Varme VT3130 Operating instructions

SERVICE INSTRUCTIONS
1
VT3130 / VT3131 / VT3132 VT3130 ECO / VT3131 ECO / VT3132 ECO VT2130 / VT2131 / VT2132

SERVICE
2
• Technical data
• Installation requirements
• Remove heat pump from pallet
• Adjustment of feet
• The display
• System options
• Alarm descriptions
• Piping (water connections)
• Safety group (water connections)
• Piping (air connections)
• Use of coils
• Use of Photovoltaic
• How to change components
• Complaints
• Contact
INDEX

SERVICE
3
TECHNICAL DATA
Voltage/frequency: 230 V ~ 50 Hz (Phase-Neutral-Earth)
Heat pump output: (with SC10GHH compressor / with BSD122 DT compressor) 1,4 kW / 1,7 kW
Heat pump input: (with SC10GHH compressor / with BSD122 DT compressor) 395 W / 600 W
High supplementary heating: 2,0 kW / 230 V
Fuse protection: > 13 A
Thermostat for supplementary heating: Bei 65 °C, Controlled via the display
Protection: IP20
Water temperature: Adjustable - max. 62 °C
Refrigerant: R 134 a (CH2FCF3)
Amount of refrigerant: 0,990 Kg or see name plate
Leak tested:
Air temperature: -10 °C to +35 °C
Air flow: 200 to 300 m3/h
Stock temperature: -20 °C bis +60 °C
External pressure in ventilation system without affecting the performance: 80 Pa (Fan speed 1)
Boiler – VT3130 / VT3130 ECO / VT2130: 270 l, Enamelled
Boiler – VT3131 / VT3131 ECO / VT2131: 258 l, Enamelled
Boiler – VT3132 / VT3132 ECO / VT2132: 242 l, Enamelled
Anode: 5/4” RT
Pressure tested: 13 bar / 1.3 MPa
Working pressure: 10 bar / 1 MPa
Max. boiler temperature: 65 °C
Weight without packaging – VT3130 / VT3131 / VT3132: 145 Kg / 168 Kg / 190 Kg
Weight without packaging – VT3130 ECO / VT3131 ECO / VT3132 ECO: 134 Kg / 157 Kg / 179 Kg
Weight without packaging – VT2130 / VT2131 / VT2132: 152 Kg / 175 Kg / 197 Kg
Weight (full load) – VT3130 / VT3131 / VT3132: 396 Kg / 411 Kg / 417 Kg
Weight (full load) – VT3130 ECO / VT3131 ECO / VT3132 ECO: 384 Kg / 399 Kg / 405 Kg
Weight (full load) – VT2130 / VT2131 / VT2132: 406 Kg / 421 Kg / 427 Kg
Water connections: Cold water: 1” RT
Hot water: 1” RT
Condensation water: 1/2” RT
Heat exchanger: 1” RT
Cirkulation: 3/4” RT
Heat exchanger, heat surface VT3131 / VT3131 ECO / VT2131: 1.00 m2 (5.90 l)
Heat exchanger, heat surface VT3231 / VT3231 ECO / VT2231: Lower 1.5m2 (9.57L) +
upper 0.6m2 (3..83 L)
Idle consumption - at 7 °C outside air and 55 °C hot water temperature: 27 W / 24 hours*
Idle consumption - at 20 °C ambient air and 55 °C hot water temperature: 20 W / 24 hours*
COP: 2.83*
COP: 3,61**
*According to EN16147:2011, XL-Profile, outside air 7 °C / hot water reference 55 °C
** According to EN16147:2011, XL-Profile, ambient air 20 °C / hot water reference 55 °C

SERVICE
4
INSTALLATION REQUIREMENTS
Models: VT3130, VT3131 and VT3132
Minimum ceiling height (Still a risk of EPP touching the ceiling) = 1970 mm
Recommended ceiling height is 1970 mm plus 300 mm = 2270 mm
to assure free movement and possibility of mounting duct connections.
Models: VT3130 ECO, VT3131 ECO and VT3132 ECO
Minimum ceiling height (Still a risk of EPP touching the ceiling) = 2100 mm
Recommended ceiling height is 2100 mm plus 300 mm = 2400 mm
to assure free movement and possibility of mounting duct connections.

SERVICE
5
INSTALLATION REQUIREMENTS
Recommended free space around the heat pump for optimal maintenance and
servicing possibilities and duct connections.
On the backside of the heat pump please also respect free space for maintenance
and servicing all hydraulic connections.
All damage and service impossibilities due to reduced accessibilty are part of the
installer/user responsibility and not covered by the manufacturer’s warranty.
300 mm
500 mm 500 mm
The heat pump should always be positioned in correct level or 1° backwards for
the defrost water to run out in a proper way.

