Vandlion V30 User manual

Vandlion digital voice recorder
0
V30
User Manual

Vandlion digital voice recorder
1
Thank you for your purchase! We are very
happy that you have chosen our portable voice
recorder. We are 100% committed to your
customer satisfaction. If you experience any
issue with your device at any time, please contact
us at [email protected] with your Amazon
order number.
1.Precautions
Charging
Do not use the Recorder or leave the recorder on
the bed, under the pillow and other locations
accessible to children during the charging
process.
Document Completeness
Do not push the power switch to prevent the
current recording document from being lost
during the recording process.
Interferences
All device are possibly interfered, which may
influence their functions. Please keep far from the

Vandlion digital voice recorder
2
interference sources when the Recorder works.
Backup
Please keep backup documents in case that
external errors or operation failure may lead the
machine to lose itself documents.
Transmission
Do not disconnect the Recorder from computer
during data transmission process to prevent data
loss.
2.Parts and Controls

Vandlion digital voice recorder
3
1.Record/Save button
2.Volume up button
3.Volume down button
4.Screen
5.Rewind/Previous file button
6.Stop/Escape button
7.Fast forward/Next file button
8.Pause/Play button
9.Power switch
10.USB port
11.Headphone jack
12.Microphone
13.Line in jack

Vandlion digital voice recorder
4
3.Charge
Connect the recorder to your computer via the
USB cable(Supplied).
Inset the micro USB end to the recorder, and the
USB end to the USB port of a running computer.
When the recorder is charging, the screen will
show electric quantity atop right.
The battery will be fully charged after about 4
hours and then can work 150 hours
4.Turn the Power On
Slide up the “Power switch”, the
“WELCOME” animation appears,
and “Home Menu” page displays.

Vandlion digital voice recorder
5
5.Turn the Power Off
Slid down the “Power switch”, the
“BYE” animation appears, and the
recorder is turned off.
Hint
When the recorder is in the stop mode, and you
leave the recorder without attempting. an
operation for approximately 5 minute, the auto
power off function will take effect.
6. Record
Slide up
and hold the “Record/Save
button”in the direction of “REC” to

Vandlion digital voice recorder
6
start recording in the stop mode.
Place the recorder so that the built-in
microphones face the direction of the source to
be recorded.
The new file will be automatically recorded as
the last file in the current folder.
Slide down and hold the “Record/Save button”,
in the direction of “SAVE” to stop
recording and save recording
documents.
7. Play
In the Home Menu page,select “Record
Settings” - “Recordings library”,and then press
“ ”button.
Press“VOL+” or “VOL-”button to select the file
you want to playback,and then press “ ”

Vandlion digital voice recorder
7
button to start playing the file.
Press “VOL+”or “VOL-”button to adjust the
volume.
Press“ ”button to stop playing.
8. “A-B”Repeat Play
Playing state,Press “ ” to
select “A”,the screen will flash “A”, press this
button again to select “B”,and then start “A-B”
repeating.
Once selected,it will repeat play the A-B interval
Press “ ”again to
cancel.
9.Erase

Vandlion digital voice recorder
8
In standby mode, select the file you want to
delete,Long press stop key to enter.
Press “ ”or“ ”button to select
“No”/“Yes”/“Delete all”, Press “ ” confirmation.
“No”：Cancel delete.
“Yes”：Delete single file.
“Delete all”：Delete all files in folder.
Press the “ ” button to confirm.
Press “ ”to return standby mode.
Note
Once a file has been erased, you cannot retrieve
it.
10.MP3 Function
Download music to the root directory of the
machine through USB.

