Vecow EMBC-1000 User manual
USER
Manual
USER
Manual
1.5.0 Edition 20170509
EMBC-1000
3.5” Embedded Single Board Computer w/ Intel®Core™ i7/i5/i3 SoC
(Skylake-U), 2 GbE LAN, 4 USB 3.0, 5 COM, SUMIT, Extended Temp
ii
Version Date Page Description Remark
0.1 04/12/2016 All Preliminary Release
1.0 05/05/2016 All Ofcial Release
1.1 05/20/2016 69-71 Update
1.2 07/11/2016 All Update
1.3 07/26/2016 All Update
1.4 07/28/2016 10-12 Update
1.5 05/09/2017 60 Update
Record of Revision
iii
This manual is released by Vecow Co., Ltd. for reference purpose only. All
product offerings and specications are subject to change without prior notice.
It does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable
for direct, indirect, special, incidental, or consequential damages arising out of
the use of the product or documentation or any infringements upon the rights of
third parties, which may result from such use.
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy, and if it is not installed and used
in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC
The products described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by Vecow Co., Ltd. The rights of all the brand names, product names, and
trademarks belong to their respective owners.
Disclaimer
Declaration of Conformity
Copyright and Trademarks
iv
Part Number Description
EMBC-1000-
600U
EMBC-1000 Embedded Single Board Computer, onboard Intel®
Core™ i7-6600U Processor (Skylake-U), 2 GbE LAN, 5 COM,
4 USB 3.0, 4 USB 2.0, 2 Mini PCIe, 16 GPIO
EMBC-1000-
300U
EMBC-1000 Embedded Single Board Computer, onboard Intel®
Core™ i5-6300U Processor (Skylake-U), 2 GbE LAN, 5 COM,
4 USB 3.0, 4 USB 2.0, 2 Mini PCIe, 16 GPIO
EMBC-1000-
955U
EMBC-1000 Embedded Single Board Computer, onboard Intel®
Celeron® 3955U Processor (Skylake-U), 2 GbE LAN, 5 COM,
4 USB 3.0, 2 USB 2.0, 2 Mini PCIe, 16 GPIO
EMBC-1000E-
600U
EMBC-1000 Embedded Single Board Computer, onboard Intel®
Core™ i7-6600U Processor (Skylake-U), 2 GbE LAN, 5 COM,
4 USB 3.0, SUMIT, 2 Mini PCIe, 16 GPIO
Order Information
v
Part Number Description
61-1301009-0DA COM Port Cable
61-13B0707-386 SATA Data Cable
61-13P0430-08A SATA Power Cable
61-193102U-156 USB 2.0 Cable
61-13T10LM-3CG Audio Cable
61-13S33KM-3CG KB/MS Cable
62-A110100-011 Heat Sink
62-A210100-011 Heat Spreader
Optional Accessories
vi
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 2
1.3.1 Specications of EMBC-1000-600U 2
1.3.2 Specications of EMBC-1000-300U 4
1.3.3 Specications of EMBC-1000-955U 6
1.3.4 Specications of EMBC-1000E-600U 7
1.4 Supported CPU List 9
1.5 Mechanical Dimensions 10
1.5.1 EMBC-1000 Mechanical Drawing (Main Board) 10
1.5.2 EMBC-1000 Heat Sink Mechanical Drawing 10
1.5.3 EMBC-1000 Heat Spreader Mechanical Drawing 11
1.5.4 EMBC-1000 Mechanical Drawing (Main Board + Heat Sink) 11
1.5.5 EMBC-1000 Mechanical Drawing (Board + Heat Spreader) 12
CHAPTER 2 GETTING TO KNOW YOUR EMBC-1000 13
2.1 Packing List 13
2.2 Connector/ Jumper Locations 13
2.3 Jumper Settings 35
CHAPTER 3 INSTALLATION 38
3.1 Installing Heat Sink 38
3.2 Installing Heat Spreader 40
3.3 Installing DDR4 SO-DIMM Module 41
3.4 Installing Mini PCIe Card 42
3.5 Installing SIM Card 43
vii
CHAPTER 4 BIOS SETUP 45
4.1 Entering Setup 45
4.2 Main Menu 46
4.3 Advanced Function 47
4.4 Chipset 57
4.5 Security 62
4.6 Boot 63
4.7 Save & Exit 64
APPENDIX A : ISOLATED DIO GUIDE 66
APPENDIX B : WDT Functions 69
APPENDIX C : Power Consumption 70
1
GENERAL INTRODUCTION
1
GENERAL INTRODUCTION
EMBC-1000 Series 3.5” Embedded Single Board Computer is an all-in-one,
compact, versatile and high performance embedded engine in the market.
