VDO CD726U-BU User manual

www.vdo.com
CD726U-BU
CD RADIO / USB MP3 / WMA 24V
OWNER’S MANUAL
VDO_CD726U-BU_EN.indd 1 29/04/15 12:16

2
CD726U-BU CD RADIO / USB MP3 / WMA 24V
Safety Information
nSafety Information
iPRECAUTIONS
• Use only in a 24-volt DC negative-ground
electrical system.
• Disconnect the vehicle’s negative battery
terminal while mounting and connecting the
unit.
• When replacing the fuse, be sure to use one
with an identical amperage rating.
Using a fuse with a higher amperage rating
may cause serious damage to the unit.
• DO NOT attempt to disassemble the unit.
Laser beams from the optical pickup are
dangerous to the eyes.
• Make sure that pins or other foreign objects
do not get inside the unit, they may cause
malfunctions, or create safety hazards such
as electrical shock or laser beam exposure.
• If you have parked the car for a long time in
hot or cold weather, wait until the temperature
in the car becomes normal before operating
the unit.
• Keep the volume at a level you can hear
outside warning sounds (horns sirens, etc.).
CD Notes
• Playing a defective or dusty CD can cause
dropouts in sound.
• Hold CDs as illustrated.
• Do not touch the unlabeled side.
• Do not attach any seal, label or data
protection sheet to either side of a disc.
• Do not expose a CD to direct sunlight or
excessive heat.
• Wipe a dirty CD from the center outward with
a cleaning cloth.
• Never use solvents such as benzine or
alcohol.
• This unit cannot play 3-inch (8 cm) CDs.
NEVER insert a 3-inch CD contained in the
adapter or an irregularly shaped CD. The
unit may not be able to eject it, resulting n a
malfunction.
• Disc can not have foreign body, the damage
caused by the disc with foreign body do not
belong to the warranty scope.
Before Operation
• Do not raise the volume level too much, as
this will block outside sounds, making driving
dangerous. Stop the car before performing
any complicated operation.
iCAUTION
• DO NOT open covers and do not repair
yourself. Consult the dealer or an experienced
technician for help.
* In addition to ordinary CDs, this unit can
playback CD - R or CD - RW, MP3.
Note:
The system just support the English and
number display, not all kinds letters are
compatible with the unit.
VDO_CD726U-BU_EN.indd 2 29/04/15 12:16

3
© Continental Trading GmbH
Panel Controls
nPanel Controls
(1) Disc eject
(2) Rotate to adjust volume
Radio: Mute
CD/MP3: Pause
Hold it to power off
(3) Band select
(4) 1-6 preset
Automatically search and save station
(5) Channel 1/Play/Stop/Top
(6) Channel 2/SCN
(7) Channel 3/RPT
(8) Channel 4/RDM
(9) Channel 5/FOLDER-
(10) Channel 6/FOLDER+
(11) Display paly time and clock in the CD state.
The LCD will display the ID3 TAG
information recycle: le name/folder name/
ID3 TAG/system time in the MP3 state.
Display PTY info and system time in the
Radio state.
(12) Menu select
(13) USB connector
(14) Seek+/Select the next track
(15) Seek-/Select the previous track
(16) Disc slot
(17) SCR button
Radio
Disc(when disc is in)
USB(when USB inserted)
AUX IN
(18) Reset hole
(19) Press to select VOL/BAS/TRE/BAL/LOUD/
FAD/AF/TA/PTY, rotate VOL knob to adjust
RADIO: Rotate to adjust radio tune
CD /MP3: Rotate to select the previous/next
track
(20) 1-6 preset:
Press to tune in a preset station.
Hold for more than 2 seconds to store a
desired station.
VDO_CD726U-BU_EN.indd 3 29/04/15 12:16

