Vertex Standard VX-450 series User manual

16-Key Version 4-Key Version Non-LCD Version
VX-450 SERIES
OPERATING MANUAL
VERTEX STANDARD CO., LTD.
4-8-8 Nakameguro, Meguro-Ku, Tokyo 153-8644, Japan
VERTEX STANDARD
US Headquarters
10900 Walker Street, Cypress, CA 90630, U.S.A.
YAESU UK LTD.
Unit 12, Sun Valley Business Park, Winnall Close
Winchester, Hampshire, SO23 0LB, U.K.
VERTEX STANDARD HK LTD.
Unit 5, 20/F., Seaview Centre, 139-141 Hoi Bun Road,
Kwun Tong, Kowloon, Hong Kong
VERTEX STANDARD (AUSTRALIA)PTY., LTD.
Normanby Business Park, Unit 14/45 Normanby Road
Notting Hill 3168, Victoria, Australia

Warning! FCC RF Exposure Requirements ............... 2
Controls & Connectors (16-Key Version) ................... 4
Controls & Connectors (4-Key Version) ..................... 5
Controls & Connectors (Non-LCD Version) ............... 6
LCD Icons & Indicators (16- & 4-Key Versions) ....... 7
Before You Begin ........................................................... 8
Battery Pack Installation and Removal ............................... 8
Low Battery Indication ....................................................... 8
Battery Charging ................................................................. 9
Operation ..................................................................... 10
P reliminary Steps ..................................................... 10
Operation Quick Start .............................................. 10
Advanced Operation ................................................... 14
Programmable Key Functions ...................................... 14
Descriptipon of Operating Functions ............................ 16
ARTS (Auto Range Transpond System) ................... 24
DTMF Paging System ................................................. 24
LOCK ........................................................................... 24
User Set Mode .............................................................. 25
Optional Accessories.................................................... 26
CONTENTS

VX-450 SERIES OPERATING MANUAL
1
IMPORTANT NOTICE FOR NORTH AMERICAN USERS REGARDING 406 MHZGUARD BAND
The U.S. Coast Guard and National Oceanographic and Atmospheric Administration have requested the
cooperation of the U.S. Federal Communications Commission in preserving the integrity of the protected
frequency range 406.0 to 406.1 MHz, which is reserved for use by distress beacons. Do not attempt to
program this apparatus, under any circumstances, for operation in the frequency range 406.0 - 406.1
MHz if the apparatus is to be used in or near North America.
Warning - Frequency band 406 - 406.1 MHz is reserved for use ONLY as a distress beacon by the
US Coast Guard and NOAA. Under no circumstance should this frequency band be part of the
preprogrammed operating frequencies of this radio.
CONGRATULATIONS!
You now have at your fingertips a valuable communications tool-a Vertex Standard two-way radio! Rug-
ged, reliable and easy to use, your Vertex Standard radio will keep you in constant touch with your
colleagues for years to come, with negligible maintenance down-time. Please take a few minutes to read
this manual carefully. The information presented here will allow you to derive maximum performance
from your radio, in case questions arise later on.
We’re glad you joined the Vertex Standard team. Call on us anytime, because communications is our
business. Let us help you get your message across.
Notice!: There are no owner-serviceable parts inside the radio. All service jobs must be referred to an
authorized Vertex Standard Service Representative. Consult your Authorized Vertex Standard Dealer for
installation of optional accessories.

VX-450 SERIES OPERATING MANUAL
2
WARNING! FCC RF EXPOSURE REQUIREMENTS
This Radio has been tested and complies with the Federal Communications Commission (FCC) RF exposure
limits for Occupational Use/Controlled exposure environment. In addition, it complies with the following Stan-
dards and Guidelines:
FCC 96-326, Guidelines for Evaluating the Environmental Effects of Radio-Frequency Radiation.
FCC OET Bulletin 65 Edition 97-01 (1997) Supplement C, Evaluating Compliance with FCC Guidelines for
Human Exposure to Radio Frequency Electromagnetic Fields.
ANSI/IEEE C95.1-1992, IEEE Standard for Safety Levels with Respect to Human Exposure to Radio Fre-
quency Electromagnetic Fields, 3 kHz to 300 GHz.
ANSI/IEEE C95.3-1992, IEEE Recommended Practice for the Measurement of Potentially Hazardous Elec-
tromagnetic Fields - RF and Microwave.
WARNING:
This radio generates RF electromagnetic energy during transmit mode. This radio is designed for and
classified as Occupational Use Only, meaning it must be used only during the course of employment by
individuals aware of the hazards, and the ways to minimize such hazards. This radio is not intended for
use by the General Population in an uncontrolled environment.
CAUTION:
To ensure that your expose to RF electromagnetic energy is within the FCC allowable limits for occupa-
tional use, always adhere to the following guidelines:
This radio is NOT approved for use by the general population in an uncontrolled exposure environ-
ment. This radio is restricted to occupational use, work related operations only where the radio opera-
tor must have the knowledge to control his or her RF exposure conditions.
When transmitting, hold the radio in a vertical position with its microphone 2 inches (5 cm) away from
your mouth and keep the antenna at least 2 inches (5 cm) away from your head and body.

