VIA Technologies EPIA-PX5000EG - VIA Motherboard - Pico ITX User manual

June 18, 2009 Version 1.11
Operating Guide
EPIA-PX Pico-ITX Mainboard

EPIA-PX Operating Guide
June 18, 2009 - i - Version 1.11
Table of Contents
Table of Contents.............................................................................................................................................................................i
VIA EPIA-PX Overview.................................................................................................................................................................1
VIA EPIA-PX Layout.....................................................................................................................................................................2
VIA EPIA-PX Specifications .........................................................................................................................................................3
VIA EPIA-PX Processor SKU.......................................................................................................................................................4
VIA VX700 All-in-One System Processor Overview ...................................................................................................................5
VIA EPIA-PX Board Dimensions and Height Distribution ........................................................................................................ 6
Power Consumption .......................................................................................................................................................................8
VIA EPIA-PX WITH 1.0 GH Z C7 PROCESSOR ................................................................................................................................8
VIA EPIA-PX WITH 500 MH Z E DEN ULV PROCESSOR .................................................................................................................9
Power Specifications.....................................................................................................................................................................10
VIA EPIA-PX Microsoft and Linux Driver Support.................................................................................................................11
M ICROSOFT D RIVER S UPPORT ......................................................................................................................................................11
L INUX D RIVER S UPPORT ..............................................................................................................................................................11
Contact...........................................................................................................................................................................................12

EPIA-PX Operating Guide
June 18, 2009 - 1 - Version 1.11
VIA EPIA-PX Overview
The VIA EPIA-PX Pico-ITX Mainboard is an ultra compact native x86 platform optimi ed for
today's demanding embedded and productivity applications. The mainboard is based on the
VIA VX700 advanced all-in-one system processor featuring an embedded hardware MPEG-2,
MPEG-4 and WMV9 video decoding accelerator. Its integrated VIA UniChrome™ Pro II
2D/3D graphics provide rich digital media performance. With the si able memory
bandwidth of DDR2 533MH SDRAM DIMM and the high data transfer speeds of ATA-133
and further enhanced by support of 8-Channel High Definition Audio Codec for Smart 7.1
surround sound and SPDIF, the VIA EPIA-PX delivers the increased performance levels
required by today’s embedded digital media applications.

EPIA-PX Operating Guide
June 18, 2009 - 2 - Version 1.11
VIA EPIA-PX Layout

EPIA-PX Operating Guide
June 18, 2009 - 3 - Version 1.11
VIA EPIA-PX Specifications
Model Name - EPIA-PX
Processor options - VIA C7 1.0GH NanoBGA2 processor
- VIA Eden ULV 500 MH NanoBGA2 processor
Chipset - VIA VX700 advanced all-in-one system processor
System Memory - 1 DDRII 533 SODIMM socket
- Up to 1GB memory si e
VGA - Integrated VIA UniChrome
TM
Pro II 3D/2D AGP graphics with
MPEG-2/4 and WMV9 video decoding Accelerator
Onboard IDE - 1 UltraDMA 133/100 connector (2.0mm 44-pin pin header)
Onboard Serial ATA - 1 SATA connector
Onboard LAN - 1 VIA VT6106S 10/100 Mbps Fast Ethernet Controller with
Power Management Functions
Onboard A dio - VIA VT1708A High Definition Audio Codec
Onboard I/O
Connectors
- 1 USB pin connector for 4 additional USB 2.0 ports
- 1 COM pin connector
- 1 PS2 mouse/keyboard pin connector
- 1 Fan pin connector for CPU Fan
- 1 LVDS/DVI panel pin connector
- 1 Audio pin connector for Line-out, Line-in, MIC-in, S/PDIF in,
and 7.1 Channels Audio Output
- 1 Multimedia connector to support External TV-Out Interface,
Video Capture Port Interface and Low Pin Count Interface.
(One VT1625M add-on card is required.)
- 1 Pico-ITX power connector
Back Panel I/O - 1 RJ45 LAN Port
- 1 VGA Port
BIOS - Award BIOS
- 4/8Mbit flash memory
System Monitoring &
Management
- Keyboard-Power-on, Timer-Power-on
- System power management, AC power failure recovery
- ADI ADM1032 CPU Temperature Monitoring (manufacturing
option)
- Watch Dog Timer (manufacturing option)
Operating Temperat re 0°C ~ 50°C
Operating H midity 0% ~ 95% (relative humidity; non-condensing)
Form Factor - Pico-ITX (10-layer)
- 10cm x 7.2cm
* The specification is subject to change without prior notice.

EPIA-PX Operating Guide
June 18, 2009 - 4 - Version 1.11
VIA EPIA-PX Processor SKU
The VIA EPIA-PX is available with the following CPU options:
•1.0 GH VIA C7
®
NanoBGA2 processor
•500 MH VIA Eden™ ULV NanoBGA2 processor

EPIA-PX Operating Guide
June 18, 2009 - 5 - Version 1.11
VIA VX700 All-in-One System Processor Overview
The VIA VX700 All-in-One System Processor is designed to enable high quality digital video
streaming and DVD playback in a new generation of fanless, small form factor PCs and IA
devices. The VX700 features the embedded VIA UniChrome™ Pro II 2D/3D MPEG-2, MPEG-
4 and WMV9 video decoding acceleration, DDR2 533MH support, motion compensation and
dual-display support to ensure a rich overall entertainment experience. Outstanding
connectivity features include USB 2.0, 10/100 LAN and ATA/133.