With 6th generation Intel® Core™ i7/ i5/ i3 processor (Skylake-U), dual channel
DDR4 2133MHz up to 16GB memory, EMBC-1000 serves up to 10% CPU
performance enhanced than the former generation Intel® SoC solution with
lower CPU power consumption; Advanced Intel® HD Graphics 520 graphics
engine supports DirectX 12, OpenGL 4.4 and OpenCL 2.0 API, onboard DVI-I,
DisplayPort and dual channel 24-bit LVDS display interface support up to ultra
HD 4K resolution, EMBC-1000 offers up to 34% improved graphics performance
than the former generation.
Multiple Gen 3 PCIe (8GT/s), SATA III (6Gbps), USB 3.0 (5Gbps), PoE (1Gbps)
LAN and exible 3G/ 4G/ WiFi/ LTE/ GPS/ GPRS/ UMTS wireless connections
make high-speed data conveying possible. Vecow EMBC-1000 Series
Embedded Single Board Computer delivers you outstanding Power-Efficient
Performance for demanding workloads.
Featured with 2 independent Gigabit LANs support iAMT 11.0, 5 COM RS-
232/ 422/ 485, 4 external USB 3.0, 4 USB 2.0, 2 Mini PCIe sockets, 1 SIM card
socket for 3G/ 4G/ LTE/ WiFi/ GPRS/ UMTS, 2 SATA III, 16 GPIO, onboard
SUMIT A, B connection, 9V to 36V wide range power input, fanless -40°C to
85°C operating temperature, smart manageability features, all-in-one and cable-
less designs, Vecow EMBC-1000 Series Embedded Single Board Computer
integrates outstanding performance, remarkable power productivity, smart
manageability, mobile availability, industrial-grade reliability and all-in-one
compact solution for low-prole high-performance embedded applications.
Vecow EMBC-1000 Series Embedded Single Board Computer delivers
outstanding performance, compact integrated functions, smart manageability,
mobile availability, trusted reliability and flexible expansion features for
your Healthcare Service, Smart Automation, Point-Of-Information (POI),
Self-Services, In-vehicle Infotainment, Industry 4.0 and any compact high-
performance Internet of Thing (IoT) applications.
1.1 Overview
2
GENERAL INTRODUCTION
©Vecow EMBC-1000 User Manual
1.3 Product Specication
1.3.1 Specications of EMBC-1000-600U
System
Processor Intel® Core™ i7-6600U Processor (Skylake-U, up to 4M
Cache, 3.4GHz)
Chipset Intel® SoC (Skylake)
BIOS AMI
SIO IT8786E
Memory 1 DDR4 2133MHz SO-DIMM, up to 16GB
Graphics
Graphics Processor Intel® HD Graphics 520
Interface • DVI-D : Up to 1920 x 1080
• DisplayPort : Up to 3840 x 2160
• LVDS : Dual Channel 24-bit, up to 1920 x 1200
Ethernet
LAN 1 Intel® I219LM Gigabit LAN supports iAMT 11.0
LAN 2 Intel® I210 Gigabit LAN
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Line-in, 1 Line-out, 1 Mic-in
1.2 Features
• 6th Gen Intel® Core™ i7/ i5/ i3 U-series SoC (Skylake-U), up to 3 independent
Full HD displays
• DDR4 2133MHz memory, up to 16GB
• Onboard DisplayPort, DVI and dual channel 24-bit LVDS display interface
• Dual Independent Gigabit LAN supports iAMT 11.0
