August 17, 2004 Version 1.00
Operating Guide
EPIA SP-Series Mini-ITX Mainboard

EPIA SP-Series Operating Guide
August 17, 2004 - i - Version 1.00
Table of Contents
TABLE OF CONTENTS ..................................................................................................................................................................I
VIA EPIA SP-SERIES OVERVIEW.............................................................................................................................................. 1
VIA EPIA SP-SERIES LAYOUT ................................................................................................................................................... 2
VIA EPIA SP-SERIES SPECIFICATIONS .................................................................................................................................. 3
VIA EPIA SP PROCESSOR SKUS ................................................................................................................................................ 4
VIA CN400 CHIPSET OVERVIEW .............................................................................................................................................. 5
VIA EPIA SP-SERIES I/O BACK PANEL LAYOUT ................................................................................................................. 6
VIA EPIA SP-SERIES LAYOUT DIAGRAM & MOUNTING HOLES ................................................................................... 7
VIA EPIA SP-SERIES LAYOUT DIAGRAM & HEIGHT DISTRIBUTION .......................................................................... 8
NOISE LEVEL DATA ..................................................................................................................................................................... 9
POWER CONSUMPTION............................................................................................................................................................ 10
VIA EPIA SP 13000..................................................................................................................................................................... 10
VIA EPIA SP 8000E .................................................................................................................................................................... 11
POWER SPECIFICATIONS ........................................................................................................................................................ 12
VIA EPIA SP-SERIES MICROSOFT AND LINUX DRIVER SUPPORT.............................................................................. 13
MICROSOFT DRIVER SUPPORT........................................................................................................................................................ 13
LINUX DRIVER SUPPORT ................................................................................................................................................................ 13
CONTACT....................................................................................................................................................................................... 14

EPIA SP-Series Operating Guide
August 17, 2004 - 1 - Version 1.00
VIA EPIA SP-Series Overview
The VIA EPIA SP-Series Mini-ITX Mainboard is an ultra compact x86 motherboard design with
unprecedented expandability and versatility for today’s ever-growing need of embedded applications. The
mainboard is based on the VIA CN400 chipset featuring an embedded hardware MPEG-2 decoder /
MPEG-4 accelerator and integrated VIA UniChrome™ Pro 2D/3D graphics for rich digital media
performance. With the sizable memory bandwidth of a 184-pin DDR400 SDRAM DIMM slot, the high data
transfer speeds of ATA-133 and Serial ATA and further enhanced by support of 6-Channel AC’97 codec
for Smart 5.1 surround sound, the VIA EPIA SP-Series delivers the increased performance levels
required of today’s embedded digital media applications.
The latest in high-bandwidth connectivity is supported with up to eight USB 2.0 ports, as well as COM
ports and one 10/100 Fast Ethernet port for extended broadband connectivity. The VIA EPIA SP-Series
also offers support for a number of LVDS embedded LCD panels, TV-out, Video interface port and has a
PCI slot for expandability options. The VIA EPIA SP-Series is compatible with a full range of Mini-ITX
chassis as well as FlexATX and MicroATX enclosures and power supplies.
The VIA EPIA SP-Series is fully compatible with Microsoft® and Linux operating systems and is available
in a variety of configurations, including the fanless VIA Eden™ ESP processor for silent system designs
and the highly efficient VIA C3™ processor for more demanding multimedia applications.

EPIA SP-Series Operating Guide
August 17, 2004 - 2 - Version 1.00
VIA EPIA SP-Series Layout

