Urbanears Stammen User manual

URBANEARS CONNECTED SPEAKERS
Stammen
User Manual
> About your speaker
> Using your speaker
> Playing via Wi-Fi
> Playing via Bluetooth
> Playing via AUX input
> Managing your presets
> Solo Mode and Multi Mode
> Maintenance & support
> Troubleshooting
> Important safety / legal information

ABOUT YOUR SPEAKER
> Features
> Technical Specification
> Included in the box
Features
Spotify & Internet Radio Presets
Your speaker lets you save your favorite music
from Spotify1and internet radio as seven different
presets. Keep a range of moods on standby, ready
for instant play at the push of a knob.
Spotify Connect, Chromecast built-in,
AirPlay & Internet Radio Support
Your speaker supports access to Spotify Connect2,
Chromecast built-in, AirPlay, and thousands of
internet radio stations.
Multi-Room Play
Two or more Urbanears Connected Speakers can
be grouped together as a multi-room system. Play
something different in each space, or synchronize
your speakers in Multi Mode to play the same music
in every room of your home.
1Saving Spotify presets requires a Spotify Premium account.
2 Spotify Connect requires a Spotify Premium account.
Technical
Specification
Included in
the box
• 1 x Stammen, Urbanears Connected Speaker
• 1 x Power cord
• 1 x Quick Start Guide, Legal and Safety, Spotify
leaflet
SPL frequency range
50 Hz–20 kHz (±3 dB)
Amplifiers
3 Class-D
Drivers
Two 3/4˝ neodymium dome
tweeters, one 4˝ woofer
Audio power output
36 W
Input voltage
100–240 V, 50–60 Hz
Max peak power
consumption
60 W
Network standby power
consumption
1.6 W
Weight
3.6 kg
Size
Width 210 mm
Height 210 mm
Length 142 mm
USB output for charging
5 VDC, 1 A
Audio interfaces
Wi-Fi
WPA2, 802.11b/g/n/ac 2.4
GHz/5 GHz with diversity
Bluetooth
Classic + Low Energy 4.2
AVRCP + A2DP
AUX
3.5 mm stereo jack

USING YOUR SPEAKER
> Interfaces
> First time setup
> The Urbanears Connected app
> Working the Knobs
> Adjusting equalizer settings
Interfaces
Knobs
01. VOLUME knob
02. SOURCE knob
Grouping indicators
03. SOLO
04. MULTI
Source indicators
05. - Wi-Fi streaming
06. Presets 1-7 - Wi-Fi streaming
07. - Bluetooth wireless connection
08. AUX - physical input
Inputs and output
09. AC mains input
10. AUX 3.5 mm audio input
11. USB 1 A, 5 V DC power output
First time setup
To get the most out of your speaker and to enable
cloud streaming, it needs to be configured first. This
will also ensure that it stays current with the latest
software updates and features.
What you need to get started
• Stammen, Urbanears Connected Speaker
• Power outlet
• Working Wi-Fi connection with access to fast
internet for streaming services
• Smartphone with at least Android 4.03 or
iOS 9.0
• The Urbanears Connected app (available on
App Store and Google Play)
Steps for initial setup
01. Plug one end of the power cord into the power
jack located on the bottom of your speaker,
and the other end into a power outlet.
Note: In some regions, several power cords may be included.
Use the power cord and plug that are applicable to your region.
Only connect to the correct mains voltage, as shown, on the
bottom of your speaker.
02. While your speaker is booting up, the
SOLO and MULTI indicators will light up
continuously. Once it is ready for setup the ring
of lights around the SOURCE knob will blink
continuously.
03. Use your smartphone to search for the
Urbanears Connected app on Google Play or
in the App Store and download it. Start up the
app and follow in-app instructions to complete
speaker setup.
Note: To set up additional speakers on the same Wi-Fi
network, repeat the steps above for each speaker added. In
theUrbanears Connected app, tap the menu button, then tap
“Setup” and follow instructions. If your speaker is not fresh out
of the box, follow the instructions found in Enter setup mode
manually.
The Urbanears
Connected app
The Urbanears Connected app helps you get set
up for the first time, and gives you access to your
speaker’s fullest capabilities. The app is compatible
with iOS and Android smartphones, and can be
downloaded for free on Google Play or in the App
Store.
