Vecow EXBC-1000 User manual

USER
Manual
USER
Manual
1.0.0 Edition 20190816
Intel®Xeon®/Core™ i7/i5/i3 Processor 5.25" Single Board Computer
Workstation-grade, 4 GigE LAN, 4 10G USB, 4 COM, 1 PCIe, SUMIT A, B
EXBC-1000

ii
©Vecow EXBC-1000 User Manual
Version Date Page Description Remark
0.10 2019/08/07 All Preliminary Release
1.00 2019/08/16 O󰀩cial Release
Record of Revision

iii
©Vecow EXBC-1000 User Manual
This manual is released by Vecow Co., Ltd. for reference purpose only. All
product o󰀨erings and specications are subject to change without prior notice.
It does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable
for direct, indirect, special, incidental, or consequential damages arising out of
the use of the product or documentation or any infringements upon the rights of
third parties, which may result from such use.
Disclaimer
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy, and if it is not installed and used
in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC
The products described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
Declaration of Conformity
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by Vecow Co., Ltd. The rights of all the brand names, product names, and
trademarks belong to their respective owners.
Copyright and Trademarks

iv
©Vecow EXBC-1000 User Manual
Part Number Description
EXBC-1000
EXBC-1000 5.25" Embedded Single Board Computer, Intel®H310
with Intel® Core™ i7/i5/i3 Processor (CFL-R S/CFL-S), 4 GigE LAN,
4 USB 3.1, 4 COM, 1 PCIe, 2 Mini PCIe, 16 GPIO
EXBC-1100
EXBC-1000 5.25" Embedded Single Board Computer, Intel® C246
with Intel® Xeon®/Core™ i7/i5/i3 Processor (CFL-R S/CFL-S),
4 GigE LAN, 4 10G USB 3.1 Gen 2, 4 COM, 1 PCIe, 2 Mini PCIe,
16 GPIO
EXBC-1100E
EXBC-1000 5.25" Embedded Single Board Computer, Intel® C246
with Intel® Xeon®/Core™ i7/i5/i3 Processor (CFL-R S/CFL-S),
4 GigE LAN, 4 10G USB 3.1 Gen 2, 4 COM, 1 PCIe, 2 Mini PCIe,
SUMIT A, B, 16 GPIO
Order Information

v
©Vecow EXBC-1000 User Manual
Part Number Description
DDR4 32G Certied DDR4 32GB 2666MHz RAM
DDR4 16G Certied DDR4 16GB 2666MHz RAM
DDR4 8G Certied DDR4 8GB 2666MHz RAM
DDR4 4G Certied DDR4 4GB 2666MHz RAM
61-13Q1009-0DA COM Port Cable
61-13B0707-386 SATA Data Cable
61-13P0430-08A SATA Power Cable
61-193102U-156 USB 2.0 Cable
75-VL1HSK0-010 Heat Sink for EXBC-1000 Series
75-VL1HSP0-010 Heat Spreader for EXBC-1000 Series
75-VL1FBK1-010 Fan Bracket for EXBC-1000 Series
Optional Accessories
Part Number Description
E-2278GE 9th Gen Intel® Xeon® E-2228GE Processor (XXM Cache, up to 4.70GHz)
E-2278GEL 9th Gen Intel® Xeon® E-2278GEL Processor (XXM Cache, up to 3.90GHz)
E-2226GE 9th Gen Intel® Xeon® E-2226GE Processor (XXM Cache, up to 4.60GHz)
E-2176G 8th Gen Intel® Xeon® E-2176G Processor (XXM Cache, up to 4.60GHz)
E-2124G 8th Gen Intel® Xeon® E-2124G Processor (XXM Cache, up to 4.50GHz)
i7-9700E 9th Gen Intel® Core™ i7-9700E Processor (XXM Cache, up to 4.40GHz)
i7-9700TE 9th Gen Intel® Core™ i7-9700TE Processor (XXM Cache, up to 3.80GHz)
i7-8700 8th Gen Intel® Core™ i7-8700 Processor (XXM Cache, up to 4.60GHz)
i7-8700T 8th Gen Intel® Core™ i7-8700T Processor (XXM Cache, up to 4.00GHz)
i5-9500E 9th Gen Intel® Core™ i5-9500E Processor (XXM Cache, up to 4.20GHz)
i5-9500TE 9th Gen Intel® Core™ i5-9500TE Processor (XXM Cache, up to 3.60GHz)
i5-8500 8th Gen Intel® Core™ i5-8500 Processor (XXM Cache, up to 4.10GHz)
i5-8500T 8th Gen Intel® Core™ i5-8500T Processor (XXM Cache, up to 3.50GHz)
i3-9100E 9th Gen Intel® Core™ i3-9100E Processor (XXM Cache, up to 3.70GHz)
i3-9100TE 9th Gen Intel® Core™ i3-9100TE Processor (XXM Cache, up to 3.20GHz)
i3-8100 8th Gen Intel® Core™ i3-8100 Processor (XXM Cache, up to 3.60GHz)
i3-8100T 8th Gen Intel® Core™ i3-8100T Processor (XXM Cache, up to 3.10GHz)
CPU List