EPIA SP-Series Operating Guide
August 17, 2004 - 3 - Version 1.00
VIA EPIA SP-Series Specifications
Processor - VIA C3/EDEN EBGA Processor
Chipset - VIA CN400 North Bridge
- VT8237 South Bridge
System Memory - 1 DDR400/333/266 DDR SDRAM slot
- Up to 1GB memory size
VGA - Integrated VIA UniChrome™ Pro AGP Graphics
Expansion Slot - 1 PCI
Onboard IDE - 2 UltraDMA 133/100 connectors
Onboard LAN - VIA VT6103 10/100 Base-T Ethernet PHY
Onboard Audio - VIA VT1617A 6 channel AC’97 Codec
Onboard TV Out - VIA VT1623 TV Encoder
Onboard 1394 - VIA VT6307S IEEE 1394 Firewire
Onboard I/O
Connectors
- 3 USB connectors for 6 USB 2.0 ports
- 2 Serial ATA ports
- 1 1394 connector for 1 1394 port
- 1 serial port connector for a second com port
- 1 VIP connector
- 1 Front-Panel Audio connector (Mic-in and Line-Out)
- 1 CD Audio-in connector
- 1 FIR connector
- 1 CIR connector (Switchable for KB/MS)
- 1 LPT port connector
- 1 Wake-on-LAN connector
- 2 FAN connectors: CPU and SYS FAN
- 1 LVDS/TTL module connector (Manufacturing option)
- 1 +12V power connector
- ATX Power connector
Back Panel I/O - 1 PS2 Mouse port
- 1 PS2 Keyboard port
- 1 RJ-45 LAN port
- 1 Serial port
- 2 USB 2.0 ports
- 1 VGA port
- 1 RCA port (SPDIF or TV out)
- 1 S-Video port
- 3 Audio jacks: line-out, line-in and mic-in (Horizontal, Smart 5.1
support)
BIOS - Award BIOS
- 4/8Mbit flash memory
System
Monitoring &
Management
- CPU voltage monitoring
- Wake-on-LAN, Keyboard-Power-on, Timer-Power-on
- System power management
- AC power failure recovery
Form Factor - Mini-ITX (6 Layer)
- 17 cm x 17 cm

EPIA SP-Series Operating Guide
August 17, 2004 - 4 - Version 1.00
VIA EPIA SP Processor SKUs
The VIA EPIA SP-Series is available in two different speed grades. The VIA EPIA SP8000E utilizes VIA’s
ultra low power VIA Eden™ ESP processor while the VIA EPIA SP13000 utilizes the robust VIA C3™
processor.
Suitable for compact systems
running multimedia
applications
Suitable for fanless systems with
low heat and ultra low-power
requirements
EPIA SP8000E
VIA Eden™ ESP 8000 processor
800 MHz
Fanless Operation
1.05v Operating Volts
128KB L1 Cache
64KB L2 Cache
MMX and SSE
Padlock and ACE Encryption
EPIA SP13000
VIA C3™ processor
1.3 GHz
1.4v Operating Volts
128KB L1 Cache
64KB L2 Cache
MMX and SSE
Padlock and ACE Encryption
PadLock ACE US government
approved Advanced Encryption
Standard (AES), performing
cryptographic functions for securing
e-mails, personal files, online
transactions, and networks.

EPIA SP-Series Operating Guide
August 17, 2004 - 5 - Version 1.00
VIA CN400 Chipset Overview
The VIA CN400 Chipset is designed to enable high quality digital video streaming and DVD playback in a
new generation of fanless, small form factor PCs and IA devices. The CN400 features the embedded VIA
UniChrome™ Pro 2D/3D MPEG-2 decoder/MPEG-4 accelerator, DDR400 support, motion compensation
and duo-view support to ensure a rich overall entertainment experience. Outstanding connectivity
features include USB 2.0, Serial ATA, 10/100 LAN and ATA133/100.

