Operating Guide
EPIA EN-Series Mini-ITX Mainboard

EPIA EN-Series Operating Guide
January 18, 2012 - i - Version 1.21
Table of Contents
Table of Contents ......................................................................................................................................................................................i
VIA EPIA EN-Series Overview..............................................................................................................................................................1
VIA EPIA EN-Series Layout..................................................................................................................................................................2
VIA EPIA EN-Series Specifications......................................................................................................................................................3
VIA EPIA EN Processor SKUs..............................................................................................................................................................4
VIA CN700 Chipset Overview ...............................................................................................................................................................5
VIA EPIA EN-Series I/O Back Panel Layout......................................................................................................................................6
VIA EPIA EN-Series Layout Diagram & Mounting Holes...............................................................................................................7
VIA EPIA EN-Series Layout Diagram & Height Distribution.........................................................................................................8
Power Consumption.................................................................................................................................................................................9
VIA EPIA EN12000E............................................................................................................................................................................9
VIA EPIA EN15000 ............................................................................................................................................................................10
Power Specifications ..............................................................................................................................................................................12
VIA EPIA EN-Series Microsoft and Linux Driver Support ...........................................................................................................13
M ICROSOFT D RIVER S UPPORT ..............................................................................................................................................................13
L INUX D RIVER S UPPORT .......................................................................................................................................................................13
Contact.....................................................................................................................................................................................................14

EPIA EN-Series Operating Guide
January 18, 2012 - 1 - Version 1.21
VIA EPIA EN-Series Overview
The VIA EPIA EN-Series Mini-ITX Mainboard is an ultra compact native x86 platform optimized for
today's demanding embedded and productivity applications. The mainboard is based on the VIA CN700
chipset featuring an embedded hardware MPEG-2 accelerator and integrated VIA UniChrome™ Pro
2D/3D graphics for rich digital media performance. With the sizable memory bandwidth of DDR2 533MHz
SDRAM DIMM and the high data transfer speeds of ATA-133 and further enhanced by support of 8-
Channel AC’97 codec for Smart 5.1 surround sound and SPDIF, the VIA EPIA EN-Series delivers the
increased performance levels required by today’s embedded digital media applications.
The latest in high-bandwidth connectivity is supported with four USB 2.0 ports, as well as a COM port and
has one 10/100/1000 Fast Ethernet port for extended broadband connectivity. The VIA EPIA EN-Series
also has one PCI slot for expandability options. The VIA EPIA EN-Series is compatible with a full range
of Mini-ITX chassis as well as FlexATX and MicroATX enclosures and power supplies.
The VIA EPIA EN-Series is fully compatible with Microsoft® and Linux operating systems and is available
in a variety of configurations, including the fanless VIA Eden™ V4 Bus NanoBGA2 processor for silent
system designs and the latest VIA C7™ V4 Bus NanoBGA2 processor for small, low power and secure
x86 processor platforms.

EPIA EN-Series Operating Guide
January 18, 2012 - 2 - Version 1.21
VIA EPIA EN-Series Layout

