Vecow ECS-9210 User manual

USER
Manual
USER
Manual
1.1.0 Edition 20170509
ECS-9200/9100
Quad Core Intel®Xeon®/ Core™i7/ i5/ i3 Fanless Embedded System
High Performance, Rugged, Expandable, -40°C to 75°C Extended Temp

ii
Version Date Page Description Remark
1.0 03/24/2017 All Ofcial Release
1.1 05/09/2017 92 Update
Record of Revision

iii
This manual is released by Vecow Co., Ltd. for reference purpose only. All
product offerings and specications are subject to change without prior notice.
It does not represent commitment of Vecow Co., Ltd. Vecow shall not be liable
for direct, indirect, special, incidental, or consequential damages arising out of
the use of the product or documentation or any infringements upon the rights of
third parties, which may result from such use.
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy, and if it is not installed and used
in accordance with the instruction manual, it may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
FCC
The products described in this manual complies with all applicable European
Union (CE) directives if it has a CE marking. For computer systems to
remain CE compliant, only CE-compliant parts may be used. Maintaining CE
compliance also requires proper cable and cabling techniques.
CE
This document contains proprietary information protected by copyright. No part
of this publication may be reproduced in any form or by any means, electric,
photocopying, recording or otherwise, without prior written authorization
by Vecow Co., Ltd. The rights of all the brand names, product names, and
trademarks belong to their respective owners.
Disclaimer
Declaration of Conformity
Copyright and Trademarks

iv
Part Number Description
ECS-9210M ECS-9200, 6 GigE LAN w/4 M12 PoE+, 2 SSD Tray, 1 PCIe x16,
8 USB 3.0, 4 COM, 3 SIM, 32 Isolated DIO
ECS-9210 ECS-9200, 6 GigE LAN w/4 PoE+, 2 SSD Tray, 1 PCIe x16,
8 USB 3.0, 4 COM, 3 SIM, 32 Isolated DIO
ECS-9201M ECS-9200, 6 GigE LAN w/4 M12 PoE+, 2 SSD Tray, 1 PCI,
8 USB 3.0, 4 COM, 3 SIM, 32 Isolated DIO
ECS-9201 ECS-9200, 6 GigE LAN w/4 PoE+, 2 SSD Tray, 1 PCI, 8 USB 3.0,
4 COM, 3 SIM, 32 Isolated DIO
ECS-9110 ECS-9100, 2 GigE LAN, 2 SSD Tray, 1 PCIe x16, 8 USB 3.0,
4 COM, 3 SIM, 16 GPIO
ECS-9101 ECS-9100, 2 GigE LAN, 2 SSD Tray, 1 PCI, 8 USB 3.0, 4 COM,
3 SIM, 16 GPIO
Order Information
Part Number Description
E3-1275 v6 7th Gen Intel® Xeon® E3-1275 v6 Processor (8M Cache, up to
4.20 GHz, 80W)
E3-1275 v5 6th Gen Intel® Xeon® E3-1275 v5 Processor (8M Cache, up to
4.00 GHz, 80W)
E3-1225 v5 6th Gen Intel® Xeon® E3-1225 v5 Processor (6M Cache, up to
3.70 GHz, 80W)
E3-1268L v5 6th Gen Intel® Xeon® E3-1268L v5 Processor (8M Cache, up
to 3.40 GHz, 35W)
i7-7700 7th Gen Intel® Core™ i7-7700 Processor (8M Cache, up to
4.20 GHz, 65W)
i7-7700T 7th Gen Intel® Core™ i7-7700T Processor (8M Cache, up to
3.80 GHz, 35W)
i7-6700 6th Gen Intel® Core™ i7-6700 Processor (8M Cache, up to
4.00 GHz)
i7-6700TE 6th Gen Intel® Core™ i7-6700TE Processor (8M Cache, up to
3.40 GHz)
Order Accessories