EPIA-PX Operating Guide
June 18, 2009 - 6 - Version 1.11
VIA EPIA-PX Board Dimensions and Height Distribution

EPIA-PX Operating Guide
June 18, 2009 - 7 - Version 1.11

EPIA-PX Operating Guide
June 18, 2009 - 8 - Version 1.11
Power Consumption
Power consumption tests were carried out on the VIA EPIA-PX. The following tables are a
comprehensive breakdown of the EPIA platform’s voltage, amp and wattage values while
running common system applications.
VIA EPIA-PX with 1.0 GHz C7 processor
A. Idle
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.24 0.27 0.88
Main Board +5V 4.94 1.11 5.48
Main Board 5VSB 4.96 0.06 0.30
Main Board +12V 11.87 0.04 0.47
Main Board Power Consumption 7.13
B. Run 3DMark2001 SE
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.24 0.24 0.78
Main Board +5V 4.93 1.72 8.48
Main Board 5VSB 4.96 0.08 0.40
Main Board +12V 11.87 0.03 0.36
Main Board Power Consumption 10.01
C. Run PassMark
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.24 0.44 1.43
Main Board +5V 4.94 1.59 7.85
Main Board 5VSB 4.97 0.06 0.30
Main Board +12V 11.88 0.03 0.36
Main Board Power Consumption 9.93
D. Run SAMSUNG Windows Diagnostic V2.07b
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.25 0.20 0.65
Main Board +5V 4.94 1.89 9.34
Main Board 5VSB 4.97 0.03 0.15
Main Board +12V 11.87 0.06 0.71
Main Board Power Consumption 10.85

EPIA-PX Operating Guide
June 18, 2009 - 9 - Version 1.11
E. Run M.C.C. Winstone 2004
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.25 0.24 0.78
Main Board +5V 4.94 1.41 6.97
Main Board 5VSB 4.96 0.01 0.05
Main Board +12V 11.88 0.03 0.36
Main Board Power Consumption 8.15
VIA EPIA-PX with 500 MHz Eden ULV processor
A. Idle
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.27 0.576 1.89
Main Board +5V 4.81 1.788 8.60
Main Board 5VSB 4.89 0.08 0.39
Main Board +12V 12.01 0.001 0.01
Main Board Power Consumption 10.89
B. Run 3DMark2001 SE
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.27 0.435 1.42
Main Board +5V 4.81 1.404 6.75
Main Board 5VSB 4.89 0.110 0.54
Main Board +12V 12.01 0.001 0.01
Main Board Power Consumption 8.73
C. Run PassMark
Measured Voltage Measured Amp. Watts
Main Board +3.3V 3.29 0.365 1.20
Main Board +5V 4.83 1.494 7.22
Main Board 5VSB 4.90 0.100 0.49
Main Board +12V 12.01 0.001 0.01
Main Board Power Consumption 8.92

EPIA-PX Operating Guide
June 18, 2009 - 10 - Version 1.11
Power Specifications
The EPIA-PX utili es a special 12-pin Pico-ITX power supply connector. Due to the EPIA-PX
platform’s ultra low power requirements a 60 Watt power supply is ample for even the
heaviest of multimedia system applications.
7 +3.3V 1 +3.3V
8 +3.3V 2 +5V_SB
9 GND 3 +12V
10 PWRON 4 +5V
11 GND 5 +5V
12 GND 6 PWRGD

EPIA-PX Operating Guide
June 18, 2009 - 11 - Version 1.11
VIA EPIA-PX Microsoft and Linux Driver Support
Microsoft Driver Support
VIA EPIA-PX offers full support for the complete range of Microsoft operating systems.
For standard operating systems, Windows 2000/XP latest drivers downloads can be found in
the VEPD website at www.viaembedded.com.
For embedded operating systems, Windows CE.NET and XP Embedded related driver
supports can be found in the VIA Arena website at www.viaarena.com.
Linux Driver Support
VIA EPIA-PX mainboards have a very high degree of support under Linux.
Support and drivers are provided through various methods including:
•Drivers provided by VIA
– Using a driver built into a distribution package
– Visiting VIA Arena website at www.viaarena.com for latest updates on a monthly
basis
•Installing a third party driver (such as the ALSA driver from the Advanced Linux
Sound Architecture project for integrated audio)
For OEM clients and system integrators developing a product for long term production, other
code and resources may also be made available. You can submit a request either through
the Developers portal on VIA Arena, or through your VEPD support contact. Alternatively,
VIA can work further towards providing additional drivers to suite your specific needs.

EPIA-PX Operating Guide
June 18, 2009 - 12 - Version 1.11
Contact
For more information on the VIA EPIA-PX Pico-ITX mainboard contact your sales
representative or visit our website at www.viaembedded.com
