Valcom VIP-201 User manual

TECHNICAL
SPECIFICATIONS
FEATURES:
Easy To Install
Live or Recorded Messages
65,000 Speakers, Expandable To 256 IP Paging Zones
Easily Connect Loudspeaker System To Existing Computer Networks
Compatible With Cisco, Nortel, Avaya, Iwatsu And Most IP Telephone Systems
Supports IP And Analog Amplified Speakers
Supports IP Talkback Speakers
Supports Legacy Paging Systems
Synchronized Clock Compatibility
PoE (802.3af) Or Local Power
SIP And Multicast
Network Supervision
Night Ring
Feedback Eliminator
DHCP
Applications
General: Paging /notification applications over existing networks
Governments: Provide secure, supervised, high survivability notification systems
Healthcare: The most practical way to page huge facilities
Education: Cost effectively page hundreds of buildings (supervised)
Transportation: Airports, Ferry Terminals, Subway Stations, Bus Stops, etc
General Description
The PagePro IP Model VIP-201 is a SIP based paging server designed for use with virtually all IP based
telephone systems. The unit provides 8 zones, groups thereof and all call paging. This PagePro IP unit
can drive up to 65,000 IP speakers or 65,000 analog speakers or provide the audio source for legacy
paging systems. It can simultaneously drive any combination of these paging applications. The VIP-201
can form the foundation of most paging projects. The 8 zones can be accessed individually or in flexible
groups.
PagePro IPTM
SIP Based Paging Server
Model VIP-201
Valcom Inc. 5614 Hollins Road Roanoke, Virginia 24019 Phone: [phone] Fax: [phone]
E-Mail: [email protected] www.valcom.com

Valcom Inc. 5614 Hollins Road Roanoke, Virginia 24019 Phone: [phone] Fax: [phone]
E-Mail: [email protected] www.valcom.com
Group Paging Features
The PagePro IP Model VIP-201 allows SIP
based phone systems to page any number of
Valcom IP speakers, Valcom Amplied
Speakers and Valcom VIP series analog
paging gateways. Valcom multicast group
paging features robust grouping and priority
controls. These controls make it easy to
distribute low priority announcements yet
allow high priority paging to override ongoing
announcements.
Group Paging Features
The PagePro IP Model VIP-201 provides 8
IP zones and 1 analog output capable of
driving a mix of Valcom self amplied
overhead paging speakers and horns. The
VIP-201 provides 8 fully customizable SIP
identities that can access any combination
of IP zones and the analog port. Analog
paging functions can be seamlessly combined
with IP paging functions allowing powerful
combinations of analog and IP paging.
Group Paging Priority Feature
Any page group or port can be assigned a
priority. These priorities allow a logical
scaled approach to group paging. An
absolute priority can be assigned to allow for
emergency override in any circumstance.
Group paging priorities work locally or across
ganged units in the same fashion allowing
facility wide emergency paging. Red Phone
functionality is easily achieved with either IP
phone or analog handsets via a Valcom
gateway.
Feedback Elimination Feature
The PagePro IP Model VIP-201 provides
programmable store and forward capability
for all paging accesses. This features
records up to 30 seconds of audio, and then
replays the audio when the page call is
terminated. The number of times the
recorded audio is played back can be set
from 1 to 4. Some paging applications
require live announcements. For these
applications the store and forward capability
can be turned on/o per page zone.
Night Ring Features
The PagePro IP Model VIP-201 provides Night
Ring functionality on any of the 8 SIP identities.
This feature generates a tone to any paging
groups when the SIP identity is called.
Audio Supervision Features
The PagePro IP Model VIP-201 provides
internal monitoring of the audio path from the
network connection to the analog output
connector and can report failures to an
external device or syslog facility.
Legacy Applications
The PagePro IP Model VIP-201 provides 1
analog output that can easily be conditioned
to drive any existing overhead paging
system. Legacy paging features can be
seamlessly combined allowing powerful
combinations of legacy analog and IP
paging.
Valcom Inc. 5614 Hollins Road Roanoke,Virginia 24019 Phone: [phone] Fax: [phone]
E-Mail: [e-mail] www.valcom.com

Valcom Inc. 5614 Hollins Road Roanoke, Virginia 24019 Phone: [phone] Fax: [phone]
E-Mail: [email protected] www.valcom.com
SPECIFICATIONS:
25 Volt Amplier
IP Sector
Analog Sector
Shipping Department
SIP Telephone
Call Manager
IP Speaker
Front Office
VIP-201
Warehouse
STATUS
LINK
ACT
PagePro IP
Cafeteria
IP Horn
Valcom PagePro IP VIP-201 allows paging from any SIP compliant telephone to 8 SIP page destinations. The
SIP page destinations can be the VIP-201's analog output, or any combination of page groups from other
Valcom VIP units. The analog output on the VIP-201 is line level –10dBm audio. This output is designed to
directly drive up to 150 Valcom self-amplified speakers. The output is also suitable for connection to an
auxiliary input on a utility amplifier of a legacy paging system.

Valcom Inc. 5614 Hollins Road Roanoke, Virginia 24019 Phone: [phone] Fax: [phone]
E-Mail: [email protected] www.valcom.com copyright ©©
©©
© June 2006
Physical
1U 19" Rack Mount
Power
External: 24 VDC @ 325 mA
POE: 802.3af, class 3
Networking
10/100 Mbps Ethernet port
Manual or Dynamic Host Configuration Protocol
(DHCP) IP address setup.
Time and date synchronization using NTP
Protocols
IETF SIP (RFC3261)
IETF IGMP version 3 (RFC3376)
IETF RTP (RFC1889)
IETF RFC2833
Digest Authentication
Audio Specifications
Local Music Source Input Impedance: 8 to 600 Ohms
Local Music Input Level: -10dBm nominal
Output Impedance: 50 Ohms
Output Level: - 10dBm nominal
Relay Specifications
Relay Current: 1 AMP @ 24VDC
Environment
Temperature: 0 to +40° C
Humidity: 0 to 85% non-precipitating
Feature Highlights
1 Audio Analog Outputs
2 Form C relay closures
Programmable Feedback elimination
Audio supervision
Night Ring
SPECIFICATIONS:
PagePro IPTM
SIP Based Paging Server
Model VIP-201