VX-450 SERIES OPERATING MANUAL
3
The radio must be used with a maximum operating duty cycle not exceeding 50%, in typical Push-to-
Talk configurations.
DO NOT transmit for more than 50% of total radio use time (50% duty cycle). Transmitting more
than 50% of the time can cause FCC RF exposure compliance requirements to be exceeded.
The radio is transmitting when the red LED on the top of the radio is illuminated. You can cause the
radio to transmit by pressing the P-T-T button.
SAR compliance for body-worn use was only demonstrated for the specific belt-clip Part Number
(CLIP-450). Other body-worn accessories or configurations may NOT comply with the FCC RF expo-
sure requirements and should be avoided.
DO NOT transmit when the radio is used in Body Worn configuration with the following accessory:
belt-clip.
It must be used ONLY for (1) there is 4 cm distance from the body during transmitting, (2) monitoring
purposes, using the speaker only and (3) for carrying purposes.
Always use Vertex Standard authorized accessories.
The information listed above provides the user with the information needed to make him or her aware
of RF exposure, and what to do to assure that this radio operates with the FCC RF exposure limits of
this radio.
Electromagnetic Interference/Compatibility
During transmissions, this radio generates RF energy that can possibly cause interference with other
devices or systems. To avoid such interference, turn off the radio in areas where signs are posted to do so.
Do not operate the transmitter in areas that are sensitive to electromagnetic radiation such as hospi-
tals, health care facilities, aircraft, and blasting sites.
WARNING! RF EXPOSURE REQUIREMENTS

VX-450 SERIES OPERATING MANUAL
4
CONTROLS & CONNECTORS (16-KEY VERSION)
PTT Switch
SIDE-1 Button
SIDE-2 Button
MIC/SP Jack
(External MIC/SP)
Battery Pack Latch16-Button DTMF Keypad
LCD (Liquid Crystal Display)Microphone
LED Indicator
Steady Red:
Transmitting in progress
Blinking Green:
Busy Channel
Steady Green:
Tone Squelch in defeated condition
Dealer Programmed Color:
Emergency, 5-Tone Decoded, or
2-Tone Decoded
Speaker
Antenna Jack
TOP SEL Key
CH (Channel)Selector
VOL/PWR Knob
: one of “Flashing in white,”
“Continuation changes in
sequential colors,” or “tog-
gling the two colors.”

VX-450 SERIES OPERATING MANUAL
5
CONTROLS & CONNECTORS (4-KEY VERSION)
Battery Pack Latch4-Button Programmable Key
LCD (Liquid Crystal Display)Microphone
LED Indicator
Steady Red:
Transmitting in progress
Blinking Green:
Busy Channel
Steady Green:
Tone Squelch in defeated condition
Dealer Programmed Color:
Emergency, 5-Tone Decoded, or
2-Tone Decoded
Speaker
Antenna Jack
TOP SEL Key
CH (Channel)Selector
VOL/PWR Knob
: one of “Flashing in white,”
“Continuation changes in
sequential colors,” or “tog-
gling the two colors.”
PTT Switch
SIDE-1 Button
SIDE-2 Button
MIC/SP Jack
(External MIC/SP)

VX-450 SERIES OPERATING MANUAL
6
CONTROLS & CONNECTORS (NON-LCD VERSION)
Battery Pack Latch
Speaker Microphone
LED Indicator
Steady Red:
Transmitting in progress
Blinking Green:
Busy Channel
Steady Green:
Tone Squelch in defeated condition
Dealer Programmed Color:
Emergency, 5-Tone Decoded, or
2-Tone Decoded
Antenna Jack
TOP SEL Key
CH (Channel)Selector
VOL/PWR Knob
: one of “Flashing in white,”
“Continuation changes in
sequential colors,” or “tog-
gling the two colors.”
MIC/SP Jack
(External MIC/SP)
PTT Switch
SIDE-1 Button
SIDE-2 Button

