VHT Special 12 User manual

12-20 Watt Hand-Wired Vacuum Tube Guitar Amplier
User Manual
VHT SPECIAL 12/20

PRODUCT SAFETY INFORMATION.................1
OVERVIEW.............................................................2
FEATURES.............................................................3
CONTROL PANEL FUNCTIONS.....................4-5
REAR PANEL FUNCTIONS.............................6-7
BLOCK DIAGRAM................................................7
BOOST CONTROL GRAPH................................8
TONE CONTROL GRAPHS..........................9-10
DEPTH CONTROL GRAPH..............................11
TEXTURE SWITCH GRAPH............................12
FX RETURN - DEPTH CONTROL GRAPH...13
FX RETURN -TEXTURE SWITCH GRAPH...14
SCHEMATIC........................................................15
TECHNICAL SPECIFICATIONS......................16
TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this amplifier near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from
the amplifier.
12) Unplug this amplifier during lightning storms or when unused for long periods of time.
13) Refer all servicing to qualified service personnel. Servicing is required when the amplifier has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been spilled or objects have fallen into the amplifier, the amplifier has been exposed to rain or
moisture, does not operate normally, or has been dropped.
14) The amplifier shall not be exposed to dripping or splashing and no objects filled with liquids, shall be placed on the amplifier.
15) This amplifier shall be connected to a mains socket outlet with a protective earthing/ground connection.
16) The mains/power plug or amplifier coupler is the disconnect device which must remain readily operable.
WARNING To reduce the risk of fire or electric shock, do not expose this amplifier to rain or moisture.
VHT SPECIAL 12/20
The Pedal-Friendly Amp with Selectable Power Ranges
Building on the success of the popular VHT Special 6 and Special 6 Ultra, the VHT Special 12/20 features increased power (with two power
ranges), a unique preamp specically designed to excel with pedals and multi-effects units, a convenient built-in 9-volt DC pedal power supply,
an all-tube buffered effects loop with send and return level controls, variable Watts control, plus VHT’s unique Depth and Texture controls.
To optimize the amp for a wide range of output tubes, the VHT Special 12/20 offers two output-power ranges; safely located behind the rear
panel, a special voltage range switch provides the proper voltages for 6V6 or EL84 output tubes (in 12-watt low-voltage/low-power mode). The
high voltage 20-watt setting provides the ideal voltages for higher-power 6L6 or EL34 output tubes. The Special 12/20 ships from the factory
with a pair of 6V6 output tubes (VHT 6V6-to-EL84 socket adapters are required for operation with EL84 tubes). In addition, the Special 12/20’s
variable Watts control can reduce the maximum output power to less than one watt for whisper-quiet volume levels.
The Special 12/20 preamp was designed to bring the most out of every effects pedal and multi-effects unit with enhanced clarity, detail, and
controlled tube compression. Its low-impedance buffered effects loop send — with variable send level — can effortlessly drive the most difcult
pedals without tone or signal loss. Thanks to its variable send and return level controls, the 12/20’s effects loop can accommodate a wide
range of pedal or rack effects. Those seeking the shortest signal path to the output stage can plug their pedals or multi-effects units directly
into to effects return jack — the 12/20’s unique output stage Depth and Texture controls are post-effects loop, so the output stage characteris-
tics can always be ne-tuned to accommodate a wide range of instruments, speakers, playing styles and environments.
As an added convenience for pedal users, the VHT Special 12/20 also features a built-in, regulated 9-volt DC pedal power supply.
Hear your pedals like never before — with the VHT Special 12/20.
2
1

