UPM Elite THM701 User manual

E L I T E
THM701
7 Day Programmable Thermostat
TOUCHSCREEN
TECHNOLOGY
http://waterheatertimer.org/Woods-timers-and-manuals.html#Noma-Garrison

Features:
Interface s with heating/air co nditioning system s for autom atic temperature control
Automatic change-over for HEATING/COOLING prog rams
Interface s with humidifier for autom atic humidity control
Sets and displays house temperature (°C / °F)
Touchscre en LCD display with bac klight
Displays day, hou r and minute (in 12 or 24 hour clock format)
Temperature can be set in half d egrees
Copy 1 day’s prog ram to another day
Automatic ventil ation
Selec table cycle rates for furnace ON/OFF interva ls
Usage monitor
Filter change reminde r
Compatible with millivolt & 24V hea ting system s
Includes mounting hardw are and 3 “AA” batteri es

Table of Contents
Operation and programming guide .................................................1
Full Display Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Symbol Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Set ºC or ºF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Set Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Program Heating / Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Set Humidity. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Copy Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Set Fan / Ventilation / System Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Override Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Hold Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Pre-comfort Recovery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Usage Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Filter Change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Battery Changing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Memory Backup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Backlight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Lock Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Option Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Installation Guide.....................................................................21
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

1
Operation and
Programming Guide

TIME
Full Display - (includes all icons - for reference only)
2
HUMIDITY
PROGRAM
PERIOD
STATUS
SYMBOLS
SYSTEM
MODE
FAN
MODE
LOCK
WEEKDAYS
TABS
UP OR DOWN

Symbol Key:
COOLING - the air conditioning system is in use.
HEATING - the furnace or heating system is in use.
FAN - the fan is running (FAN symbol will flash).
HUMIDITY - the humidifier is in use.
FILTER CHANGE - the furnace filter should be changed.
BATTERY - the batteries are low and need to be replaced.
LOCK - the thermostat settings are locked and setting cannot be changed.
3
These symbols appear to indicate the following:

CELSIUS DEFAULT: Since Celsius (°C) is the default mode no action
is required to use the thermostat in this mode.
(°C or °F) It is VERY IMPORTANT that you choose Fahrenheit (°F) before
you begin using the thermostat. If you proceed to set the clock and program
settings with the default Celsius(°C)and THEN change to the Fahrenheit (°F)
setting; the clock, programs and all system settings will be deleted.
IMPORTANT - Getting Started
** **
4
Select ºC or ºF (Celsius or Fahrenheit)
Press OPTION for 3 seconds just after batteries are installed.
Select Option oP9 with the (left) arrows to choose between °F or °C mode.
To choose Fahrenheit select value 1 with the (right) arrows. (1=°F)(0=°C Default)
Press OK to exit
(*see option section for more details)
2
1
3
4

Set Time and Weekday
SET CLOCK
5
Press the Clock area for 3 seconds.
(The clock numbers will begin to flash)
Set the time with UP or DOWN arrows.
(Scroll to current hour and minute.)
Press OK then select the WEEKDAY
by touching that day.
(The selected weekday will be display
with a flashing underline.)
Press OK to exit
2
1
3
4
Choose 12 or 24 hour clock
Press the OPTION tab for 3 seconds.
Select Option oP1 with the (left)arrows
Choose value with the(right) arrows:
0=12 hour mode (Default)
1=24 hour mode
Press OK to exit
(*SEE OPTION Section for more details, and to
select Daylight Savings Time)
2
1
3
SET TIME
SET WEEKDAY
Note: 12 hour mode is the default
so no action is required to use the
thermostat in this mode.
Note: Clock operates by the days
of the week but does not track the
date or year.
4

Program Heating and Cooling
This thermostat is equipped with 7 DAY PROGRAMMING. Monday + Tuesday + Wednesday
+ Thursday + Friday + Saturday + Sunday programming with 4 settings per day. This thermostat
is pre-programmed for your convenience or you can set your own programs as desired.
P1: MORNING
P2: DAY
P3: EVENING
P4: NIGHT
This is typically for the morning when you may prefer a warmer temperature.
This is an energy-savings mode for the time you are away from home. The setting
can be adjusted to minimize energy consumption.
This is for the time you return home and want the house at a comfortable temperature,
typically warmer settings during winter and cooler settings during summer.
This is the time when you are usually asleep. You may choose to set temperature for
energy savings or comfort as desired.
:
:
:
:
PERIOD
MORNING
DAY
EVENING
NIGHT
P TIME
P1
P2
P3
P4
6:00am
8:00am
5:00pm
10:00pm
HEAT SETPOINT COOL SETPOINT
o o
69.0 F (20.5 C)
o o
63.5 F (17.5 C)
o o
70.0 F (21.0 C)
o o
62.5 F (17.0 C)
o o
77.0 F (25.0 C)
o o
84.0 F (29.0 C)
o o
77.0 F (25.0 C)
o o
79.0 F (26.0 C)
SCHEDULE OF PRE-PROGRAMMED TIME AND TEMPERATURE SETTINGS
6
Note: The program periods
can be set to the different or
the same temperatures.
For example: Period 1, 2,
or 3 can all be set to (22 )
if you are home all day and
want the temperature to
stay warm, but at night it
can set cooler. (17 )
oC
o
be C

TIME
PROGRAM Display
7
3)Select
PROGRAM PERIOD
P1 - Morning
P2 - Day
P3 - Evening
P4 - Night
2)Select any WEEKDAY,
the selected day
will be underlined
5)Select COPY, then
other weekday(s) to copy
PROGRAM 1-4 settings
4)Use the UP or DOWN arrows to set the
start time and temperature for each program period.
1) Select the PROGRAM tab to enter the program mode.