vi
©Vecow EXBC-1000 User Manual
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 3
1.3.1 Specications of EXBC-1000 3
1.3.2 Specications of EXBC-1100 5
1.3.3 Specications of EXBC-1100E 7
1.4 Supported CPU List 9
1.5 Mechanical Dimension 10
1.5.1 Dimensions of EXBC-1000 Series 10
1.5.2 Dimensions of Heat Spreader 10
1.5.3 Dimensions of Heat Sink 10
1.5.4 Dimensions of Fan Bracket 11
1.5.5 Dimensions of EXBC-1000 Series + Heat Spreader 11
1.5.6 Dimensions of EXBC-1000 Series + Heat Sink 12
1.5.7 Dimensions of EXBC-1000 Series + Fan Sink 12
CHAPTER 2 GETTING TO KNOW YOUR EXBC-1000 13
2.1 Packing List 13
2.2 Connector/Jumper Locations 14
2.3 Jumper Settings 27
CHAPTER 3 SYSTEM SETUP 31
3.1 Installing CPU 31
3.2 Installing Heat Spreader 32
3.3 Installing Heat Sink 33
3.4 Installing Fan Sink 34
3.5 Installing DDR4 SO-DIMM Modules 35
3.6 Installing Mini PCIe Card 36
3.7 Installing SIM Card 37

vii
©Vecow EXBC-1000 User Manual
CHAPTER 4 BIOS SETUP 38
4.1 Entering BIOS Setup 38
4.2 Main 39
4.3 Advanced 39
4.4 Chipset 50
4.5 Security 56
4.6 Boot 58
4.7 Save & Exit 59
APPENDIX A : GPIO GUIDE 60
APPENDIX B : Software Functions 63
APPENDIX C : RAID Functions 65
APPENDIX D : Power Consumption 69
APPENDIX E : Supported Memory & Storage List 71

