Utah Sandar UTAH-100/X16V Installation and operating instructions

Utah Sandar AS
User Manual & Installation Guide
UTAH100/X16V
16x16, 8x8 Wide Band Router with/without
UTAH-100/X16V, UTAH-100/X16VCP,
UTAH-100/X8V, UTAH-100/X8VCP

User Manual & Installation Guide
UTAH100/X16V
Document: 3256_user11
Date: 2010-03-10, Rev. 1.1
2
CONTENTS
CONTENTS.................................................................................................................................................................. 2
INTRODUCTION......................................................................................................................................................... 3
WARRANTY................................................................................................................................................................. 3
DOCUMENT REVISION HISTORY......................................................................................................................... 3
SAFETY & ENVIRONMENT..................................................................................................................................... 4
GENERAL ................................................................................................................................................................... 4
SAFETY SYMBOLS ..................................................................................................................................................... 4
SAFETY EARTH GROUND.......................................................................................................................................... 4
ENVIRONMENT ........................................................................................................................................................... 4
INSTALLATION .......................................................................................................................................................... 5
INITIAL INSPECTIONS ................................................................................................................................................. 5
ESD HANDLING......................................................................................................................................................... 5
BEFORE APPLYING POWER ...................................................................................................................................... 5
SERVICE..................................................................................................................................................................... 5
GENERAL DESCRIPTION........................................................................................................................................ 6
EXTERNAL POWER SUPPLY...................................................................................................................................... 7
UTAH-100 CONTROL SOFTWARE:...................................................................................................................... 7
PINOUT......................................................................................................................................................................... 7
POWER CONNECTION ............................................................................................................................................... 7
PORT PIN ORIENTATION ........................................................................................................................................... 7
SPECIFICATIONS...................................................................................................................................................... 9
BLOCK DIAGRAM ...................................................................................................................................................10
MODEL UTAH100/X16V......................................................................................................................................... 10
MODEL UTAH100/X16VCP.................................................................................................................................. 11

User Manual & Installation Guide
UTAH100/X16V
Document: 3256_user11
Date: 2010-03-10, Rev. 1.1 3
Utah Sandar AS
Thorøyaveien 11
N-3209 Sandefjord,
Norway
Tel.: [phone]
Fax: [phone]
INTRODUCTION
Thank you for choosing a Utah Sandar product.
We are convinced that your choice will prove to be a wise
and worthy decision for many years to come.
Your Utah Sandar product has been tested for performance at the
factory according to the specifications given for the system in this
manual. However, before putting the device into
operation we kindly ask you to read this manual, and
act according to the information given.
All information given in this document is property of Utah
Sandar. To the knowledge of Utah Sandar there are no
errors in the manual. Should any errors be discovered,
please notify Utah Sandar. Utah Sandar will under no
circumstances accept responsibility neither for errors in this
manual, nor consequences of such errors.
WARRANTY
This Utah Sandar product is warranted against defects in materials and workmanship for a period of two
(2) years from the date of invoice. During the warranty period, Utah Sandar will, at its option, either
repair or replace products that prove to be defective.
The warranty shall not apply to defects resulting from improper or inadequate installation or
maintenance by buyer, buyer-supplied software or interfacing, unauthorized modification or misuse,
operation outside of the environmental specifications for the product, or improper site preparation or
maintenance.
If a product needs to be returned for service, please first contact the Utah Sandar Helpdesk to obtain a
Return Material Authorization (RMA) number. Make sure the packaging provides sufficient protection
against ESD and mechanical damage. Please enclose a note with the RMA, return address, contact
person details and a failure symptom description.
DOCUMENT REVISION HISTORY
Re
v
. Date Description
1.0 2010-01-13 Changed the specifications
B 2009-10-26 Changed Company and product name
A 2009-06-02 Preliminary