With the Urbanears Connected app you can:
• Set up, modify, and play your presets
• Select a sound source
• Manage Multi Mode groups
• Browse and connect to thousands of internet
radio stations
• Check what song or other media is currently
playing
• Adjust equalizer settings
• Adjust individual and multi-room volume
settings
• Rename your speaker
• Adjust streaming quality
Working the
Knobs
After initial setup, you can operate your speaker by
simply pushing and turning the two knobs located
on its top panel. It can also be operated using the
Urbanears Connected app, Spotify, and other music
apps.
Select a sound source
Turn the SOURCE knob to a selection, then push
once to activate. The indicator light next to your
selection will become fully lit.
Play/Pause
Push the SOURCE knob once to play or pause your
music.1
Next song
Double-click the SOURCE knob to skip to the next
song.2
Previous song
Triple-click the SOURCE knob to skip back to the
previous song.3
Save a preset
While playing music via Spotify Connect or internet
radio, turn the SOURCE knob to a number selection.
Push and hold for 3 seconds.
See Managing your presets.
Increase volume
Turn the VOLUME knob clockwise (+) to increase
volume.
Decrease volume
Turn the VOLUME knob anti-clockwise (–) to
decrease volume.
Switch between Solo Mode and Multi Mode
Push the VOLUME knob once to switch between
Solo Mode and Multi Mode. The indicator light
shows which mode your speaker is currently in.
See Solo Mode and Multi Mode.
1Not supported for AUX sources.
2Not supported for AUX sources.
01
04
05
06
07
03
08
02
3Not supported for AUX sources.
Adjusting
equalizer settings
The equalizer can be adjusted from inside the
Urbanears Connected app. Fine-tune your
speaker’s treble/bass balance to complement
different types of music and find your listening
sweet spot.

PLAYING VIA WIFI
> Playing via Spotify Connect
> Playing via Chromecast built-in
> Playing via AirPlay
> Playing internet radio
There are several ways to play via Wi-Fi. When any
of the following Wi-Fi sources are active, the source
indicator next to will be lit, except for when a
preset is playing.
Playing via
Spotify Connect
Spotify Connect lets you control your speaker from
inside the Spotify app.
01. Start playing some music.
02. Select your speaker from the “Devices
Available” menu.
Note: Spotify Connect requires a Spotify Premium account.
Playing via
Chromecast
built-in
The Urbanears Connected app comes with
Chromecast built-in, which allows you to stream
music/tunes/podcasts/playlists to your speaker
from your favorite apps.
01. Tap the Cast button inside the music app, then
select your speaker from the menu.
Note: The Google Terms of Service and Privacy Policy must
be accepted in the Urbanears Connected app before first time
use.
Playing via
AirPlay
AirPlay lets you stream any sound source to your
speaker from your iOS device orApple computer.
01. If the app has the AirPlay button embedded,
tap the button and select your speaker from
the menu.
02. To stream any sound to your speaker from
an iOS device, select your speaker in the
“Control Center” of your device.
Playing internet
radio
Your speaker has an embedded internet radio
service that gives you access to thousands of radio
stations around the world.
01. Open the Urbanears Connected app and tap
on the speaker you want to stream to.
02. Swipe to “Cloud” in the source menu.
03. Tap on “Internet Radio” and select a station to
play.

PLAYING VIA BLUETOOTH
> Bluetooth pairing
> Playing via Bluetooth
To play music from a Bluetooth compatible device,
start by pairing the device with your speaker.
Bluetooth pairing
01. Turn the SOURCE knob to , then push and
hold for 3 seconds.
The indicator next to blinks slowly when your
speaker becomes discoverable.
02. Enable Bluetooth on your device
(smartphone, tablet, or computer).
03. Select your speaker from the list of available
Bluetooth devices and accept pairing.
The devices are successfully paired and
connected when the indicator on your
speaker lights up continuously and you hear a
confirmation sound.
Note: Bluetooth pairing can also be initiated via the Urbanears
Connected app.
Playing via
Bluetooth
Once your speaker has been paired with a Bluetooth
device, the pairing is saved and you can reconnect
at any time. Your speaker can save up to 8 device
pairings.
01. Turn the SOURCE knob to and push once.
02. Your speaker connects to the last paired
Bluetooth device. If it is not available, it will try
to connect to the second last.