1
©Vecow EXBC-1000 User Manual GENERAL INTRODUCTION
GENERAL INTRODUCTION
1.1 Overview
Vecow EXBC-1000 is a workstation-grade 5.25" Embedded Single Board
Computer. Workstation-grade Intel® C246/H310 chipset exible supports 8-core
9th Generation Intel® Xeon®/Core™ i7/i5/i3 processor (CFL-R S/CFL-S), dual
channel DDR4 2666MHz up to 64GB ECC memory, advanced Intel®UHD
Graphics 630 supporting DirectX 12, OpenGL 4.5, OpenCL 2.0 API, and up to
Ultra HD 4K resolution, Vecow EXBC-1000 5.25" SBC delivers leading CPU &
chipset performance, power e󰀩ciency, and graphics performance; Multiple 10G
SuperSpeed USB 3.1 Gen 2 (10Gbps), PCIe 3.0 (8GT/s), SATA III (6Gbps),
USB 3.1 (5Gbps), GigE LAN (1Gbps) and wireless connections make seamless
real-time high-speed data conveying possible.
Fanless design supporting -25°C to 60°C operating temperature, multiple
DisplayPort, DVI and dual channel 24-bit LVDS display interfaces support triple
independent displays and up to 4K resolution; 4 USB 3.1 Gen 2 ports support up
to 10Gbps SuperSpeed data delivery; 4 GigE LAN, 4 COM RS-232/422/485, 2
SATA III, 16 GPIO; SIM socket for WiFi, 4G, 3G, LTE, GPRS or UMTS wireless
data transfer; 1 PCIe expansion for PCIe x16, PCIe x4, PCIe x1 or USB 2.0; 2
Mini PCIe for PCIe, USB, SIM Card or optional mSATA; optional full function
SUMIT A, B expansion supports multiple SIM sockets, 10GigE RJ45 or 10G
SPF+ Fiber connections; iAMT 12.0, TPM 2.0, Wake on LAN and PXE smart
manageability, Vecow ECX-1000 Series 5,25" SBC serves compact & flexible
solutions to meet your project requirements.
Workstation-grade Intel® Xeon®/Core™ i7/i5/i3 processor (Co󰀨ee Lake), running
with Intel® C246/H310 chipset, fanless, leading performance, exible expansion,
easy customization, industrial-grade reliability and compact integrated features,
Vecow EXBC-1000/1100 Series 5.25" Embedded Single Board Computer is
your powerful solution for Smart Manufacturing, Healthcare Service, Robotics
Control, Public Infotainment, Gaming, Kiosk/POS and any Industrial 4.0/AIoT
applications.
1

2
©Vecow EXBC-1000 User Manual GENERAL INTRODUCTION
1.2 Features
• Workstation-grade Platform : LGA 1151 Socket supports 8 cores 9th Generation
Intel® Xeon®/Core™ i7/i5/i3 Processor (Coffee Lake-Refresh S) running with
Intel® C246/H310 Chipset
• Fanless, -25°C to 60°C Operating Temperature
• 2 DDR4 2666MHz Memory, up to 64GB (ECC/Non-ECC)
• Display : Multiple DisplayPort, DVI and dual channel 24-bit LVDS display
interfaces support triple independent display, up to 4K resolution
• 4 USB 3.1 Gen 2 support up to 10Gbps data transfer
• 4 independent GigE LAN, iAMT 12.0 supported
• SIM Card socket support WiFi/4G/3G/LTE/GPRS/UMTS
• 4 COM RS-232/422/485, 16 GPIO
• Expansion : 1 PCIe, 2 Mini PCIe, 1 SUMIT A, B
• 12V DC Power Input
• Easy to customize for low-profile system applications

3
©Vecow EXBC-1000 User Manual GENERAL INTRODUCTION
1.3 Product Specication
1.3.1 Specications of EXBC-1000
System
Processor 8 cores Intel® Core™ i7/i5/i3 Processor (CFL-R S/CFL-S)
Chipset Intel® H310 Chipset
BIOS AMI
SIO IT8786E
Memory
• DDR4 2666MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
Graphics
Graphics Processor Intel® UHD Graphics 630
Interface
4 display interfaces :
• 1 DVI-D : Up to 1920 x 1200 @60Hz
• 2 DisplayPort : Up to 4096 x 2304 @60Hz
• LVDS : Dual channel 24-bit, up to 1920 x 1200
Ethernet
LAN1 Intel® I219LM GigE LAN supports iAMT 12.0
LAN2 Intel® I210 GigE LAN
LAN3 Intel® I210 GigE LAN
LAN4 Intel® I210 GigE LAN
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Storage
SATA 2 SATA III (6Gbps)
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
I/O Interface
Front I/O
• 1 DVI-D Connector
• 1 DisplayPort Connector
• 4 USB 3.1 Connector
• 4 RJ45 Connector
• 1 Mic-in
• 1 Line-out
• 1 Power Button
• 1 Reset Button

