Viali V14DWW16 User manual

instruction manual
V14DWW16
V14DWS16
DISHWASHER
(COLD WATER CONNECTION ONLY)
V14DWW_S16_IB_161209_grace.indd 1 9/12/16 10:42 am

V14DWW_S16_IB_161209_grace.indd 2 9/12/16 10:42 am

1
Contents
Contents 1
Guide to the Appliance 2
Caring for the Environment 4
Safety Information and Warnings 5
Items in the Box 7
Installation Instructions 9
Basic Set Up 13
Operation Instructions 18
Advanced Features 21
Hints and Tips 24
Troubleshooting 26
Care and Maintenance 29
Technical Specifications 32
V14DWW_S16_IB_161209_grace.indd 1 9/12/16 10:42 am

2
1
2
Dishwasher Features
1. Control panel 2. Door handle
Guide to the Appliance
1. Mains cable (connect
to power supply)
2. Drain hose (connect
to drainage)
3. Water inlet (connect
to water supply;
COLD water only)
2
3
1
NOTE: This product has been wet tested to ensure correct operation. As a result some
water may remain inside the unit. This is normal and safe. Remove any water droplets
from the exterior if necessary.
V14DWW_S16_IB_161209_grace.indd 2 9/12/16 10:42 am

3
Guide to the Appliance
NOTE: Due to production improvements, the appliance may differ slightly from the
diagram shown. Diagrams in this instruction manual are for reference only.
Control Panel
1. On/Off button and indicator
2. Half load wash button and
indicator
3. Delay wash start button and
delay hour indicators
4. PROGRAM button and program
indicators
5. Child lock button and indicator
6. Rinse aid refill warning indicator
7. End wash indicator
8. Water faucet indicator
9. Start/Pause button
1 2 3 4 5
6
1/2
7 8
9
1. Spray arm
2. Detergent dispenser
3. Upper basket
4. Lower basket
5. Filter
6. Rinse aid reservoir
3
4
2
1
1
5
6
V14DWW_S16_IB_161209_grace.indd 3 9/12/16 10:42 am

4
Responsible disposal of the packaging
The packaging of your appliance has been selected from environmentally friendly
materials and can usually be recycled. Please ensure these are disposed of correctly.
Plastic wrapping can be a suffocation hazard for babies and young children, please
ensure all packaging materials are out of reach and are safely disposed of. Please
ensure they are offered for recycling rather than throwing these materials away.
Responsible disposal of the appliance
At the end of its working life, do not throw this appliance out with your household
rubbish. An environmentally friendly method of disposal will ensure that valuable raw
materials can be recovered and used again.
Electrical and electronic appliances contain materials and substances which, if handled
or disposed of incorrectly, could be potentially hazardous on the environment and
human health.
Observe any local regulations regarding the disposal of electrical consumer goods
and dispose of it appropriately. Contact your local authorities for advice on recycling
facilities in your area.
The plug must be rendered useless and the cable cut off directly behind the appliance
or the machine to prevent misuse.
Caring for the Environment
V14DWW_S16_IB_161209_grace.indd 4 9/12/16 10:42 am

5
Safety Information and Warnings
For your continued safety and to reduce the risk of injury or electric shock, please follow all
the safety precautions listed below.
• Read all the instructions carefully before using this appliance and keep them for future
reference.
• Retain the manual. If you pass the appliance on to a third party, make sure to include
this manual.
• Keep ventilation openings in the appliance enclosure clear of obstructions. The
ventilation openings at the base of the machine must not be obstructed by carpet.
• Choose a location for your appliance away from heat sources such as radiators or fires.
• Switch off water and power and unplug before fitting or removing tools/attachments,
after use and before cleaning.
• Keep your fingers away from moving parts and fitted attachments.
• Never use a damaged machine.
• If the mains cable is damaged, it must be replaced by the manufacturer, its service
agent or a qualified technician in order to avoid a hazard.
• Keep the power unit, mains cable and plug away from water.
• Never exceed the maximum capacities.
• Only use the appliance for its intended domestic use.
• This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
• Children should be supervised to ensure that they do not play with the unit.
• Keep the appliance and its cord out of reach of children.
• This appliance is intended for indoor household use and similar applications such as:
– farm houses and by clients in hotels, motels and other residential type environment;
– bed and breakfast type environment;
– staff kitchen areas in shops, offices and other working environments.
• Keep children away from detergents and rinse aids. These may cause chemical burns in
the mouth, throat and eyes or asphyxiation.
• Keep children away from the appliance when the door is open.
• 2 people are required to lift this appliance.
WARNING.
• It is hazardous for anyone other than authorised service personnel to carry out servicing or
repairs which involve the removal of covers.
• To avoid the risk of an electrical shock, do not attempt repairs yourself.
• Do not sit or stand on the door or dish rack.
• Do not move your appliance by holding the door or its edges. Hold the unit around its
sides or base when moving it.
• Do not touch the heating element during or immediately after use.
• Do not operate your appliance unless all enclosure panels are properly in place. Do
not open the door while there is a program running, as there is a risk of hot water and
steam spraying out of the dishwasher which may cause scalding.
V14DWW_S16_IB_161209_grace.indd 5 9/12/16 10:42 am

