UP Xtreme Edge Compute enabling kit User manual

Quick Start Guide
UP Xtreme Edge Compute enabling kit
Powerful, Industrial, AI-Proof and expandable UP Xtreme Edge is an ultra-low voltage Edge
Compute --26 Watt only powered by Intel 8th Core CPU
What’s in your kit?
1x UP Xtreme Edge
Ubuntu 18.04 & OpenVINO™ Toolkit
1x power adapter
1x EU power cord & 1x US power code
You will need the followings, not included:
• A monitor with either HDMI or DisplayPort
• USB keyboard and mouse
• Ethernet cable (or optional WiFi, purchased separately)
Connect
keyboard
Mouse
ee
Monitor
Ethernet
cable
UP Xtreme Edge
Connect all needed hardware
XTREME
1

Quick Start Guide
Power on
a. Make sure to connect monitor before powering up – if the system is powered up before
connecting a monitor, you may need to power cycle the system to see the display
b. Connect power supply to the system and plug in power supply to an outlet.
Caution: this is a high-performance system and may get hot during operation.
Log in
Log into your Ubuntu 18.04 OS
After the booting, please follow the system instruction to set up language, time zone, user
name, password etc.
If you have proxy settings set them now: (System Settings > Network > Network Proxy).
Get Started
To start IoT development, you can download any other IoT development platforms on line.
To start AI development: Open the “Getting Started” icon on the Desktop. It will open a
browser to software.intel.com/up-squared-ai-vision-dev-kit/get-started. Follow the instruc-
tions there.
Copyright © 2018 AAEON Europe B.V. All rights reserved. UP is a registered trademark of AAEON Europe B.V. Specifications are subjective to change without notice.
Intel, Movidius and Myriad are trademarks of Intel Corporation or its subsidiaries in the U.S. and/or other countries. Other brands and product names are trademarks or
registered trademarks of their respective holder
Optional accessories:
AI hardware accelerator
UP AI Core XM 2280
WiFi Bluetooth Connectivity
M.2 Intel ® AC-9260 WiFi Kit
(802.11ac, bluetooth 5.0)
LTE Connectivity
mPCIe Quectel 4G LTE
CAT4 Global module
EG-25G
2
3
4

China RoHS Requirement
Component Name
Hazardous or Toxic Materials or Elements
Lead (Pb)
Mercury (Hg) Cadmium (Cd) Hexavalent Chromium (Cr(VI)) Polybrominated biphenyls (PBBs) Polybrominated diphenyl ethers
(PBDEs)
PCB and Components
X
O
O
O
O
O
Wires & Connectors for
Ext. Connections
X O O O O O
Chassis
O
O
O
O
O
O
CPU & RAM
X
O
O
O
O
O
HDD Drive
X
O
O
O
O
O
LCD Module
X
X
O
O
O
O
Optical Drive
X
O
O
O
O
O
Touch Control Module
X
O
O
O
O
O
PSU
X
O
O
O
O
O
Battery
X
O
O
O
O
O
This form is prepared in compliance with the provisions of SJ/T 11364.
O: The level of toxic or hazardous materials present in this component and its parts is below the
limit specified by GB/T 26572.
X: The level of toxic of hazardous materials present in the component exceed the limits specified
by GB/T 26572, but is still in compliance with EU Directive 2011/65/EU (RoHS 2).
Notes:
1. The Environment Friendly Use Period indicated by labelling on this product is applicable only
to use under normal conditions.
2. Individual components including the CPU, RAM/memory, HDD, optical drive, and PSU are
optional.
3. LCD Module and Touch Control Module only applies to certain products which feature these
components.
Hazardous and Toxic Materials List
Product Specification
System UP Xtreme
SoC
Intel® Core™ i7-8665UE ( up to 4.4 GHz)
Intel® Core™ i7-8565U (up to 4.60 GHz)
Intel® Core™ i5-8365UE ( up to 4.1 GHz)
Intel® Core™ i3-8145UE ( up to 3.9 GHz)
Intel® Celeron 4305UE ( up to 2.0 Ghz)
# of Cores
i3-8145UE/ Celeron 4305UE-Duo Core
i7-8665UE/i7-8565U/i5-8365UE-Quad Core
Graphics
Intel® UHD Graphics 610-Celeron 4305UE
Intel® UHD Graphics 620
VPU
optional ( via M.2 2280, mPCIe, 100-pin)
FPGA
Intel® FPGA Altera MAX 5
MCU
STM32
System memory
4GB DDR4
8GB DDR4
16GB DDR4
Storage capacity
64GB
Power requirement
12~60V DC-IN (lockable connector)

Safety Precaution
Please read the following safety instructions carefully
It is advised that you keep this manual for future references
1. All cautions and warnings on the device should be noted.
2. Make sure the power source matches the power rating of the device.
3. Position the power cord so that people cannot step on it. Do not place anything over the power
cord.
4. Always completely disconnect the power before working on the system’s hardware.
5. No connections should be made when the system is powered with a sudden rush of power as it
may damage sensitive electronic components.
6. If the device is not to be used for a long time, disconnect it from the power supply to avoid
damage by transient over-voltage.
7. Always disconnect this device from any power supply before cleaning.
8. While cleaning, use a damp cloth instead of liquid or spray detergents.
9. Make sure the device is installed near a power outlet and is easily accessible.
10. Keep this device away from humidity.
11. Place the device on a solid surface during installation to prevent it from falling.
12. Do not cover the openings on the device. This is to ensure optimal heat dissipation.
13. Keep an eye for high temperatures when the system is running.
14. Do not touch the heat sink or heat spreader when the system is running
15. Never pour any liquid into the openings. This could cause fire or electric shock.
16. As most electronic components are sensitive to static electrical charge, be sure to ground yourself
when installing internal components to prevent static charge. Use a grounding wrist strap and contain
all electronic components in any static-shielded containers.
17. If any of the following situations arise, please contact our service personnel:
I. Damaged power cord or plug
II. Liquid intrusion through the device
III. Exposure to moisture
IV. Device is not working as expected or in a manner as described in this manual
V. The device is dropped or damaged
VI. Any obvious signs of damage displayed on the device
18. Do not leave this device in an uncontrolled environment with temperatures beyond 70 °C. The
device's permitted storage temperatures are (-40°C ~ 80°C) in order to prevent damage.
Regulatory
FCC Statement
This device complies with Part 15 FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received including interference that may cause undesired
operation.
Caution: There is a danger of explosion if the battery is incorrectly replaced. Replace only
with the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer?s instructions and your local government?s recycling
or disposal directives.
Attention: Il y a un risque d?explosion si la batterie est remplacée de façon incorrecte. Ne la
remplacer qu?avec le même modèle ou équivalent recommandé par le constructeur.
Recycler les batteries usées en accord avec les instructions du fabricant et les directives
gouvernementales de recyclage.