TEXTURE
12/20
31 2 5 7 8 9 10 12
6
4 11
1. Power Switch: This switch turns the amplier on or off.
2. Pentode/Standby/Triode: The Triode setting reduces the amplier’s maximum output power to approximately one-half of the Pentode set-
ting. Triode setting produces a richer and smoother tone, with earlier breakup than the Pentode setting. The middle position is Standby mode.
3. Watts Control: The Watts control adjusts the output tube’s operating voltage and maximum output power. Maximum output power ranges
from less-than 1 watt (fully counterclockwise) to 12 or 20 watts (fully clockwise).
4. Jewel Light: This light will be illuminated when the Power Switch is in the On position; the jewel light will be off when the Power switch is in
the Off position.
CONTROL PANEL FEATURES
VHT SPECIAL 12/20 FEATURES
12-20 Watts Maximum Output Power
High/Low Tube Voltage Switch
Two 6V6 Output Tubes
Accepts EL84 Ourput Tubes*
Also Accepts 6L6 or EL34 Output Tubes
Three 12AX7 Preamp Tubes
Volume and Tone Controls
Footswitchable Boost Mode
Effects Loop Send and Return Level Controls
Tube-Driven Effects Loop
Tube-Driven Preamp Line Out
6-Position Depth Control
3-Position Texture Switch
Pentode/Standby/Triode Switch
Watts Control
9V DC Out Power Supply
12” VHT ChromeBack Speaker, 60-watt, 16 ohm (Combo Only)
Switchable 4, 8, or 16 Ohm Speaker Output
Mod-Friendly Eyelet-Type Board
Hand-wired
*With VHT 6V6-to-EL84 Socket Adapters
34

CONTROL PANEL FEATURES CONTINUED
5. Depth Control: This 6-position rotary switch selects the output tube’s low-frequency roll-off point. Set fully clockwise for the deepest low-
frequency extension. Lower settings (counterclockwise) expose more midrange texture and detail; the lowest settings emphasize more pres-
ence and bite.The three clockwise settings are voiced for single-coil pickups, and the three counterclockwise settings are voiced for humbuck-
ing pickups.
6. Texture Switch: This 3-position rocker switch selects the output’s high-frequency roll-off point. The middle position provides maximum
top-end extension and the most harmonically complex texture; the left position provides subtle high-frequency roll-off for a slightly smoother
texture; the right position rolls-off more high frequencies for the smoothest texture.
7. Send Level: A pedal-friendly low-impedance tube-buffered effects send level control. Normal settings are between half and fully clockwise.
8. Return Level: A pedal-friendly high-impedance tube input effects return. Normal settings are between half and fully clockwise.
9. Tone Control: This control adjusts the balance of the high and low frequencies.
10. Volume Control: Turning this knob clockwise increases the preamp drive and overall sound level.
11. Pull Boost: Pull this knob to partially bypass the internal tone shaping/voicing circuitry, which boosts the preamp gain and increases the
midrange emphasis. This feature can also be accessed by the footswitch.
NOTE: THE BOOST FOOTSWITCH WILL ONLY FUNCTION WHEN THE VOLUME KNOB IS IN THE PULLED POSITION.
12. Input: Pedal-friendly tube input, 1 megohm input impedance.
123456 7
8
REAR PANEL FEATURES
1. Footswitch Jack: Plug the Boost footswitch into this jack.
NOTE: THE BOOST FOOTSWITCH WILL ONLY FUNCTION WHEN THE VOLUME KNOB IS IN THE PULLED POSITION.
2. 9V DC Out: Plug the included 9V DC power supply cable into this jack to power your 9V DC pedal(s) or pedal board. The light will illuminate
at all times when powered on, unless the internal 9V DC fuse has blown. Maximum current draw = 1,000 mA.
3. Effects Loop Send and Return Jacks: The post-preamp Effects Loop can accommodate a wide range of effects. The send level is depen-
dent on the preamp gain. High preamp gain levels may overdrive some sensitive guitar-level effects pedals. Adjust the Effects Loop Send and
Return levels for best pedal sound and lowest noise.
5 6