• 2 Mini PCIe Socket for 3G/ 4G/ LTE/ WiFi/ GPRS/ UMTS
• 4 USB 3.0, 5 COM, 16 GPIO
• Supports full function SUMIT A, B expansion
• 9V to 36V DC Power Input
• Easy to customize for low-profile system applications
• One-stop SUMIT Expansion Design and Manufacturing Services
3
GENERAL INTRODUCTION
I/O Interface
Front I/O • 1 DVI-D Connector
• 1 DisplayPort Connector
• 4 USB 3.0 Connector
• 2 RJ45 Connector
• 1 COM RS-232/ 422/ 485 DB9 Connector
Internal I/O • 1 ATX 4-pin Power Connector
• 4 COM RS-232/ 422/ 485 Connector
• 2 Mini PCIe Connector
• 1 SIM Card Socket
• 1 DDR4 SO-DIMM Socket
• 1 LVDS Backlight Connector
• 2 SATA Connector
• 1 SATA Power Connector
• 2 USB 2.0 Connector for 4 USB Port
• 1 GPIO Connector
• 1 Fan Connector
Storage
SATA 2 SATA III (6Gbps)
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
Expansion
Mini PCIe 2 Mini PCIe Socket :
• 1 Mini PCIe for PCIe/ USB/ SIM Card
• 1 Mini PCIe for PCIe/ USB/ Optional mSATA
SUMIT (Optional) • 1 SUMIT Connector A (Internal)
• 1 SUMIT Connector B (Internal)
Power
Power Input 9V to 36V, DC-in
Power Interface ATX Power Connector
Others
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
Microsoft Windows 10, Windows 8.1, Windows 7
Linux Fedora 19, Ubuntu 10.04 LTS, or Linux Kernel 3.0 above
Mechanical
Dimension (W x H) 146mm x 102mm (5.75” x 4.02”)
4
GENERAL INTRODUCTION
©Vecow EMBC-1000 User Manual
Environment
Operating Temperature -40°C to 85°C (-40°F to 185°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 70°C
EMC CE, FCC
1.3.2 Specications of EMBC-1000-300U
System
Processor Intel® Core™ i5-6300U Processor (Skylake-U, up to 4M
Cache, 3.4GHz)
Chipset Intel® SoC (Skylake)
BIOS AMI
SIO IT8786E
Memory 1 DDR4 2133MHz SO-DIMM, up to 16GB
Graphics
Graphics Processor Intel® HD Graphics 520
Interface • DVI-D : Up to 1920 x 1080
• DisplayPort : Up to 3840 x 2160
• LVDS : Dual Channel 24-bit, up to 1920 x 1200
Ethernet
LAN 1 Intel® I219LM Gigabit LAN supports iAMT 11.0
LAN 2 Intel® I210 Gigabit LAN
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Line-in, 1 Line-out, 1 Mic-in
I/O Interface
Front I/O • 1 DVI-D Connector
• 1 DisplayPort Connector
• 4 USB 3.0 Connector
• 2 RJ45 Connector
• 1 COM RS-232/ 422/ 485 DB9 Connector
5
GENERAL INTRODUCTION
Internal I/O • 1 ATX 4-pin Power Connector
• 4 COM RS-232/ 422/ 485 Connector
• 2 Mini PCIe Connector
• 1 SIM Card Socket
• 1 DDR4 SO-DIMM Socket
• 1 LVDS Connector
• 1 LVDS Backlight Connector
• 2 SATA Connector
• 1 SATA Power Connector
• 2 USB 2.0 Connector for 4 USB Port
• 1 GPIO Connector
• 1 Fan Connector
Storage
SATA 2 SATA III (6Gbps)
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
Expansion
Mini PCIe 2 Mini PCIe Socket :
• 1 Mini PCIe for PCIe/ USB/ SIM Card
• 1 Mini PCIe for PCIe/ USB/ Optional mSATA
SUMIT (Optional) • 1 SUMIT Connector A (Internal)