4
CD726U-BU CD RADIO / USB MP3 / WMA 24V
Operate Guide
nOperate Guide
Disc Load / Eject
Load: Insert the disc into the slot.
Eject: Press to eject the disc.
Band Mode
Press the button to change bands:
FM1 FM2 FM3 MW1 MW2 LW.
SRC
Press the [SRC] button to switch between and
select available sources, the mode as follows:
TUNER->CD/MP3/USB->AUX.
Auto Memory Store(Radio mode)
Press the [PS/AST] button to scan the preset
stations 1-6 for 10 seconds each.
Hold the [PS/AST] button more than 2 seconds,
the strongest available stations will be
automatically saved in the memory of preset
button 1-6.
Seek Mode
Disc/USB playback: Press the / to
select the next or previous track.
Hold the / to enter fast forward or
reverse back mode.
EQ Loud Mode
Press the [TUNE] Knob and rotate to select sound
effect EQ OFF POP ROCK CLASSIC
JAZZ CUSTOM.
Press the [TUNE] button and press
/ to select BAS/TRE, rotate the [TUNE]
knob to adjust value.
Clock Setting
If RDS clock (CT) doesn’t work, you can adjust
manually the Clock time.
Long press the [DISP] button to set the time.
Select [CLOCK] with the search buttons
/ .
Press [TUNE] knob and rotate it to adjust the
hours.
Press [TUNE] knob and rotate it to adjust the
minutes.
Press the [TUNE] knob to exit the clock setting.
System Setting
On the radio source hold the [DISP] to enter the
system setup menu, press the / to
select: TA TA RETUN AF REG CT
DX/LO ST/MONO CLOCK 12/24H
BEEP SWRC SET LOGIC AREA
SET, and rotate the [TUNE] to setting.
BEEP setting: The beep tone feature allows the
selection of an audible beep tone to be heard
each time the menu is accessed.
SWRC setting: Rotate the [TUNE] knob to select
ON or OFF.
DX/LO setting: Rotate the [TUNE] knob to select
DX or LO.
CT setting: Rotate the [TUNE] knob to select ON
or OFF.
REG setting: Rotate the [TUNE] knob to select ON
or OFF.
AF setting: Rotate the [TUNE] knob to select ON
or OFF.
TA RETUN setting: Rotate the [TUNE] knob to
select RETUNE S or L. Setting for “L”, Auto search
the TA time space for 180 sec,Setting for “S”, auto
search the TA time space for 45 sec.
TA setting: Rotate [TUNE] knob to select ON or
OFF.
AREA SEL setting: Rotate the [TUNE] knob to
select USA, EUROPE, NORTH AFRICA, ASIA,
JAPAN.
LOGIC ON/OFF: Logic ON to limit the use of the
set to one hour when the car ignition is switched
off. Logic OFF to prevent the set from turning on
when the car ignition is switched off.
SCROLL setting(CD SRC): Rotate the [TUNE]
knob to select ON or OFF.
VDO_CD726U-BU_EN.indd 4 29/04/15 12:16

5
© Continental Trading GmbH
Sound Setting
nSound Setting
Press the [TUNE] knob to enter sound effect
setting mode. First press shows current EQ.
Rotate the [TUNE] knob to changes BEAT EQ in
this order:
EQ OFF ->POP ->ROCK ->CLASSIC ->JAZZ
->CUSTOM
Rotate the [TUNE] knob to select CUSTOM, and
press the knob, then press the / button
to select: BAS-G -> TRE-G, rotate the knob to
select a value.
BAS-G / TRE-G: (-7)- (+7)
Press the [TUNE] button, and press /
button to select USER preset:
BALANCE ->FADER ->LOUD, rotate the [TUNE]
knob to select a value.
BALANCE: LEFT 1-7->CENTER->RIGHT 1-7
FADER: FRONT 1-7->CENTER->REAR 1-7
LOUD: ON/OFF
MP3 Track Search
CD/MP3 mode:
Press the [MENU] button to select “TRACK
SCH” mode, and press the [TUNE] knob to enter
searching mode. Then rotate and press the
[TUNE] knob to select a track number which you
want, then press the [TUNE] knob to conrm.
RDS(PTY SEEK)
Only the radio region is Europe and on the FM the
PTY can be seached. Press the [MENU] button to
PTY function, rotate the [TUNE] knob to display
the program types, and press [TUNE] to select the
desired.
Note:
If radio region isn’t Europe, RDS and DAB
FMLK won’t display.