v
Part Number Description
i5-7500 7th Gen Intel® Core™ i5-7500 Processor (6M Cache, up to
3.80 GHz, 65W)
i5-7500T 7th Gen Intel® Core™ i5-7500T Processor (6M Cache, up to
3.30 GHz, 35W)
i5-6500 6th Gen Intel® Core™ i5-6500 Processor (6M Cache, up to
3.60 GHz)
i5-6500TE 6th Gen Intel® Core™ i5-6500TE Processor (6M Cache, up to
3.30 GHz)
i3-7101E 7th Gen Intel® Core™ i3-7101E Processor (3M Cache, up to
3.90 GHz, 65W)
i3-7101TE 7th Gen Intel® Core™ i3-7101TE Processor (3M Cache, up to
3.40 GHz, 35W)
i3-6100 6th Gen Intel® Core™ i3-6100 Processor (3M Cache, 3.70
GHz)
i3-6100TE 6th Gen Intel® Core™ i3-6100TE Processor (4M Cache, 2.70
GHz)
DDR4 16G Certied DDR4 16GB 2133MHz RAM
DDR4 8G Certied DDR4 8GB 2133MHz RAM
DDR4 4G Certied DDR4 4GB 2133MHz RAM
PWA-280WB-WT
280W, 24V, 85V AC to 264V AC Power Adapter with 3-pin
Terminal Block (7.62mm pitch), Wide Temperature -30°C to
+70°C
PWA-160WB-WT
160W, 24V, 85V AC to 264V AC Power Adapter with 3-pin
Terminal Block (7.62mm pitch), Wide Temperature -30°C to
+70°C
PWA-120W 120W, 24V, 90V AC to 264V AC Power Adapter with 4-pin
Mini-DIN Connector
VESA Mount VESA Mounting Kit
DIN-RAIL DIN Rail Kit
Rack Mount 2U Rackmount Kit
TMK2-20P-100 Terminal Block 20-pin to Terminal Block 20-pin Cable, 100cm
TMK2-20P-500 Terminal Block 20-pin to Terminal Block 20-pin Cable, 500cm
TMB-TMBK-20P Terminal Board with One 20-pin Terminal Block Connector
and DIN-Rail Mounting
3G Module Mini PCIe 3G/GPS Module with Antenna
4G Module Mini PCIe 4G/GPS Module with Antenna
WiFi & Bluetooth
Module Mini PCIe WiFi & Bluetooth Module with Antenna

vi
Table of Contents
CHAPTER 1 GENERAL INTRODUCTION 1
1.1 Overview 1
1.2 Features 2
1.3 Product Specication 2
1.3.1 Specications of ECS-9210M 2
1.3.2 Specications of ECS-9210 4
1.3.3 Specications of ECS-9201M 7
1.3.4 Specications of ECS-9201 9
1.3.5 Specications of ECS-9110 12
1.3.6 Specications of ECS-9101 14
1.4 Supported CPU List 16
1.5 Mechanical Dimension 17
1.5.1 Dimensions of ECS-9210M 17
1.5.2 Dimensions of ECS-9210 17
1.5.3 Dimensions of ECS-9201M 18
1.5.4 Dimensions of ECS-9201 18
1.5.5 Dimensions of ECS-9110 19
1.5.6 Dimensions of ECS-9101 19
CHAPTER 2 GETTING TO KNOW YOUR ECS-9200/9100 20
2.1 Packing List 20
2.2 Front Panel I/O & Functions 21
2.3 Rear Panel I/O & Functions 28
2.4 Main Board Expansion Connectors 36
2.5 Main Board Jumper & Deep Switch Settings 48
2.6 Ignition Control 52
CHAPTER 3 SYSTEM SETUP 56
3.1 How to Open Your ECS-9200/9100 56
3.2 Installing CPU 60

vii
3.3 Installing DDR4 SO-DIMM Modules 63
3.4 Installing Mini PCIe Card 64
3.5 Installing CFast Card 65
3.6 Installing SIM Card 66
3.7 Installing PCI/ PCIe Card 67
3.8 Installing SSD/ HDD 69
3.9 Installing M.2 71
3.10 Installing M2DOM 72
3.11 Mounting Your ECS-9200/9100 74
CHAPTER 4 BIOS SETUP 80
4.1 Entering BIOS SETUP 80
4.2 Main 81
4.3 Advanced 81
4.4 Chipset 90
4.5 Security 95
4.6 Boot 96
4.7 Save & Exit 97
APPENDIX A : Isolated DIO Guide 98
APPENDIX B : Software Functions 101
APPENDIX C : RAID Installation Guide 104
APPENDIX D : Power Consumption 108
APPENDIX E : Supported Memory & Storage List 112

