Venue Lighting Effects HyperFlex 12G User manual

HyperFlex 12G
USer MANUAl
www.venuelightingeffects.com

HYPERFLEX 12G USER MANUAL
2
Table of conTenTs
INTRODUCTION ...................................................................2
SAFETY PRECAUTIONS .........................................................3
UNIT OVERVIEW ...................................................................4
RIGGING THE FIXTURES ........................................................4
LAMP INSTALLATION/REPLACEMENT .........................................5
GOBO SELECTION ADVANCE ...................................................5
BEAM ANGLE ......................................................................6
FIXTURE CLEANING .............................................................. 6
TROUBLESHOOTING ............................................................. 7
OPERATION AND TECHNICAL SPECIFICATIONS ............................ 7
InTroducTIon
Thank you for purchasing Venue’s HyperFlex 12G light fixture. A high-output
special event projector, it’s equipped with 12 event gobos that are ideal for
discos, clubs, bars, and parties. The HyperFlex 12G offers users the choice of
static, continuous or sound activation to satisfy any application.
For safe operation, read this manual before powering or installing the fixture.
Be sure to follow the safety precautions listed below, and observe all warnings
printed in this manual and on the fixture.

www.venuelightingeffects.com 3
safeTy PrecauTIons
• PleasekeepthisUserGuideforfutureconsultation.Ifyoudosellthisunit
to another user, ensure that they also receive this instruction booklet.
• Unpackandchecktheunittomakesuretherewasnotransportation
damagebeforeusingtheunit.
• Beforeoperating,ensurethatthevoltageandfrequencyofpower
supplymatchthepowerrequirementsoftheunit.
• It’simportanttogroundtheinternalyellow/greenconductorbetweenthe
chassis and cover in order to avoid possible electric shocks.
• Theunitisforindooruseonly.Useonlyinadrylocation.
• Theunitmustbeinstalledinalocationwithadequateventilation,atleast
50cmfromadjacentsurfaces.Besurethatnoventilationslotsareblocked.
• Disconnectmainspowerbeforefuse/lampreplacementorservicing.
• Replacefuse/lamponlywiththesametype.
• Duringoperation,ensurethatammablematerialsarenotneartheunit.
• Usesafetycableswhenxingthisunit.
• Maximumambienttemperatureis104F.Donotoperate
theunitifthetemperatureishigherthanthis.
• Unitsurfacetemperaturemayreachupto185F.Don’ttouchthehousing
bare-handduringitsoperation.Turnoffthepowerandallowabout15minutes
for the unit to cool down before replacing bulb or serving.
• Intheeventofaseriousoperatingproblem,stopusingtheunitimmediately.
Never try to repair the unit by yourself. Repairs not carried out by professionals
canleadtodamageormalfunction.Pleasecontactthenearestauthorized
technicalassistancecenter.Also,alwaysusethesametypespareparts.
• Don’tconnectthedevicetoanydimmerpackorpowerpack.
• Donottouchanywireduringoperation,astheunit’shighvoltage
 mightcauseanelectricshock.
CAUTION
There are no user-serviceable parts inside the unit. Do not open the housing
orattemptanyrepairsyourself.Intheunlikelyeventyourunitrequiresservice,
please contact your nearest dealer.

HYPERFLEX 12G USER MANUAL
4
unIT overvIew
1.Screwforopeningthelampcompartment
2.Opticallenswithmanualfocusadjustment
3. Microphone
4. Mains input with IEC socket and integrated fuse holder,
whichconnectsthesuppliedmainscable
5. Cooling fan
6. Hangingbracketthatfastenstheunit,andamounting
holetocomplementtheunit’smountinghook
7. Gobo Advance button changes the gobo selection
8.Modeselectbuttontogglesbetweenstatic,auto,andsoundactivemode
rIggIng The fIxTures
Theunitshouldbemountedviaitsscrewholesonthebracket.Alwaysensure
thattheunitisrmlyxedtoavoidvibrationandslippingwhileoperating.Also
makesurethatthestructuretowhichyouareattachingtheunitissecureandis
abletosupportupto10timestheunit’sweight.Alwaysuseasafetycablethat
canhold12timesoftheweightoftheunitwheninstallingthexture.
Installationmustonlybecarriedoutbyqualiedservicepeople.Thedevice
shouldbeinstalledinanprivateareaawayfrompeople.
3 4 56
12
7
8

www.venuelightingeffects.com 5
lamP InsTallaTIon/
rePlacemenT
•Alwaysswitchoffthemainssupplyandneverhandlethelampwhenitishot.
• Donottouchthebulbwithbarehands.Ifthisdoeshappen,cleanthelamp
with denatured alcohol and wipe with a lint-free cloth.
gobo selecTIon advance
Press the Red Gobo button to advance through the 12 Gobos.
Pullthesocketoffthelamp.
Do not pull the wires.
1 2 3 4 5 6 7 8 9 10 11 12
1 2 3 4 5 6 7 8 9 10 11 12

