VEVOR CH-HGGJ01 User manual

Technical Support and E-Warranty Certificate www.vevor.com/support
POTS AND PANS ORGANIZER
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.

1
Thanks for purchasing one of our products, please read carefully the assembly
instructions before the installation.
Model: CH-HGGJ01；CH-HGGJ02；CH-HGGJ03
Have product questions? Need technical support? Please feel free to
contact us:
[e-mail]
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
Pots and Pans Organizer

2
PRODUCT PARAMETERS
ASSEMBLY PRECAUTIONS
1. Assembly needs to follow these instructions. Incorrect assembly can be
a hazard.
2. Wear safety goggles and heavy-duty work gloves during assembly.
3. Do not assemble when tired or under the influence of alcohol, drugs or
medication.
4. Weight capacity and other product capabilities apply to a properly and
completely assembled product only.
5. Keep the assembly area clean and well-lit.
6. Keep bystanders out of the area during assembly.
7. Select the cabinet consistent with or close to the installation size for
installation
Model
Product Size（W*D*H）
Loading
Capacity
Installation size(mm)
(W*D*H）
CH-HGG
J01
248x530x220mm
（9-3/4"x20-7/8"x8-7/8"）
120 lb
(Max)
260x560x300mm
（10-1/3"x22"x8-4/5"）
CH-HGG
J02
298x530x220mm
（11-3/4"x20-7/8"x8-7/8"）
120 lb
(Max)
312x560x300mm
（12-1/3"x22"x8-4/5"）
CH-HGG
J03
348x530x220mm
（13-3/4"x20-7/8"x8-7/8"）
120 lb
(Max)
365x560x300mm
（14-1/3"x22"x8-4/5"）

3
USE PRECAUTIONS
WARNING: TO PREVENT SERIOUS INJURY AND DEATH FROM
TIPPING:
1. This product is not a toy. Do not allow children to play with or approach
this item.
2. Use as intended only. Do not sit or stand on the product.
3. Inspect before every use. Do not use it if parts are loose or damaged.
4. Use on Kitchen cabinet only and Do not use it alone on the ground or on
the desktop.
5. Do not exceed the listed weight capacity. Tighten all knobs securely
before applying load. Be aware of dynamic loading! The sudden load
movement may briefly create an excess load, causing product failure.

4
PARTS LIST
Note:CH-HGGJ03 Part (C) quantity is 5 PCS and (D) is 10 PCS.
No.
A
B
C
D
E
Name
Base
Slide
Frame
M6
ST4*12
Parts
Quantiy
1 PCS
1 set
4 PCS
8 PCS
4 PCS
No.
F
G
Name
M4*6
Wrench
Parts
Quantiy
4 PCS
1 PCS

5
ASSEMBLY STEPS
STEP1
STEP2
1.Push up the buckle and
take out the inner-slide.
2.Fix the frame(A) onto the
base with the M6screws(B)
And fix t he base on to the
inner-slide(C)with M4*6
screw(D).
B

6
STEP3
COMPLETION
Model
Installation size(mm)
(W*D*H）
CH-H
GGJ01
260x560x300mm
（10-1/3"x22"x8-4/5"）
CH-H
GGJ02
312x560x300mm
（12-1/3"x22"x8-4/5"）
CH-H
GGJ03
365x560x300mm
（14-1/3"x22"x8-4/5"）
3.Select the appropriate Installation size
according to the product.Fix the slide(B)
onto the bottom of the cabinet with the
ST4*12 screws(E).
4. Insert thei nner-slide back to
the slide and finish the
installation.

7
Cleaning
-For cleaning, wipe the surface with a damp (not wet) cloth or wipe dry
with a clean lint free cotton cloth.
-Window cleaning liquid or a similar cleaning liquid can be used to
clean the surface.

Support and E-Warranty Certificate
www.vevor.com/support
