Universal Timer Cyber ExerCycl User manual

Cyber ExerCycle
Cyber ExerCycleCyber ExerCycle
Cyber ExerCycle TM
TMTM
TM
Game Controller for Your Exercise Equipment
Game Controller for Your Exercise EquipmentGame Controller for Your Exercise Equipment
Game Controller for Your Exercise Equipment
USER GUIDE
Rev 2

1
T BLE OF CONTENTS
T BLE OF CONTENTST BLE OF CONTENTS
T BLE OF CONTENTS
1. INSTALLING CYBER EXERCYCLE ON YOUR BIKE ................................................ 2
2. INSTALLING AND RUNNING CYBER EXERCYCLE SETUP APPLICATION ........ 4
3. CONNECTING THE CONTROLLER TO THE PC ......................................................... 7
4. REQUIREMENTS............................................................................................................ 10
5. PRECAUTIONS ............................................................................................................... 11
6. TERMS AND CONDITIONS .......................................................................................... 12
7. RETURN AND ARRANTY......................................................................................... 12

2
1. INSTALLING CYBER EXERCYCLE ON YOUR BIKE
Connect Cyber ExerCycle to your exercise equipment in three steps:
• ttach the sensor and the magnet to the pedals of your bike
• Mount the controller to the frame of your bike.
• Plug the controller into a USB port of your computer.
ttach the sensor to the stationary parts of the bike. Run the sensor cable up the frame.
Wrap the cable around the frame if required, so that the cable is not loose. Ensure that
the cable will not get tangled in the pedals.
Note the orientation of the sensor to get correct forward pedaling direction.
Mount the magnet so that it does not interfere with the sensor (ensure that the
minimum distance between the sensor and the magnet is between 0.25" to 1").
If the crank arm is made our of steel, the magnet may simply stick to the metal.
Optionally use double sided tape to attach the magnet.
s you move the pedals the magnet should come close to the sensor once per full
rotation on the crank set.

3
Mount the controller box to the frame of your bike using Velcro. The controller box
should typically be located close to the bike handles (makes handling the joystick easier)
The sensor attaches to the controller box using 2.5mm plug.
PC connects to the controller box through the mini USB connector.
If you have any questions regarding the installation, please email us at
[e-mail]

4
2. INSTALLING AND RUNNING CYBER EXERCYCLE
SETUP APPLICATION
Cyber ExerCycle can be configured for one of 5 modes:
• Joystick Mode
Joystick ModeJoystick Mode
Joystick Mode. The controller emulates joystick.
• Flight Simulator
Flight SimulatorFlight Simulator
Flight Simulator Mode
Mode Mode
Mode. The controller emulates joystick.
• Net thlon Mode
Net thlon ModeNet thlon Mode
Net thlon Mode. The controller emulates joystick and mouse.
• Keyboard Mode
Keyboard ModeKeyboard Mode
Keyboard Mode. The controller emulates joystick.
• Keyboard and Mouse Mode
Keyboard and Mouse ModeKeyboard and Mouse Mode
Keyboard and Mouse Mode. The controller emulates keyboard and mouse.
The controller allows you to configure pedaling intensity. This determines on how fast
you need to pedal to move your character or a vehicle on the screen. The settings range
from very easy (40 RPM) to very hard (185 RPM).
Once configured, the controller will remember your selections even if the controller is
connected to another PC.
Once you download the file. Unzip it into a temporary folder and run the setup file.

5
Follow installation instructions of the setup file:
Press next to continue.

6
Once installed, you can locate the application in CyberExerCycle folder
(on Windows 7, ST RT button -> LL Programs -> CyberExerCycle)
Run the application. You will see the following screen. Note that the buttons on the
right side are grayed out.
Connect the controller to the USB port and press "Connect" button. Set the maximum
pedaling speed and select the operation mode by simply clicking on one of the mode
buttons:
Finish by closing the application:

7
3. CONNECTING THE CONTROLLER TO THE PC
Connect the game controller to your PC using the supplied USB cable. The controller
operates as a standard HID device, therefore does not require any special drivers. The
controller requires USB port 1.0 or later.
fter connecting the controller to your PC, Windows will automatically install all the
required drivers. When running the status LED on the side of the controller box will turn
on green.
Confirm the installation of the device by opening the control panel and viewing installed
devices. The controller emulates a keyboard, joystick and a mouse.
Windows 7:

8
Windows Vista:

9
fter mounting all the components and connecting the controller to the PC, run the
setup utility and configure Cycber ExerCycle to Joystick Mode, 40rpm setting.
Verify the operation of Cyber ExerCycle:
• Pressing "Z" button on the joystick should make the LED on the controller turn
solid green. (CEC_KIT_PC only)
• Moving the magnet close to the sensor forces the status LED to turn sold green.
s you move the magnet away, the status LED should start blinking again.
• Open Game Controller Properties and try different controller inputs such as
pressing buttons (CEC_KIT_PC only), shaking the joystick (CEC_KIT_PC only).
When pedaling you should see the Y xis of the display move. (make sure that
the controller is setup for Joystick Mode)
Reconfigure Cycber ExerCycle to the mode required by your game. For example, in
order to use Cyber ExerCycle with Net thlon, you need to configure the controller for
Net thlon mode. If playing such games as Skyrim, use Keyboard and Mouse Mode.
Refer to game specific setup: http://www.cyberbiking.com/games.html

10
4. REQUIREMENTS
The controller and the software is compatible with the following operating systems:
• Windows XP
• Windows Vista
• Windows 7
In-game configuration may be required. simple utility may need to be installed on
Windows (uses .Net framework 2) computer to configure the controller.
Please confirm that your PC meets minimum requirements of the games you wish to
play.
Many of the games provide a free demo download, allowing you to evaluate the game
and your computer performance. Please contact respective game manufacturer for game
support.

11
5. PRECAUTIONS
Some people may have seizures or blackouts triggered by light flashes or patterns, such
as while watching TV or playing video games, even if they have never had a seizure
before. nyone who has had a seizure, loss of awareness, or other symptom linked to
an epileptic condition should consult a doctor before playing a video game.
Parents should watch when their children play video games.
Stop playing and consult a doctor if you or your child have any of the following
symptoms:
• Convulsions
• ltered Vision
• Eye or Muscle Twitching
• Loss of wareness
• Disorientation
• Involuntary Movements
lways maintain a good grip on the exercise equipment to ensure that you do not fall
during exercise. Limit the game play to avoid repetitive motions injuries and eyestrain.
ll exercise comes with the some precautions. If you're currently inactive, it is always a
good idea to consult with your doctor before jumping into an exercise program. This is
especially true if you're overweight, have a medical condition, or are getting up there in
the years.
lso remember to warm up thoroughly before each workout. Your risk of injury drops
dramatically if you spend 5 minutes warming up and lightly stretching before getting
down to the serious workout.
For more information, please consult user guide your exercise equipment. lso, please
follow all safety precautions as indicated by the manufacturer of the exercise
equipment.

12
6. TERMS AND CONDITIONS
Refer to http://www.cyberbiking.com/terms_and_cond.html for full details on terms and
conditions policy.
7. RETURN AND WARRANTY
Refer to http://www.cyberbiking.com/warranty.html for full details on returns and
warranty policy.

13
Copyright Universal Timer Ltd. © 2010 - 2012
n electronic version of this manual in PDF format can be downloaded from:
http://www.cyberbiking.com/download/CyberExerCycle_RevB.pdf
Setup application for the controller (for windows) can be downloaded from:
http://www.cyberbiking.com/download/CyberExerCycleInstall_1.1.0.zip
