Vassilias R-7660 User manual

Instruction manual
R-7660
Rating: AC220V-240V~50Hz, 1850-2200W
When using your kettle，basic safety precautions should always be followed，including the
followings:
1．Read all instruction carefully and thoroughly，before any operation of the kettle．
2．Close supervision is necessary when any appliance is used by or near children.
3．Before connecting the kettle，check whether the voltage indicated on the appliance
(underside of kettle and base unit) corresponds with the mains voltage in your home. If
this is not the case，contact your dealer and not use the kettle.
4．Switch off and unplug from the outlet before filling，emptying or cleaning，or when not
in use．
5．Do not overfill as boiling water may be ejected，the maximum level indicator．Fill with
cold water only．
6．To avoid against fire，do not operated in the presence of explosive and/or flammable
fumes．Such as do not operate or place any party of this appliance on or near gas and
electric burner or in a heated oven．
7．Do not let the cord hang over the edge of a table or a counter．Do not let the cord touch
hot surface．
8．Never yank on the cord as this may damage the cord and eventually cause a risk of
electric shock．
9．If the cord or plug is damaged，or after the appliance malfunctions or is dropped or
damaged in any way，return the appliance completely to your nearest authorized service
agent for examination，repair or adjustment．
10．Avoid touching the surface of the hot kettle，use the handle and knobs．
11．To avoid possible steam damage，not face the spout when operating the kettle．
12．If operated on wood furniture，use a protective pad to prevent damage to delicate
finishes．

13．To avoid scalding，always ensure the lid is correctly positioned before operation．
14．Scalding may occur if the lid is removed while heating．
15．Remove and replace the lid carefully when hot．
16．Extreme caution must be used when moving the kettle containing hot water．Never lift
the kettle by its lid．Always use the body handle.
17．Do not switch your kettle on if it is empty．
18．To protect from electrical hazard，do not immerse this kettle，power base or cord set in
any liquid．
19．Use the kettle only with the supplied base unit．Do not use the base unit for other
purposes．
20．To protect against fire，do not operated in the presence of explosive and/or flammable
fumes．
21．While the water boiling or in the short time after the water boils, please be sure that
don’t attempt to open the cover for avoid the steam scalding your hand．
22．Please avoid the liquid sprinkling in the LCD board and the pressed key place in the
operating process. Because the water possibly can plunge in the product, causes the
function to be unusual．
23．Please do not have to add surpasses the maximum water volume the water, because this
has the possibility to damage the product, causes the product movement to appear
exceptionally．
24．Please regular clean descale or pot bottom residuum, because this possibly can affect the
normal use of the product．
25．If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
26．This appliance should not be used by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have
been supervised by the person who is responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
27．Save the instruction
Instruction for use
1．Before use preparatory work：
（１）Before first use，fill the kettle with clean water to maximum capacity and boil．Discard
the water and repeat the process．
（２）The kettle should always be unplugged when filling or adding water．
（３）Fill the kettle with water to desired level．Do not overfill or there will be a risk of
spillage or spitting．The water level indicator will assist you to measure the correct
amount．You can fill the kettle via the spout or after opening the lid．Do not forget to
close the lid after filling，otherwise the kettle will not automatically switch off after
use．
（４）Do not fill with less than 0.5 liters of water（to “min”indication）to prevent the kettle
running dry while operating．
（５）Do not fill with more than 1.7 liters of water（to “max”indication）．
（６）An automatic safety cut-out has been fitted for protection against overheating，it will
operate if the kettle is switched on when containing insufficient water．Always ensure
the water inside the kettle covers the minimum mark on the water level indicator
gauge．If the automatic safety cut-out has operated，switch the kettle off，disconnect
from the power outlet and allow the kettle to cool down for 5 to 10 minutes．The refill
with and switch on，the kettle will work as normal．
（7）After boiling, the kettle switches off automatically.
Disconnect the kettle from the mains electricity supply.
Do not open the lid when pouring.
If the kettle is overfilled, boiling water may be ejected.