EPIA SP-Series Operating Guide
August 17, 2004 - 6 - Version 1.00
VIA EPIA SP-Series I/O Back Panel Layout
The EPIA SP’s ultra compact 17cm x 17cm, integrated design supports all the standard legacy x86
connectivity options as well as USB 2.0, VGA port, RJ45 LAN port, serial port and VIA 6 channel AC’97
audio.
PS/2 Mouse
PS/2 Keyboard VGA Out S-Video
RJ45
USB
COM1
Line-InLine-Out Microphone
RCA / SPDIF
10.31 [0.406]
158.75 [6.25]
137.61 [5.418]
125.11 [4.926]
112.61 [4.433]
98.66 [3.884]
83.19 [3.275]
64.18 [2.527]
38.85 [1.530]
14.44 [0.569]
2.44 [0.096]
0.00 [0.00]
44.45 [1.75]
29.06 [1.144]
25.56 [1.006]
10.08 [0.397]
10.31 [0.406]
3.81 [0.15]
0.00 [0.00]

EPIA SP-Series Operating Guide
August 17, 2004 - 7 - Version 1.00
VIA EPIA SP-Series Layout Diagram & Mounting Holes

EPIA SP-Series Operating Guide
August 17, 2004 - 8 - Version 1.00
VIA EPIA SP-Series Layout Diagram & Height Distribution

EPIA SP-Series Operating Guide
August 17, 2004 - 9 - Version 1.00
Noise Level Data
VIA and the EPIA series have been at the forefront of the quiet computing initiative. The VIA EPIA SP-
Series has been designed to be totally non-obtrusive with noise levels equivalent to a person whispering.
With noise levels ranging from the totally silent VIA EPIA SP8000E to 25dBA for the VIA EPIA SP13000,
a new wave of system design innovation and exciting opportunities are being created in an almost
limitless number of emerging new market segments - ranging from fanless thin clients, flat panel small
form factor desktop replacement systems, LCD PCs and a host of other space and power saving
systems.
Common Sounds dBA Level
Threshold of hearing 0 dBA
VIA EPIA SP8000E 0 dBA
Normal breathing 10 dBA
Whispering at 1 meter 20 dBA
VIA EPIA SP13000 25 dBA
Conventional PC 35 – 50 dBA
Rainfall 50 dBA
Normal speech 60 dBA
The dBA scale is logarithmic, i.e. 10 dBA represents a doubling in volume. dBA values are measured at a
distance of one meter.

EPIA SP-Series Operating Guide
August 17, 2004 - 10 - Version 1.00
Power Consumption
Power consumption tests were carried out comparing the VIA EPIA SP13000 (running the 1.3GHz VIA
C3™ processor) and the VIA EPIA SP8000E (running the 800MHz VIA Eden™ ESP processor). The
following tables are a comprehensive breakdown of the EPIA platform’s voltage, amp and wattage values
while running common system applications.
VIA EPIA SP 13000
A. Playing DVD – Power DVD 4.0
Voltage Measured Amp. Watts
Main Board +3.3V 3.256 3.152 10.263
Main Board +5V 5.074 3.515 17.835
Main Board 5VSB 5.076 0.092 0.467
Main Board +12V 11.995 0.220 2.639
31.204
Main Board Power Consumption
B. 3DMark 2001
Voltage Measured Amp. Watts
Main Board +3.3V 3.205 4.455 14.278
Main Board +5V 5.052 3.636 18.369
Main Board 5VSB 5.083 0.012 0.061
Main Board +12V 12.100 0.065 0.787
33.495
Main Board Power Consumption
C. Idle
Voltage Measured Amp. Watts
Main Board +3.3V 3.295 3.176 10.465
Main Board +5V 5.101 1.147 5.851
Main Board 5VSB 5.081 0.030 0.152
Main Board +12V 12.045 0.176 2.120
18.588
Main Board Power Consumption
D. Run C.C. Winstone 2001
Voltage Measured Amp. Watts
Main Board +3.3V 3.265 2.970 9.697
Main Board +5V 5.056 3.091 15.628
Main Board 5VSB 5.077 0.069 0.350
Main Board +12V 12.049 0.157 1.892
27.567
Main Board Power Consumption