SERVICE
6
INSTALLATION REQUIREMENTS
Defrost water tube must be mounted in
correct level of the defrost water outlet of the
heat pump and into the drainage. If tube is
above correct level the defrost water will run
backwards and into the heat pump and could
cause water leakage and this will cause
exclusion of warranty.

SERVICE
7
When the heat pump is placed at the customer the pallet must be removed.
• Tip or place the heat pump horizontal on the floor for easy dismounting of the pallet
• Loosen the screws that act as adjustable feet. (do not remove the screws)
• Remove the disc from all three feet
• Remove the pallet
REMOVE HEAT PUMP FROM PALLET

SERVICE
8
To adjust the feet do the following.
• The thrust washer (3) is placed under the adjustment screw
• The lock nut (1) is loosened
• The foot screw (2) is adjusted so that the heat pump is in a vertical position (90° or 1° backwards) and does not tilt
(important for the outlet of the defrost water)
• The lock nut (1) is tightened again.
• Ensure that the heat pump is installed in the right level to keep Manufacturer’s warranty
12
3
ADJUSTMENT OF FEET

SERVICE
9
LED for compressor
LED for supplementary heating
Button:
• choose option by rotation
• Accept option by press
• If submenus are available
a flash will appear;
rotate and press for acceptance
Display
THE DISPLAY

SERVICE
10
SYSTEM OPTIONS
Display View – Main menu
Main menu is visible for the consumer
When the power is first connected select language
(Factory setting is standard ENGLISH)
You can choose between: Danish, German, English, Spanish, French,
Polish, Slovenian and Italian.
If you need to change language at a later stage, this can be done
through the installers menu (service menu).
Shows the consumer the current water temperature
Only Info
Shows the customer the current evaporator temperature
Only info

SERVICE
11
SYSTEM OPTIONS
Display View – Main menu
Main menu is visible for the consumer
Shows the different alarms that can appear.
Up to 3 alarms are shown. ”0” = no alarm.
See alarm descriptions later in the service instructions.
Alarms are reset through pressure of the button.
Shows the current operating condition of the heat pump.
The following announcements can occur:
”off” = switched off
”Standby” = standby
”H.Water” = Works
”Legionel” = 65°C heating up in course (once a week)
”Def.Gas / Def. Stop” = Defrost condition
Shows the adjusted operating temperature.
Please note! This is an average temperature and not the hot water
output.
The temperature can be changed through pressure and again released
of the button, the operating temperature will then flash. By turning the
button, the desired water temperature will occur. If the desired water
temperature is reached, the button is pressed again for acceptance. The
standard factory setting temperature is "45°C".

SERVICE
12
SYSTEM OPTIONS
Display View – Main menu
Main menu is visible for the consumer
Minimum temperature.
The temperature can be changed through pressure and again release of the button, the
operating temperature will then flash. By turning the button, the desired minimum water
temperature will occur. If the desired temperature is reached, the button is pressed
again for acceptance. The minimum temperature is normally about. "35°C". If the
water temperature become lower than "T min" , the additional heating system will be
activated, if you in the menu "H.pump" have selected, e.g. "HP+EL" (or HP+Boil if
boiler is installed)
Select the combination of the Heat source.
There are the following options in the program:
"OUT", "HP", "EL", "HP+EL","BOILER", "HP+BOIL".
If no boiler is installed, the last 2 combinations are not in use
Similar function as T min. Used for “Draw Down function" and
"Holiday" function . The factory setting is "10 ° C".

SERVICE
13
SYSTEM OPTIONS
Display View – Main menu
Main menu is visible for the consumer
Here the automatic Legionella function can be switched on.
If switched ("ON") the heat pump will once weekly increase the
temperature to 65°C, in order to eliminate possible bacteria.
We recommend activating the legionella function in the night time where
hot water is not used.
The procedure must be activated in the parameter menu.
If the legionella procedure is activated, the legionella sequence will start immediately.
If the legionella procedure is deactivated, the legionella sequence will stop immediately.
If activated a new “legionella protection” cycle starts automatically after 7 days (168 hours). The function will be
deactivated at power cut.
In order to protect your installation against “legionella” or other bacteria, the water temperature goes up to 62°C by
means of the HP and the supplementary additional heating. At 62°C the device switches to the “supplementary
heating only mode” to heat further up to 65°C. This temperature is maintained for 1 hour before it will switch back to
normal operating mode. The “legionella protection cycle” is limited to 12 hours. If the legionella temperature is not
reached*, an alarm will be displayed. The alarm will disappear automatically after the next successful legionella
sequence or be reset on user acknowledgement.
* If the air temperature is too low and/or the DHW energy requirement during the “legionella protection” cycle is
higher than the needed output for the “legionella-protection” procedure.

