VDO CR 5206 X User manual

RDS Tuner & Cassette Player
CR 5206 X Product Information
• 4 x 35 Watts max. Power
• Changer Control
• Programmable Steering Wheel
Remote Control Interface
• Auxiliary Input
• Switchable Illumination Color
Programmable Steering Wheel Remote Control Interface
This programmable interface allows the operation of the head
unit via the OEM steering wheel remote control of the car.
Changer Control
A stereo preamp input connection for VDO Dayton MP3 CD
Changers, USB or iPOD adaptors to enjoy even more music when
driving long distances.
Auxiliary Input
The Aux In delivers the possibility for a convenient connection of
further sources to the head unit.
Switchable Illumination Color
In order to achieve an optimized integration in various dash-
boards, you are able to switch illumination color of the head unit:
Orange/Green/Dual.
SWITCHABLE
ILLUMINATION
INFRARED
CONTROL
USB
CONNECT
VIEWER
JPEG
USB
CONNECT
VIEWER
JPEG

Connections
A: Car Interface
B: Speakers
C1:
C2: RC3 interface (SWRC-In)
C3: CD/MP3 Changer In/Aux In
D:
E: Aerial Plug (ISO)
F: Fuse
G: Remote Control
H: Telephone Mute (Fly Lead, pink)
Item Number
CR 5206 X
EAN Code
4025515255628
Product Design
• Black Finish
• Switchable Illumination Color
Tuner
• RDS Tuner
• FM with RDS Traffic, News
• MW, LW
• RDS PTY-Weather
• TA EON
• RDS Clock
• Preset Buttons: 10 FM, 5 FM AST, 5 MW,
5 MW AST, 5 LW
Cassette Player
• Autoreverse
• Tape In/Out Buttons (Flush Buttons)
• Fast Forward
• Fast Rewind
• Reverse
• Eject
• Auto Playback
Internal Amplier
• Max. Power: 4 x 35 Watts
• RMS Power: 4 x 19 Watts
• Aux In
• Bass Boost
• 6 Sound Presets
(Jazz/Pop/Vocal/Flat/Classic/Rock)
• Volume Mute
General
• Telephone Mute
• Mounting angle: +30° / -10°
• Dimensions (w x h x d):
180 x 50 x 150 mm
Options
• Speakers
• 6 Disc DVD or CD (MP3/WMA) Changer
• Programmable Remote Control
• USB Adaptor
• iPod
®
Adaptor
iPod
®
is a registered trademark of Apple Computer
RDS Tuner & Cassette Player
CR 5206 X Technical Information
09/2006 • CR 5206 X • Subject to modification • VU26-0013-2535502
E
CR 5206 X
BF
A
C1 C2 C3
HG
E
CR 5206 X - 24V
BF
A
C1 C2 C3
HG
E
TR 5106
BF
A
C1 C2 C3
HG