VX-450 SERIES OPERATING MANUAL
7
LCD ICONS & INDICATORS (16-KEY & 4-KEY VERSIONS)
12 Character Alpha-numeric Display
Zone Number
RSSI Indicator (four steps)
Encryption is activated
Option SW (Key Function)
is activated
Low Transmit Power Mode On
“Audio Compander” is activated
“CALL” Indicator
Receiver Monitor
“Talk-Around” is enabled
“Voice Message” is received
Battery Indicator
“Zone Scan” is enabled
Priority Channel
“DUAL WATCH” is activated
: “Scan” is activated
: “Priority Scan” is activated

VX-450 SERIES OPERATING MANUAL
8
BEFORE YOU BEGIN
Battery Pack Installation and Removal
To install the battery pack, align the battery pack
to the radio with an offset about 1/2 inch from the
top edge of battery compartment, then slide the
battery pack upward until it locks in place with a
“Click.”
Low Battery Indication
As the battery discharges during use, the voltage
gradually becomes lower. When the battery voltage
becomes to low, substitute a freshly charged battery
and recharge the depleted pack. The LED indicator
on the top of the radio will blink red when the bat-
tery voltage is low.
Caution
Danger of explosion if battery is replaced with
an incorrect battery. Replace only with the same
or equivalent type.
To remove the battery, turn the radio off and re-
move any protective cases. Slide the Battery Pack
Latch on the bottom of the radio toward the front
panel while sliding the battery down about 1/2
inch. Then lift the battery out from the radio while
unfolding the Belt Clip.
Do not attempt to open any of the recharge-
able Lithium-Ion packs, as they could ex-
plode if accidentally short-circuited.

VX-450 SERIES OPERATING MANUAL
9
BEFORE YOU BEGIN
Battery Charging
Insert the DC plug from the PA-45 AC Adapter
into the DC jack on the rear panel of the CD-49
Desktop Rapid Charger, then plug the PA-45 AC
Adapter into the AC line outlet.
Insert the battery pack into the CD-49 Desktop
Rapid Charger while aligning the slots of the bat-
tery pack with the guides in the nest of the CD-
49; refer to the illustration at the right for details
on proper positioning of the pack. If charging with
the transceiver attached, turn the transceiver off,
and the antenna jack should be at the left side when
viewing the charger from the front.
If the battery pack is inserted correctly, the LED
indicator will glow red. A fully-discharged pack
will be charged completely in approximately 1.5
hours (FNB-V112LI, 2.5 hours: FNB-V113LI).
The LED indicator will blink red/green alternately
when charging is nearing completion.
When charging is completed, the LED indicator
will change to green. Even if the charging is com-
pleted, the LED indicator will sometimes change
to red for trickle charging.
Disconnect the pack from the CD-49 Desktop
Rapid Charger, and unplug the PA-45 AC Adapter
from the AC line outlet.
WARNING
Perform the battery charging where the ambient tem-
pera-ture range +5 °C to +35 °C. Charge out of
this range could cause damage to the battery pack.

VX-450 SERIES OPERATING MANUAL
10
OPERATION
Preliminary Steps
Install a charged battery
pack onto the transceiver, as
described previously.
Screw the supplied antenna
onto the Antenna jack.
Never attempt to operate
this transceiver without an
antenna connected.
If you have a Speaker/Mi-
crophone, we recommend
that it not be connected until you are familiar with
the basic operation of the VX-450.
Operation Quick Start
Turn the top panel’s
VOL/PWR knob clock-
wise to turn the radio on.
Turn the top panel’s CH
Selector knob to choose
the desired operating
channel. On the 16-key
and 4-key versions, a
channel name will appear
on the LCD.
If you want to select the operating channel from a
different Memory Channel Zone, press the Pro-
grammable key (assigned to the Memory Zone
Up or Down function) to select the Memory Chan-
nel Zone you want before selecting the operating
channel. A Zone name will appear on the LCD
whenever the Programmable key is pressed.
Note: Some models are programmed so that the
operating channels are selected by the Program-
mable key and the Memory Channel Zone is se-
lected by the CH selector knob. For further de-
tails, contact your Vertex Standard dealer.