Vandlion digital voice recorder
9
Press “ ” to enter the MP3 player interface.
Play music with the same voice.
11. Recording Settings
In standby mode, press the “ ” key to enter.
The following settings press the “ ” button
to confirm, press the “ ” key to exit
Press “ ”to select the recording settings,
press the “ ” to enter.
1)Recorder Mode
a.Normal Mode
b. VOR Mode
Note
When you choose the voice
mode, the recording state, the sound around the
machine is greater than the set value, start
recording, less than the machine set value,

Vandlion digital voice recorder
10
tentative recording, please
use this feature.
2) Catalog choice
a. A
b. B
c. C
d. D
When selecting the A folder, the voice file is
stored in the A folder.
3) Record type
a.PCM
b.SP Recording
c.LP Recording
d.Long REC
4) Record from
a.Microphone
b.Line-in
When you need to record,
select Line-in
5) Scene
a.Interview
b.Conference

Vandlion digital voice recorder
11
c.Train Station
d.Remote
According to the different settings, recording
effect is not the same.
6) Vox Set
a.Clsoe
b.Open
7) VOR Level
When the sound recording
is turned on, it can adjust
the size of the input.
8) AGC Set
Can set the level of noise
reduction
9) Record Subsection
According to their own
needs, recording files can
be divided into: 30 minutes,
60 minutes.....360 minutes。
12. Play Mode

Vandlion digital voice recorder
12
In standby mode, press the “ ” key to enter.
The following settings press the “ ” button
to confirm, press the “ ” key to exit.
Press “ ”to select the Play Mode, press the
“ ” to enter.
1) RePeat One
2) Repeat All
3) Normal
4) Random
You can select four play modes.
13.Screen saver Time
The following settings press the “ ” button
to confirm, press the “ ” key to exit.
1) Open
2) 5 Second
3) 10 Second
4) 20 Second
5) 30 Second
Save time by selecting screen savers
14.Time Settings
The following settings press the “ ” button
to confirm, press the “ ” key to exit.

Vandlion digital voice recorder
13
1) Press “ ”to select the
desired position.
2) Press“+/-”adjust number.
15. Language
The following settings press the “ ” button
to confirm, press the “ ” key to exit.
1) Simple Chinese/Trad
Chinese/English..............
Indonesian.
2) Support 24 languages
16. Tools
The following settings press the “ ” button
to confirm, press the “ ” key to exit.
1) Auto Record
a.Record(Off)
b.Record(On)
Timing recording, the
power switch must be in
the “On” state.
When I choose to

Vandlion digital voice recorder
14
“Record(On)” quasi current system time.
Into the regular “Record(On)”, adjust the start
time, press the “ ”or“ ”button to select the
location, “+/-” adjust the number.
2) Password Switch
a.Password Off
b.Password On
When you “Password On”,
set a password.
3) Password Set
Press “ ”or“ ”to adjust
position, “+/-” key to adjust
number.
Set a good password, boot with the connection
PC need a password.
please record the password set, forget the
password, enter 9999, long press the “ ” key
to crack.
17. Auto switch off
a.Close
b.1 Minute
c. 5 Minute

Vandlion digital voice recorder
15
d.10 Minute
e. 30Minute
f. 60Minute
Press the “ ”or“ ”button to select the timing
of the shutdown time.
18. Restore factory Settings
All settings are restored to the initial state.
19.Copy Files with PC
Connect the Recorder to the PC via the USB
cable.

Vandlion digital voice recorder
16
Copy files or folders to your computer.
Copy the PC side of the music to voice recorder.

Vandlion digital voice recorder
17
20. General Specification
Display screen
128*64 LCD screen
Disk Capacity
8GB/16GB
Product size
4.25 x1.41x0.4 Inches
Weight
2.57 OZ
Recording Format
WAV
Recording Mode
Microphone/Line-in
WAV
REC type
Recording bit
ratetime(8GB
8GB Storage time
PCM
384kbps
45hours
SP Recording
192kbps
90hours
LP Recording
128kbps
126hours
Long REC
32kbps
280hours
Music Format
MP3，WAV
Interface
USB2.0
Use temperature
0°C~45°C
Power Supply
Built-in lithium polymer battery
Battery Capacity
1600mAh
Earphone jack
3.5 mm Stereo
microphone jack
3.5 mm
Built in speaker output
8Ω1W

Vandlion digital voice recorder
18
CONTACT US
We really appreciate you choosing Vandlion®as
your trusted brand of digital voice recorders and
we sincerely hope you enjoy your purchase. We
love making our customers happy by providing
true value with our products.
If you have any questions or concerns, please let
us know immediately,please contact Vandlion®
directly at [email protected] .
We will do everything to make sure you are
happy!