• 1 SUMIT Connector B (Internal)
Power
Power Input 9V to 36V, DC-in
Power Interface ATX Power Connector
Others
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
Microsoft Windows 10, Windows 8.1, Windows 7
Linux Fedora 19, Ubuntu 10.04 LTS, or Linux Kernel 3.0 above
Mechanical
Dimension (W x H) 146mm x 102mm (5.75” x 4.02”)
Environment
Operating Temperature -40°C to 85°C (-40°F to 185°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 70°C
EMC CE, FCC
6
GENERAL INTRODUCTION
©Vecow EMBC-1000 User Manual
1.3.3 Specications of EMBC-1000-955U
System
Processor Intel® Celeron® 3955U Processor (Skylake-U, up to 4M Cache,
3.4GHz)
Chipset Intel® SoC (Skylake)
BIOS AMI
SIO IT8786E
Memory 1 DDR4 2133MHz SO-DIMM, up to 16GB
Graphics
Graphics Processor Intel® HD Graphics 520
Interface • DVI-D : Up to 1920 x 1080
• DisplayPort : Up to 3840 x 2160
• LVDS : Dual Channel 24-bit, up to 1920 x 1200
Ethernet
LAN 1 Intel® I219LM Gigabit LAN supports iAMT 11.0
LAN 2 Intel® I210 Gigabit LAN
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Line-in, 1 Line-out, 1 Mic-in
I/O Interface
Front I/O • 1 DVI-D Connector
• 1 DisplayPort Connector
• 4 USB 3.0 Connector
• 2 RJ45 Connector
• 1 COM RS-232/ 422/ 485 DB9 Connector
Internal I/O • 1 ATX 4-pin Power Connector
• 4 COM RS-232/ 422/ 485 Connector
• 2 Mini PCIe Connector
• 1 SIM Card Socket
• 1 DDR4 SO-DIMM Socket
• 1 LVDS Connector
• 1 LVDS Backlight Connector
• 2 SATA Connector
• 1 SATA Power Connector
• 1 USB 2.0 Connector for 2 USB Port
• 1 GPIO Connector
• 1 Fan Connector
Storage
SATA 2 SATA III (6Gbps)
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
7
GENERAL INTRODUCTION
Expansion
Mini PCIe 2 Mini PCIe Socket :
• 1 Mini PCIe for PCIe/ USB/ SIM Card
• 1 Mini PCIe for PCIe/ USB/ Optional mSATA
SUMIT (Optional) • 1 SUMIT Connector A (Internal)
• 1 SUMIT Connector B (Internal)
Power
Power Input 9V to 36V, DC-in
Power Interface ATX Power Connector
Others
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
Microsoft Windows 10, Windows 8.1, Windows 7
Linux Fedora 19, Ubuntu 10.04 LTS, or Linux Kernel 3.0 above
Mechanical
Dimension (W x H) 146mm x 102mm (5.75” x 4.02”)
Environment
Operating Temperature -40°C to 85°C (-40°F to 185°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 70°C
EMC CE, FCC
1.3.4 Specications of EMBC-1000E-600U
System
Processor Intel® Core™ i7-6600U Processor (Skylake-U, up to 4M
Cache, 3.4GHz)
Chipset Intel® SoC (Skylake)
BIOS AMI
SIO IT8786E
Memory 1 DDR4 2133MHz SO-DIMM, up to 16GB
8
GENERAL INTRODUCTION
©Vecow EMBC-1000 User Manual
Graphics
Graphics Processor Intel® HD Graphics 520
Interface • DVI-D : Up to 1920 x 1080
• DisplayPort : Up to 3840 x 2160
• LVDS : Dual Channel 24-bit, up to 1920 x 1200
Ethernet
LAN 1 Intel® I219LM Gigabit LAN supports iAMT 11.0
LAN 2 Intel® I210 Gigabit LAN
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Line-in, 1 Line-out, 1 Mic-in