Input Stage
Input Eects Loop Buer
Return V4
Send Return
Line Out
Watts Texture SpeakerPull Boost
Special 12/20 Block Diagram
Volume Tone
Tone Stack DepthSend Level Return Level Voltage Amplier Cathode Follower Phase Splitter
V5
Output Tubes
BLOCK DIAGRAM
-48
-6
-46
-44
-42
-40
-38
-36
-34
-32
-30
-28
-26
-24
-22
-20
-18
-16
-14
-12
-10
-8
d
20 20k50 100 200 500 1k 2k 5k 10k
Hz
-48
-6
-46
-44
-42
-40
-38
-36
-34
-32
-30
-28
-26
-24
-22
-20
-18
-16
-14
-12
-10
-8
d
B
r
-48
-6
-46
-44
-42
-40
-38
-36
-34
-32
-30
-28
-26
-24
-22
-20
-18
-16
-14
-12
-10
-8
d
B
r
BOOST — ON/OFF
REAR PANEL FEATURES CONTINUED
4. Line Out Jack: The preamp Line Out is in parallel with the Effects Loop Send and Return jacks, it can be used to send a tube-buffered low-
impedance (unbalanced) signal to other equipment such as mixing consoles or other ampliers. Multiple Special 12/20 ampliers can be linked
by connecting the Line Out jack to the Effects Return of the second amplier. Several Special 12/20’s can be linked in this manner, with the
rst amplier’s preamp serving as the master preamp for all additional ampliers.
5. Impedance Selector: This 3-position slide switch selects the appropriate output impedance to match your speaker cabinet’s impedance.
6. Speaker Output Jacks: These two jacks are wired in parallel. The Special 12/20 combo has a 16-ohm speaker that is connected to the
internal speaker jack. The combo’s speaker remains connected when using the external Speaker Output jacks. When using the combo with an
additional speaker cabinet, switch the Impedance selector to 8 ohms.
7. Power IEC Receptacle/Line Voltage Selector: Your amplier will ship with the correct voltage setting, fuse and AC plug type for your
region. When traveling to different countries, remove the plastic protector and select the appropriate voltage. For lowest noise and safest
operation, always use the correct plug type for your region/country, and always provide the amplier with proper AC grounding.
8. 12/20-Watt High/Low Power Voltage Selector: Located behind the rear panel, this switch selects the appropriate maximum voltage for
each output tube type. Set it to the 20-watt High Volt position when using 6L6 or EL34 output tubes. Set it to the 12-watt Low Volt position
when using 6V6 or EL84 output tubes. (EL84 output tubes require 6V6-to-EL84 adapters.)
78

TONE CONTROL — NO BOOST TONE CONTROL — PULL BOOST
-55
+20
-50
-45
-40
-35
-30
-25
-20
-15
-10
-5
+0
+5
+10
+15
d
B
r
20 20k50 100 200 500 1k 2k 5k 10k
Hz
-55
+20
-50
-45
-40
-35
-30
-25
-20
-15
-10
-5
+0
+5
+10
+15
d
B
r
-55
+20
-50
-45
-40
-35
-30
-25
-20
-15
-10
-5
+0
+5
+10
+15
d
B
r
20 20k50 100 200 500 1k 2k 5k 10k
Hz
-55
+20
-50
-45
-40
-35
-30
-25
-20
-15
-10
-5
+0
+5
+10
+15
d
B
r
9 10

DEPTH CONTROL — PREAMP INPUT (NO BOOST) TEXTURE SWITCH — PREAMP INPUT (NO BOOST)
-32.5
+10
-30
-27.5
-25
-22.5
-20
-17.5
-15
-12.5
-10
-7.5
-5
-2.5
+0
+2.5
+5
+7.5
d
B
r
20 20k50 100 200 500 1k 2k 5k 10k
Hz
-32.5
+10
-30
-27.5
-25
-22.5
-20
-17.5
-15
-12.5
-10
-7.5
-5
-2.5
+0
+2.5
+5
+7.5
d
B
r
-10
+22
-8
-6
-4
-2
+0
+2
+4
+6
+8
+10
+12
+14
+16
+18
+20
d
B
r
400 20k500 600 700 800 900 1k 2k 3k 4k 5k 6k 7k 8k 9k 10k
Hz
-10
+22
-8
-6
-4
-2
+0
+2
+4
+6
+8
+10
+12
+14
+16
+18
+20
d
B
r
11 12