PLAYING VIA AUX INPUT
Use the AUX input to connect audio devices directly
to your speaker. Audio devices with a compatible 3.5
mm AUX output plug can be connected, like MP3
players, smartphones, and tablets.
01. Insert one end of the AUX cable into the AUX
input on the bottom of your speaker.
02. Insert the other end of the AUX cable into the
AUX output port on your audio device.
03. Turn the SOURCE knob to AUX, then push
once to activate.
Note: When playing music via AUX, skipping to the next or
previous song can only be done using the controls on your
connected device.

MANAGING YOUR PRESETS
> Adding Spotify presets
> Adding internet radio presets
Your speaker can save up to seven of your favorite
Spotify playlists and internet radio stations as
presets for instant streaming. Select individual
presets by turning the SOURCE knob to a number
and pushing it to play.
Presets can be added and managed using the
SOURCE knob on your speaker, or from inside the
Urbanears Connected app.
To modify individual presets, simply save a new
preset over a current one.
Adding Spotify
presets
Saving a Spotify preset requires a Spotify Premium
account.
01. Open the Spotify app.
02. Select your speaker from the “Devices
Available” menu in the Spotify player.
03. Select and play your chosen playlist.
04. While your music is playing, turn the SOURCE
knob to a preset position (1-7).
05. Push and hold the SOURCE knob for 3
seconds until the preset position indicator
blinks and you hear a confirmation sound.
Adding internet
radio presets
01. Open the Urbanears Connected app.
02. Select your speaker on the home screen.
03. Swipe to “Cloud” in the source menu, then tap
on “Internet Radio”.
04. Select a station and tap it to start playing.
05. While the radio station is playing, turn the
SOURCE knob to a preset position (1-7).
06. Push and hold the SOURCE knob for 3
seconds until the preset position indicator
blinks and you hear a confirmation sound.

SOLO MODE AND MULTI MODE
> Setting your speaker to Multi Mode or Solo
Mode
> Playing in Multi Mode via Spotify Connect
> Playing in Multi Mode via Chromecast
built-in
> Playing in Multi Mode via AirPlay
> Playing in Multi Mode via Bluetooth
> Playing in Multi Mode via AUX
Multiple Urbanears Connected Speakers can be
added to the same Wi-Fi network to form a multi-
room system. Play each speaker individually in Solo
Mode, or group up to five speakers together in Multi
Mode for synchronized play. Multi Mode can be
managed on your speaker’s top panel, or inside the
Urbanears Connected app
Setting your
speaker to
Multi Mode or
Solo Mode
01. To switch from Solo Mode to Multi Mode on
your speaker, push the VOLUME knob.
02. The indicator under MULTI will light up when
selected.
03. Repeat for each additional speaker that you
want to add to the Multi Mode group.
04. To remove a speaker from the group, push the
VOLUME knob again.
05. Your speaker will switch to Solo Mode and will
leave the Multi Mode group.
Note: In Solo Mode, your speaker is listed as a single speaker
with its given name in the “Devices Available” menu on AirPlay
and Spotify. In Multi Mode, your speakers are listed as “Multi”
in the “Devices Available” menu. Even if only one speaker is
set to Multi Mode, it will still be listed with the name “Multi” on
AirPlay and Spotify.
Playing in Multi
Mode via Spotify
Connect
Spotify Connect lets you play music in Multi Mode
from inside the Spotify app.
01. Set all the speakers that you want to play as a
group to Multi Mode.
02. Play music and select the group called “Multi”
from the “Devices Available” menu.
Note: Spotify Connect requires a Spotify Premium account.
Playing in
Multi Mode via
Chromecast
built-in
Setting up your speaker for multi-room playback
using Chromecast built-in is done inside the Google
Home app.
With this app you can group your Urbanears
Connected Speakers together, and with other
Chromecast built-in devices.
Note: When your speaker is playing via Chromecast built-in its
SOLO indicator is lit.
Playing in Multi
Mode via AirPlay
AirPlay can be used when playing from an iOS
device via Wi-Fi.
01. Set all the speakers that you want to play as a
group to Multi Mode.
02. Tap the AirPlay symbol in the “Control Center”
menu, then select the group called “Multi”.
Playing internet
radio in
Multi Mode
Choose an internet radio station to play on all the
speakers in your Multi Mode group.
01. Set all the speakers that you want to play as a
group to Multi Mode.