EPIA EN-Series Operating Guide
January 18, 2012 - 3 - Version 1.21
VIA EPIA EN-Series Specifications
Model Name EPIA EN15000 EPIA EN12000E
Processor VIA C7 1.5GHz NanoBGA2 VIA Eden 1.2GHz NanoBGA2
Chipset - VIA CN700 North Bridge
- VIA VT82 7R-Series South Bridge
System Memory - 1 DDR2 400/5 DIMM slot
- Up to 1GB memory size
VGA - Integrated VIA UniChrome™ Pro AGP graphics with MPEG-2 acceleration
Expansion Slots - 1 PCI
Onboard IDE - 2 UltraDMA 1 /100/66 Connectors
Onboard LAN - VIA VT6122 Gigabit Ethernet Controller
Onboard A dio - VIA VT1618 8-channel AC’97 Codec
Onboard TV O t - VIA VT1625 HDTV Encoder
Onboard 1394 - VIA VT6 07S IEEE 1 94 Firewire
Onboard I/O
Connectors
- 1 USB pin header for 2 additional USB 2.0 ports
- 1 1 94 pin header for a 1 94 port
- 1 SIR pin header (IRDA 1.0)
- 2 S-ATA Connectors
- 1 LPC pin header
- 1 Front-panel audio pin header (Mic-in and Line-out)
- 1 Serial port pin header for a second com port
- 1 CIR pin header (Switchable for KB/MS)
- 2 Fan connectors: CPU/Sys FAN
- 2 S/PDIF connectors: (S/PDIF-in and S/PDIF-out)
- 1 Component (YPbPr) video pin header
- 1 SM Bus pin header
- 1 LVDS/TTL/DVI module connector (an add-on card is required)
- 1 Front-Panel pin header
- 1 ATX Power Connector
Back Panel I/O - 1 PS2 Mouse port
- 1 PS2 Keyboard port
- 1 RJ-45 LAN port
- 1 Serial port
- 4 USB 2.0 ports
- 1 VGA port
- 1 RCA port (S/PDIF or TV out)
- 1 S-Video port
- Audio jacks: line-out, line-in and mic-in (Horizontal, Smart 5.1
Support)
BIOS Award BIOS, LPC 4/8Mbit flash memory
Operating System Windows 2000 / XP, Linux, Win CE, XPe
Software Application - VIA FliteDeck™ Suite
MissionControl-H/W Monitoring, Remote SNMP Management
FlashPort-Live BIOS Flash
SysProbe-Live DMI Browser
System Monitoring &
Management
- CPU temperature reading, CPU voltage monitoring
- Wake-on-LAN, Keyboard-Power-on, Timer-Power-on, Watch Dog Timer,
FAN control
- System power management, AC power failure recovery
Operating Temperat re
0 ~ 50°C
Operating H midity 0% ~ 95% (relative humidity; non-condensing)
Form Factor - Mini-ITX (6-layer)
- 17 cm x 17 cm
* The specification is subject to change without prior notice.

EPIA EN-Series Operating Guide
January 18, 2012 - 4 - Version 1.21
VIA EPIA EN Processor SKUs
The VIA EPIA EN-Series is available in 1.2GHz and 1.5GHz speed grades. The VIA EPIA EN12000E
and the VIA EPIA EN15000 utilize the most efficient VIA C7™ / Eden V4 Bus NanoBGA2 processor.
EPIA EN12000E / EPIA EN15000
VIA Eden / C7™ V4 B s NanoBGA2
processor
1.2 GHz / 1.5 GHz
1.004v Operating Volts (1.2GHz)
128KB L1 Cache
128KB L2 Cache
MMX and SSE, SSE2 and SSE3
Padlock and ACE Encryption
Suitable for small, low power, ultra
efficient and secure x86 platform.
The VIA FliteDeck™ Suite, an
advanced system management
suite that enables to user to
effortlessly track and monitors
mission critical system data and
enable seamless live Windows®-
based BIOS updates as well as
comprehensive BIOS status
information.
PadLock ACE US government
approved Advanced Encryption
Standard (AES), performing
cryptographic functions for
securing e-mails, personal files,
online transactions, and networks.

EPIA EN-Series Operating Guide
January 18, 2012 - 5 - Version 1.21
VIA CN700 Chipset Overview
The VIA CN700 Chipset is designed to enable high quality digital video streaming and DVD playback in a
new generation of fanless, small form factor PCs and IA devices. The CN700 features the embedded VIA
UniChrome™ Pro 2D/3D MPEG-2 acceleration, DDR2 533MHz support, motion compensation and duo-
view support to ensure a rich overall entertainment experience. Outstanding connectivity features include
USB 2.0, 10/100 LAN and ATA/133.

