Installation Guide
for Uplogix Local Managers
Version 5.1
October 2014
www.uplogix.com

Information in this document is subject to change without notice.
© 2014 Uplogix, Inc. All Rights Reserved. Uplogix, the Uplogix logo, and SurgicalRollback
are trademarks of Uplogix, Inc. in the United States and other jurisdictions. All other marks
referenced are those of their respective owners.
Uplogix, Inc.
7600-B North Capital of Texas Highway
Suite 220
Austin, Texas 78731
USA

Contents
About this guide ..................................................................................................... 1
Target audience .................................................................................................................... 1
Typographical conventions ..................................................................................................... 1
Safety summary ................................................................................................................... 2
AC Models ......................................................................................................................... 2
DC Models ......................................................................................................................... 2
Uplogix 500/5000 Local Managers ........................................................................................... 3
Uplogix 500 ....................................................................................................................... 3
Uplogix 5000 ..................................................................................................................... 3
Hardware installation............................................................................................. 4
Installing the Uplogix 500 Local Manager ................................................................................. 5
Uplogix 500 ....................................................................................................................... 5
Unpacking the shipping box ................................................................................................. 5
Installing optional equipment ............................................................................................... 5
Installing the chassis .......................................................................................................... 8
Making the connections required for initial configuration.......................................................... 9
Making the remaining connections ...................................................................................... 11
Installing the Uplogix 5000 Local Manager.............................................................................. 13
Uplogix 5000 ................................................................................................................... 13
Unpacking the shipping box ............................................................................................... 13
Installing optional equipment ............................................................................................. 14
Expansion cards ............................................................................................................... 17
Ethernet expansion card port mapping ................................................................................ 18
Installing or replacing an expansion card............................................................................. 19
Installing the chassis ........................................................................................................ 20
Making the connections required for initial configuration........................................................ 20
Making the remaining connections ...................................................................................... 21
Removing an expansion card that will not be replaced........................................................... 23
Quick setup .......................................................................................................... 24
Initial configuration using the keypad .................................................................................... 24
Initial configuration via console connection............................................................................. 26
Configuring the Local Manager for your LAN ........................................................................... 27
Configuring an optional Pulse server...................................................................................... 28
Configuring communication with the Uplogix Control Center (UCC) ............................................ 28
Remote access via the management IP connection .................................................................. 29
Locking the keypad and changing the admin password ............................................................ 29
Configuring managed device and power control ports .............................................................. 30
Managed Device Ports....................................................................................................... 30
Power Control Ports .......................................................................................................... 30
Support and regulatory information ..................................................................... 31
Getting technical support ..................................................................................................... 31
Requesting an account ...................................................................................................... 31
Requesting support........................................................................................................... 31
Providing comments about this guide.................................................................................. 31
Regulatory notices .............................................................................................................. 31
Safety notices .................................................................................................................. 31
EMC notices..................................................................................................................... 32

RoHS compliance.............................................................................................................. 32
CE Mark R & TTE directive ................................................................................................. 32
Index ................................................................................................................... 33

Installation Guide for Uplogix Local Managers 1
About this guide
This guide describes the procedures for installing, cabling, and provisioning Uplogix Local
Managers.
Information in this document is subject to change without notice. Please visit
www.uplogix.com/support for the latest updates to Uplogix product documents.
Target audience
This guide is for trained, qualified network support technicians responsible for installing the
Uplogix Local Manager.
Typographical conventions
The following conventions are used in this guide.
Sample text from the command line interface is presented in this font. Text that you enter is
presented in this font. For example:
[admin@UplogixLM]#show who
admin ssh Mar 22 13:38 (192.0.2.101)
Keyboard characters are enclosed in angle brackets. For example, press <Enter>.

Installation Guide for Uplogix Local Managers 2
Safety summary
Following all cautions and warnings will ensure your own safety and protect the Uplogix Local
Manager from potential damage or loss of data.
Caution: Read the installation instructions before connecting the Uplogix Local Manager to
a power source.
Read and understand the following instructions before using the Uplogix Local Manager:
Always disconnect the Uplogix Local Manager from power before cleaning and
servicing.
Do not spray liquids directly onto the Uplogix Local Manager when cleaning. Always
apply the liquid first to a static free cloth.
Do not immerse the Uplogix Local Manager in any liquid or place any liquids on it.
Do not disassemble the Uplogix Local Manager. There are no user serviceable parts
inside the chassis, return to Uplogix for repair.
AC Models
Use three wire electrical extension cords with a current rating equal to or greater than
your Uplogix Local Manager’s current rating.
Only connect the Uplogix Local Manager to surge-protected power outlets.
DC Models
Use the supplied power cable (UP610052) with Molex connector and three-wire split
out to connect the DC Local Manager to power.
Ensure proper connections are made to earth ground, positive voltage and power
return by a qualified electrician. See Making the connections required for initial
configuration for more information.
SAVE THESE INSTRUCTIONS.