02. Inside the Urbanears Connected app, select
one of the speakers in your Multi Mode group
and then select an internet radio station to
play.
Playing in
Multi Mode via
Bluetooth
Connect a Bluetooth source to one speaker and
play it on all the speakers in your Multi Mode group.
01. Set all the speakers that you want to play as a
group to Multi Mode.
02. Turn the SOURCE knob on one of the
speakers in your Multi Mode group to , then
push to activate.
03. Connect your phone or other compatible
device to this speaker via Bluetooth and play.
See Playing via Bluetooth.
Playing in Multi
Mode via AUX
Connect an AUX source, such as a CD-player,
phone, or vinyl player to one speaker to play it on all
the speakers in your Multi Mode group.
01. Set all the speakers that you want to play as a
group to Multi Mode.
02. Connect an AUX source to one of the
speakers in your Multi Mode group.
03. Turn its SOURCE knob to AUX, then push to
activate. See Playing via AUX input.

MAINTENANCE & SUPPORT
> Maintenance
> Cleaning your speaker
> About your Wi-Fi connection
> Charging or powering a USB device
> Enter setup mode manually
> Factory reset your speaker
Maintenance
Refer all servicing of your speaker to qualified
service personnel. Servicing is required when
your speaker has been damaged in any way or
ceases to operate normally. Seek qualified service
in instances of damage to your speaker’s power
supply cord or plug, damage caused by liquid or
exposure to rain or moisture, damage from foreign
objects, or if your speaker has been dropped.
Cleaning your
speaker
Before cleaning your speaker, always unplug it from
the wall socket. Use a dry, lint-free cloth to gently
wipe the surface.
Never use soap, detergents, or aerosol cleaners!
About your Wi-Fi
connection
By its nature, wireless LAN may experience
radio interference depending on environmental
conditions (such as wireless router performance,
distance, obstruction, interference with other
wireless devices, etc.)
Depending on the wireless router used, some
network operations may perform differently.
For detailed information on networking
with a wireless router or modem, refer to its
documentation.
Charging or
powering a USB
device
The USB output connector on the bottom of your
speaker can be used to charge or power your phone
or MP3 player.
01. Insert a USB Type A cable into the USB 5VDC
output located on the bottom of your speaker.
02. Insert the other end of the cable into the USB
connector on your device.
Enter setup mode
manually
When your speaker is new out of the box it will
enter setup mode automatically when connected
to power. If you move or change the Wi-Fi network
settings set your speaker in setup mode manually.
03. Turn the SOURCE knob to .
04. Push and hold until the ring of lights around it
blink continuously to clear all previous Wi-Fi
network connections.
05. Continue with the setup. See First time setup.
Factory reset your
speaker
Factory reset clears all custom settings, presets,
Wi-Fi settings, and Bluetooth pairings from your
speaker.
01. Press and hold the VOLUME and SOURCE
knobs at the same time for 7 seconds until
both the SOLO and MULTI indicators are lit.
02. Your speaker will reset to its factory state after
about 1 minute. It is then restored to setup
mode and is ready to be configured. See First
time setup.

TROUBLESHOOTING
> Your speaker does not turn on
> Your speaker cannot be discovered in the
Urbanears Connected app
> There is no sound
> Noise when charging via USB and playing via
AUX from same device
> Your speaker cannot connect to a new Wi-Fi
network
> Your speaker cannot connect or pair with a
Bluetooth device
> You are prompted for a pin code when pairing
Bluetooth devices
> The audio is cutting out when playing in Multi
Mode
> Your speaker is not responding
> You don’t have access to a Wi-Fi network
> You don’t have a smartphone or tablet
Your speaker
does not turn on
Make sure that your speaker is plugged into a
working AC power outlet using its power cord. See
First time setup.
Your speaker
cannot be
discovered in
the Urbanears
Connected app
If your speaker is not visible in the Urbanears
Connected app, make sure that:
• Your speaker has finished starting up. During
start-up, both SOLO and MULTI indicators are
lit.
• The mobile device is connected to the same
Wi-Fi network as your speaker.
If your speaker is still not showing up in the
Urbanears Connected app:
01. Put your speaker in setup mode manually.
See Enter setup mode manually.
There is no sound
If your speaker is on but you can’t hear any sound,
make sure that:
• The volume is not too low or muted on your
sound source and speaker. See Working the
Knobs.