EPIA EN-Series Operating Guide
January 18, 2012 - 6 - Version 1.21
VIA EPIA EN-Series I/O Back Panel Layout
The EPIA EN’s ultra compact 17cm x 17cm, integrated design supports all the standard legacy x86
connectivity options as well as PS2 Mouse port, PS2 Keyboard port, VGA port, COM port, RJ45 LAN port,
USB 2.0 ports, RCA port, S-Video port and AC’97 audio jacks.
44.45
158.75
10.31
25.55
10.08
29.06
10.15
10.33
24.33
35.14
2.54
2.54
3.81 2.44

EPIA EN-Series Operating Guide
January 18, 2012 - 7 - Version 1.21
VIA EPIA EN-Series Layout Diagram & Mounting Holes

EPIA EN-Series Operating Guide
January 18, 2012 - 8 - Version 1.21
VIA EPIA EN-Series Layout Diagram & Height Distribution

EPIA EN-Series Operating Guide
January 18, 2012 - 9 - Version 1.21
Power Consumption
Power consumption tests were carried out comparing the VIA EPIA EN12000E (running with the 1.2GHz
VIA Eden V4 Bus NanoBGA2 processor) and the VIA EPIA EN15000 (running with the 1.5GHz VIA C7™
V4 Bus NanoBGA2 processor). The following tables are a comprehensive breakdown of the EPIA
platform’s voltage, amp and wattage values while running common system applications.
VIA EPIA EN12000E
A. Playing DVD – Power DVD 4.0
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.385 1.058 3.581
Main Board +5V 5.072 1.544 7.831
Main Board 5VSB 5.066 0.182 0.922
Main Board +12V 12.214 0.164 2.003
14.338
Main Board Power Consumption
B. Playing MP3 – Media Player
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.380 1.060 3.583
Main Board +5V 5.070 1.538 7.798
Main Board 5VSB 5.062 0.183 0.926
Main Board +12V 12.200 0.165 2.013
14.320
Main Board Power Consumption
C. Running NetworkApplication – Files Copy
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.383 1.031 3.488
Main Board +5V 5.079 1.237 6.283
Main Board 5VSB 5.065 0.167 0.846
Main Board +12V 12.190 0.165 2.011
12.628
Main Board Power Consumption
D. Idle
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.384 1.036 3.506
Main Board +5V 5.081 1.177 5.980
Main Board 5VSB 5.065 0.174 0.881
Main Board +12V 12.186 0.166 2.023
12.390
Main Board Power Consumption

EPIA EN-Series Operating Guide
January 18, 2012 - 10 - Version 1.21
E. Run C.C. Winstone 2001
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.381 1.027 3.472
Main Board +5V 5.071 1.515 7.683
Main Board 5VSB 5.062 0.173 0.876
Main Board +12V 12.198 0.165 2.013
14.043
Main Board Power Consumption
F. S3 Mode
Measured Voltage Measured Amp. Watts
Main Board +3.3V 0.000 0.000 0.000
Main Board +5V 0.000 0.000 0.000
Main Board 5VSB 5.085 0.297 1.510
Main Board +12V 0.000 0.000 0.000
1.510
Main Board Power Consumption
VIA EPIA EN15000
A. Playing DVD – Power DVD 4.0
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.377 1.061 3.583
Main Board +5V 5.059 1.930 9.764
Main Board 5VSB 5.057 0.198 1.001
Main Board +12V 12.217 0.201 2.456
16.804
Main Board Power Consumption
B. Playing MP3 – Media Player
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.377 1.062 3.586
Main Board +5V 5.053 2.220 11.218
Main Board 5VSB 5.058 0.207 1.047
Main Board +12V 12.239 0.202 2.472
18.323
Main Board Power Consumption
C. Running NetworkApplication – Files Copy
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.382 1.022 3.456
Main Board +5V 5.067 1.518 7.692
Main Board 5VSB 5.063 0.183 0.927
Main Board +12V 12.222 0.202 2.469
14.543
Main Board Power Consumption