Installation Guide for Uplogix Local Managers 3
Uplogix 500/5000 Local Managers
The Uplogix Local Manager is a management device that connects directly to managed
network devices and servers.
Uplogix 500
The Uplogix 500 is a small form factor Local Manager offering a fixed set of console ports for
connection to managed devices.
There are six serial ports that can be connected to managed devices. One port is dedicated for
connection to an intelligent power controller.
Uplogix 5000
The Uplogix 5000 may be customized by installing expansion cards in the two modular bays.
Each expansion bay can be used to add either 4, 8 or 16 serial ports or eight dedicated
Ethernet ports, for pairing with serial ports, when direct Ethernet connections are needed for
managed devices.

Installation Guide for Uplogix Local Managers 4
Hardware installation
Ensure that the power source:
Provides appropriate power, AC or DC, as required by the system.
Provides overload protection
Is connected to earth ground
Warning: The power source must meet all these requirements to ensure safe and reliable
operation.
Ensure that the installation site meets the requirement that the ambient temperature does not
exceed 113° F (45° C) or fall below 32°F (0°C).
Caution: The unit will overheat if the site does not meet these requirements.
Caution: Use only the power supply shipped with the Local Manager 500. Using a different
power supply will void your warranty and may damage the equipment.

Installation Guide for Uplogix Local Managers 5
Installing the Uplogix 500 Local Manager
Uplogix 500
This section includes:
Unpacking the shipping box
Installing optional equipment
Installing the chassis
Making the connections required for initial configuration
Making the remaining connections
Unpacking the shipping box
Verify that you have received the following items:
Uplogix 500 Local Manager
1 Power supply and cord
1 mounting bracket
1 DB-9 to RJ-45 serial adaptor
Screws
Four clear rubber bumpers
Installing optional equipment
The Uplogix 500 supports field-installable modems, small form factor pluggable (SFP)
modules, and a temperature and humidity sensor. The Uplogix 500 also supports a 2-bracket
kit for center-mounting. Optional equipment may ship separately from the Local Manager.
Installing an Option Card in the Option Slot
The Local Manager supports five styles of equipment for installation in the option slot: V.92
modem, GPRS cellular modem, CDMA cellular modem, a DB-9 connection for an external
modem, and a SFP module to support a fiber connection.
Caution: To prevent equipment damage, do not connect the internal modem to digital PBX
systems, VoIP analog terminal adapters, or cellular modems. It is designed for use with
analog telephone lines only. Uplogix is not responsible for damage caused from attaching
the modem to a digital phone switch.

Installation Guide for Uplogix Local Managers 6
Prior to installation of any option slot card, ensure that the Local Manager is powered off.
V.92 modem
The V.92 modem may already be installed in the option slot. Follow these steps if the V.92
modem is not already installed:
1. Power off the Local Manager.
2. Remove the option slot cover, align the modem carrier card with the internal rails, and
slide the modem into place.
3. Replace the screws.
4. Connect a POTS telephone line to the RJ-11 jack on the modem and power on the
Local Manager.
GPRS cellular modem
Follow these steps to install the GPRS cellular modem:
1. Power off the Local Manager.
2. Install an activated SIM card on the modem.
3. Remove the option slot cover, align the modem carrier card with the internal rails, and
slide the modem into place.
4. Feed wire into the option slot compartment, align modem cover plate with the option
slot screw holes, and replace the screws.
5. Install antenna.
6. Power on the Local Manager.

Installation Guide for Uplogix Local Managers 7
CDMA cellular modem
Follow these steps to install the CDMA cellular modem:
1. Power off the Local Manager.
2. Note the Electronic Serial Number (ESN) on the modem, as this will be needed in
order to activate the modem on your carrier’s network.
3. Remove the option slot cover, align the modem carrier card with the internal rails, and
slide the modem into place.
4. Feed wire into the option slot compartment, align modem cover plate with the option
slot screw holes, and replace the screws.
5. Install antenna.
6. Power on the Local Manager.
DB-9 option card for external modem
The DB-9 option card may already be installed in the option slot. Follow these steps if the DB-
9 option card is not already installed:
1. Power off the Local Manager.
2. Remove the option slot cover, align the modem carrier card with the internal rails, and
slide the modem into place.
3. Replace the screws.
4. Connect an external modem to the Local Manager using a serial DB-9 cable and power
on the Local Manager.