DEPTH CONTROL — EFFECTS RETURN INPUT TEXTURE SWITCH — EFFECTS RETURN INPUT
-10
+22
-8
-6
-4
-2
+0
+2
+4
+6
+8
+10
+12
+14
+16
+18
+20
d
B
r
20 20k50 100 200 500 1k 2k 5k 10k
Hz
-10
+22
-8
-6
-4
-2
+0
+2
+4
+6
+8
+10
+12
+14
+16
+18
+20
d
B
r
-2
+8.5
-1.5
-1
-0.5
+0
+0.5
+1
+1.5
+2
+2.5
+3
+3.5
+4
+4.5
+5
+5.5
+6
+6.5
+7
+7.5
+8
d
B
r
400 20k500 600 700 800 900 1k 2k 3k 4k 5k 6k 7k 8k 9k 10k
Hz
-2
+8.5
-1.5
-1
-0.5
+0
+0.5
+1
+1.5
+2
+2.5
+3
+3.5
+4
+4.5
+5
+5.5
+6
+6.5
+7
+7.5
+8
d
B
r
13 14

a
355
75 65
320 27 315 27
225 220 217
277V DC
R66
470K
TestConditions:
1. Wattsand Depth to Max
2. Toneto Center
3. Volumeto Max
4. Sensitivity: 30mV 1kHz Input = 10V Out
5. 6V6GTW Output Tubes
DEPTH
2P-6T ROTARYSWITCH
Push = Closed (Clean)
Pull = Open (Boost)
SLOW BLOW
2011-7-7
230V
120V
100V
EL34/6V6GTW
SLOW BLOW
SLOW BLOW
SLOW BLOW
D S
G
INPUT
VOLUME
TECHNICAL SPECIFICATIONS
Name/Model: VHT Special 12/20 — 12-20 watt hand-wired vacuum tube guitar amplier
Power Requirements & Consumption: 100/115VAC, 50/60Hz; 120VAC, 60Hz; 220VAC/230VAC240/VAC, 50/60Hz
Maximum Output Power: 12-20 watts (depending on output tube type and Volt setting)
Speaker (combo only): One 12” VHT ChromeBack (60-watts, 16 ohms)
Amp Type: All-tube hand-wired push/pull cathode biased output stage
Tubes: Three 12AX7; two 6V6
Controls: Input, Volume (with Pull-Boost), Tone, Effects Send & Return, Texture, Depth,
Watts, Pentode/Standby/Triode, High/Low Tube Voltage
Cabinet: Finger jointed birch plywood
Cosmetics: Black vinyl, white piping, and black grille cloth
Dimensions (H x W x D): Combo: 19’’ x 19.5’’ x 10.5” (475mm x 495mm x 265mm)
Head: 11” x 19.5’’ x 8.5’’ (280mm x 495mm x 215mm)
Net Weight: Head: 28 lbs. (12.5 KG)
Combo: 43 lbs. (19.5 KG)
15 16

LIMITED WARRANTY INFORMATION
This amplifier is warranted, to the original Purchaser, to be free from defects in material and workmanship for a period of five (5)
years, excluding the tubes and speaker, which are warranted for ninety (90) days, from the original date of purchase.
The manufacturer shall, at its option, either repair or replace the defective product if the product is returned to the original place
of purchase. If any product returned is not defective within this warranty, the manufacturer shall so advise the Purchaser and
thereafter shall dispose of said product in accordance with the Purchaser’s instructions and at the Purchaser’s cost. This warranty
is not transferable by the Purchaser.
The warranty shall not apply to wearable parts, these items include, but are not limited to, amplifier knobs, feet, and handles.
The warranty shall not apply, if the product has been misused or damaged as a result of neglect, abuse, alteration, improper
handling, unauthorized repair or modification, accident or causes external to the product, such as, but not limited to, excessive heat
or humidity.
The manufacturer’s sole and exclusive maximum liability for any claim by the Purchaser shall not exceed the wholesale
value of the product. In no event shall the manufacturer be liable for any indirect, incidental, collateral, exemplary, or
consequential damages of losses arising out of the Purchaser’s purchase of the product. The above limitations may not apply in
some states (U.S.), international regions or countries.
VHT
AMPLIFICATION
HANDWIRED IN CHINA
