Vehicle Systems VBV-750 User manual

BV-750
VEHICLE CCTV SYSTEM
VBV-750
Model:
VBV-750M MONITOR
VBV-700CM CONTROL MODULE
VBV-700C CAMERA

INTRODUCTION
The vehicle CCTV system has been designed to provide years of trouble
-free
operation. Please read this manual thoroughly. This m
anual contains
instructions to ease the installation of the camera and monitor. The vehicle
CCTVsystemisasupplementtostandardrear
-view mirror systems, and will
provide additional rear
-view vision when installed and maintained properly.
The vehicle C
CTV system is not intended in any way to be a substitute for
careful, cautious, defensive driving or for the consistent adherence to all
applicable traffic laws and motor safety regulations. This product is not intended
to be a substitute for rear view mir
rors or for any other motor vehicle or boat
equipment mandated by law.
FEATURES
VBV-700C CAMERA
• 270,000 pixel image sensor
• 0.1Lux sensitivity
• Automatic electronic iris provides a clearer, more consistent image in low and
brightlight
• Wide
-anglelens provides a broad viewing area (110°Diag.)
• Durable, waterproof construction
• Wind deflector reduces build up of dirt on lens
•Waterproofcableconnection
VBV-750M TFT LCD COLOUR 5.0" MONITOR
• Day/night switch
• Menu button for Picture, System, Opt
ion,andClock
• Camera 1/Camera 2
• Power/stand
-by switch
BE
-700CM CONTROL BOX
• Audio/Video input and output terminal
• Up to two cameras can be connected to the control box.
CONTENTS OF 1 COMPLETE SYSTEM
VBV
-700C CCD CAMERA:
-
Camera
-
Camerabracket
-
Attachment screws with washers
-
Wind deflector
VBV
-750M MONITOR:
-
Monitor
-
Monitor bracket
BE
-700CM CONTROL BOX
-
Powercable
Control Box
Special Cable: 1
-20 meter cable with waterproof connector. Oil, gas, grease
resistant. UV stable
BEFOREIN
STALLATION
1. This system operates from 10 volts DC to 32 volts DC, negative ground.
2.Please install thissystemaccording to theinstructionsin this manual.
3. Do not disassemble the camera or the monitor. This voids the warranty.
Disassembling the ca
merawill compromise the Waterproofseal.
4. Connect the system to an ignition switched power source. Connection to a
battery source will reduce battery life.
WARNING
1. To prevent electrical shock, DO NOT OPEN THE MONITOR CASE. There
are potentially leth
al voltages inside the monitor. There are no user serviceable
parts inside. If evidence of tampering is detected, the warranty will be
considered void.
2. Keep monitor away from leaking water, rain, moisture etc. It is NOT
waterproof. Any moisture inside t
he monitor could cause extensive damage.
3. Use the thumbscrews to mount the monitor to bracket.
INSTALLATION INSTRUCTIONS
VBV
-700C CAMERA
1. Attach camera bracket (see Fig. 1) to upper portion of vehicle.
Attachmentpoint must besturdyenoughto support
camera and bracket.
2. Attach camera to bracket using screws provided. Adjust angle as indicated in
Fig. 2. (Use rear bumper and back of vehicle as a reference point.)
3. Wind deflector may be installed. This deflector is designed to reduce the build
up o
f dust, dirt and moisture on the camera lens. (See Fig.2)
VBV
-750M MONITOR
1. Attach monitor inside vehicle in a location convenient to the driver (e.g. centre
of dash, overhead or in dash). (See Fig.3.)
2. Use a compression plate
or rear-mounting bracket to attach the monitor
bracket to the dash or overhead. (See Fig. 3.)
3. Adjust mounting angle of the monitor to allow driver to easily view the screen
from all seat positions. (See Fig. 4.)
VBV
-700CMCONTROL-BOX
Attachmonitorinsidevehicle
. Attachment point must be sturdy enough to
support the box. (See Fig.5)
CABLE
1.Thecamera
-to-cableconnectioniswaterproof.Thecable-to-control-box
connection is not waterproof. Be sure to orient the cable properly. The cylindrical
end attaches to the camera. T
he rectangular box end attaches to the control-
box.
(See Fig. 6.)
2. Do not run the cable over sharp edges or corners. Do not kink the cable.
Keep the cable away from hot and rotating parts.
3. Place all excess cable in convoluted tubing.
4. W
irethecablesecurely.
WIRING CAMERA AND MONITOR
1. See wiring diagram for connections to ignition, ground and back up circuit.
(See Fig. 5.)
2. Wiring camera: Drill a 20mm
-diameter hole into vehicle body near the
camera and bracket. Connect camera co
nnector to extension cable in vehicle.
Push extra cable into vehicle (be careful not to kink cable) and fit grommet into
hole. Apply sealant around grommet to increase resistance to water penetration.
3. Wiring control
-box: Insert extension cable into camera #2 (R) position. If 1
camera is used, be sure to mark each extension cable properly and plug second
and third cable into camera #1 position. Bundle excess cable together using a
cable tie or vinyl tape. This will avoid possible damage to cable during op
eration.
4. The red wire is connected to an ignition power source, the black wire is
connectedtochassisground,thebrownwireisconnected to the vehicles back
up circuit and the white is connected to the parking light for dimmer effect.
FUNCTIONS AND OPERATION
MONITOR (see Fig.7)
1) POWER LED
When the red LED is turned on, it indicates power on.
Puttingthe gear intothereverse,the view ofcamera2 shall beshownonthe
monitor.
2) Power ON/OFF Switch
3) ?+,?-CONTROLBUTTON
. This button can adjust a speaker’s volume and also Menu adjusts.
§Turning up the option, press this button and it will be up
gradually.Whilethe optionbeing up, the marks below are
shown on the monitor.
§Turning down the option, press this button and it will be down
gradually.Whilethe optionbeing down, the marks below is
shown on the monitor
. The function above is preceded than any others.
4) "MENU" Button
If you press the button "MENU", the list of function will be shown on the monitor.
§PICTURE
§SYSTEM
§OPTION
§CLOCK
Selectable function lists disappear within seconds if there is no new input sign.