VX-450 SERIES OPERATING MANUAL
11
Rotate the VOL/PWR
knob to set the volume
level. If no signal is
present, press and hold in
the SIDE-1 button (un-
der the PTT switch)
more than 2 seconds;
background noise will
now be heard, and you
may use this to set the
VOL/PWR knob for the
desired audio level. Press
and hold the SIDE-1 button more than 2 seconds
(or press the SIDE-1 button twice) to quiet the
noise and resume normal (quiet) monitoring.
To transmit, monitor the channel and make sure it
is clear.
Press and hold the PTT
switch. Speak into the
microphone area of the
front panel grille (above
the upper left edge of the
LCD) in a normal voice
level. To return to the Receive mode, release the
PTT switch.
Press the (Orange) TOP
SEL key to activate one
of the preprogrammed
functions which may
have been enabled at the
time of programming by
the dealer. See the next section for details regard-
ing the available features.
If a Speaker/Microphone
is available, remove the
plastic cap and its two
mounting screws from
the right side of the trans-
ceiver, then align the con-
nector of the Speaker/
Microphone on the trans-
ceiver body; secure the
connector pin using the screws supplied with the
Speaker/Microphone. Hold the speaker grille up
next to your ear while receiving. To transmit, press
the PTT switch on the Speaker/Microphone, just
as you would on the main transceiver’s body, and
speak into the microphone on a normal voice level.
Note 1): Save the original plastic cap and its
mounting screws. They should be reinstalled
when not using the Speaker/Microphone.
OPERATION

VX-450 SERIES OPERATING MANUAL
12
2) When you press the PTT switch on the
Speaker/Microphone, it disables the internal mi-
crophone, and vice versa.
If the Busy Channel Lockout feature has been
programmed on a channel, the radio will not trans-
mit when a carrier is present. Instead, the radio
will generate short beep three times and indicate
“*CH Busy *” on the display (16-key and 4-
key versions). Release the PTT switch and wait
for the channel to be clear of activity.
If CTCSS or Digital Coded Squelch (DCS) Lock-
out has been programmed on a channel, the radio
can transmit only when there is no carrier being
received or when the carrier being received in-
cludes the correct CTCSS tone or DCS code.
Automatic Time-Out Timer
If the selected channel has been programmed for au-
tomatic time-out, you must limit the length of each
transmission. While transmitting, a beep will sound
10 seconds before time-out. Another beep will sound
just before the deadline; the “TX” indicator will dis-
appear and transmission will cease soon thereafter.
To resume transmitting, you must release the PTT
switch and wait for the “penalty timer” to expire.
OPERATION

VX-450 SERIES OPERATING MANUAL
13
NOTE

VX-450 SERIES OPERATING MANUAL
14
ADVANCED OPERATION
Programmable Key Functions
All versions of the VX-450 include the TOP SEL,
SIDE-1, and SIDE-2 key. The 16-key and 4-key ver-
sions include the [A], [B], [C], and [D]function keys.
Furthermore, the 16-key version includes the []and
[#]function keys.
The Programmable key functions can be customized,
via programming by your Vertex Standard dealer, to
meet your communications/network requirements.
Some features may require the purchase and instal-
lation of optional internal accessories. The possible
Programmable key programming features are illus-
trated at the right, and their functions are explained
on page 16. For further details, contact your Vertex
Standard dealer.
For future reference, check the box next to each func-
tion that has been assigned to the Programmable key
on your particular radio, and keep it handy.
TOP SEL
FUNCTION
None
Monitor
Lamp
Lock1
Scan
Dual Watch
Low Power
Talk Around
TX Save Disable
Encryption
FM Scan
Zone Up1
Zone Down1
Channel Up1
Channel Down1
Set1
Call/Reset
SIDE-1 SIDE-2 [A] [B] [C] [D]
PROGRAMMABLE KEY
[] [#]

VX-450 SERIES OPERATING MANUAL
15
ADVANCED OPERATION
FUNCTION
Call 1
Call 2
Call 3
Call 4
Call 5
Code Up1
Code Down1
Code Set1
Speed Dial2
Option SW 1
Option SW 2
Emergency
PRI-11
Selectable Tone1
Direct Channel #11
Direct Channel #21
Direct Channel #31
Direct Channel #41
REC3
PLAY3
SQL
AF Min Volume
Status Set1
Status Up1
Status Down1
Status Check
Lone Worker
DTMF Code Set2
TA Scan
Priority Disable
Beep Off
Whisper
Duty
TOP SEL SIDE-1 SIDE-2 [B] [C] [D]
PROGRAMMABLE KEY
[A] [] [#]
1:This function can not be selected on the Non-LCD Version
2:This function is only selected on the 16-key Version
3:Requires DVS-8 Voice Storage Unit