1
GENERAL INTRODUCTION
1
GENERAL INTRODUCTION
Vecow ECS-9200/9100 Series is a high-performance, all-in-one integrated,
expandable Fanless Embedded Workstation System. LGA1151 Socket
supports Quad Core 7th/6th Generation Intel® Xeon®/Core™ i7/i5/i3 processor
(Kaby Lake-S/Skylake-S) running with workstation-grade Intel® C236 chipset,
dual channel DDR4 2133MHz up to 32GB ECC memory, advanced Intel®
HD Graphics 630/530 supporting DirectX 12, OpenGL 4.4 and OpenCL 2.0
API, onboard DVI-I, DVI-D and DisplayPort display interface for Ultra HD 4K
resolution, ECS-9200/9100 offers leading CPU performance, power efciency,
and graphics performance; PCIe 3.0 (8GT/s), Multiple SATA III (6Gbps), USB 3.0
(5Gbps), PoE (1Gbps) LAN and multiple wireless connections make seamless
high-speed data conveying possible. Vecow ECS-9200/9100 Series Expandable
Fanless Embedded System delivers outstanding system performance, power
productivity and flexible manageability for performance-driven embedded
computing applications.
All-in-one and cable-less designs, fanless -40°C to 75°C extended operating
temperature, 6 GigE LAN ports with 4 IEEE 802.3at (25.5W/48V) PoE+ without
additional power connections, 2 Front-access 2.5” SSD/HDD trays, 1 patented
easy-swap PCI/PCIe slot, 3 external SIM card sockets for 3G/4G/LTE/WiFi/
GPRS/UMTS, 1 onboard M.2 socket, 1 M2DOM socket for up to 8GT per
second data transfer, 1 front-access CFast socket, 2 SATA III supports software
RAID functions, 8 external USB 3.0, 4 COM RS-232/422/485, 32 Isolated DIO,
6V to 36V wide range power input with 80V surge protection, configurable
ignition power control, PCIe x16 expansion supports up to 160W power budget,
smart remote management features, remote power switch, EN50155 and
EN50121-3-2 compliant, Vecow ECS-9200/9100 Series Expandable Rugged
Embedded System serves outstanding system performance, versatile I/O
functions, flexible expansion features, and rugged reliability for embedded
applications.
With outstanding system performance, all-in-one integrated features, smarter
manageability, flexible expandability, great mobile availability, 6V to 36V
power input with 80V surge protection, ignition power control, intelligent
circus protection and more rugged reliability, Vecow ECS-9200/9100 Series
Expandable Fanless Embedded System is your superb solution for Machine
Vision, Rolling Stock, Intelligent Surveillance, Smart Manufacturing, ITS,
Intelligent Automation, Vehicle Computing, and any Industry 4.0 performance-
driven real-time embedded computing applications.
1.1 Overview