HYPERFLEX 12G USER MANUAL
6
beam angle
Theoptimalprojectorplacementisatleast15feetfromawall.Fromthis
distance the light effect will cover an area of 10x10 feet.
fIxTure cleanIng
Thecleaningofinternalandexternalopticallensesand/ormirrorsmustbe
carriedoutperiodicallytooptimizelightoutput.Cleaningfrequencydepends
ontheenvironmentinwhichthextureoperates.Damp,smokyordirty
surroundingscancausegreateraccumulationofdirtontheunit’soptics.
• Cleanwithsoftcloth,usingnormalglasscleaneruid.
• Alwaysdrytheunit’spartscarefully.
•Cleantheexternalopticsatleastevery20days.
•Cleantheinternalopticsevery30to60days.
760 260
0 1 2 3 4 56
Distance (m)
1.97
0.985
0m(ø)
0.985
1.97
36o
130(Lux)

www.venuelightingeffects.com 7
TroubleshooTIng
oPeraTIon and TechnIcal
sPecIfIcaTIons
•Assoonasyouplugtheunitintothemainspower,theunitstartsrunning.
•Theunitrunsinautomaticorsound-activatedmode.
•Theunitisfan-cooledandthermal-switchedforoverheatprotection.
Specification:
• Voltage:AC120V~60Hz230V/240V/250V~50Hz/60Hz
• Fuse:20mmglass250VT6.3A/20mmglass250VT5A
• Bulb:ELC24V250W
• Dimension:12”x10.36”x5.5”
• Weight:17.64lbs.
Problem Probable cause(s) Suggestedremedy
No power to the fixture Check power connections.
Blown fuse
Burnedoutlamp Installnewlamp.
Fixture too hot
No action
Sound too low to
activate control circuit
Electricalmalfunction Refer to service technician.
Increasevolume.
Allow unit to cool down
by improving air ow
around the unit.
If power is applied but
does not light, check fuse
and replace if necessary
No light

One(1)YearLimitedWarranty
Subjecttothelimitationssetforthbelow,Venue™herebyrepresentsandwarrantsthatthecomponentsofthisproductshallbefree
fromdefectsinworkmanshipandmaterials,includingimpliedwarrantiesofmerchantabilityortnessforaparticularpurpose,subject
tonormaluseandservice,forone(1)year(ninety(90)daysonlamps)totheoriginalownerfromthedateofpurchase.
Retailerandmanufacturershallnotbeliablefordamagesbaseduponinconvenience,lossofuseofproduct,lossoftime,interrupted
operationorcommercial lossor anyotherincidental orconsequential damagesincluding butnotlimited tolost prots,downtime,
goodwill,damage toor replacementof equipmentand property,andanycosts ofrecovering,reprogramming,or reproducingany
programordatastoredinequipmentthatisusedwithVenue™products.Thisguaranteegivesyouspeciclegalrights.Youmayhave
otherlegalrightswhichvaryfromstatetostate.Somestatesdonotallowlimitationsonhowlonganimpliedwarrantylasts,sothe
abovelimitationmaynotapplytoyou.
California Prop 65 Warning
Thisproductmaycontainachemical(s)knowntothestateofCaliforniatocausecancerorbirthdefectsorotherreproductiveharm.
Venue Lighting Effects
P.O. Box 5111
ThousandOaks,CA91359-5111
Alltrademarksandregisteredtrademarksmentionedhereinarerecognizedasthepropertyoftheirrespectiveholders.
Made in China
0906-9016
www.venuelightingeffects.com
We declare that our products (lighting equipments) comply with the
following specication and bears CE mark in accordance with the
provisionoftheElectromagneticCompatibility(EMC)Directive89/336/EEC.
 EN55014-2:1997A1:2001,EN61000-4-2:1995;EN61000-4-3:2002;
 EN61000-4-4:1995;EN61000-4-5:1995,EN61000-4-6:1996,
 EN61000-4-11:1994.
Harmonized Standard
 EN60598-1:2000+ALL:2000+A12:2002
 Safetyofhouseholdandsimilarelectricalappliances
 Part1:Generalrequirements
EC Declaration of Conformity