Installation Guide for Uplogix Local Managers 8
Installing an SFP module
Follow these steps to install the SFP module in the chassis option slot of the Local Manager:
1. Power off the Local Manager
2. Remove the option slot cover, align the carrier card with the internal rails, and slide the
module into place.
3. Replace the screws.
4. Install either a 1000Base SX (GLC-SX-MM) SFP or the 1000Base LX/LH (GLC-LH-SM) SFP
for fiber connectivity. Both the 1000Base SX (GLC-SX-MM) SFP and the 1000Base LX/LH
(GLC-LH-SM) SFP are customer-provided equipment.
Note: SFP modules are hot swappable, but the SFP carrier option card is not hot
swappable.
Installing a Temperature and Humidity Sensor
The Local Manager supports a USB-connected temperature and humidity sensor. Follow these
steps to connect the sensor. Note the Local Manager does not need to be powered down for
installation of this sensor.
1. Plug the sensor into one of the two USB connections on the Local Manager
2. Place sensor collection end in the area you wish to collect environmental information,
ideally not near a fan or on hot equipment.
It may take up to 10 minutes for the sensor to normalize to the environmental temperature
and begin reporting consistent data.
Installing the chassis
The Local Manager is designed to be mounted in a rack or placed on a tabletop. To mount the
Local Manager in a rack:
1. Use the screws provided to attach the mounting bracket.
2. The mounting bracket can be installed on either side of the Uplogix 500.
3. Mount the Local Manager in the rack.

Installation Guide for Uplogix Local Managers 9
Installing optional center-mounting kit
Uplogix sells an optional kit for center-mounting the Uplogix 500.
To mount the Local Manager with the center-mount kit in a rack:
1. Attach the mounting brackets.
2. Mount the Local Manager in the rack.
Making the connections required for initial configuration
To complete initial setup, you must make these connections:
Power
Console

Installation Guide for Uplogix Local Managers 10
Connecting power
The Uplogix Local Manager uses an external power supply, which is shipped with the device.
Caution: Use only the power supply shipped with the Local Manager 500. Using a different
power supply will void your warranty and may damage the equipment.
Connect the power supply to the DC connector on the back of the device.
Connect the power cord to the power supply. Use either the provided power cord or one that is
suitable for your location. The Uplogix Local Manager uses a power cord with a standard IEC-
320-C13 female cord end.
Connect the power cord to a power outlet. An amber light indicates that the unit has power
applied. Power on the unit by pressing the power button. The system status LED (denoted with
an ‘i’ label on the chassis) will blink while the Local Manager boots up and becomes a solid
green light when the boot sequence is complete.

Installation Guide for Uplogix Local Managers 11
Connecting a workstation
To complete initial setup, you must connect your workstation to the Local Manager's RJ-45
console port.
If your workstation has a DB-9 serial port, use the DB-9 to RJ-45 adaptor provided by
Uplogix (see diagram below) and a straight Ethernet cable to connect to the console port.
If your workstation does not have a DB-9 serial port, you will need to use a USB to DB-9
serial adaptor together with a straight Ethernet cable and the DB-9 adaptor provided by
Uplogix to connect to the console port.
The default settings for the console port are 9600, 8, N, 1.
Note: The mini-USB console port will be supported in a future software release.
Following initial setup, you may choose to disconnect the console cable and manage the Local
Manager via Ethernet.
Making the remaining connections
These connections are not required to complete the initial setup:
Power controller
Management Ethernet
Devices to be managed

Installation Guide for Uplogix Local Managers 12
Connecting a power controller
Connect the power controller's serial port to port 1/6 on the Local Manager. A straight
Ethernet cable is typically used for this connection. However, some power controllers require
special cables. Consult your power controller documentation if a straight Ethernet cable does
not work.
Connecting management Ethernet
To manage the Local Manager and attached devices in-band through the network, connect
Gigabit Ethernet port 0 (GE-0) on the front panel to your network using a straight Ethernet
cable. Both GE-0 and GE-1 auto negotiate their speed and duplex settings by default.
Alternatively, if your management network is fiber based, connect to the SFP in the option
slot. If GE-0 or GE-1 are connected to the network, they will take precedence over the fiber
connection.
When connected, secondary management Ethernet port GE-1 acts as a standby redundant
Ethernet management connection by default. GE-1 will become active if the GE-0 link drops.
Therefore, it is important that GE-0 and GE-1 be connected to switch ports in the same
network or VLAN.
Connecting devices to be managed
Connect the console ports of up to five devices to the five serial ports (1/1 through 1/5) on the
Local Manager. A straight Ethernet cable works for most devices, but some devices do require
a rolled cable or a cable with a non-standard pin out. Consult your managed device’s
documentation for console port serial setting and pin out information as necessary.
Note: If port 1/5 on your Local Manager is labeled as ‘1/5-DTE’, you will likely need to use a
rolled cable to connect this port to a managed device.