• The correct audio source is selected. See
Working the Knobs.
• The intended sound source is connected. See
Playing via Bluetooth or Playing via AUX input.
• Your speaker is connected to a Wi-Fi
network when playing via Spotify, AirPlay or
Chromecast built-in. See First time setup.
Noise when
charging via USB
and playing via
AUX from same
device
On some devices, normal noise from the USB port
can cause interference when playing audio via AUX
input. If this happens, try one of the solutions below.
• Disconnect AUX and connect via Wi-Fi or
Bluetooth.
• Use a different playback device.
• Use a separate charger for the playback device
• Purchase an optional USB Type A noise filter.
Your speaker
cannot connect
to a new Wi-Fi
network
If you move or change your Wi-Fi network,
reconfigure the speaker to use the new Wi-Fi
network.
01. Turn the SOURCE knob to .
02. Push and hold until the ring of lights around it
blink continuously to clear all previous Wi-Fi
network connections.
03. Reselect a Wi-Fi network from inside the
Urbanears Connected app.
Your speaker
cannot connect
or pair with a
Bluetooth device
When pairing your speaker with a Bluetooth device,
make sure that:
• Bluetooth is enabled on your device
(smartphone, tablet, computer).
• The device and the speaker are within 10
meters of each other, unobstructed by walls or
doors.
You are prompted
for a pin code
when pairing
Bluetooth devices
In most cases, a pin code (password) is not needed.
If a pin code is requested, enter: 0000.
The audio is
cutting out when
playing in Multi
Mode
If the Wi-Fi bandwidth is too low for Multi Mode to
play at normal quality, the audio can start cutting out.
Adjust the streaming quality to compensate for the
low Wi-Fi bandwidth.
01. Open the Urbanears Connected app and tap
the menu button.
02. Tap on Settings and then “Multi Streaming
Quality”.
03. Set “Multi Streaming Quality” to “Low”.
Your speaker is
not responding
In the rare case that your speaker is not responding
due to a software problem, do the following:
01. Unplug your speaker from the wall socket.
02. Wait for 15 seconds, then plug it in again.
03. Wait for the speaker to start up.
If your speaker is still not responding after start-up is
completed:
04. Reset your speaker to its factory state. See
Factory reset your speaker.
05. Redo the initial setup. See First time setup.
You don’t have
access to a Wi-Fi
network
To play your speaker when there is no Wi-Fi network
available:
• Connect a compatible device to your speaker
using Bluetooth. See Playing via Bluetooth.
• Connect a compatible device to your speaker
using a cable. See Playing via AUX input.
You don’t have a
smartphone or
tablet
To play your speaker without using a smartphone or
tablet:
• Connect a compatible device to your speaker
using Bluetooth. See Playing via Bluetooth.
• Connect a compatible device to your speaker
using a cable. See Playing via AUX input.

IMPORTANT SAFETY / LEGAL
INFORMATION
> Legal notice
> Important safety instructions
> Warning
> Installation & connection
> Cleaning & maintenance
> Disposal & recycling information
> FCC statement
> IC statement
> Declaration of conformity
Legal notice
© Zound Industries International AB. All Rights Reserved. Zound Industries
International AB is hereinafter referred to as “Zound Industries”.
URBANEARS™ and the speaker product, packaging, logo and wordmark
are intellectual properties of Zound Industries and may not be used without
permission.
Wi-Fi®, the Wi-Fi logo and the Wi-Fi CERTIFIED™ logo is a certification mark
of Wi-Fi Alliance® .
The Bluetooth® word mark and logos are registered trademarks owned
by the Bluetooth SIG, Inc. and any use of such marks by Zound Industries is
under license.
Android™, Google Play™, and Chromecast™ are trademarks of Google Inc.
Apple, AirPlay, iPod, iPhone, iPad, and the Apple and AirPlay logos are
trademarks of Apple Inc. registered in the U.S. and other countries.
Spotify® and Spotify Connect logos™ are trademarks of the Spotify Group,
registered in the U.S. and other countries.
“Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an
electronic accessory has been designed to connect specifically to iPod,
iPhone, or iPad, respectively, and has been certified by the developer to meet
Apple performance standards. Apple is not responsible for the operation of
this device or its compliance with safety and regulatory standards. Please note
that the use of this accessory with iPod, iPhone, or iPad may affect wireless
performance.