User Manual & Installation Guide
UTAH100/X16V
Document: 3256_user11
Date: 2010-03-10, Rev. 1.1
4
SAFETY & ENVIRONMENT
General
This product and related documentation must be reviewed for familiarization with safety markings and
instructions before operation. This product has been designed and tested in accordance with the
relevant international standards.
Safety Symbols
Indicates hazardous voltages.
Indicates earth (ground) terminal.
!
The CAUTION sign denotes a hazard. It calls attention to an operating procedure,
practice, or the like, which if not correctly performed or adhered to could result in
damage to or destruction of part or all of the product. Do not precede beyond a
CAUTION sign until the indicated conditions are fully understood and met.
STOP
The WARNING sign denotes a hazard. It calls attention to a procedure, practice, or the
like, which, if not performed or adhered to could result in personal injury. Do not proceed
beyond a WARNING sign until the indicated conditions are fully understood and met.
Safety Earth Ground
This is a Safety Class 1 product (a protective earth terminal (Ch) is provided).
An uninterrupted safety earth ground must be provided from the main power source to the product input
wiring terminals, power, cord, or supplied power cord set. Whenever it is likely that the protection has
been impaired, the product must be made inoperative and secured against any unintended operation.
Environment
WEEE: All Utah Sandar products will comply with the EU Directive 2002/96/EC on
Waste from Electrical and Electronic Equipment aka WEEE directive. Please contact
your local Utah Sandar sales representative for information about returning these
products for safe disposal/recycling. Utah Sandar equipment that complies with the
directive will be marked with a WEEE-compliance emblem.
RoHS: All Utah Sandar products will comply with the EU Directive 2002/95/EC on
Restriction of Hazardous Substances aka RoHS directive. Thereby not containing above
the limits specified in the said directive of any of the banned substances. Utah Sandar
equipment that complies with the directive will be marked with a RoHS-compliance
emblem.
Exempt: Spare/Expansion parts for older systems are exempt from the directive.

User Manual & Installation Guide
UTAH100/X16V
Document: 3256_user11
Date: 2010-03-10, Rev. 1.1 5
INSTALLATION
Initial Inspections
Check the contents of the shipment for completeness and possible transport damage.
If the contents are incomplete or damaged, contact Utah Sandar AS immediately for repairing or
replacement parts of the equipment.
ESD Handling
This product may contain Electrostatic Sensitive Devices (ESD).
Precautions to minimise the risk of damage, due to electrostatic discharge during
handling, are recommended. For guidance, refer to British Standard BS CECC 00015,
Part 1:
BASIC SPECIFICATION FOR PROTECTION OF ELECTROSTATIC SENSITIVE DEVICES
!
Before Applying Power
Verify that the product is configured to match the available main power source per the
input power configuration instructions provided in this manual and product marking.
STOP
Service
Servicing, adjustments, maintenance or repair of this product may be performed by
qualified personnel only. Adjustments described in this manual may be performed with
power supplied to the product while protective covers are removed. Energy available at
many points may, if contacted, result in personal injury. Capacitors inside this product
may still be charged even when disconnected from their power source.

User Manual & Installation Guide
UTAH100/X16V
Document: 3256_user11
Date: 2010-03-10, Rev. 1.1
6
GENERAL DESCRIPTION
The UTAH100/X16V Compact 16x16 Wideband Router fully complies with the relevant standards for
PAL and NTSC and Wideband formats. The router has a multi-sync loop through input that handles bi-
level and tri level sync. Having both an Ethernet SNMP/HTTP/SanEth) and DSUB9P RS-232 interface
for remote control and configuration makes it very adaptable to any 3rd party control system.
16 LED’s in the front lit in presences of signal on the outputs.
The Power consumption and the heat dissipation for the UTAH100/X16V family is low saving the
environment and giving the products a long lifetime.
The UTAH-100/X16HD is delivered in four models:
Model UTAH-100/X16V : 16x16 with 16 LEDs for signal presences in the front.
Model UTAH-100/X16VCP : 16x16 with Push Buttons in the front 16 for outputs selection and 16
for input selection.
Model UTAH-100/X8V : 8x8 with 8 LEDs for signal presences in the front.
Model UTAH-100/X8VCP : 8x8 with Push Buttons in the front 8 for outputs selection and 8
for input selection.
The UTAH100/X16V is delivered with a standard off-the-shelf universal AC/DC converter. Two
Independent power inputs are provided to enable redundant supplies.
The 19” wide, 1RU high and 60 millimetres deep frame houses the switch, local control unit and RS-232
and Ethernet remote control interface. Two 12 VDC 2.1mm power input connectors enable use of
redundant power supplies.
UTAH-100/X16V
UTAH-100/X16VCP
UTAH-100/X8V
UTAH-100/X8VCP