6
Safety Information and Warnings
• Do not place any heavy objects on the open door. The appliance could tip.
• When loading items to be washed:
-Locate sharp items so that they will not damage the door seal;
-Knives and other utensils with sharp points must be loaded in the basket with the points
downwards or placed horizontally.
• Do not allow plastic items to come into contact with heating element.
WARNING. Some dishwasher detergents are strongly alkaline. They can be extremely
dangerous if swallowed. Avoid contact with skin and eyes and keep children away from the
dishwasher when the door is open.
• Check that the detergent receptacle is empty after completion of the wash cycle.
• Do not wash plastic items unless they are marked dishwasher safe or equivalent.
• Use only detergent and rinse aids designed for an automatic dishwasher.
• The door should not be left in the open position since this could present a tripping
hazard.
• For energy saving, always remember to switch the appliance off when you have finished
using it. The unit should not be left unattended when in use.
• Remove the door to the washing compartment when removing an old unit from service
or discarding it.
• During installation, the power supply cord must not be excessively or dangerously bent
or flattened.
• Do not tamper with controls.
• The appliance is to be connected to the water mains using new hose sets. Old hose sets
should not be reused.
• The maximum number of place settings to be washed is 14.
• The maximum permissible inlet water pressure is 1 MPa, and the minimum permissible
inlet water pressure is 0.04 MPa.
WARNING. This appliance must be earthed.
• The plug must be plugged into an appropriate mains socket that is installed and earthed
in accordance with local standards and requirements.
• Improper connection could result in a risk of electric shock.
• Check with a qualified electrician or service representative if you are in doubt whether the
appliance is properly earthed or the plug does not fit correctly.
• Never modify the plug provided with the appliance.
V14DWW_S16_IB_161209_grace.indd 6 9/12/16 10:42 am

7
Items in the Box
Remove all items from the packaging. Retain the packaging. If you dispose of it please
do so according to local regulations.
The following items are included:
Instruction
Manual
Main Unit Instruction Manual
Cutlery Basket Upper Basket Shelf
V14DWW_S16_IB_161209_grace.indd 7 9/12/16 10:42 am

8
Items in the Box
Detergent Measuring Spoon
(approx. 20g)
Measuring Cup
(approx. 60ml)
Water Supply Hose
U-shape Hose Holder
V14DWW_S16_IB_161209_grace.indd 8 9/12/16 10:42 am

9
Installation Instructions
When selecting a position for your dishwasher you should make sure the installation
surface is flat and firm, and the room is well ventilated. Avoid locating your dishwasher
near a heat source, eg. cooker, boiler or radiator. Extreme cold ambient temperatures
may also cause the appliance not to perform properly. This dishwasher is not designed
for use in a garage or outdoors.
Do not cover the dishwasher. When installing, ensure that free space is left at the sides.
All parts removed must be saved to do the reinstallation in the future. Ensure the
dishwasher is unplugged and empty. We recommend that 2 people handle the
dishwasher during installation.
1. Please ensure the dishwasher is installed
by a qualified technician. Refer to the
tools required.
2. Ensure there is clearance each side of the
unit to allow slight sideways movement
for servicing when required. Good
levelling is essential for correct
closure and sealing of the door.
When the unit is correctly levelled,
the door should not catch the
inner liner on either side of the
cabinet. The adjustable feet may
be loosened or tightened in order
to obtain the optimum levelling of
the unit.
The figure outlines the minimum
dimensions required to
accommodate the dishwasher within
fitted kitchen furniture units.
3030
level
level
level
level
600
845
850 640
min.100
80
603
598
units in mm
V14DWW_S16_IB_161209_grace.indd 9 9/12/16 10:42 am