All other trademarks are the property of their respective owners and may not
be used without permission.
For more legal information related to this product and to its use in your specific
region, and for more detailed information about Zound Industries and partner
& license information, please visit the website:
http://www.urbanears.com
Important safety
instructions
01. Read these instructions
02. Keep these instructions
03. Heed all warnings
04. Follow all instructions
05. Do not use this apparatus near water
06. Clean only with dry cloth
07. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
08. Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
09. Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of
the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart or rack is used, use
caution when moving the cart/apparatus combination to avoid injury from
tip-over.
13. Unplug this apparatus during lightning storms or when unused for long
periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
Warning
• Keep the product and its accessories away from young children. This is
not a toy.
• Do not install the product in an area that impedes access to the power
plug. Disconnecting the power plug is the only way to completely remove
power to the product and the plug must be readily accessible at all times.
• To reduce the risk of fire or electric shock, do not expose this apparatus
to rain or moisture. The apparatus shall not be exposed to dripping or
splashing and that objects filled with liquids, such as vases, shall not be
placed on apparatus.
• Do not drop the product.
• Do not cover the product to avoid risk of overheating.
• Do not listen too close to the product.
• Do not listen for an extended period of time at a high sound pressure
level.
• Do not insert body parts or objects into the bass port for risk of injury.
• The mains plug is used as disconnect device, the disconnect device shall
remain readily operable.
• Please refer the information on exterior bottom enclosure for electrical
and safety information before installing or operating the apparatus. 0
This equipment is a Class II or double insulated electrical appliance. It has
been designed in such a way that it does not require a safety connection to
electrical earth.
This lightning flash with arrowhead symbol within an equilateral triangle
is intended to alert the user to the presence of non-insulated “dangerous
voltage” within the product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
Warning: To reduce the risk of electric shock, do not remove cover (or back)
as there are no user-serviceable parts inside. Refer servicing to qualified
personnel.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance instructions in
the literature accompanying the appliance.
For complete safety information, visit the website: http://www.urbanears.com
Installation &
connection
• Connect the product according to the instructions in the manual.
• Connect the product only to the correct mains voltage as shown on the
equipment.
• Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit the
apparatus.
• Use only power cables of the type specified in the operating instructions
or as marked on the product.
• Do not defeat the safety purpose of the polarized or grounding-type
plug. A polarized plug has two blades with one wider than the other. A
grounding plug has two blades and a third grounding prong.
• The wide blade or the third prongs are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
• Unplug the product during lightning storms or when unused for long
periods of time.
• Do not install this equipment in a confined or building-in space, and
remain a well ventilation conditions at open site. The ventilation should
not be impeded by covering the ventilation openings with items such as
newspaper, table-cloths, curtains etc.
• No naked flame sources, such as lighted candles, should be placed on the
apparatus.
• The use of apparatus in tropical or moderate climates.
Cleaning &
maintenance
Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord
or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
Clean only with dry cloth.
For more detailed cleaning and maintenance instructions, visit the website:
http://www.urbanears.com
Disposal &
recycling
information
The crossed-out wheeled bin symbol on your product (and any included
batteries and other electronic accessories) indicates that they should not be
disposed of as normal household rubbish. Do not dispose of your product,
batteries and electronic accessories as unsorted municipal waste. Your
product, batteries and electronic accessories should be handed over to a
certified collection point for recycling or proper disposal at the end of their life.
For more information related to disposal and recycling, visit the website:
http://www.urbanears.com
FCC statement
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
To comply with FCC’s and Industry Canada’s RF radiation exposure limits for
general population/uncontrolled exposure, this device must be installed to
provide a separation distance of at least 20cm from all persons.
This device must not be co-located or operating in conjunction with any other
antenna or transmitter.
WARNING: Any changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
High power radars are allocated as primary users of the 5.25 to 5.35 GHz
and 5.65 to 5.85 GHz bands. These radar stations can cause interference
with and/or damage this device. No configuration controls are provided for
this wireless equipment allowing any change in the frequency of operations
outside the FCC grant of authorization for US operation according to Part
15.407 of the FCC rules.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
IC statement
This device complies with RSS247 of Industry Canada.
Cet appareil se conforme à RSS247 de Canada d’Industrie.