EPIA SP-Series Operating Guide
August 17, 2004 - 11 - Version 1.00
VIA EPIA SP 8000E
A. Playing DVD – Power DVD 4.0
Voltage Measured Amp. Watts
Main Board +3.3V 3.295 2.970 9.785
Main Board +5V 5.034 1.091 5.492
Main Board 5VSB 5.092 0.061 0.312
Main Board +12V 12.128 0.123 1.487
17.076
Main Board Power Consumption
B. 3DMark 2001
Voltage Measured Amp. Watts
Main Board +3.3V 3.352 3.212 10.767
Main Board +5V 5.026 1.212 6.092
Main Board 5VSB 5.092 0.061 0.312
Main Board +12V 12.128 0.123 1.487
18.659
Main Board Power Consumption
C. Idle
Voltage Measured Amp. Watts
Main Board +3.3V 3.302 2.576 8.505
Main Board +5V 5.068 0.424 2.150
Main Board 5VSB 5.092 0.066 0.336
Main Board +12V 12.127 0.127 1.544
12.535
Main Board Power Consumption
D. Run C.C. Winstone 2001
Voltage Measured Amp. Watts
Main Board +3.3V 3.321 2.545 8.453
Main Board +5V 5.028 1.152 5.790
Main Board 5VSB 5.092 0.061 0.311
Main Board +12V 12.128 0.123 1.487
16.041
Main Board Power Consumption

EPIA SP-Series Operating Guide
August 17, 2004 - 12 - Version 1.00
Power Specifications
The EPIA SP utilizes an industry standard 20-pin ATX main connector to the power supply. Due to the
EPIA SP platform’s ultra low power requirements, a 90 – 120 Watt ATX power supply is ample for even
the heaviest of multimedia system applications.
1 +3V 11 +3V
2 +3V 12 -12V
3 Gnd 13 Gnd
4 +5V 14 PWR_ON
5 Gnd 15 Gnd
6 +5V 16 Gnd
7 Gnd 17 Gnd
8 PWR_GD 18 NC
9 5V_SB 19 +5V
10 +12V 20 +5V
Note: NC = no connection
1
2
3
4
5
6
7
8
9
11
12
13
14
17
18
19
2010

EPIA SP-Series Operating Guide
August 17, 2004 - 13 - Version 1.00
VIA EPIA SP-Series Microsoft and Linux Driver Support
Microsoft Driver Support
VIA EPIA SP-Series offer full support for the complete range of Microsoft operating systems.
For standard operating systems, Windows 98/Me/2000/XP latest drivers downloads can be found in the
VEPD website at www.viaembedded.com.
For embedded operating systems, Windows CE.NET and XP Embedded related driver supports can be
found in the VIA Arena website at www.viaarena.com.
Linux Driver Support
VIA EPIA SP mainboards have a very high degree of support under Linux.
Support and drivers are provided through various methods including:
• Drivers provided by VIA
– Using a driver built into a distribution package
– Visiting VIA Arena website at www.viaarena.com for latest updates on a monthly basis
• Installing a third party driver (such as the ALSA driver from the Advanced Linux Sound
Architecture project for integrated audio)
For OEM clients and system integrators developing a product for long-term production, other code and
resources may also be made available. You can submit a request either through the Developers portal on
VIA Arena, or through your VEPD support contact. Alternatively, VIA can work further towards providing
additional drivers to suite your specific needs.

EPIA SP-Series Operating Guide
August 17, 2004 - 14 - Version 1.00
Contact
For more information on the VIA EPIA SP-Series Mini-ITX Mainboard contact your sales representative or
visit our website at www.viaembedded.com
USA
440 Mission Court, Suite 220
Fremont, CA 94539
Tel: [phone]
Fax: [phone]
Email: [email protected]
Germany
Mottmann Strasse 12
53842 Troisdorf-Oberlar
Tel: [phone]
Fax: [phone]
Email: [email protected]
Taiwan
8F, 533, Chung Cheng Road
Hsin Tien, Taipei
Tel: [phone]
Fax: [phone]
Email: [email protected]
China
6F, DAscom Tower
9 Shangdi East Road
Haidian District
Beijing, 100085
Tel: [phone]
Fax: [phone]
Email: [email protected]