SERVICE
14
SYSTEM OPTIONS
Display View – Main menu
Main menu is visible for the consumer
When selected "0" the fan will stop together with the heat
pump.
When selected "1" for low speed or "2" for high speed in
the condition standby. (= constant ventilation)
Fan speed, when the heat pump
runs.
"1" = low speed
"2" = high speed
This function permits to operate the DHW HP with cheap and
environmentally friendly energy from your own solar cell panels.
"Off" = Solar cells are not connected to system or not chosen to be used
by the user.
"HP only" , “EL only” and “HP + EL”: These values indicate the
chosen operation mode, when the solar cell function is activated by the
external inverter signal, see electrical diagram for correct wiring.

SERVICE
15
SYSTEM OPTIONS
Display View – Main menu
Main menu is visible for the consumer
5°C – T max
Set point temperature of “HP only “operating mode, when
Solarcel function activated (inverter signal)
5°C – T max
Set point temperature of “EL only “ or “HP + EL”
operating mode, when Solarcel function activated
(inverter signal)
This parameter activates/deactivates the holiday mode.
The holiday mode can be selected with the rotary/push button. The possible
selection are:
“Off”, “1 week”, “ 2 weeks”, “3 weeks”, “3 days”, “Manual”
When the holiday mode is activated, “T2 min” is the safety level for frost
protection.

SERVICE
16
SYSTEM OPTIONS
Display View – Main menu
Main menu is visible for the consumer
This parameter displays the number of holidays at
individual (manual) choice.
The holiday days can be selected with the rotary/push
button. The possible selection are: 1-99
This parameter displays status of the remaining number
of holidays. The possible values are: 0-99
This parameter activates/deactivates the BOOST operating mode in the
case of additional need for DHW. If the BOOST operating mode is
activated “ON”, the DHW production will be made by the HP and the
supplementary electrical heating either for a maximum cycle of 1 hour or if
Tmax is reached.
Possible values are:
“Off”, “On”. The factory setting is “OFF”.

SERVICE
17
SYSTEM OPTIONS
Display View – Main menu
Main menu is visible for the consumer
“AUS”, 30m/15s, 30m/30s, 60m/15s, 60m/30s, 90m/15s, 90m/30s
When activated the fan will stop for either 15 or 30 seconds every full
operating 30 minutes, 60 minutes or 90 minutes, according to the
selected value.

SERVICE
18
SYSTEM OPTIONS
Display View – Service menu
Service menu is only for the installer. Press the button for approx. 5 seconds
SERVICE MENU – Only for the installer.
The menu "software" tells which software version is installed.
The number “1.58" is the current installed version
SERVICE MENU – Only for the installer
“Defrost” shows the defrosting method:
"GAS", Only for VT2130 / VT2131 / VT2132
Only for VT3130 / VT3131 / VT3132
Only for VT3130 ECO / VT3131 ECO / VT3132 ECO
Service Def.None, Def.Gas
If the signal anode is factory mounted the value of the parameter
“ANODE” is already set to “ON”. If the signal anode is retrofit, the
parameter “ANODE” has to be set manually to “ON”. If a standard anode
is installed, the parameter “ANODE” has to be set to the value “OFF”.
If no signal anode is installed the normal anode must be checked for
replacement with a new anode 1 time per year due to different local
water quality.

SERVICE
19
SYSTEM OPTIONS
Display View – Service menu
Service menu is only for the installer. Press the button for approx. 5 seconds
SERVICE MENU – Only for the installer
Temperature "T max". Here the maximum desired operating temperature
can be adjusted. The temperature adjusted under "T max " is afterwards
the highest possible temperature in menu "SETPOINT".
”T max” can be adjusted from 5°C to 62°C. Please note, that efficiency
of the heat pump is reduced at higher temperatures = higher current
consumption.

SERVICE
20
ALARM DESCRIPTIONS
There are 3 alarm levels.
• Information alarm.
• Cooling circuit alarm.
• Alarm for the whole heat pump.
3 different alarms can be show at the same time. The alarm must be reset by pressing the control button push/rotate
at the control panel.
The information alarm
• it does not affect the heat pump, but tell the user that there is a problem, which must be solved as soon as
possible. (alarm no. 8, 9 and 10).
The cooling circuit alarm
• warm water production with the compressor stops. When the heating element is chosen, it will take over the hot
water production to the setPoint. (Alarm no. 3, 4, 5 and 6).
Alarm for the whole heat pump
• warm water production stops completely. It acts probably over a defective operating sensor (alarm no. 1 and 2).
The user can see the alarms in the alarm menu when the alarms are acknowledged. The error must be
eliminated and the alarm has to be acknowledged before the normal operation will take place again. If the error is
not eliminated the alarm will continue. In the case of several simultaneous alarms they are placed in row. The
alarms will be shown in a priority list.