4
©Vecow EXBC-1000 User Manual GENERAL INTRODUCTION
Internal I/O
• 1 ATX 6-pin Power Connector
• 4 COM RS-232/422/485 Connector
• 2 Mini PCIe Connector
• 1 SIM Card Socket
• 2 DDR4 SO-DIMM Socket
• 1 LVDS Connector
• 1 LVDS Backlight Connector
• 2 SATA Data Connector
• 1 SATA Power Connector
• 1 GPIO Header
• 2 Fan Connector
• 1 PCIe Slot
• 1 USB 2.0 Wafer with 2 ports
• 1 PS/2 MB/MS Header
• 1 Reset ON/OFF Connector
• 1 Clear CMOS Header
Expansion
PCIe Slot 1 PCIe Slot for PCIe x16
Mini PCIe
2 Mini PCIe sockets :
• 1 Mini PCIe for PCIe/USB/SIM Card
• 1 Mini PCIe for PCIe/USB/Optional mSATA
Power
Input Voltage 12V DC-in (±5%)
Power Interface ATX Power Connector
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x L) 203mm x 146mm (7.99" x 5.75")
Weight 351 g (0.77 lb)
Environment
Operating Temperature 35W TDP CPU with Heat Sink : -25°C to 60°C (-13°F to 140°F)
65W TDP CPU with Fan : -25°C to 60°C (-13°F to 140°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 60°C
EMC CE, FCC

5
©Vecow EXBC-1000 User Manual GENERAL INTRODUCTION
1.3.2 Specications of EXBC-1100
System
Processor 8 cores Intel® Xeon®/Core™ i7/i5/i3 Processor (CFL-R S/CFL-S)
Chipset Intel® C246 Chipset
BIOS AMI
SIO IT8786E
Memory
• DDR4 2666MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
Graphics
Graphics Processor Intel® UHD Graphics 630
Interface
4 display interfaces :
• 1 DVI-D : Up to 1920 x 1200 @60Hz
• 2 DisplayPort : Up to 4096 x 2304 @60Hz
• LVDS : Dual channel 24-bit, up to 1920 x 1200
Ethernet
LAN1 Intel® I219LM GigE LAN supports iAMT 12.0
LAN2 Intel® I210 GigE LAN
LAN3 Intel® I210 GigE LAN
LAN4 Intel® I210 GigE LAN
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Storage
SATA 2 SATA III (6Gbps)
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
I/O Interface
Front I/O
• 1 DVI-D Connector
• 1 DisplayPort Connector
• 4 USB 3.1 Connector
• 4 RJ45 Connector
• 1 Mic-in
• 1 Line-out
• 1 Power Button
• 1 Reset Button

6
©Vecow EXBC-1000 User Manual GENERAL INTRODUCTION
Internal I/O
• 1 ATX 6-pin Power Connector
• 4 COM RS-232/422/485 Connector
• 2 Mini PCIe Connector
• 1 SIM Card Socket
• 2 DDR4 SO-DIMM Socket
• 1 LVDS Connector
• 1 LVDS Backlight Connector
• 2 SATA Data Connector
• 1 SATA Power Connector
• 1 GPIO Header
• 2 Fan Connector
• 1 PCIe Slot
• 1 USB 2.0 Wafer with 2 ports
• 1 PS/2 MB/MS Header
• 1 Reset ON/OFF Connector
• 1 Clear CMOS Header
Expansion
PCIe Slot 1 PCIe Slot for PCIe x16/PCIe x4/PCIe x1/USB 2.0
Mini PCIe
2 Mini PCIe sockets :
• 1 Mini PCIe for PCIe/USB/SIM Card
• 1 Mini PCIe for PCIe/USB/Optional mSATA
Power
Input Voltage 12V DC-in (±5%)
Power Interface ATX Power Connector
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x L) 203mm x 146mm (7.99" x 5.75")
Weight 351 g (0.77 lb)
Environment
Operating Temperature
35W TDP CPU with Heat Sink : -25°C to 60°C (-13°F to 140°F)
65W TDP CPU with Fan : -25°C to 60°C (-13°F to 140°F)
80W TDP CPU with Fan : -25°C to 60°C (-13°F to 140°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 60°C
EMC CE, FCC