Installation Guide for Uplogix Local Managers 13
Installing the Uplogix 5000 Local Manager
Uplogix 5000
This section includes:
Unpacking the shipping box
Installing optional equipment
Expansion cards
Ethernet expansion card port mapping
Installing or replacing an expansion card
Installing the chassis
Making the connections required for initial configuration
Making the remaining connections
Removing an expansion card that will not be replaced
Unpacking the shipping box
Verify that you have received the following items:
Uplogix 5000 Local Manager
2 US power cords (AC unit) or 2 Molex to 3-wire power cords (DC unit)
2 rack mounting brackets
1 DB-9 to RJ-45 adapter
Screws

Installation Guide for Uplogix Local Managers 14
Installing optional equipment
The Uplogix 5000 supports field-installable modems, small form factor pluggable (SFP)
modules, and a temperature and humidity sensor. Optional equipment may ship separately
from the Local Manager.
Installing an Option Card in the Option Slot
The Local Manager supports five styles of equipment for installation in the option slot: V.92
modem, GPRS cellular modem, CDMA cellular modem, a DB-9 connection for an external
modem, and a SFP module to support a fiber connection.
Caution: To prevent equipment damage, do not connect the internal modem to digital PBX
systems, VoIP analog terminal adapters, or cellular modems. It is designed for use with
analog telephone lines only. Uplogix is not responsible for damage caused from attaching
the modem to a digital phone switch.
Prior to installation of any option slot card, ensure that the Local Manager is powered off.
V.92 modem
The V.92 modem may already be installed in the option slot. Follow these steps if the V.92
modem is not already installed:
1. Power off the Local Manager.
2. Remove the option slot cover, align the modem carrier card with the internal rails, and
slide the modem into place.
3. Replace the screws.
4. Connect a POTS telephone line to the RJ-11 jack on the modem and power on the
Local Manager.

Installation Guide for Uplogix Local Managers 15
GPRS cellular modem
Follow these steps to install the GPRS cellular modem:
1. Power off the Local Manager.
2. Install an activated SIM card on the modem.
3. Remove the option slot cover, align the modem carrier card with the internal rails, and
slide the modem into place.
4. Feed wire into the option slot compartment, align modem cover plate with the option
slot screw holes, and replace the screws.
5. Install antenna.
6. Power on the Local Manager.
CDMA cellular modem
Follow these steps to install the CDMA cellular modem:
1. Power off the Local Manager.
2. Note the Electronic Serial Number (ESN) on the modem, as this will be needed in
order to activate the modem on your carrier’s network.
3. Remove the option slot cover, align the modem carrier card with the internal rails, and
slide the modem into place.
4. Feed wire into the option slot compartment, align modem cover plate with the option
slot screw holes, and replace the screws.
5. Install antenna.
6. Power on the Local Manager.

Installation Guide for Uplogix Local Managers 16
DB-9 option card for external modem
The DB-9 option card may already be installed in the option slot. However, follow these steps
if the DB-9 option card is not already installed:
1. Power off the Local Manager.
2. Remove the option slot cover, align the modem carrier card with the internal rails, and
slide the modem into place.
3. Replace the screws.
4. Connect an external modem to the Local Manager using a serial DB-9 cable and power
on the Local Manager.
Installing an SFP module
Follow these steps to install the SFP module in the chassis option slot of the Local Manager:
1. Power off the Local Manager
2. Remove the option slot cover, align the carrier card with the internal rails, and slide
the module into place.
3. Replace the screws.
4. Install either a 1000Base SX (GLC-SX-MM) SFP or the 1000Base LX/LH (GLC-LH-SM)
SFP for fiber connectivity. Both the 1000Base SX (GLC-SX-MM) and the 1000Base
LX/LH (GLC-LH-SM) are customer provided equipment.
Note: SFP modules are hot swappable, but the SFP carrier option card is not hot
swappable.