10
Installation Instructions
4. Position the dishwasher next to a water
tap and a drain. Ensure the water inlet
and drain hoses are not kinked or
squashed. The unit must not stand on the
mains cable.
5. Make sure your plumbing is suitable
for use with the dishwasher. If in doubt
contact a qualified plumber. This unit
MUST BE connected to COLD WATER
MAINS ONLY using the new water inlet
hose. OLD HOSE SETS MUST NOT BE
RE-USED. The water pressure from the
water mains needs to be at a minimum
of 0.04 MPa and a maximum of 1.00
MPa.
3. Do not connect the unit to the mains
socket before installation. Ensure you are
not installing the unit right in front of the
mains socket. This is to avoid potential
damage to the back of the unit.
NOTE. If fitting under a benchtop, seal
any exposed particle board above the
dishwasher door to prevent damage from
condensation.
V14DWW_S16_IB_161209_grace.indd 10 9/12/16 10:42 am

11
Installation Instructions
NOTE. You may use a Y-adaptor (not included)
for an additional water feed for another
appliance, for example a washing machine.
This is only applicable for cold water mains.
A Y-adaptor is available from most DIY stores.
cold water
mains
Y-Adaptor
(not included)
water supply hose
Connect
to another
appliance
if required
• Connect one end of the water supply
hose to your dishwasher, and then
connect the other end of the hose to
your water mains. Please ensure the
black rubber seal is in place.
• After connecting the hose, turn on
your water mains and check for
leaks.
• Connect the dishwasher to the mains
socket.
• Do not bend your drain hose.
V14DWW_S16_IB_161209_grace.indd 11 9/12/16 10:42 am

12
Installation Instructions
• You may use the U-shaped drain
hose holder to secure your drain
hose and to avoid bending it.
IMPORTANT. Before connecting to the waste
pipe, make sure to check the waste pipe
and remove any stopper or blockage inside,
otherwise the unit may not be able to expel
the waste water properly.
U-shaped
drain hose
holder
water drain hose
• Secure the drain hose to the waste
pipe to avoid it coming off during
the washing process.
MA X 1 00 0 mm
A
C ounter
F ront
Drain pipe
NOT E
The top of the hose
must be les s than
1000mm.
40 mm
B
IMPORTANT.
• Extension drain hose. If a longer drain hose
is required, ensure to use a similar hose. The
drain hose must not be longer than 4m.
• The drain hose should be placed between 40
cm and 100 cm from the floor level, otherwise
the unit may not be able to expel the waste
water properly.
• Please close the hydrant after use.
• The drain hose must be correctly fitted to
avoid water leaks. Ensure the drain hose is not
kinked or squashed.
V14DWW_S16_IB_161209_grace.indd 12 9/12/16 10:42 am

13
Basic Set Up
Before loading the dishwasher
In general, please observe the following notes before loading your cutlery and crockery
into the basket.
• Remove lipstick stains and any food residues from crockery and dishes. Rinse if
necessary.
• Dishes and cutlery must not lie inside one another, or cover each other.
• Load your cutlery and crockery so that water can access all surfaces.
• Ensure all items are securely positioned.
• Hollow items such as cups, glasses, pans, etc. must be placed upside down in
the basket.
• Wide based items should be placed at an angle so that water can run off them
freely.
• The spray arms must not be blocked by items which are too tall or hang through
the baskets. If in doubt, test for free movement by manually rotating the spray
arms.
• Ensure that small items cannot fall through the holders in the baskets.
IMPORTANT.
• For safety reasons, do not operate the dishwasher without the upper and lower
baskets in place.
• Do not wash items soiled with ash, sand, wax, lubricating grease or paint in the
dishwasher. These items can damage the dishwasher. Ash does not dissolve and
will be distributed in the dishwasher.
• Ensure the dishwasher is level.
• Check the water inlet valve is open.
• Check there are no leaks at the water inlet or drain hoses.
• Ensure there are no kinks in the water inlet and drain hoses.
• Check the power is on.
WARNING. Knives and other utensils with sharp points must be loaded in the basket
with their points down or in a horizontal position.
V14DWW_S16_IB_161209_grace.indd 13 9/12/16 10:42 am

14
Basic Set Up
Upper basket
• Please use the upper basket for small and lightweight items such as cups,
saucers, glasses, dessert bowls, etc. Shallow pans or casserole dishes can also
be placed in the upper basket.
• Long items such as soup ladles, mixing spoons and long knives should be placed
lying down across the front of the upper basket.
Adjusting the upper basket
The height of the upper basket can be adjusted in order to create more space for
large utensils both for the upper/lower basket. The height of the upper basket can
be adjusted by placing the wheels on different height of the rails. Long items, serving
cutlery, salad servers and knives should be placed on the shelf so that they do not
obstruct the rotation of the spray arms.
Lower position Upper position
Hinged cup rack
To make room for taller items in the dishwasher basket, raise the cup rack upwards.
You can then lean the tall glasses against it.
Raise upwards
V14DWW_S16_IB_161209_grace.indd 14 9/12/16 10:42 am