User Manual & Installation Guide
UTAH100/X16V
Document: 3256_user11
Date: 2010-03-10, Rev. 1.1 7
External Power Supply
The external Power Supply is an AC/DC Switch Mode desktop power supply module with compact
design. The power supply has a universal input voltage, with 3 pins IEC 320 connector. The output
voltage is 13.2 VDC and is short circuit proof and deliver up to 40W. One secondary cable with the
modular connector in the one end connects to the power supply and the other end with a 5.5/2.1mm jack
connects to the UTAH-100/XHDA frame. Utah Sandar recommends the Power Supply 9920 from
Mascot A/S, but other types of Power Supplies may be used with similar specifications. Mains cord is
not included.
Mounting bracket is available.
UTAH-100 CONTROL SOFTWARE:
For Quick Start Guide see the attached document in the delivery.
UTAH-100 Control Software see the document file: UTAH-100-ControlSoftware10.pdf attached
in the user manual CD.
PINOUT
Power Connection
The UTAH100/X16V units have two 2.1mm DIN 12VDC connector with + at centre.
The power unit supplied for the UTAH100/X16V is a 12 VDC with a max rating of 0.8A (10W)
Port Pin Orientation
Ethernet Port
The Ethernet port is an 8-pin RJ-45 jack meeting the requirements of ISO 8877 for 10/100Base-T.
Ethernet Pin Assignment
Pin Signal Name Figure
RJ-45
1 TxD+ (Transmit Data)
2 TxD- (Transmit Data)
3 RxD+ (Receive Data)
4 Not used
5 Not used
6 RxD- (Receive Data)
7 Not used
8 Not used
RS-232 Port

User Manual & Installation Guide
UTAH100/X16V
Document: 3256_user11
Date: 2010-03-10, Rev. 1.1
8
Serial port, RS-232 is a DSUB9pin (male) connector. Use the following figure and tables for pin
orientation and pin assignment information.
Serial Pin Assignment
Port Signal
Pin1 Signal Pin 2 Signal Pin3 Signal Pin4 Signal Pin5 Signal Pin6 Signal Pin7 Signal Pin 8 Signal Pin 9
RS-
232 Not
connected
RxD TxD Not
connected
GND Not
connected
Not
connected
Not
connected
Not
connected

User Manual & Installation Guide
UTAH100/X16V
Document: 3256_user11
Date: 2010-03-10, Rev. 1.1 9
SPECIFICATIONS
T
ype Analogue Video
Standard PAL, NTSC
Number of In/Out Model UTAH100/X16V
Model UTAH100/X16VCP
Model UTAH100/X8V
Model UTAH100/X8VCP
16x16
16x16 with 32Pb Control Panel
8x8
8x8 with 16Pb Control Panel
Impedance 75 Ohm
Output level 1Vp-p ±1%
Return Loss Input/Output up to 5 MHz
5 MHz to 270 MHz
≥35dB
> 15dB
Crosstalk up to 5 MHz ≥60dB
5 MHz – 100 MHz ≥35dB
Frequency Response 100 kHz – 50 MHz + 0/- 0.5 dB
BW > 100 MHz
Connecto
r
BNC
V
ideo Reference Input
T
ype Analogue Video Reference according to SMPTE RP168
Standard PAL, NTSC
Connecto
r
BNC Loop-Through
Impedance Hi-Z, External 75 Ohm termination
Input Level 0.5 Vpp - 2 Vpp
Input Return Loss to 5 MHz (75 Ohm term.) > 40 dB
Ethernet
T
ype 10/100 Base T
Standard IEEE 802.3
Connecto
r
RJ45
RS-232
T
ype RS-232(DTE)
Connecto
r
DSUB 9 PIN
Electrical
DC input 12 VDC
DC Connecto
r
DC Jack 2.1mm
DC Powe
r
8x8
8x8 CP
16x16
16x16 CP
6.4 W
7 W
7.2 W
8 W
Operating Temperature Range 0 °C - +45 °C
Humidity 90 % non condensing
External Power Supply Universal 90-250VAC, 50/60Hz
Mechanical
Dimensions W: 482.6mm (19”) H: 43.6mm (1U) D: 52mm + Connectors
W
eight 0.7/0.8 kg
Utah Sandar AS reserves the right to change specifications without prior notice.

User Manual & Installation Guide
UTAH100/X16V
Document: 3256_user11
Date: 2010-03-10, Rev. 1.1
10
BLOCK DIAGRAM
Model Utah100/X16V