You can choose or select easily any function on the menu lists.
5) SEL.
SELECT CONTROL BUTTON
Use these buttons in order toselect the option.
6) Camera selector button
Following the turns below, it can be selected that CA1, CA2.
TheOSD indicates whichcameraisoperating now.
7) REMOTE-CONTROLLERSENSOR
The monitor is to be operated by a remote-controller.
To operate the system with the remote-controller turn the remote-controller
towards the sensor on the face of monitor.
8) Earphone Jack
9) BRACKET RAIL
Mountingbracketisadjustable.
METHOD OF ADJUST
1. PICTURE CONTROL
1) Press the "MENU" button
2) Select “PICTURE”
3) Move the cursor to the "CONTRAST,BRIGHT,COLOR, SHARPANDTINTS"
with the SEL button.
4) Press the "?+ or ?-” button.
5) Select one of five options.
6) Choose it with the "?+ or ?-“button.
7) Press the "MENU" button
2. SYSTEM CONTROL
1) Press the "MENU" button
2) Select “SYSTEM”
3) Move the cursor to the "INPUT, COLOR SYSTEM, BLUE BACK,
LANGUAGE, " with the SEL button.
4) Press the "?+ or ?-" button.
5) Select one of five options.
6) Choose it with the "?+ or ?-” button.
7) Press the "MENU" button
3. OPTION CONTROL
1) Press the "MENU" button
2) Select “SEL”
3) Move the cursor to the "HORIZONTAL, VERTICAL" with the SEL button.
4) Press the "?+ or ?-" button.
5) Select one of two options.
6) Choose it with the "?+ or ?-" button.
7) Press the "MENU" button Press the "MENU" button
4. CLOCK CONTROL
1) Press the "MENU" button
2) Select “CLOCK”
3) Move the cursor to the "TIME, ON TIME, OFF TIME, ATTENTION, CH-TIME"
with the SEL.-button.
4) Press the "?+ or ?-“button.
5) Select one of five options.
6) Choose it with the "?+ or ?-" button.
7) Press the "MENU" button Press the "MENU" button
REMOTE CONTROLLER (see Fig.8)
1) MODE (Mode):
Press this button; users can realize the five picture statuses of Standard,
Soft,Vivid,lightandPersonal.
2) POWER (Power switch):
Press this button is to turn off the monitor, press it again is to turn on the
machine.
3) MUTE (Mute):
Press this button, sound disappears, press it again or ?+ or ?-is to resume
normal sound.
4) CALL (Call):
Press this button is to display AVcharacter currently watching.
5) TIMER:
Time setup of sleep off, it is used to set the time off within 120 minutes.
6) C / E / R / P / G:
Press this button can realize the switch of Chinese, English, Russian, Arabic
and German menu.
7) CALE:
Press this button is to show Year, Month, Day and Week. Press ?SEL or ?
SELis to adjust the Year, press ?+ or ?-is to adjust the Month.
8) VIDEO (CA1 / CA2 shift):
Press this button is to realize switch between CA1 and CA2 pictures.
: Press this button is to flip the picture horizontally.
: Press this button is to flip the picture vertically.
CAMERA
1. Waterproof connector (See Fig.9)
CAUTION
1. DO NOT OPEN THE CAMERA CASE. This will break the camera’s
Waterproof seal. If evidence of tampering is detected, the warranty Will be
considered void.
2. Do not recommend mounting the camera near the lower area of the
vehicle (e.g. bumper). This reduces the view of the camera and increases
the chance of physical damage to the camera.
3. Use only the Inner Hexagonal screw and washers to mount the camera.
MAINTENANCE
Remove dust and dirt with a damp soft cloth. Heavier dirt should be
removed with a damp soft cloth and mild detergent. Do not use strong
cleaning agents containing gasoline, thinner, benzene or alcohol. These
substances may damage the exterior surface of the monitor.
CAUTION
1. Before drilling, be sure no cable or wiring is on the other side. Be sure to
drill a 20mm -diameter hole only.
2. Feed as much cable as possible into vehicle and clamp securely. This
reduces the possibility of it being hooked or snagged.
3. Keep all cables away from HOT, ROTATING and ELECTRICALLY
NOISYcomponents.
4. To increase protection of cable, place all excess wire and extension cable
in convoluted tubing.
5. Do not twist camera cable and do not cut camera pigtail or cable.
SPECIFICATIONS
VBV-700C CAMERA
PICK-UP DEVICE INTERLINE TRANSFER TYPE CCD
TV SYSTEM PAL
PICTURE ELEMENTS 500(H) ×580(V)PAL
SENSINGAREA 4.9mm x 3.7mm
IMAGE SIZE 1/3 INCH
SYNCHRONIZATION INTERNAL
HORIZONTAL RESOLUTION 380 TV LINES
REQUIRED ILLUMINATION 0.1 LUX MINIMUM / F1.2
SIGNAL TO NOISE RATIO MINIMUM 50DB(AT AGC OFF)
POWERSUPPLY 12VDC
POWER CONSUMPTION 2.4W(AT 12V DC)
CURRENT CONSUMPTION MAX. 350Ma
LENS ANGLE 110º
OPERATIONTEMP -20°C TO +70 °C
STORAGE TEMP -30°C TO +60°C
VBV-750M MONITOR
PICTURE TUBE: 5.0” INCH, COLOUR TFT -LCD
DEFLECTION ANGLE: 45°(LEFT/RIGHT), 10°(TOP), 30°(DOWN)
POWER SOURCE: 12-24VDC
(WITH USE OF CONTROL -BOX)
12 VDC (WITHOUT USE OF CONTROL-
BOX)
POWER CONSUMPTION: ~ 8W/700MA MAXIMUM
OUTPUT VOLTAGE: 9.6VDC
TV SYSTEM: PAL/NTSC
VIDEO INPUT/OUTPUT: COMPOSITEVIDEO SINGLE
1VP-P 75 OHM
RESOLUTION: 960(H) X 234(V)
CONTRAST: 150:1
VIEWING ANGLE (U X D X R/L) 15 X 35 X 50
OPERATING TEMPERATURE: -10°C ~ TO +60°C
STORAGE TEMPERATURE: -25°C ~ +70°C
WEIGHT: 0.43KG
DIMENSIONS: (W X H X T)mm 163 X 125 X 30.5
VBV-700CM CONTROL BOX
POWER INPUT 12-32VDC
POWER OUTPUT 11-12VDC,2A
POWER OUTPUT MAX. 20 W
VIDEOSYSTEM PAL
VIDEO OUTPUT 1VP-P 75 OHM
VOLTAGE OUTPUT 12 VDC
OPERATING TEMPERATURE -10° TO +60°C
STORAGE TEMPERATURE -25° TO +80°C
CASE MATERIAL ALNICO
WEIGHT ~0.5 KG
DIMENSIONS (W X H X D)mm 146 X 37 X 79
DISCLAIMER
The use of the VBV-750 Vehicle CCTV system does not guarantee or
promise that the user will not be in an accident or otherwise not collide with
an object. The vehicle CCTV systemis not intended in any way to be a
substitutefor careful and cautiousdriving or for the consistent adherence to
all applicable traffic laws and motor safety regulations. This product is not
intended to be a substitute for rear-view mirrors or for any other motor
vehicle or boat equipment mandated by law.
BRIGADE ELECTRONICS PLC
TEL: [phone]
FAX: [phone]
Email: [e-mail]
Website: www.brigade-electronics.co.uk
ENGLISH
V
VBV
-
750 VEHICLE CCTV SYSTEM

