Velodyne MIC-5 User manual

USER’S
MANUAL
Mic-5
bass
management
kit

Mic-5 Bass Management Kit
.www.velodyne.com MIC-5 User’s Manual
The MIC-5 Bass Management Kit is designed to integrate with the Velodyne Digital Drive®and
SPL™ -R EQ software for users looking to optimize their bass response for more than one spot
in a room. In the past, with a single microphone, the user needed to either optimize the bass
for a single position, or move the mic manually among various spots and optimize the EQ curve
accordingly. With the MIC-5, from one to five microphones can be used in different listening
positions with the EQ software seeing an average of all the locations together as a single
response curve.
The MIC-5 works with all Digital Drive (DD) subwoofers including the DD-10, DD-12, DD-15,
DD-18 and the DD-1812. It also can be used with all SPL-R subwoofers including the
SPL-800R, the SPL-1000R, the SPL-1200R and the SPL-1500R. It also works with the Digital
Drive SMS™-1.
The MIC-5 comes complete with:
•MIC-5 hub
•Five high precision microphones with stands and windscreens
•Five 6-foot XLR mic cables
•One 20-foot XLR mic cable for use with Digital Drive systems including the SMS-1
•One 20-foot microphone cable (mini-jack) for use with SPL-R subwoofers
•Carrying case
To use the MIC-5, simply install the mics in their stands, place them in the desired listening
positions, and connect them to the MIC-5 hub using the included 6-foot XLR microphone cables.
Select the number of microphones to be used by pressing the button on the MIC-5 hub until
the appropriate number of microphones is indicated. Use the appropriate long microphone
cable to connect to the Digital Drive subwoofer,SPL-R subwoofer
,or SMS-1. Then use the
Digital Drive or SPL-R equalization softwarenormally as indicated in the user’smanual.
The MIC-5 uses two 9-volt batteries (included). The low-battery light indicates the need for
new batteries.

Specifications:
.www.velodyne.com MIC-5 User’s Manual
Input
•Input – Selectable from 1 to 5 Female XLR Inputs
•Input Impedance – 10 K
Output
•1XLR Male – Frequency Range 16 Hz to 200 Hz
•13.5 mm Female - Frequency Range 16 Hz to 200 Hz
Controls
•Microphone Selector – 1 to 5 Microphones
•Power Button
•Indicator Light – Low Battery
•Indicator Light – Microphones Selected
MIC-5 Hub
Microphones
•5Pieces Included with Set
•Male XLR Output
•Microphone Linearity +/- 1 dB from 16 Hz to 200 Hz
Cables
•1–20foot XLR Male to Female Cable
•1–20 foot 3.5 mm Male to Male Cable
•5–6foot XLR Male to Female Cables
Accessories
•Mini Screwdriver (for battery installation and removal)
•Carrying Case (with handle)
Carrying Case
Dimensions (H/W/D)5.5” x 30” x 19”
(14 x 76.2 x 48.3 cm)
Shipping Weight 18 pounds
Warranty 2years
Battery (Included)
•9volt (2 pieces)
Accessories

.www.velodyne.com MIC-5 User’s Manual
Other Velodyne Subwoofer Products:
LIMITED WARRANTY
VELODYNE ACOUSTICS, Inc. (“VELODYNE”) warrants all electronics and powered subwoofers for a period of two
years and full range speakers for a period of five years. All VELODYNE products have a warranty from the date of
purchase against defects in materials and workmanship subject to the following conditions:
1. VELODYNE is not responsible for defects which result from the use of an amplifier or controller other than
the one originally supplied with the unit (subwoofer) or defects which result from modifications or repairs
made by any component of the system by anyone other than a VELODYNE factoryauthorized
service representative.
2. This warranty is void if any repairs or service covered by the terms of this warranty are made to any
component of the system by anyone other than a VELODYNE factory authorized service representative.
3. VELODYNE is not responsible for damage caused by accidents, abuse, misuse, natural or personal disaster
or unauthorized modification. The VELODYNE products arenot intended for professional or commercial use
and VELODYNE is not responsible for damage resulting from such use.
4. The VELODYNE product warranty is limited to units that are purchased from authorized VELODYNE dealers
and finalized within authorized dealer locations.
5. This warranty is nontransferable under any condition.
TO OBTAIN SERVICE
Information regarding service may be obtained from the dealer from whom you purchased the unit, or by contacting
VELODYNE customer service. Warranty service must be performed by a VELODYNE factory authorized service
representative within the warranty period set forth above. If VELODYNE determines the unit is defective, VELODYNE
will, at VELODYNE’s option, repair or replace the product at no charge if the product is forwarded prepaid to a factory
authorized service representative. Products forwarded to the factory authorized service representative should be
shipped securely and properly packaged, insured and freight prepaid.
Digital Drive Series
DD-10
DD-12
DD-15
DD-18
Digital Drive 1812
Signature Edition
DLS-R Series
DLS-3500R
DLS-3750R
DLS-4000R
DLS-5000R
DPS Series
DPS-10
DPS-12
110V
MiniVee™
SMS™-1
SPL-R Series
SPL-800R
SPL-1000R
SPL-1200R
SPL-1500R
VRP Series
VRP-1000
VRP-1200
VX Series
VX-10
Digital Drive Series
DD-10
DD-12
DD-15
DD-18
Digital Drive 1812
Signature Edition
CHT-R Series
CHT-8R
CHT-10R
CHT-12R
CHT-15R
230V
SMS™ -1
SPL-800i
SPL-R Series
SPL-800R
SPL-1000R
SPL-1200R
SPL-1500R

.www.velodyne.com MIC-5 User’s Manual
Velodyne Acoustics, Inc.
345 Digital Drive
Morgan Hill, CA 95037
408.465.2800 voice
408.779.9227 fax
408.779.9208 service fax
www.velodyne.com
Service E-mail: ser[email protected]
Product E-mail: [email protected]
Technical E-mail: [email protected]
63-MICKIT1 MAR06
