USAVision UA-CB550F3 User manual

Before attempting to connect or operate this product,
please read these instructions carefully and save this manual forfuture use. UVSANALOG-QG-A
Quick Start Guide
HD Analog Cameras
UA-CB550F3
UA-CR200F2, CR510F2
UA-CR250F2, CR550F2

© 2022 USAVision, Inc. All rights reserved.
Under the copyright laws, this manual may not be copied, in whole or in part, without
the written consent of USAVision.
Every effort has been made to ensure that the information in this manual is accurate.
USAVision makes no expressed or implied warranty of any kind and assumes no
responsibility for errors or omissions. No liability is assumed for incidental or
consequential damages arising from the use of the information or products contained
herein. Features and specifications are subject to change without notice.
USA Vision Systems Inc.
9301 Irvine Blvd,
Irvine, CA 92618, USA
Tel: [phone]
Fax: [phone]
https://www.geovision.com.tw/us/
February 2022
Scan the following QR codes for product warranty and technical support policy:
[Warranty] [Technical Support Policy]

Contents
1. Connection Diagram...........................................................................................1
2. Installation ...........................................................................................................2
2.1 Bullet Camera Installation ........................................................................................2
2.2 Dome Camera Installation........................................................................................3
i
2.3 Vandal Proof Dome Camera Installation ..................................................................6

1
1. Connection Diagram

2. Installation
2.1 Bullet Camera Installation
Ceiling Mounting
Insert three expansion bolts in place into the ceiling and fix the equipment with three
mounting screws.
2

2.2 Dome Camera Installation
Ceiling Mounting
Paste the sticker in place at the proper position as selected.
Remove the collar off the camera by rotating it down.
3

Fix the pedestal by drilling locking holes around the sticker and inserting three
expansion bolts into the holes and fastening it with three locking screws.
Mount the collar back by rotating it up.
4

Adjust it to an appropriate angle.
5
Complete of Installation

2.3 Vandal Proof Dome Camera Installation
Ceiling Mounting
Apply the position sticker to the desired camera mounting position.
6

7
Cover Component
Remove the cover component by loosening the three locking screws with the included
hex wrench.
Use the position indicated on the position sticker to drill the holes needed to mount the
camera base. Insert the expansion bolt into the holes. Match the base's mount
openings to the expansion bolts position, and then place the mounting screws through
the base's mount opening into the expansion bolt. Tighten the mounting screws to
ensure the camera base mounted securely.
zPlace the cover component back onto the base.
zPlease make sure the locking screw position on the cover component matches the
locking post on the base.
zTighten the locking screws after the cover component is in the correct position.