15
Basic Set Up
Loading the upper basket
For optimum loading of crockery in the upper basket, please refer to the below table
and image.
Number Item
1 Cups
2 Saucers
3 Glasses
4Dessert dishes
NOTE. To make room to load more items in the dishwasher basket, attach the shelf as
shown in the image. Align the gaps of the shelf with the edge of the upper basket, then
push down hard to ensure all the gaps are securely attached with the basket. You can
then place light flat items on it. You can also remove it when it is not required for use.
Lower basket
We recommend that large items and the most difficult to clean items are placed in the
lower basket, such as plates, serving platters, saucepans, serving bowls, pots, pans,
lids etc. We recommend placing serving dishes and lids at the side of the basket to
avoid blocking the rotation of the spray arms.
If required, the upper basket should be adjusted to create more space for large plates
on the upper or lower basket.
Shelf
IN
MAX Ø240mm
MAX Ø250mm
MAX Ø190mm
MAX Ø300mm
V14DWW_S16_IB_161209_grace.indd 15 9/12/16 10:42 am

16
Basic Set Up
Hinged spikes
The spikes are used for holding plates and platters. They can be lowered to make more
room for large items.
Fold backwards
Raise upwards
Loading the lower basket
For optimum loading of crockery in the lower basket, please refer to the below table
and image.
Number Item
4Dessert dishes
5Dinner plates
6Soup plates
IN
V14DWW_S16_IB_161209_grace.indd 16 9/12/16 10:42 am

17
Basic Set Up
Cutlery basket
To make unloading much easier, cutlery should be grouped in zones and placed in the
cutlery basket. Please refer to the table below for the optimum placement of cutlery.
Number Item
1Soup spoons
2 Forks
3 Knives
4 Teaspoons
5Dessert spoons
IN
WARNING.
• Do not let any items extend through the bottom of baskets.
• To avoid the risk of injury, please load your knives and other sharp utensils with
handles upwards. Do not hold them by their sharp edges.
• The cutlery basket comes with covers, and they are designed for you to load the
cutlery into the appropriate slots. If you use the basket without the cover, it may
reduce the washing results of your cutlery.
• Please ensure the covers are securely locked to the basket before operation.
• To comply with Standards of Performance, all cutlery must be loaded according to
the instructions in this manual.
V14DWW_S16_IB_161209_grace.indd 17 9/12/16 10:42 am

18
Operation Instructions
Starting a wash cycle
1. Ensure the unit is connected to the mains power and the cold water supply is fully
opened (water pressure between 0.04 MPa and 1.00 MPa). If the indicator
light is on, it means the water tap is not yet opened.
2. Open the door. Pull out the lower and upper baskets, load the dishes and push
the baskets back. It is recommended that the lower basket is loaded first, and
then the upper basket.
3. Pour in the detergent or place the detergent tablet in the detergent compartment
and close firmly afterwards.
4. Close the door. A click should be heard when the door is closed correctly. Do not
slam the door.
5. Press the button.
6. Press the PROGRAM button to select the wash cycle program based on the
loading and soil requirements. Please refer to the Wash Cycle Table. The
program indicator will light up for the selected program. You can also select
other functions together with the main program by pressing the Half load wash
button or Delay wash start button.
7. Press the button. The dishwasher will start.
NOTE. If you open the dishwasher’s door during the washing cycle, the machine will
pause. After you close the door, the dishwasher will continue the current washing
program after 10 seconds.
Changing a program
To change the program if the washing cycle has already started, follow the steps below.
1. Press the button to pause the cycle. Open the door carefully as hot water and
steam may spray out. Check if the unit has dispensed the detergent or detergent
tablet. This will depend on how long the washing cycle has been running.
2. If the detergent dispenser lid is opened, we suggest you to allow the wash cycle
to complete. Close the door and press the button to resume the program.
3. If the detergent dispenser lid is still closed, close the door, then press and hold
the PROGRAM button for 3 seconds to cancel the program. Afterwards press the
PROGRAM button to select the required new program and press the button.
The unit will start the new washing cycle.
WARNING.When the door is opened during a wash cycle, there is a risk of hot water
and steam spraying out of the dishwasher which may cause scalding.
V14DWW_S16_IB_161209_grace.indd 18 9/12/16 10:42 am