This device complies with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables
aux appareils radio exempts de licence. L’exploitation est autorisée aux deux
conditions suivantes :(1) l’appareil ne doit pas produire de brouillage, et (2)
l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
Radiation Exposure Statement: The product complies with the Canada
portable RF exposure limit set forth for an uncontrolled environment and are
safe for intended operation as described in this manual.
The further RF exposure reduction can be achieved if the product can be kept
as far as possible from the user body or set the device to lower output power if
such function is available.
Déclaration d’exposition aux radiations : Le produit est conforme aux limites
d’exposition pour les appareils portables RF pour les Etats-Unis et le Canada
établies pour un environnement non contrôlé.
Le produit est sûr pour un fonctionnement tel que décrit dans ce manuel.
La réduction aux expositions RF peut être augmentée si l’appareil peut être
conservé aussi loin que possible du corps de l’utilisateur ou que le dispositif
est réglé sur la puissance de sortie la plus faible si une telle fonction est
disponible.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du
Canada.
CAN ICES-3 (B)/NMB-3(B)
To prevent radio interference to the licensed service, this device is intended to
be operated indoors and away from windows to provide maximum shielding.
Equipment (or its transmit antenna) that is installed outdoors is subject to
licensing.
Pour empêcher que cet appareil cause du brouillage au service faisant
l’objet d’une licence, il doit être utilisé a l’intérieur et devrait être placé loin des
fenêtres afin de fournir un écran de blindage maximal. Si le matériel (ou son
antenne d’émission) est installé à l’extérieur, il doit faire l’objet d’une licence.
Notice for 5 GHz devices
Caution: (i) The device for operation in the band 5150 - 5250 MHz is only for
indoor use to reduce the potential for harmful interference to co-channel
mobile satellite systems; (ii) the maximum antenna gain permitted for devices
in the bands 5250 - 5350 MHz and 5470 - 5725 MHz shall comply with the
e.i.r.p. limit: and (iii) the maximum antenna gain permitted for devices in the
band 5725 - 5825 MHz shall comply with the e.i.r.p. limits specified for point-
to-point and non point-to-point operation as appropriate. (iv) Users should
also be advised that high-power radars are allocated as primary users (i.e.
priority users) of the bands 5250 - 5350 MHz and 5650 - 5850 MHz and that
these radars could cause interference and/or damage to LE-LAN devices.
Exposure of humans to RF fields (RSS-102)
The computers employ low gain integral antennas that do not emit RF field
in excess of Health Canada limits for the general population; consult Safety
Code 6, obtainable from Health Canada’s Web site at http://www.hc-sc.gc.ca/
The radiated energy from the antennas connected to the wireless adapters
conforms to the IC limit of the RF exposure requirement regarding IC
RSS-102, Issue 5 clause 4. SAR tests are conducted using recommended
operating positions accepted by the FCC/ RSS with the device transmitting at
its highest certified power level in all tested frequency band without distance
attaching away from the body. Non-compliance with the above restrictions
may result in violation of FCC RF exposure guidelines.
Conformité des appareils de radiocommunication aux limites d’exposition
humaine aux radiofréquences (CNR-102)
L’ordinateur utilise des antennes intégrales à faible gain qui n’émettent pas
un champ électromagnétique supérieur aux normes imposées par Santé
Canada pour la population. Consultez le Code de sécurité 6 sur le site
Internet de Santé Canada à l’adresse suivante : http://www.hc-sc.gc.ca/
L’énergie émise par les antennes reliées aux cartes sans fil respecte la limite
d’exposition aux radiofréquences telle que définie par Industrie Canada dans
la clause 4.1 du document CNR-102, version 5. Tests DAS sont effectués
en utilisant les positions recommandées par la FCC/CNR avec le téléphone
émet à la puissance certifiée maximale dans toutes les bandes de fréquences
testées sans distance attacher loin du corps. Non-respect des restrictions ci-
dessus peut entraîner une violation des directives de la FCC/CNR.
Declaration of
conformity
Hereby, Zound Industries International AB, declares that this product is in
compliance with the essential requirements and other relevant provisions of
Directive R&TTE 1999/5/EC and the RoHS directive 2011/65/EU.
For the declaration of conformity, visit this website: http://www.urbanears.
com
Zound Industries International AB, Centralplan 15 111 20 Stockholm Sweden
Website: http://www.urbanears.com
The user is recommended to visit the Website regularly for up-to-date
information.