I/O Interface
Front I/O • 1 DVI-D Connector
• 1 DisplayPort Connector
• 4 USB 3.0 Connector
• 2 RJ45 Connector
• 1 COM RS-232/ 422/ 485 DB9 Connector
Internal I/O • 1 ATX 4-pin Power Connector
• 4 COM RS-232/ 422/ 485 Connector
• 2 Mini PCIe Connector
• 1 SIM Card Socket
• 1 DDR4 SO-DIMM Socket
• 1 LVDS Connector
• 1 LVDS Backlight Connector
• 2 SATA Connector
• 1 SATA Power Connector
• 1 GPIO Connector
• 1 Fan Connector
Storage
SATA 2 SATA III (6Gbps)
mSATA 1 SATA III (Mini PCIe Type, 6Gbps)
Expansion
Mini PCIe 2 Mini PCIe Socket :
• 1 Mini PCIe for PCIe/ USB/ SIM Card
• 1 Mini PCIe for PCIe/ USB/ Optional mSATA
SUMIT (Optional) • 1 SUMIT Connector A (Internal)
• 1 SUMIT Connector B (Internal)
Power
Power Input 9V to 36V, DC-in
Power Interface ATX Power Connector
9
GENERAL INTRODUCTION
Others
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
Microsoft Windows 10, Windows 8.1, Windows 7
Linux Fedora 19, Ubuntu 10.04 LTS, or Linux Kernel 3.0 above
Mechanical
Dimension (W x H) 146mm x 102mm (5.75” x 4.02”)
Environment
Operating Temperature -40°C to 85°C (-40°F to 185°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 70°C
EMC CE, FCC
1.4 Supported CPU List
CPU Name TDP Cache Max. Frequency Embedded
i7-6600U 15W 4MB Up to 3.40GHz Yes
i5-6300U 15W 4MB Up to 3.00GHz Yes
i3-6100U 15W 4MB Up to 2.30GHz Yes
Celeron 3955U 15W 2MB Up to 2.00GHz Yes
10
GENERAL INTRODUCTION
©Vecow EMBC-1000 User Manual
1.5 Mechanical Dimensions
1.5.1 EMBC-1000 Mechanical Drawing (Main Board)
Unit: mm (inch)
5.0 (0.2”)
11.8 (0.5”)
56.2 (2.2”)
141.9 (5.6”)
5.1 (0.2”)
7.6 (0.3”)
81.3 (3.2”)
96.6 (3.8”)
146 (5.75”)
102 (4.02”)
ø 3.3 (ø0.1”)
ø 7.2 (ø0.3”)
146 (5.75”)
9.9 (0.4”)
12.9 (0.5”)
16.3 (0.6”)
18.3 (0.7”)
31.6 (1.2”)
1.5.2 EMBC-1000 Heat Sink Mechanical Drawing
Unit: mm (inch)
106.2 (4.18”)
150.4 (5.92”)
12.5 (0.49”)
30.4 (1.19”)
11
GENERAL INTRODUCTION
1.5.4 EMBC-1000 Mechanical Drawing (Main Board + Heat Sink)
Unit: mm (inch)
150.4 (5.9”)
32.0 (1.3”)106.2 (4.2”)
1.5.3 EMBC-1000 Heat Spreader Mechanical Drawing
Unit: mm (inch)
103.8 (4.08”)
148.0 (5.82”)
12.7 (0.5”)
12
GENERAL INTRODUCTION
©Vecow EMBC-1000 User Manual
1.5.5 EMBC-1000 Mechanical Drawing (Board + Heat Spreader)
Unit: mm (inch)
14.3 (0.6”)103.8 (4.1”)
148.0 (5.8”)
13
GETTING TO KNOW YOUR EMBC-1000
2
GETTING TO KNOW YOUR EMBC-1000
2.1 Packing List
Item Description Qty
1EMBC-1000 SBC 1
2Driver/ User Manual DVD 1
3
Cable Kit
● COM Port Cable
● SATA Data Cable
● SATA Power Cable
● USB 2.0 Cable
● Audio Cable
2
1
1
1
1
2.2 Connector/ Jumper Locations
2.2.1 Top Side
2
1
2
10
1
9
J1
J3
BIOS
CN16
CN10 CN11
CN15
CN9
CN1
CN3
CN13 CN14
SIM
CON1
CN4
CN5CN6
CN8 JUSB1JUSB2
Buzzer
Battery
JPWBTN
JRESET
JSTATUS
JHDD
SYS FAN1
JCOM2
JCOM3
JCOM4
JCOM5
SIO
JDIO2
JDIO1
JPMS
JPKB
Table of contents
Other Vecow Motherboard manuals