EPIA EN-Series Operating Guide
January 18, 2012 - 11 - Version 1.21
D. Idle
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.385 1.037 3.510
Main Board +5V 5.074 1.278 6.485
Main Board 5VSB 5.066 0.188 0.952
Main Board +12V 12.216 0.204 2.492
13.439
Main Board Power Consumption
E. Run C.C. Winstone 2001
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.380 1.022 3.454
Main Board +5V 5.062 1.717 8.691
Main Board 5VSB 5.061 0.196 0.992
Main Board +12V 12.225 0.201 2.457
15.595
Main Board Power Consumption
F. S3 Mode
Measured Voltage Measured Amp. Watts
Main Board +3.3V 0.000 0.000 0.000
Main Board +5V 0.000 0.000 0.000
Main Board 5VSB 5.083 0.323 1.642
Main Board +12V 0.000 0.000 0.000
1.642
Main Board Power Consumption

EPIA EN-Series Operating Guide
January 18, 2012 - 12 - Version 1.21
Power Specifications
The EPIA EN utilizes an industry standard 20-pin ATX main connector to the power supply. Due to the
EPIA EN platform’s ultra low power requirements a 90 – 120 Watt ATX power supply is ample for even
the heaviest of multimedia system applications.
1 +3V 11 +3V
2 +3V 12 -12V
3 Gnd 13 Gnd
4 +5V 14 PWR_ON-
5 Gnd 15 Gnd
6 +5V 16 Gnd
7 Gnd 17 Gnd
8 PWR_GD 18 NC
9 5V_SB 19 +5V
10 +12V 20 +5V
Note: NC = no connection
1
2
3
4
5
6
7
8
9
11
12
13
14
17
18
19
2010

EPIA EN-Series Operating Guide
January 18, 2012 - 13 - Version 1.21
VIA EPIA EN-Series Microsoft and Linux Driver Support
Microsoft Driver Support
VIA EPIA EN series offers full support for the complete range of Microsoft operating systems.
For standard operating systems, Windows 98/Me/2000/XP latest drivers downloads can be found in the
VEPD website at www.viaembedded.com.
For embedded operating systems, Windows CE.NET and XP Embedded related driver supports can be
found in the VIA Arena website at www.viaarena.com.
Linux Driver Support
VIA EPIA EN mainboards have a very high degree of support under Linux.
Support and drivers are provided through various methods including:
• Drivers provided by VIA
– Using a driver built into a distribution package
– Visiting VIA Arena website at www.viaarena.com for latest updates on a monthly basis
• Installing a third party driver (such as the ALSA driver from the Advanced Linux Sound
Architecture project for integrated audio)
For OEM clients and system integrators developing a product for long term production, other code and
resources may also be made available. You can submit a request either through the Developers portal
on VIA Arena, or through your VEPD support contact. Alternatively, VIA can work further towards
providing additional drivers to suite your specific needs.

EPIA EN-Series Operating Guide
January 18, 2012 - 14 - Version 1.21
Contact
For more information on the VIA EPIA EN-Series Mini ITX Mainboard contact your sales representative or
visit our website at www.viaembedded.com
Taiwan Headquarters
1F, 531 Zhong-Zheng Road
Xindian District, New Taipei City
231,
Taiwan
TE : 886.2.2218.5452
FAX: [phone]
Email: embedd[email protected]
USA
940 Mission Court
Fremont, CA 94539
USA
TE : 1.510.683.3300
FAX: [phone]
Email: [e-mail]
Europe
In den Dauen 6
53117 Bonn
Germany
TE : 49.228.688565.0
FAX: [phone]
Email: embedd[email protected]
China
Tsinghua Science Park Bldg. 7
No. 1 Zongguancun East Road
Haiden District, Beijing 100084
TE : 86.10.59852288
FAX: [phone]
Email: embedd[email protected]
Japan
3-15-7 Ebisu MT Bldg. 6F
Higashi, Shibuya-ku
Tokyo 150-0011
TE : 81.3.5466.1637
FAX: [phone]
Email: [e-mail]
Korea
2F, Sangjin Bldg., 417
Dogok-Dong, Gangnam-Gu
Seoul 135-854
TE : 82.2.571.2986
FAX: [phone]
Email: embedd[email protected]