VX-450 SERIES OPERATING MANUAL
16
Description of Operating Functions
MONITOR
Press the assigned Programmable key to cancel
CTCSS- and DCS-controlled squelch; the BUSY/TX
indicator will glow green. Press and hold this button
for 2 seconds to hear background noise (unmute the
audio); the BUSY/TX indicator will blink green.
LAMP
Press the assigned Programmable key to illuminate
the LCD for five seconds.
LOCK
Press the assigned Programmable key to lock the CH
Selector knob, Programmable keys, and PTT switch.
The precise lockout configulation is programmed by
your Dealer.
SCAN
The Scanning feature is used to monitor multiple sig-
nals programmed into the transceiver. While scan-
ning, the transceiver will check each channel for the
presence of a signal, and will stop on a channel if a
signal is present.
To activate scanning:
Press the assigned Programmable key to activate
scanning.
The scanner will search the channels of each chan-
nel, looking for active ones; it will pause each time
it finds a channel on which someone is speaking.
Press the assigned Programmable key again to dis-
able scanning. Operation will revert to the pro-
grammed revert channel.
Note: Your dealer may have programmed your ra-
dio to stay on one of the following channels if you
press the PTT switch during scanning pause:
Current channel (“Talk Back”)
“Last Busy” channel
“Priority” channel
“Home” channel
“Scan Start” channel
ADVANCED OPERATION

VX-450 SERIES OPERATING MANUAL
17
DUAL WATCH
The Dual Watch feature is similar to the SCAN fea-
ture, except that only two channels are monitored:
The current operating channel; and
The Priority channel.
To activate Dual Watch:
Press the assigned Programmable key.
The scanner will search the two channels; it will
pause each time it finds a channel on which some-
one is speaking.
To stop Dual Watch:
Press the assigned Programmable key.
Operation will revert to the “Dual Watch Start”
channel.
LOW POWER
Press the assigned Programmable key to set the
radio’s transmitter to the “Low Power” mode, thus
extending battery life. Press the key again to return
to “Normal” transmit power when in difficult terrain.
When the radio’s transmitter is set to “Low Power”
mode, the “ ” icon will be indicated on the dis-
play.
TALK AROUND (TA)
Press the assigned Programmable key to activate the
Talk Around feature when you are operating on du-
plex channel systems (separate receive and transmit
frequencies, utilizing a “repeater” station). The Talk
Around feature allows you to bypass the repeater sta-
tion and talk directly to a station that is nearby. This
feature has no effect when you are operating on “sim-
plex” channels, where the receive and transmit fre-
quencies are already the same.
When the “TA” function is activated, the “ ” icon
will be indicated on the display.
Note that your dealer may have mode provision for
“Talk Around” channels by programming “repeater”
and “Talk Around” frequencies on two adjacent chan-
nels. If so, the key may be used for one of the other
Pre-Programmed Functions.
ADVANCED OPERATION

VX-450 SERIES OPERATING MANUAL
18
TX SAV E DISABLE
Press the assigned Programmable key to disable the
Transmit Battery Saver, if you are operating in a lo-
cation where high power is almost always needed.
The Transmit Battery Saver helps extend battery life
by reducing transmit power when a very strong sig-
nal from an apparently nearby station is being re-
ceived. Under some circumstances, though, your
hand-held radio may not be heard well at the other
end of the communication path, and high power may
be necessary at all times.
ENCRYPTION
Press the assigned Programmable key to toggle the
Encryption feature “On” and “Off.”
FM SCAN
The FM Scan feature checks a User-assigned Prior-
ity Channel regularly as you scan other channels.
Thus, if only Channels 1, 3, and 5 (of the 8 available
channels) are designated for “Scanning,” the user may
nonetheless assign Channel 2 as the “User-assigned”
Priority Channel via the “Follow-Me” feature.
To activate FM Scan, first select the channel you want
to designate as the “User-Assigned Priority Chan-
nel” and press the assigned programmable key. Then
rotate the CH Selector knob to recall to the “Scan-
ning Start” channel which has been programmed by
your dealer to activate the scanner. When the scan-
ner stops on an “Active” channel, the User-assigned
Priority Channel will automatically be checked ev-
ery few seconds; if activity is found on the User-as-
signed Priority Channel, the radio will switch between
it and the Dealer-Assigned Priority Channel, if any.
ADVANCED OPERATION
