relate to Uni-I/O modules. You can mix Uni-I/O modules
with Uni-I/O Wide modules,considering that 1 Uni-I/O Wide module equals 1½ Uni-I/O module.
Configuring for maximum I/Os
The figure below shows the greatest number of I/O modules that can be connected to a single
UniStream™ controller using Uni-I/O modules and 5 Local I/O Expansion adapters with power supplies.
Configurations with Short-range adapter, no Power Supply (UAG-XKxxxx).
If UAG-XKxxxx is the only adapter connected to the controller, the system can support up to 8 modules.
If a UAG-XKxxxx follows another adapter with an integrated power supply, the support capacity of that
powered module limits the number of Uni-I/Os that can be connected to the UAG-XKxxxx; in any event,
no more than 8 Uni-I/Os can follow a UAG-XKxxxx adapter.
This example combines all types of adapters:
Unitronics 4

UAG-XKxxx, UAG-XKPxxx, UAG-CX-XKPxxx, UAG-CX-XKPLxxxx, UAG-XKPLxxxx
Technical Specifications
Daisy-chaining Configuration Summary
UniStream Modular and UniSream PLC
The tables below show the possible configurations between two cabinets.
Optional configurations in the cabinet
with the UniStream Controller Optional configurations
in the other cabinet
Controller
1st
2nd
Max.
UniStream
Modular 7"
Max.
UniStream
Modular
10.4",15.6"
Max.
UniStream
PLC
-
-
3
5
8
XK
-
8
8
8
XKP
-
19
21
24
XKP
XK
19
21
24
XK
XKP
24
24
24
XKP
XKP
35
37
40
3rd
4th
5th
Max.
Modules
XKL
-
-
16
XK
-
16
XKP
-
32
XKP
XK
32
XK
XKP
32
XKP
XKP
48
XK-UAG-XKxxxx (Short Range Local Expansion Adapter without power supply)
XKP-UAG-XKPxxxx (Short Range Local Expansion Adapter with power supply)
XKL-UAG-XKLxxxx (Long Range Local Expansion Adapter)
NOTE Each combination in the right table can be used with each combination in the left table. They are
independent of each other and the total number of I/O modules that are supported is the sum of
the two tables.
UniStream™ built-in
You must use the UAG-CX-XKPxxx or UAG-CX-XKPLxxx, and it must be the adapter that is directly
connected to the controller.
Optional configurations in the cabinet
with the UniStream Controller Optional configurations
in the other cabinet
Controller
1st
2nd
Max. Modules
-
-
0
CX
-
16
XK
24
XKP
32
3rd
4th
5th
Max. Modules
XKL
-
-
16
XK
-
16
XKP
-
32
XKP
XK
32
XK
XKP
32
XKP
XKP
48
Environmental
Protection IP20, NEMA1
Operating Temperature -20°C to 55°C (-4°F to 131°F)
Storage Temperature -30°C to 70°C (-22°F to 140°F)
Relative Humidity (RH) 5% to 95% (non-condensing)
Operating Altitude 2,000 m (6,562 ft)
Shock IEC 60068-2-27, 15G, 11ms duration
Vibration IEC 60068-2-6, 5Hz to 8.4Hz, 3.5mm constant amplitude, 8.4Hz to
150Hz, 1G acceleration
Unitronics 5

UAG-XKxxx, UAG-XKPxxx and UAG-CX-XKPxxx
UniStream®
Dimensions
UAG-XKxxx UAG-XKPxxx UAG-XKPLxxxx
UAG-CX-XKPxxx
UAG-CX-XKPLxxxx
Weight Base: 65 g
(0.14 lb)
End: 142 g
(0.31 lb)
Base: 65 g
(0.14 lb)
End: 150 g
(0.33 lb)
Base: 64 g
(0.14 lb)
End: 92 g
(0.2 lb)
Base: 15 g
(0.033 lb)
End: 150 g
(0.33 lb)
Base: 15 g
(0.14 lb)
End: 92 g
(0.2 lb)
Size Refer to the images below
Base Unit (UAG-XKxxx, UAG-XKPxxx and UAG-XKPLxxxx)
Top View
Side View Front View
Unitronics 6

UAG-XKxxx, UAG-XKPxxx, UAG-CX-XKPxxx, UAG-CX-XKPLxxxx, UAG-XKPLxxxx
Technical Specifications
Base Unit (UAG-CX-XKPxxx, UAG-CX-XKPLxxxx)
Top View
Front View
Side View
Unitronics 7

UAG-XKxxx, UAG-XKPxxx and UAG-CX-XKPxxx
UniStream®
End Unit
Top View
Side View Front View
The information in this document reflects products at the date of printing. Unitronics reserves the right, subject to all applicable laws,
at any time, at its sole discretion, and without notice, to discontinue or change the features, designs, materials and other
specifications of its products, and to either permanently or temporarily withdraw any of the forgoing from the market.
All information in this document is provided "as is" without warranty of any kind, either expressed or implied, including but not limited
to any implied warranties of merchantability, fitness for a particular purpose, or non-
infringement. Unitronics assumes no
responsibility for errors or omissions in the information presented in this
document. In no event shall Unitronics be liable for any
special, incidental, indirect or consequential damages of any kind, or any damages whatsoever arising out of or in connection with the
use or performance of this information.
The tradenames, trademarks, logos and service marks presented in this document, including their design, are the property of
Unitronics (1989) (R"G) Ltd. or other third parties and you are not permitted to use them without the prior written consent of
Unitronics or such third party as may own them.
08/17