The kettle is only to be used with the stand provided.
（8）This appliance is intended to be used in household and similar applications such as:
- staff kitchen areas in shops, offices and other working environments.
- farm houses
- by clients in hotels, motels and other residential type environments
- bed and breakfast type environments.
２．Basal operation：
(1).Put the base on the dry , smooth and horizontal plane , insert the plug to the socket .When the
kettle was inserted into the base , the power puts through automatically．The “ ” key indicate
green color with the two sound “DI -DI”.
(2). Press the “ ” key shortly, with one sound “Di.”, it starts running. The “ ” key
indicate red color.
(3). After the water boils, indicate turns to green color with the two sound “DI -DI”(the
light will be off 5 minutes after water boiled).
３．Self -defined operation：
(1). Press “ ”for 2 seconds, with the buzzer sends out “di” sound, indicate red
color and twinkle, it starts running with the function of keep warm. The light
will be twinkle after water boiled, the kettle will keep the water temperature for 2
hours. During the 2 hours, it will go on heating when the temperature arrives at
90℃.with such recycles until 2 hours.
Press “ ”for 2 seconds, with the buzzer sends out “di” sound, indicate red
color and twinkle, it starts running with the function of keep warm.
Turn the knob in clockwise and the display show 40℃and flash for three times,
the display will start show the current temperature of the water, the kettle will be in
keep warm function automatically when water reach 40℃.the kettle will keep the
water temperature for 2 hours. During the 2 hours, it will go on heating when the
temperature arrives at 35℃.with such recycles until 2 hours.
Turn the knob in clockwise and the display show 50℃and flash for three times,
the display will start show the current temperature of the water, the kettle will be in
keep warm function automatically when water reach 50℃.the kettle will keep the
water temperature for 2 hours. During the 2 hours, it will go on heating when the
temperature arrives at 45℃.with such recycles until 2 hours.
Turn the knob in clockwise and the display show 60℃and flash for three times,

the display will start show the current temperature of the water, the kettle will be in
keep warm function automatically when water reach 60℃.the kettle will keep the
water temperature for 2 hours. During the 2 hours, it will go on heating when the
temperature arrives at 55℃.with such recycles until 2 hours.
Turn the knob in clockwise and the display show 70℃and flash for three times,
the display will start show the current temperature of the water, the kettle will be in
keep warm function automatically when water reach 70℃.the kettle will keep the
water temperature for 2 hours. During the 2 hours, it will go on heating when the
temperature arrives at 65℃.with such recycles until 2 hours.
Turn the knob in clockwise and the display show 90℃and flash for three times,
the display will start show the current temperature of the water, the kettle will be in
keep warm function automatically when water reach 90℃.the kettle will keep the
water temperature for 2 hours. During the 2 hours, it will go on heating when the
temperature arrives at 85℃.with such recycles until 2 hours.
*Note: same operation if you operated in anti-clockwise.
**Note: The kettle can have keep warm function only under above operation way and
when the body left base, the function will be lost and need reset.
(2). Press the “ ” key shortly,with one sound “Di.”, it starts running. Turn the knob in
clockwise and
•the display show 40℃with three times flash, the display show the current
temperature of the water and the kettle will stopped boiling when water reach
40℃.
•The display show 50℃with three times flash, the display show the current
temperature of the water and the kettle will stopped boiling when water reach
50℃.
•The display show 60℃with three times flash, the display show the current
temperature of the water and the kettle will stopped boiling when water reach
60℃.
•The display show 70℃with three times flash, the display show the current
temperature of the water and the kettle will stopped boiling when water reach
70℃.
•The display show 80℃with three times flash, the display show the current
temperature of the water and the kettle will stopped boiling when water reach
80℃.
•The display show 90℃with three times flash, the display show the current
temperature of the water and the kettle will stopped boiling when water reach
90℃.
Note: same operation if you operated in anti-clockwise.
4．After the use finished，please put plug off the power socket.
How to care for your kettle

•Wipe the exterior of the kettle with a soft，damp cloth or sponge．Remove stubborn spots
with a cloth moistened with mild liquid detergent．Do not use abrasive scouring pads or
powers．
•Never immerse the kettle in water or other liquids．
•From time to time，depended on the nature of your water supply，a boiled scale deposit is
naturally formed and can be found mostly adhered to the heating element，thus reducing
the heating efficiency．
•The amount of boiled scale deposited（and subsequently the need to clean or rescale）
largely depends on the water hardness in your area the frequency with which the kettle is
used．
•Boiled scale is not harmful to your health．But if poured into your beverage，it can give a
powdery taste to your drink．Therefore，the kettle should be descaled periodically as
indicated below:
Descaling
Descale kettle regularly．With normal use：at least twice a year
1．Fill the kettle up to “max” with a mixture of one part ordinary vinegar and two parts
water．Switch on and wait for the appliance to switch off automatically．
2．Let the mixture remain inside the kettle overnight．
3．Discard the mixture the next morning．
4．Fill the kettle with clean water up to “max” mark and boil again．
5．Discard the boiled water to remove any remaining scale and vinegar．
6．Rinse the inside of the kettle with clean water．
Power: 220-240V 50/60Hz 1850-2200W

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection center or to a dealer
providing this service.
Disposing of a household appliance separately avoids possible negative consequences for the
environment and health, deriving form inappropriate disposal and enables the constituent materials
to be recovered to obtain significant savings in energy and resources.As a reminder of the need to
dispose of household appliances separately, the product is marked with a crossed-out wheeled
dustbin.