2
GENERAL INTRODUCTION
©Vecow ECS-9200/9100 User Manual
1.2 Features
• LGA 1151 Socket supports Quad Core 7th/6th Generation Intel® Xeon®/Core™
i7/i5/i3 Processor (Kaby Lake-S/Skylake-S) with Intel® C236 Chipset
• Fanless, -40°C to 75°C Extended Operating Temperature
• 2 DDR4 2133MHz Memory, up to 32GB
• 6 Independent GigE LAN with 4 M12 IEEE 802.3at PoE+, iAMT 11.0 supported
• Expansion : 1 PCI/PCIe x16, 3 Mini PCIe/mSATA, 1 M.2
• PCIe x16 expansion supports up to 160W Power Budget
• Storage : 2 Front-access 2.5" SSD Tray, 1 CFast Socket, 1 M2DOM, 2 SATA III
• DVI-I, DVI-D and DisplayPort display interfaces, up to 4K display
• 32 Isolated DIO, 8 USB 3.0, 4 COM
• 3 External SIM Card Socket support 3G/4G/LTE/WiFi/GPRS/UMTS
• M2DOM supports up to 8GT/s data rate
• 6V to 36V DC Power Input with 80V Surge Protection
• Configurable Ignition Power Control
1.3 Product Specication
1.3.1 Specications of ECS-9210M
System
Processor Quad Core 7th/6th Intel® Xeon®/Core™ i7/i5/i3 Processor
(Kaby Lake-S/Skylake-S)
Chipset Intel® C236
BIOS AMI
SIO IT8786E
Memory • DDR4 2133MHz
• Up to 32GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 with auto flow control (ESD 8KV)
USB • 8 External USB 3.0 (4 Front, 4 Rear)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO (16 DI, 16 DO)
LED Power, HDD, Wireless, PoE
SIM Card 3 External SIM Card Socket

3
GENERAL INTRODUCTION
Expansion
Mini PCIe 3 Full-size for PCIe/USB/External SIM Card/mSATA
PCI/PCIe 1 PCIe x16 Slot supports up to 160W Power Budget
M.2 1 M.2 Socket (Key ID : M)
Graphics
Graphics Processor Intel® HD Graphics 630/530
Interface • DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support software RAID 0, 1
mSATA 3 SATA III (Mini PCIe Type, 6Gbps)
M2DOM 1 PCIe 3.0 (8GT/s)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN
PoE (M12)
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, M12
Connector
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, M12
Connector
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, M12
Connector
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, M12
Connector
Power
Input Voltage 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power

4
GENERAL INTRODUCTION
©Vecow ECS-9200/9100 User Manual
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux
Mechanical
Dimensions (WxDxH) 260mm x 215mm x 79mm (10.2" x 8.5" x 3.1")
Weight 4.2 kg (9.26 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature 35W TDP CPU :
• Core™ i7, i5, i3 : -40°C to 75°C (-40°F to 167°F)
• Xeon® E3-1268L v5 : -40°C to 70°C (-40°F to 158°F)
65W TDP CPU :
• Core™ i7, i5, i3 : -40°C to 55°C (-40°F to 131°F)
80W TDP CPU :
• Xeon® E3-1275 v6, E3-1275 v5, E3-1225 v5 :
-40°C to 45°C (-40°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @ Wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2
1.3.2 Specications of ECS-9210
System
Processor Quad Core 7th/6th Intel® Xeon®/Core™ i7/i5/i3 Processor
(Kaby Lake-S/Skylake-S)
Chipset Intel® C236
BIOS AMI

5
GENERAL INTRODUCTION
SIO IT8786E
Memory • DDR4 2133MHz
• Up to 32GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 with auto flow control (ESD 8KV)
USB • 8 External USB 3.0 (4 Front, 4 Rear)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO (16 DI, 16 DO)
LED Power, HDD, Wireless, PoE
SIM Card 3 External SIM Card Socket
Expansion
Mini PCIe 3 Full-size for PCIe/USB/External SIM Card/mSATA
PCI/PCIe 1 PCIe x16 Slot supports up to 160W Power Budget
M.2 1 M.2 Socket (Key ID : M)
Graphics
Graphics Processor Intel® HD Graphics 630/530
Interface • DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support software RAID 0, 1
mSATA 3 SATA III (Mini PCIe Type, 6Gbps)
M2DOM 1 PCIe 3.0 (8GT/s)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210

6
GENERAL INTRODUCTION
©Vecow ECS-9200/9100 User Manual
Power
Input Voltage 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux
Mechanical
Dimensions (WxDxH) 260mm x 215mm x 79mm (10.2" x 8.5" x 3.1")
Weight 4.2 kg (9.26 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature 35W TDP CPU :
• Core™ i7, i5, i3 : -40°C to 75°C (-40°F to 167°F)
• Xeon® E3-1268L v5 : -40°C to 70°C (-40°F to 158°F)
65W TDP CPU :
• Core™ i7, i5, i3 : -40°C to 55°C (-40°F to 131°F)
80W TDP CPU :
• Xeon® E3-1275 v6, E3-1275 v5, E3-1225 v5 :
-40°C to 45°C (-40°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @ Wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