7
©Vecow EXBC-1000 User Manual GENERAL INTRODUCTION
1.3.3 Specications of EXBC-1100E
System
Processor 8 cores Intel® Xeon®/Core™ i7/i5/i3 Processor (CFL-R S/CFL-S)
Chipset Intel® C246 Chipset
BIOS AMI
SIO IT8786E
Memory
• DDR4 2666MHz (ECC/Non-ECC)
• Up to 64GB
• 2 260-pin SO-DIMM Socket
Graphics
Graphics Processor Intel® UHD Graphics 630
Interface
4 display interfaces :
• 1 DVI-D : Up to 1920 x 1200 @60Hz
• 2 DisplayPort : Up to 4096 x 2304 @60Hz
• LVDS : Dual channel 24-bit, up to 1920 x 1200
Ethernet
LAN1 Intel® I219LM GigE LAN supports iAMT 12.0
LAN2 Intel® I210 GigE LAN
LAN3 Intel® I210 GigE LAN
LAN4 Intel® I210 GigE LAN
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Storage
SATA 2 SATA III (6Gbps)
mSATA 2 SATA III (Mini PCIe Type, 6Gbps)
I/O Interface
Front I/O
• 1 DVI-D Connector
• 1 DisplayPort Connector
• 4 USB 3.1 Connector
• 4 RJ45 Connector
• 1 Mic-in
• 1 Line-out
• 1 Power Button
• 1 Reset Button

8
©Vecow EXBC-1000 User Manual GENERAL INTRODUCTION
Internal I/O
• 1 ATX 6-pin Power Connector
• 4 COM RS-232/422/485 Connector
• 2 Mini PCIe Connector
• 1 SIM Card Socket
• 2 DDR4 SO-DIMM Socket
• 1 LVDS Connector
• 1 LVDS Backlight Connector
• 2 SATA Data Connector
• 1 SATA Power Connector
• 1 GPIO Header
• 2 Fan Connector
• 1 PCIe Slot
• 1 USB 2.0 Wafer with 2 ports
• 1 PS/2 MB/MS Header
• 1 Reset ON/OFF Connector
• 1 Clear CMOS Header
Expansion
SUMIT • 1 SUMIT Connector A (Internal)
• 1 SUMIT Connector B (Internal)
PCIe Slot 1 PCIe Slot for PCIe x16/PCIe x4/PCIe x1/USB 2.0
Mini PCIe
2 Mini PCIe sockets :
• 1 Mini PCIe for PCIe/USB/SIM Card
• 1 Mini PCIe for PCIe/USB/Optional mSATA
Power
Input Voltage 12V DC-in (±5%)
Power Interface ATX Power Connector
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control when
CPU overheats.
Software Support
OS Windows 10, Linux
Mechanical
Dimension (W x L) 203mm x 146mm (7.99" x 5.75")
Weight 351 g (0.77 lb)
Environment
Operating Temperature
35W TDP CPU with Heat Sink : -25°C to 60°C (-13°F to 140°F)
65W TDP CPU with Fan : -25°C to 60°C (-13°F to 140°F)
80W TDP CPU with Fan : -25°C to 60°C (-13°F to 140°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% humidity, non-condensing
Relative Humidity 95% at 60°C
EMC CE, FCC