Fig 1
Mount camera assembly
high-mounted. Centred.
Camera mounting
hole pattern.

Approximately 90-degree field of view
Back of vehicle, viewing at monitor screen
Optional wind deflector
Fig. 2
Fig. 3

Steel Plate for reinforcement (recommended for secure mounting).
Fig. 4.

White (dimmer DC 12V-32V)
BV-750
CA1CA 2 (R)DC 12V- 32V
CAMERA
POWER
CAMERA 2
Cable
Brown (reverse trigger)
Red (DC 12V –32V)
Black (ground)
Fig. 5

1
2
3
4
5
6
7
8
BV-750
FRONT VIEW
1. Power LED
2. Power ON/OFF Switch
3. ?+, ?-CONTROL
BUTTON
4. MENU
5. SEL.
6. CAMERA CA1/CA2
7. REMOTE CONTROLLER
SENSOR
8. EARPHONE JACK
FRONT VIEW
1. MODE
2. POWER
3. MUTE
4. CALL
5. TIMER
6. C/E/R/P/G LANG.
7. CALE
8. CA1/CA2
+
MODE
CALL TIMER
G/E/R/P/G
CALE CA1/CA2
1
2
3
4
5
6
7
8

Fig .6

Brigade Electronics Plc
Brigade House
The Mill, Station Road
South Darenth, Kent DA4 9BD
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.brigade-electronics.co.uk