7
GENERAL INTRODUCTION
1.3.3 Specications of ECS-9201M
System
Processor Quad Core 7th/6th Intel® Xeon®/Core™ i7/i5/i3 Processor
(Kaby Lake-S/Skylake-S)
Chipset Intel® C236
BIOS AMI
SIO IT8786E
Memory • DDR4 2133MHz
• Up to 32GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 with auto flow control (ESD 8KV)
USB • 8 External USB 3.0 (4 Front, 4 Rear)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO (16 DI, 16 DO)
LED Power, HDD, Wireless, PoE
SIM Card 3 External SIM Card Socket
Expansion
Mini PCIe 3 Full-size for PCIe/USB/External SIM Card/mSATA
PCI/PCIe 1 PCI Slot
M.2 1 M.2 Socket (Key ID : M)
Graphics
Graphics Processor Intel® HD Graphics 630/530
Interface • DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support software RAID 0, 1
mSATA 3 SATA III (Mini PCIe Type, 6Gbps)
M2DOM 1 PCIe 3.0 (8GT/s)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN

8
GENERAL INTRODUCTION
©Vecow ECS-9200/9100 User Manual
PoE (M12)
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, M12
Connector
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, M12
Connector
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, M12
Connector
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210, M12
Connector
Power
Input Voltage 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux
Mechanical
Dimensions (WxDxH) 260mm x 215mm x 79mm (10.2" x 8.5" x 3.1")
Weight 4.2 kg (9.26 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature 35W TDP CPU :
• Core™ i7, i5, i3 : -40°C to 75°C (-40°F to 167°F)
• Xeon® E3-1268L v5 : -40°C to 70°C (-40°F to 158°F)
65W TDP CPU :
• Core™ i7, i5, i3 : -40°C to 55°C (-40°F to 131°F)
80W TDP CPU :
• Xeon® E3-1275 v6, E3-1275 v5, E3-1225 v5 :
-40°C to 45°C (-40°F to 113°F)

9
GENERAL INTRODUCTION
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @ Wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2
1.3.4 Specications of ECS-9201
System
Processor Quad Core 7th/6th Intel® Xeon®/Core™ i7/i5/i3 Processor
(Kaby Lake-S/Skylake-S)
Chipset Intel® C236
BIOS AMI
SIO IT8786E
Memory • DDR4 2133MHz
• Up to 32GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 with auto flow control (ESD 8KV)
USB • 8 External USB 3.0 (4 Front, 4 Rear)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO (16 DI, 16 DO)
LED Power, HDD, Wireless, PoE
SIM Card 3 External SIM Card Socket
Expansion
Mini PCIe 3 Full-size for PCIe/USB/External SIM Card/mSATA
PCI/PCIe 1 PCI Slot
M.2 1 M.2 Socket (Key ID : M)
Graphics
Graphics Processor Intel® HD Graphics 630/530
Interface • DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz

10
GENERAL INTRODUCTION
©Vecow ECS-9200/9100 User Manual
Storage
SATA 2 SATA III (6Gbps) support software RAID 0, 1
mSATA 3 SATA III (Mini PCIe Type, 6Gbps)
M2DOM 1 PCIe 3.0 (8GT/s)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN
PoE
LAN 3 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 4 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 5 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
LAN 6 GigE IEEE 802.3at (25.5W/48V) PoE+ by Intel® I210
Power
Input Voltage 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux
Mechanical
Dimensions (WxDxH) 260mm x 215mm x 79mm (10.2" x 8.5" x 3.1")
Weight 4.2 kg (9.26 lb)

11
GENERAL INTRODUCTION
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature 35W TDP CPU :
• Core™ i7, i5, i3 : -40°C to 75°C (-40°F to 167°F)
• Xeon® E3-1268L v5 : -40°C to 70°C (-40°F to 158°F)
65W TDP CPU :
• Core™ i7, i5, i3 : -40°C to 55°C (-40°F to 131°F)
80W TDP CPU :
• Xeon® E3-1275 v6, E3-1275 v5, E3-1225 v5 :
-40°C to 45°C (-40°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @ Wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2