9
©Vecow EXBC-1000 User Manual GENERAL INTRODUCTION
1.4 Supported CPU List
Processor No. Cores TDP Cache Max. Frequency ECC Memory
Intel® Xeon® E-2278GE 880W 16M Up to 4.7GHz Y
Intel® Xeon® E-2278GEL 835W 16M Up to 3.9GHz Y
Intel® Xeon® E-2226GE 680W 12M Up to 4.6GHz Y
Intel® Xeon® E-2176G 680W 12M Up to 4.6GHz Y
Intel® Xeon® E-2124G 4 71W 8M Up to 4.6GHz Y
Intel® Core™ i7-9700E 865W 12M Up to 4.4GHz N
Intel® Core™ i7-9700TE 835W 12M Up to 3.8GHz N
Intel® Core™ i7-8700 665W 12M Up to 4.6GHz N
Intel® Core™ i7-8700T 635W 12M Up to 4.0GHz N
Intel® Core™ i5-9500E 665W 9M Up to 4.2GHz N
Intel® Core™ i5-9500TE 635W 9M Up to 3.6GHz N
Intel® Core™ i5-8500 665W 9M Up to 4.1GHz N
Intel® Core™ i5-8500T 635W 9M Up to 3.5GHz N
Intel® Core™ i3-9100E 4 65W 6M Up to 3.7GHz Y
Intel® Core™ i3-9100TE 4 35W 6M Up to 3.2GHz Y
Intel® Core™ i3-8100 4 65W 6M Up to 3.6GHz Y
Intel® Core™ i3-8100T 4 35W 6M Up to 3.1GHz Y

10
©Vecow EXBC-1000 User Manual GENERAL INTRODUCTION
1.5 Mechanical Dimension
1.5.1 Dimensions of EXBC-1000 Series
203.0 (7.99”)
102.4 (4.03”) 85.8 (3.38”)
5.0 (0.20”)
59.7 (2.35”)
73.7 (2.90”)
85.7 (3.38”)102.4 (4.03”)
24.9 (0.98”)
146.0 (5.75”)
27.4 (1.08”)
Unit : mm (inch)
1.5.2 Dimensions of Heat Spreader
206.5 (8.13”)
148.4 (5.84”)
120.0 (4.72”)
100.0 (3.94”)
9.0 (0.35”)
1.5.3 Dimensions of Heat Sink
206.5 (8.13”)
149.4 (5.88”)
26.0 (1.02”)
Unit : mm (inch)
Unit : mm (inch)

11
©Vecow EXBC-1000 User Manual GENERAL INTRODUCTION
1.5.4 Dimensions of Fan Bracket
130.0 (5.12”)
40.6 (1.59”)
208.5 (8.21”)
151.6 (5.97”)
1.5.5 Dimensions of EXBC-1000 Series + Heat Spreader
148.4 (5.84”)
206.5 (8.13”)
120.0 (4.72”)
100.0 (3.94”)
148.4 (5.84”)
40.4 (1.59”)
Unit : mm (inch)
Unit : mm (inch)

12
©Vecow EXBC-1000 User Manual GENERAL INTRODUCTION
1.5.6 Dimensions of EXBC-1000 Series + Heat Sink
206.5 (8.13”)
149.4 (5.88”)57.4 (2.26”)
1.5.7 Dimensions of EXBC-1000 Series + Fan Sink
208.5 (8.21”)
78.7 (3.10”) 151.6 (5.97”)
Unit : mm (inch)
Unit : mm (inch)

13
©Vecow EXBC-1000 User Manual GETTING TO KNOW YOUR EXBC-1000
2
GETTING TO KNOW YOUR EXBC-1000
2.1 Packing List
Item Description Qty
1EXBC-1000 5.25 Embedded Single Board Computer 1
2Driver/User Manual DVD 1
3
Cable Kit
• COM Port Cable
• COM Screw#4-40, L=5mm
• SATA Data Cable
• SATA Power Cable
• USB 2.0 Cable
2
4
1
1
1