12
GENERAL INTRODUCTION
©Vecow ECS-9200/9100 User Manual
1.3.5 Specications of ECS-9110
System
Processor Quad Core 7th/6th Intel® Xeon®/Core™ i7/i5/i3 Processor
(Kaby Lake-S/Skylake-S)
Chipset Intel® C236
BIOS AMI
SIO IT8786E
Memory • DDR4 2133MHz
• Up to 32GB
• 2 260-pin SO-DIMM Socket
I/O Interface
Serial 4 COM RS-232/422/485 with auto flow control (ESD 8KV)
USB • 8 External USB 3.0 (4 Front, 4 Rear)
• 1 USB 2.0 (Internal)
Isolated DIO 32 Isolated DIO (16 DI, 16 DO)
LED Power, HDD, Wireless
SIM Card 3 External SIM Card Socket
Expansion
Mini PCIe 3 Full-size for PCIe/USB/External SIM Card/mSATA
PCI/PCIe 1 PCIe x16 Slot supports up to 160W Power Budget
M.2 1 M.2 Socket (Key ID : M)
Graphics
Graphics Processor Intel® HD Graphics 630/530
Interface • DVI-I : Up to 1920 x 1200 @ 60Hz
• DVI-D : Up to 1920 x 1200 @ 60Hz
• DisplayPort : Up to 4096 x 2304 @ 60Hz
Storage
SATA 2 SATA III (6Gbps) support software RAID 0, 1
mSATA 3 SATA III (Mini PCIe Type, 6Gbps)
M2DOM 1 PCIe 3.0 (8GT/s)
Storage Device • 1 CFast Socket, Push-in/Push-out Ejector
• 2 Front-access 2.5" SSD/HDD Tray
Audio
Audio Codec Realtek ALC892, 5.1 Channel HD Audio
Audio Interface 1 Mic-in, 1 Line-out
Ethernet
LAN 1 Intel® I219LM GigE LAN supports iAMT 11.0
LAN 2 Intel® I210 GigE LAN

13
GENERAL INTRODUCTION
Power
Input Voltage 6V to 36V, DC-in
Power Interface 3-pin Terminal Block : V+, V-, Frame Ground
Ignition Control 16 Mode (Internal)
Remote Switch 3-pin Terminal Block : On, Off, IGN
Surge Protection Up to 80V/1ms Transient Power
Others
TPM Optional Inneon SLB9665 supports TPM 2.0, LPC
interface
Watchdog Timer Reset : 1 to 255 sec./min. per step
Smart Management Wake on LAN, PXE supported
HW Monitor Monitoring temperature, voltages. Auto throttling control
when CPU overheats.
Software Support
OS Windows 10, Windows 8.1, Windows 7, Linux
Mechanical
Dimensions (WxDxH) 260mm x 215mm x 79mm (10.2" x 8.5" x 3.1")
Weight 4.2 kg (9.26 lb)
Mounting • Wallmount by mounting bracket
• DIN Rail Mount (Optional)
• 2U Rackmount (Optional)
Environment
Operating Temperature 35W TDP CPU :
• Core™ i7, i5, i3 : -40°C to 75°C (-40°F to 167°F)
• Xeon® E3-1268L v5 : -40°C to 70°C (-40°F to 158°F)
65W TDP CPU :
• Core™ i7, i5, i3 : -40°C to 55°C (-40°F to 131°F)
80W TDP CPU :
• Xeon® E3-1275 v6, E3-1275 v5, E3-1225 v5 :
-40°C to 45°C (-40°F to 113°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F)
Humidity 5% to 95% Humidity, non-condensing
Relative Humidity 95% at 75°C
Shock • IEC 60068-2-27
• SSD : 50G @ Wallmount, Half-sine, 11ms
Vibration • IEC 60068-2-64
• SSD : 5Grms, 5Hz to 500Hz, 3 Axis
EMC CE, FCC, EN50155, EN50121-3-2
